Aaeon EMB-830 User manual

EMB-830
EmbeddedATX
Socket 478 based Intel Pentium 4
With LCD, Ethernet, Audio,&
PCMCIA/Mini PCI

Embedded ATX Board EMB-830
i
Copyright Notice
This document is copyrighted, 2003. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products
described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its use.
The material inthis document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Embedded ATX Board EMB-830
ii
Acknowledgments
All other products’name or trademarks are properties of their respective
owners.
l Award is a trademark of Award Software International, Inc.
l CompactFlash™is a trademark of the Compact Flash Association.
l Intel®,Pentium®4, and Celeron®are trademarks of Intel®Corporation.
l Microsoft Windows®is a registered trademark of Microsoft Corp.
l ITE is a trademark of Integrated Technology Express, Inc.
l IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
l SoundBlaster is a trademark of Creative Labs, Inc.

Embedded ATX Board EMB-830
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•1 EMB-830 Embedded ATX Board
•1 Quick Installation Guide
•1 CD-ROM for manual (in PDF format), BIOS, and
drivers
•1 Jumper cap
•1 Audio Cable
•1 USB Cable
•1 TV-out Cables
•240 pin IDE Cable
•1 44 pin IDE Cable
•4 or 2 COM port Cables (Quantity depends on how many
COM port on board)
If any of these items should be missing or damaged, please contact your
distributor or sales representative immediately.

Embedded ATX Board EMB-830
iv
Contents
Chapter 1 General Information
1.1Introduction .................................................................................... 1-2
1.2Features ............................................................................................ 1-3
1.3Specifications................................................................................... 1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions .......................................................................... 2-2
2.2 Location of Connectors and Jumpers......................................... 2-3
2.3 Mechanical Drawing ...................................................................... 2-5
2.4 List of Jumpers................................................................................ 2-7
2.5 List of Connectors.......................................................................... 2-8
2.6 Setting Jumpers............................................................................... 2-10
2.7 Clear CMOS (JP1).......................................................................... 2-11
2.8 COM2 RS-232/422/485 Selection (JP2 &JP4)......................... 2-11
2.9 COM1 Ring/+5V/+12V Selection (JP3) .................................. 2-11
2.10 COM2 Ring/+5V/+12V Selection (JP5)................................ 2-11
2.11COM3 Ring/+5V/+12V Selection (JP6) ................................. 2-12
2.12 COM4 Ring/+5V/+12V Selection (JP7)................................ 2-12
2.13 Audio Out Selection (JP8) .......................................................... 2-12
2.14 LCD Voltage Selection (JP9)...................................................... 2-12
2.15 COM6 Ring/+5V/+12V Selection (JP10).............................. 2-13
2.16 COM5 Ring/+5V/+12V Selection (JP11).............................. 2-13
2.17 EIDE Connector (CN1) ............................................................. 2-13

Embedded ATX Board EMB-830
v
2.18 CD-In Connector (CN2) ............................................................ 2-14
2.19 Audio 5.1 Channel/ SPDIF Connector (CN3)....................... 2-15
2.20 USB5 & USB6 connector (CN4)............................................... 2-15
2.21 PCI Extension Connector (CN5).............................................. 2-15
2.22 IrDA Connector (CN6) .............................................................. 2-16
2.23 Fan Connector (CN7, CN8 and CN23)................................... 2-16
2.24 Internal Keyboard Connector (CN9) ....................................... 2-16
2.25 Internal Mouse Connector (CN10)........................................... 2-17
2.26 COM3 RS-232 Serial Port Connector (CN11)........................ 2-17
2.27 COM4 RS-232 Serial Port Connector (CN12)........................ 2-17
2.28 Digital I/O-2 Connector (CN13).............................................. 2-17
2.29 Option PME Connector (CN14) .............................................. 2-18
2.30 External Power-on Function Connector (CN15)................... 2-18
2.31ATX Power-12V Connector (CN16) ....................................... 2-18
2.32TV-Out Connector (CN17)........................................................ 2-19
2.33Channel 1 LVDS Connector (CN18) ....................................... 2-19
2.34Channel 2 LVDS Connector (CN19) ....................................... 2-19
2.35COM6 RS-232 Serial Port Connector (CN20)........................ 2-20
2.36COM5 RS-232 Serial Port Connector (CN21)........................ 2-20
2.37Digital I/O-1 Connector (CN22).............................................. 2-20
2.38Front Panel Connector (CN26)................................................. 2-21
2.39ATX Power Connector (CN27) ................................................ 2-21
Chapter 3 Award BIOS Setup
3.1 System Test and Initialization. ..................................................... 3-2
3.2 Award BIOS Setup......................................................................... 3-3

