Aaeon IMBI-Q57 User manual

Industrial Motherboard IMBI-Q57
IMBI-Q57
Intel® CoreTM i3/i5/i7 DT Processor
Dual View With VGA & DVI
Two 240-pin DDR3 1066/1333 SDRAM
4 SATA2/ RAID 0, 1, 5, 10
8 USB 2.0/ 1 RS-232/ 1 RS-232/422/485
IMBI-Q57 Manual Rev.A 1st Ed.
October 2010

Industrial Motherboard IMBI-Q57
i
Copyright Notice
This document is copyrighted, 2010. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Industrial Motherboard IMBI-Q57
ii
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
zAward is a trademark of Award Software International, Inc.
zCompactFlash™ is a trademark of the Compact Flash
Association.
zIntel®, Core™ i3/i5/i7 are trademarks of Intel®Corporation.
zMicrosoft Windows®is a registered trademark of Microsoft Corp.
zITE is a trademark of Integrated Technology Express, Inc.
zIBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
zSoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their
respective owners.

Industrial Motherboard IMBI-Q57
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 IMBI-Q57 Mini-ITX Main Board
•1 SATA Signal Cable
•1 COM Port Cable with DB-9
•1 USB Cable
•1 I/O Shield
•1 CD-ROM for Manual (in PDF Format) and Drivers
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.

Industrial Motherboard IMBI-Q57
iv
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 Specifications............................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions....................................................2-2
2.2 Location of Connectors and Jumpers .......................2-3
2.3 Mechanical Drawing..................................................2-5
2.4 List of Jumpers..........................................................2-7
2.5 List of Connectors .....................................................2-8
2.6 Setting Jumpers ........................................................2-9
2.7 Auto PWRBTN Selection (JP1)...............................2-10
2.8 CMOS Setting (JP2)................................................2-10
2.9 TPM Setting (JP3)...................................................2-10
2.10 BIOS Load Optimized Defaults Selection (JP4)....2-10
2.11 Front Panel Connector (FP1)................................2-10
2.12 Pin Header (USB_F1, USB_F2)............................2-11
2.13 RS-232 Serial Port Connector (COM1).................2-11
2.14 RS-232/422/485 Serial Port Connector (COM2)...2-11
2.15 Digital I/O Pin Header (DIO1)................................ 2-11
2.16 SATA Connector (SATA1~4) ................................2-12
2.17 FAN Connector (CPU_FAN,SYS_FAN1~2).......... 2-12
2.18 24-Pin ATX Power Connector (ATX1)...................2-12

Industrial Motherboard IMBI-Q57
v
2.19 4-Pin ATX Power Connector (ATX2)..................... 2-13
2.20 Expansion Interface (PICMGA1)........................... 2-13
2.21 Expansion Interface (PICMGB1)........................... 2-16
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. ..................................3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation.................................................................4-3
Appendix A Programming The Watchdog Timer
A.1 Programming .........................................................A-2
A.2 ITE8718 Watchdog Timer Initial Program..............A-6
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-3
B.3 IRQ Mapping Chart................................................B-3
B.4 DMA Channel Assignments .................................B-3
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables.................. C-2
Appendix D RAID & AHCI Settings
D.1 Setting RAID......................................................... D-2
D.2 Setting AHCI....................................................... D-12

Industrial Motherboard IMBI-Q57
Chapter 1 General Information 1- 1
General
Chapter
1
Information

Industrial Motherboard IMBI-Q57
Chapter 1 General Information 1- 2
1.1 Introduction
The IMBI-Q57 supports Intel®CoreTM i3/i5/i7 DT processor.
Moreover it supports two DDR3 1066/1333 SDRAM memory up to
8GB. This model accommodates two Intel®PCI-Express Gigabit
Ethernet controllers that those are controlled by Intel®82578DM
(supports Intel®AMT6.0) and Intel®82574L/82583V. This
configuration provides outstanding computing ability, fast network
connections and multi-task data transmission.
The graphic controller is integrated on Intel®Gen 6.0 that support
dual view with VGA and DVI to meet the demand of the media and
high definition. In addition, IMBI-Q57 deploys 8 USB 2.0, 2 COMs,
Keyboard & Mouse, and multiple extended bus for a flexible
expansion selection. The storage of IMBI-Q57 supports 4 SATA2
ports to support RAID 0, 1, 5, 10 function.
The IMBI-Q57 provides an ideal combination of high performance,
widely expandable interfaces and compact size that is easy to apply
for multiple applications. The IMBI-Q57 will be an ideal product for
your requirements.

