Aaeon TKS-G21-CV05 User manual

Embedded Box TKS-G21-CV05
TKS-G21-CV05
Fanless Embedded Box
Intel
®Atom™ D2700 2.13 GHz Processor
2 GbE LAN, 4 USB2.0, 6 COM, 1 VGA
1 Mini PCIe, 1 CFast
TKS-G21-CV05 Manual 1st Ed.
March 2012

Embedded Box TKS-G21-CV05
i
Copyright Notice
This document is copyrighted, 2012. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Embedded Box TKS-G21-CV05
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
CompactFlash™is a trademark of the Compact Flash
Association.
Microsoft Windows®is a registered trademark of Microsoft
Corp.
Intel®, Atom™ are trademarks of Intel Corporation.
PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

Embedded Box TKS-G21-CV05
iii
Packing List
Before you begin operating your PC, please make sure that the
following materials are enclosed:
1 TKS-G21-CV05 Embedded Controller
1 CD-ROM for manual (in PDF format) and drivers
If any of these items should be missing or damaged, please contact
your distributor or sales representative immediately.

Embedded Box TKS-G21-CV05
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from anyAC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a firm surface during installation. Dropping
it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.

Embedded Box TKS-G21-CV05
v
d. The equipment does not work well, or you cannot get it
to work according to the user’s manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE IS BELOW -20°C
(-4°F) OR ABOVE 55°C (131°F). IT MAY DAMAGE THE
EQUIPMENT.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received including
interference that may cause undesired
operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.

Embedded Box TKS-G21-CV05
vi
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Boxer/ Industrial System
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
中央处理器
与内存 ×○○○○○
硬盘 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、电源为选购品。

Embedded Box TKS-G21-CV05
vii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Hardware Installation
2.1 Dimension and I/O of TKS-G21-CV05......................2-2
2.2 Location of Connectors and Jumpers of the Main Board
.........................................................................................2-3
2.3 List of Jumpers..........................................................2-5
2.4 List of Connectors .....................................................2-5
2.5 COM Port # 2 RS-232/422/485 Selection (CN19) ....2-7
2.6 Digital I/O Connector (CN7)......................................2-9
2.7 Hard Disk Installation ................................................ 2-10
2.8 Accessory Installation................................................2-14
2.9 Wallmount Kit Installation..........................................2-17
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3

Embedded Box TKS-G21-CV05
viii
Appendix A Programming The Watchdog Timer
A.1 Programming ........................................................A-2
A.2 ITE8783 Watchdog Timer Initial Program..............A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 1st MB Memory Address Map.................................B-4
B.3 IRQ Mapping Chart................................................B-6
B.4 DMA Channel Assignments...................................B-6
Appendix C AHCI Setting
C.1 Setting AHCI......................................................... C-2
Appendix D Digital I/O
D.1 Digital I/O.............................................................. D-2

Embedded Box TKS-G21-CV05
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Embedded Box TKS-G21-CV05
Chapter 1 General Information 1- 2
1.1 Introduction
The newest EmBox series TKS-G21-CV05 has been introduced by
AAEON and it utilizes Intel®Atom™ processor. In this era of
information explosion, the advertising of consumer products will not
be confined to the family television, but will also spread to
high-traffic public areas, like department stores, the bus,
transportation station, the supermarket etc. The advertising
marketing industry will resort to every conceivable means to
transmit product information to consumers. System integrators will
need a multifunction device to satisfy commercial needs for such
public advertising.
The TKS-G21-CV05 is designed for indoor environments due to the
following reasons; first, the TKS-G21-CV05 offers low power
consumption system that while operating in ambient temperatures
ranging from 0° to 50°C. The TKS-G21-CV05 is a standalone high
performance controller designed for long-life operation and with
high reliability. It can replace traditional methods and become the
mainstream controller for the multimedia entertainment market.

