Aaeon EPIC-KBS9-PUC User manual

Last Updated: April 2, 2019
EPIC-KBS9-PUC
BOX PC
User’s Manual 1st Ed

Preface II
BOX PC EPIC-KBS9-PUC
Copyright Notice
This document is copyrighted, 2019. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.

Preface III
BOX PC EPIC-KBS9-PUC
Acknowledgements
All other product names or trademarks are properties of their respective owners. The
publisher and writer of this document make no claim to ownership of these products,
nor is any claim implied for products not specifically named in this section.
Microsoft Windows is a registered trademark of Microsoft Corp.
Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel Corporation
Core, Atom are trademarks of Intel Corporation
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
All other product names or trademarks are properties of their respective owners.

Preface IV
BOX PC EPIC-KBS9-PUC
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
EPIC-KBS9-PUC
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
BOX PC EPIC-KBS9-PUC
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver installation
instructions (if any), to facilitate users in setting up their product.
Users may refer to the product page at AAEON.com for the latest version of this
document.

Preface VI
BOX PC EPIC-KBS9-PUC
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
4. Always completely disconnect the power before working on the system’s
hardware.
5. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any
static-shielded containers.

Preface VII
BOX PC EPIC-KBS9-PUC
17. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
BOX PC EPIC-KBS9-PUC
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur.
Recycler les batteries usées en accord avec les instructions du fabricant et les directives
gouvernementales de recyclage.

Preface IX
BOX PC EPIC-KBS9-PUC
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
○
○
○
○
○
○
外部信号
连接器及线材
○
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。

Preface X
BOX PC EPIC-KBS9-PUC
China RoHS Requirement (EN)
Poisonous or Hazardous Substances or Elements in Products
AAEON Main Board/ Daughter Board/ Backplane
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components
O
O
O
O
O
○
Wires &
Connectors
for External
Connections
O
O
O
O
O
O
O：The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one of the
component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is applicable under normal
usage only

Preface XI
BOX PC EPIC-KBS9-PUC
Table of Contents
Chapter 1 - Product Specifications.......................................................................................... 1
1.1 Specifications............................................................................................................ 2
Chapter 2 –Hardware Information ........................................................................................1
2.1 Dimensions ............................................................................................................... 2
2.2Jumpers and Connectors....................................................................................... 6
2.3 List of Jumpers ......................................................................................................... 8
2.3.1 Clear CMOS Jumper (JP6).......................................................................... 9
2.3.2 AT/ATX mode Selection (JP7) ....................................................................9
2.3.3 Front Panel PIN Header (JP9)...................................................................10
2.4 List of Connectors................................................................................................... 11
2.4.1 External +12V Input (CN2) ........................................................................12
2.4.2 Audio Port (CN5) ........................................................................................12
2.4.3 RTC Battery Connector (CN6)..................................................................13
2.4.4 +5V Output for SATA HDD (CN7) ...........................................................13
2.4.5 USB 2.0 Port (CN8).....................................................................................13
2.4.6 USB 2.0 Port (CN9).....................................................................................14
2.4.7 SATA Port (CN10).........................................................................................14
2.4.8 Mini-Card/mSATA Connector (CN11)......................................................15
2.4.9 SATA Port (CN13).........................................................................................17
2.4.10 CPU FAN Connector (CN14).....................................................................18
2.4.11 LPC Port (CN15)...........................................................................................18
2.4.12 COM Port (CN16)........................................................................................19
2.4.13 COM Port (CN17).......................................................................................20
2.4.14 USB 2.0/3.0 Port 1~Port 2 (CN22)...........................................................21
2.4.15 HDMI (CN23)..............................................................................................22
2.4.16 DIO (CN24) .................................................................................................23

Preface XII
BOX PC EPIC-KBS9-PUC
2.4.17 External +12V Input [Reserved] (CN27) ................................................23
2.4.18 CRT (CN31)..................................................................................................24
2.4.19 PCIE [x4] Slot (CN53) ................................................................................24
2.4.20 LAN (RJ-45) Port1~4 (CN54)...................................................................25
2.4.21 System FAN Connector (CN56) ..............................................................25
2.4.22 LAN (RJ-45) Port1~2 [Reserved] (CN57)...............................................26
2.4.23 DDR4 SO-DIMM Slot (DIMM1 & DIMM2).............................................26
2.5 Block Diagram........................................................................................................27
Chapter 3 - BIOS Setup ........................................................................................................... 1
3.1 System Test and Initialization ................................................................................ 2
3.2 AMI BIOS Setup ....................................................................................................... 3
3.3 Setup Submenu: Main............................................................................................4
3.4 Setup Submenu: Advanced................................................................................... 5
3.4.1 CPU Configuration ...................................................................................... 6
3.4.2 Trusted Computing...................................................................................... 7
3.4.3 SATA Configuration ..................................................................................... 8
3.4.4 USB Configuration....................................................................................... 9
3.4.5 Hardware Monitor ......................................................................................10
3.4.5.1 Smart Fan Mode Configuration.................................................. 11
3.4.6 SIO Configuration.......................................................................................13
3.4.6.1 Serial Port Configuration..............................................................14
3.4.7 Power Management...................................................................................15
3.5 Setup Submenu: Chipset ......................................................................................16
3.5.1 System Agent (SA) Configuration ...........................................................17
3.5.1.1 Graphics Configuration ................................................................18
3.5.2 PCH-IO Configuration ...............................................................................19
3.6 Setup Submenu: Security.....................................................................................20
3.7 Setup Submenu: Boot ...........................................................................................21