Embedded ATX Board EMB-830
vi
3.3Standard CMOS Features ............................................................. 3-6
3.4Advanced BIOS Features ............................................................. 3-7
3.5Advanced Chipset Features .......................................................... 3-8
3.6Integrated Peripherals.................................................................... 3-9
3.7Power Management Setup ............................................................ 3-10
3.8PnP/PCI Configuration ................................................................ 3-11
3.9PC Health Status............................................................................. 3-12
3.10 Frequency/ Voltage Control...................................................... 3-13
3.11 Load Fail-Safe Defaults............................................................... 3-14
3.12 Load Optimized Defaults ........................................................... 3-14
3.13 Set Supervision/ User Password ............................................... 3-14
3.14 Save & Exit Set-up....................................................................... 3-15
3.15 Save without Saving ..................................................................... 3-15
Chapter 4 Driver Installation
4.1 Installation 1.................................................................................... 4-2
4.2 Installation 2.................................................................................... 4-4
4.3Installation 3.................................................................................... 4-5
Appendix A Programming the WatchDog Timer
A.1 Watchdog timer of EMB-830..................................................A-2
A.2Configuring Sequence Description ........................................A-2
A.3ITE8712 Watchdog timer initial program.............................A-5

Embedded ATX Board EMB-830
Chapter 1 General Information 1-1
General
Information
Chapter

Embedded ATX Board EMB-830
Chapter 1 General Information 1 -2
1.1 Introduction
EMB-830 is the world’s first Pentium 4 industrial board in embedded
ATX form factor. It features a PGA478 socket that can
accommodate Pentium 4 supporting FSB up to 400/533MHz.
Best performance for multimedia solution
AAEON’s EMB-830 also supports DDR DRAM up to 2.0Gbyte, 4X
AGP, and 6 channels audio output. It can provide the strong
multimedia functions. Therefore EMB-830 can be broadly
implemented in several markets, such as Point of sale, point of
information (Kiosk), and gaming markets.
Slim form factor
If you are looking for a slim board for space-constrained applications,
EMB-830 is the one. EMB-830 is low-profile design, meanwhile it
supports 6USB2.0, mini PCI, and PCMCIA (optional item) slots.
EMB-830 promises you the greatest expansion possibilities with the
most cost-effective expansion standards, PCMCIA or Mini PCI. With
numerous off-the-shelf PCMCIA/Mini PCI modules, you get easy
access to solutions ranging from IEEE 1394, Modem, Storage, Sound
Card,SCSI card, Audio/Video capture card, Wireless LAN module,
to Bluetooth module. Especially for customers whose application is
various or changing, EMB-830 reserves more than enough flexibility
for future expansion.
More
EMB-830 provides 10/100Base-TFast Ethernet ports as standard.
But for high-speed market, there is another option for you. You can
choose to have one 10/100 Base-T Fast Ethernet and one Gigabit
Ethernet. Talking about the display signal transmission, EMB-830
integrated dual channel LVDS interface onboard, which allows long
distance display signal transmission.

Embedded ATX Board EMB-830
Chapter 1 General Information 1 -3
1.2Features
•Embedded ATX form factor
•ATX family backwards-compatible rear I/O panel
•Supports Intel Pentium 4
•Supports 6 channel audio output
•Onboard with dual channel LVDS interface
•Supports dual 10/100 Base-T Fast Ethernet and Gigabit
Ethernet (optional)
•Supports USB 2.0 / Mini PCI/ PCMCIA (Option) /
CompactFlash