Embedded Box TKS-G21-CV05
Chapter 1 General Information 1- 3
1.2 Features
Intel®AtomTM D2700 2.13 GHz Processor
DDR3 1066 SODIMM x 1, Up To 4 GB
CRT (VGA) Single View
Realtek ALC 662 Codec for 2CH HD Audio
Gigabit Ethernet x 2
2.5” SATA Hard Disk Drive Bay x 1
USB2.0 x 4, COM x 6, 8-Bit Digital I/O
Mini PCIe x 1, CFastx 1
WiFi & Bluetooth® Combo Module (Optional To Occupy One
PCI-Express Slot)
+12V Power Input
Fanless

Embedded Box TKS-G21-CV05
Chapter 1 General Information 1- 4
1.3 Specifications
CPU Onboard Intel®Atom™ D2700
Processor up to 2.13 GHz
Chipset Intel®Atom™ D2700 + NM10
System Memory 204-pin DDR3 SODIMM x 1, Max. 4
GB (DDR3 1066)
Display
Interface VGA D-SUB 15 x 1
SSD CFast™ x 1 Storage
Device HDD 2.5" Hard Disk Drive Bayx1
LAN Realtek RTL 8111E, 10/100/1000
Base-TX Ethernet
Network Wireless 802.11b/g/n WiFi (Optional)
USB Host USB TypeA x 2
Serial Port COM x 3
Front I/O
Audio Line-out, Mic-in
USB Host USB Type A x 2
LAN RJ-45 x 2
Serial Port COM x 3
DIO 8-bit (Programmable) x 1
Rear I/O
KB/MS Through USB port
Expansion Mini Card Mini Card x 1 (Internal)
Indicator Front Power LED x 1, HDD LED x 1
Power Requirement +12V DC Input
System Cooling Fanless

Embedded Box TKS-G21-CV05
Chapter 1 General Information 1- 5
Mounting Desktop or Wallmount (optional)
Operating Temperature 32°F ~ 122°F (0°C ~ 50°C)
Storage Temperature -40°F ~ 176°F (-40°C ~ 80°C)
Anti-Vibration
0.5g rms/ 5 ~ 500Hz/ random
operation (CFast);
1 g rms/ 5 ~ 500Hz/ random operation
(Internal Hard Disk Drive active
Module)
Anti-Shock
50 G peak acceleration (11 msec.
duration) (CFast);
20 G peak acceleration (11 msec.
duration) (Hard Disk Drive Module)
Certification EMC CE/FCC Class A
Dimension 7" x 7" x 1.97" (180mm x 180mm x
50mm)
Gross Weight Heavy duty steel (1.78 kg/ 3.92 lb)

Embedded Box TKS-G21-CV05
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Chapter
2
Guide

Embedded Box TKS-G21-CV05
Chapter 2 Quick Installation Guide 2 - 2
2.1 Dimension and I/O of TKS-G21-CV05
Front side
Back side

Embedded Box TKS-G21-CV05
Chapter2QuickInstallationGuide2 - 3
2.2 Location of Connectors and Jumpers of the Main Board
Component Side

Embedded Box TKS-G21-CV05
Chapter 2 Quick Installation Guide 2 - 4
Solder Side

Embedded Box TKS-G21-CV05
Chapter2QuickInstallationGuide2 - 5
2.3 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 Auto Power Button Selection
JP2 Clear CMOS
JP3 COM2 RI/+5/+12V Selection
2.4 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's connectors:
Label Function
CN1 Front Panel
CN5 SATA Port
CN6 External 12V Input
CN7 Digital I/O
CN9 +5V Output for SATAHDD using
CN11 COM Port #6
CN13 COM Port #5
CN16 COM Port #4
CN18 COM Port #3
CN19 COM Port #2

Embedded Box TKS-G21-CV05
Chapter 2 Quick Installation Guide 2 - 6
CN28 2nd RJ-45 Ethernet
CN29 1st RJ-45 Ethernet
CN30 USB Port #1 and #2
CN31 Audio Line In/Out and MIC
CN32 CRT/DVI (Configured by manufacturing)
CN33 COM Port #1
CFD1 CFAST
PCIE1 Mini Card/mSATA (Configured by Manufacturing)
DIMM1 DDR3 SODIMM Slot