Preface XIII
BOX PC EPIC-KBS9-PUC
3.7.1 BBS Priorities...............................................................................................22
3.8 Setup Submenu: Save & Exit...............................................................................23
Chapter 4 –Driver Installation ................................................................................................ 1
4.1 Driver Installation..................................................................................................... 2
Appendix A –Mating Connectors ......................................................................................... 4
A.1 List of Mating Connectors and Cables................................................................5
Appendix B - I/O Information ................................................................................................ 6
B.1 I/O Address Map ..................................................................................................... 7
B.2 Memory Address Map ........................................................................................... 9
B.3 IRQ Mapping Chart................................................................................................ 11
Appendix C –Digital I/O Ports..............................................................................................13
C.1 Digital I/O Register.................................................................................................14
C.2 Digital I/O Sample Code.......................................................................................17
Appendix D - Watchdog Timer Programming....................................................................18
D.1 Watchdog Timer Registers ...................................................................................19
D.2 Watchdog Sample Program................................................................................20

BOX PC EPIC-KBS9-PUC
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
BOX PC EPIC-KBS9-PUC
1.1 Specifications
System
Form Factor
4” EPIC Board
CPU
6th/7th Generation Intel® Core™
i7/i5/i3/Celeron® S-series (Supports 35~65W)
Chipset
H110/H170/Q170 (6W)
Memory Type
DDR4 (Non-ECC) SODIMM x 2, 2133MHz, up
to 32G
Max. Memory Capacity
Up to 32G
BIOS
AMI
Wake On LAN
Yes
Watchdog Timer
255 Levels
Power Requirement
+12V with lockable DC jack
Power Supply Type
ATX
Power Consumption (Typical)
--
Dimension (L x W x H)
216mm x 180mm x 65mm (unit size)
380mm x 350mm x 180mm (with packaging)
Operating Temperature
32°F ~ 122°F (0°C ~ 50°C)
Storage Temperature
-4°F ~ 176°F (-20°C ~ 80°C)
Operation Humidity
0 ~ 90% @ 40°C, non-condensing
MTBF (Hours)
--

Chapter 1 –Product Specifications 3
BOX PC EPIC-KBS9-PUC
System
Certification
CE/FCC Class A
Anti-vibration
1 Grms/ 5~500 Hz/ operation—with mSATA
Display
VGA/LCD Controller
6th/7th Generation Intel® Core™
i3/i5/i7/Celeron®
Video Output
HDMI (Rear), VGA (Internal Only)
Backlight Inverter Supply
--
I/O
Ethernet
Intel® i211 10/100/1000Base-TX x 2 or 4 ports
Audio
--
USB Port
USB3.0 x 2 (Real IO)
USB2.0 x 2 (Internal)
Serial Port
COM x 2 (All Internal), RS-232/422/485
Parallel Port
--
HDD Interface
SATA 3.0 x 2
FDD Interface
--
SSD
Full size mSATA x1 (Default) or
2.5” HDD x1 (Optional)
Expansion Slot
Mini-PCIe slot (Share with mSATA as above)
PCIe[x4] Slot x 1 (Q170 and H170 SKU)
DIO
8-bit

Chapter 1 –Product Specifications 4
BOX PC EPIC-KBS9-PUC
I/O
TPM
--
Touch
--

BOX PC EPIC-KBS9-PUC
Chapter 2
Chapter 2 –Hardware Information

Chapter 2 –Hardware Information 2
BOX PC EPIC-KBS9-PUC
2.1 Dimensions
Top and Side
Front

Chapter 2 –Hardware Information 3
BOX PC EPIC-KBS9-PUC
Rear EPIC-KBS9-PUC-A10-0002
Rear EPIC-KBS9-PUC-A10-0001