Industrial Motherboard IMBI-Q57
Chapter 1 General Information 1- 3
1.2 Features
zIntel®32/45nm Core™ i7/i5/i3 LGA1156 CPU Integrated
Graphics & Memory Controller
zIntel®Q57
zDual-Channel DDR3 1066/1333 Memory up to 8 GB
zIntel®Gigabit Ethernet x 2 Support Intel®AMT 6.0
zIntel®Gen 6.0 Integrated Graphics Engine Supports Dual
View With VGA & DVI
zSATA2 x 4, RAID 0, 1, 5, 10
zUSB 2.0 x 8, COM x 2
zMultiple Extended Bus With Golden Finger

Industrial Motherboard IMBI-Q57
Chapter 1 General Information 1- 4
1.3 Specifications
System
zForm Factor Mini-ITX
zProcessor Intel®32/45nm Core™ i7/i5/i3
LGA1156 CPU, TDP: 95W Max.
zSystem Memory Supports Dual Channel with
240-pin DDR3 1066/1333 SDRAM
x 2, up to 8GB
zChipset Intel®Q57
zEthernet Intel®PCI-Express 10/100/
1000Base-TX, RJ-45 x 2
LAN1: Intel®82578DM (supports
Intel® AMT 6.0);
LAN2: Intel®82574L/82583V
zAudio HD Audio Codec with Realtek
ALC888
zBIOS AMI BIOS 64Mb SPI ROM
zI/O Chip ITE IT8718F I/O controller
zStorage SATA2 connector x 4,
support RAID 0,1,5,10
zDIO Programmable 8-bit digital I/O
interface (4 input/4 output)
zWatchdog Timer Reset: 1 sec.~255 min. and 1 sec.
or 1 min./step

Industrial Motherboard IMBI-Q57
Chapter 1 General Information 1- 5
zH/W Status Monitor Monitoring system temperature,
voltage, and cooling fan status
zExpansion Interface Multiple Extended Bus with
Golden Finger
zPower Requirement Standard ATX 24-pin connector,
one 4-pin ATX 12V, three 4-pin fan
wafer for CPU x 1, System x 2
zBoard Size (L x W) 6.7" x 6.7" (170 x 170 mm)
zGross Weight 0.88 lb (0.4 Kg)
zOperating Temperature 32°F ~140°F (0°C ~60°C)
zStorage Temperature -4°F ~158°F (-20°C ~70°C)
zStorage Humidity 10~80%, non-condensing
Display
zChipset Intel®Core™ i3/i5 + Q57
zGraphic Engine Intel®Gen 6.0 integrated
Graphics Engine
zResolution Analog up to 2048x1536 @ 75
Hz; Flat panels up to 1920x1080
@ 60 Hz
zOutput Interface VGA x 1, DVI-D x 1
I/O
zSerial Port RS-232 x 1; RS-232/422/485 box
header x 1

Industrial Motherboard IMBI-Q57
Chapter 1 General Information 1- 6
zKeyboard & Mouse Keyboard x 1 & Mouse x 1
zUniversal Serial Bus USB 2.0 x 8 (four on the I/O side,
four with header)
zAudio Audio Jack x 3 with BTX Type
(Mic-in, Line-in, Line-out)
zEthernet RJ-45 x 2
zDisplay VGA x 1, DVI-D x 1

Industrial Motherboard IMBI-Q57
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Chapter
2
Guide

Industrial Motherboard IMBI-Q57
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

Industrial Motherboard IMBI-Q57
Chapter2QuickInstallationGuide2 - 3
2.2 Location of Connectors and Jumpers
Component Side

Industrial Motherboard IMBI-Q57
Chapter 2 Quick Installation Guide 2 - 4
Solder Side

Industrial Motherboard IMBI-Q57
Chapter2QuickInstallationGuide2 - 5
2.3 Mechanical Drawing
Component Side

Industrial Motherboard IMBI-Q57
Chapter 2 Quick Installation Guide 2 - 6
Solder Side

Industrial Motherboard IMBI-Q57
Chapter2QuickInstallationGuide2 - 7
2.4 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 Auto PWRBTN Selection
JP2 CMOS Setting Selection
JP3 TPM Setting Selection
JP4 BIOS load optimized defaults Setting Selection

Industrial Motherboard IMBI-Q57
Chapter 2 Quick Installation Guide 2 - 8
2.5 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Label Function
FP1 Front Panel Connector
CN2 DVI-I & CRT Port Connector
COM1 RS-232
COM2 RS-232/422/485 Pin Header
KBMS1 PS/2 Keyboard/Mouse Connector
USB_LAN1 100/1000Base-TX Ethernet & Dual USB
Connector
USB_LAN2 100/1000Base-TX Ethernet & Dual USB
Connector
AUDIO1 Audio Line-in/ Line-out/ MIC
DIMM1,DIMM2 DDR3 DIMM Slot
USB_F1,USB_F2 USB Pin Header
CPU_FAN1,SYS_FAN1
SYS_FAN2 4-Pin System Fan Connector
ATX2 4 -Pin ATX Power +12V Connector
ATX1 24 pin ATX Power
SATA1~SATA4 SATA Connector
DIO1 Digital I/O
PICMGA1, PICMGB1 Expansion Interface