Embedded ATX Board EMB-830
Chapter 1 General Information 1 -4
1.3 Specifications
System
lCPU: Support Intel Pentium 4 (400/533
MHz FSB data rate)
lMemory:184-pin DDR RAM slot x 2, support
up to 2.0G byte at 200/ 266/ 333
MHz operation
lChipset: Intel®82845 GV, 82801 (ICH4)
lBIOS: Award 4 Mb FLASH BIOS
lAudio: ICH4/ ALC650 to support 6
channel audio output (with
headphone amplifier)
lSSD: One Type II CompactFlash Card
lWatchdog timer: Can generate a system reset,
Software selectable time-out interval
(1sec~255 sec, 1sec/step)
lDMA: 7 DMA channels (8237 equivalent)
lInterrupt: 15 interrupt levels (8259 equivalent)
lEthernet: Default: One 10/100 Base-T Fast
Ethernet (Intel 82562ET)
Optional: one 10/100 Base-T Fast
Ethernet and one Gigabit Ethernet
(Intel 82562ET/82540EM)
lExpansion Interface: Type II PCMCIA x

Embedded ATX Board EMB-830
Chapter 1 General Information 1 -5
2(Cardbus)(Option)and Type Ⅲ
MINI PCI x1and low-profile PCI
expansion via PCI riser x 1 (Option)
lH/W status monitoring: ITE IT8712F integrated, supports
power supply voltages and
temperatures monitoring and fan
monitoring
lBattery: Lithium battery for data retention
lPower supply voltage: ATX
lOperating temperature:32 to 140 °F (0 to 60°C)
lBoard size/Weight:9.6" (L) x 9.6" (W) (243.84 mm x
243.83 mm); 0.88lb(0.4Kg)
Display
lChipset Built in Intel 82845GV
lMemory size: Share up to 8MB DDR-RAM
lResolution: CRT：Up to 1600 x 1200 with 24bit
color
LCD：Up to 1280 x 1024 with 24bit
color
lLCD Interface: Up to 2 channels 24-bit LVDS
lDual Display Simultaneous Scan: CRT+LCD:
1024 x 768 @ 24bpp
lHardware support for LCD landscape/portrait rotation.

Embedded ATX Board EMB-830
Chapter 1 General Information 1 -6
I/O
lMIO: EIDE (Ultra DMA100)x2, FDD x
1, RS-232/422/485 x 1, RS-232 x 3
or 5(COM 5 and COM 6 are
optional), LPT x 1, VGA x 1,
External ATX Power Connector x 1,
Keyboard/ Mouse Connector x 1
lIR interface: One IrDA Tx/Rx header
lAudio:Mic in, Line in, Line out, CD Audio
in, and Audio 6 channel output
lUSB: One 5x2 pin header support 2 USB
ports and 4 D-sub USB ports

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide
Quick
Installation
Guide
Chapter
Part No. 2007830010 V.1 Printed in Taiwan 5/2003
Notice:
The Quick Installation Guide is derived from
Chapter 2 of
user manual. For other chapters and
further installation
instructions, please refer to the user manual CD-ROM
that
came with the product.

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide 2 -2
2.1 Safety Precautions
Always completely disconnect the power cord from
your board whenever you are working on it. Do not
make connections while the power is on, because a
sudden rush of power can damage sensitive
electronic components.
Always ground yourself to remove any static charge
before touching the board. Modern electronic
devices are very sensitive to static electric charges.
Use a grounding wrist strap at all times. Place all
electronic components on a static-dissipative surface
or in a static-shielded bag when they are not in the
chassis

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide 2 -3
2.2Location of Connectors and Jumpers
Locating connectors and jumpers (component side)

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide 2 -4
Locating connectors and jumpers (solder side)

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide 2 -5
2.3 Mechanical Drawing
Mechanical drawing (component side)

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide 2 -6
Mechanical drawing (solder side)

Embedded ATX Board
EMB-830
Chapter 2 Quick Installation Guide 2 -7
2.4List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Jumpers
Label Function
JP1Clear CMOS
JP2
COM2 RS-232/422/485 Selection
JP3
COM1 Ring/+5V/+12V Selection
JP4
COM2 RS-232/422/485 Selection
JP5
COM2 Ring/+5V/+12V Selection
JP6
COM3 Ring/+5V/+12V Selection
JP7
COM4 Ring/+5V/+12V Selection
JP8
Audio Out Selection
JP9
LCD Voltage Selection
JP10
COM6 Ring/+5V/+12V Selection
JP11
COM5 Ring/+5V/+12V Selection
