Aaeon ?COM-BT User manual

SMARC Module μCOM-BT
μCOM-BT
Intel® Atom™/ Celeron®Processor
Onboard Memory 2GB
Gigabit Ethernet
2 SATA
2 USB 2.0, 1 USB 3.0, 3 PCI-E[x1]
LVDS, HDMI, HD Audio
μCOM-BT Rev. A Manual 1st Ed.
July 1, 2015

SMARC Module μCOM-BT
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i

SMARC Module μCOM-BT
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
AMI is a trademark of American Megatrends Inc.
Intel®, and Atom™are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
SoundBlaster is a trademark of Creative Labs, Inc.
All other product names or trademarks are properties of their
respective owners.
ii

SMARC Module μCOM-BT
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
•4 M2.5 Screw
•1 DVD-ROM for drivers and manual (in PDF
format)
•1 μCOM-BT
If any of these items should be missing or damaged, please
contact your distributor or sales representative immediately.
iii

SMARC Module μCOM-BT
China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Main Board/ Daughter Board/ Backplane
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：此产品所标示之环保使用期限，系指在一般正常使用状况下。
iv

SMARC Module μCOM-BT
China RoHS Requirements
Poisonous or Hazardous Substances or Elements in Products
AAEON Main Board/ Daughter Board/ Backplane
Component
Poisonous or Hazardous Substances or Elements
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
Biphenyls
(PBB)
Polybrominated
Diphenyl Ethers
(PBDE)
PCB & Other
Components X O O O O O○
Wires &
Connectors
for External
Connections
X O O O O O
O
：
The quantity of poisonous or hazardous substances or elements found in each of the
component's parts is below the SJ/T 11363-2006-stipulated requirement.
X: The quantity of poisonous or hazardous substances or elements found in at least one
of the component's parts is beyond the SJ/T 11363-2006-stipulated requirement.
Note: The Environment Friendly Use Period as labeled on this product is
applicable under normal usage only
v

SMARC Module μCOM-BT
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 Specifications............................................................ 1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions.................................................... 2-2
2.2 Mechanical Drawings................................................2-3
2.3 List of Jumpers..........................................................2-7
2.4 List of Connectors ..................................................... 2-8
2.5 RTC Clear, AT/ATX and Boot Mode Selection (SW1)
......................................................................................... 2-9
2.6 RTC Battery Connector (BAT1) ...............................2-9
2.7 MXM 314 Pin Definitions .........................................2-10
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. .................................. 3-2
3.2 AMI BIOS Setup........................................................3-3
Chapter 4 Driver Installation
4.1 Installation ................................................................. 4-3
Appendix A Programming The Watchdog Timer
A.1 Watchdog Timer Initial Program ............................A-2
vi

SMARC Module μCOM-BT
Appendix B I/O Information
B.1 I/O Address Map....................................................B-2
B.2 Memory Address Map............................................B-4
B.3 IRQ Mapping Chart................................................B-5
Appendix CProgramming the Digital I/O
C.1 Digital I/O Sample Program.................................. C-2
vii

SMARC Module μCOM-BT
General
Information
Chapter
1
Chapter 1 General Information 1- 1

SMARC Module μCOM-BT
1.1 Introduction
This User’s Manual contains all the essential information, such as
detailed descriptions and explanations on the product’s hardware and
software features, its specifications, dimensions, jumper/connector
settings/definitions, and driver installation instructions, to facilitate
users in setting up their product.
Usersmay refer to the AAEON.com for the latest version of this
document.
Chapter 1 General Information1- 2

SMARC Module μCOM-BT
1.2 Features
Onboard Intel®Atom™ E3800 Series or Celeron®N2807
Processor SoC
Onboard DDR3L 2 GB Memory
Gigabit Ethernet
18/24-bit Single Channel LVDS
HDMI 1.4a x 1
High Definition Audio Interface
SATA x 2
USB 2.0 x 2, USB 3.0 x 1, GPIO, PCI-Express [x1] x 3
SMARC platform, 82mm x 50mm
Chapter 1 General Information 1 - 3

SMARC Module μCOM-BT
1.3 Specifications
System
Form Factor SMARC, 82 x 50 mm
Processor Intel®Atom™ E3800 Series or Celeron®
N2807 Processor SoC
System Memory Onboard DDR3L 2 GB
Chipset Intel®Atom™ SoC
I/O Chipset Intel®Atom™ SoC
Ethernet Intel®I211AT, I210IT
BIOS AMI BIOS, Legacy free BIOS
Wake On LAN Yes
Watchdog Timer ITE IT8528VG
H/W Status Monitoring Supports CPU temperature monitoring
Expansion Interface PCIe x 3
I2C x 2, SMBus x 1
SPI x 1
UART x 1 for TX/RX/RTS#/CTS#
UART x 1 for TX/RX only
Chapter 1 General Information1- 4

SMARC Module μCOM-BT
Power Requirement Standard: DC 5V
Board Size 3.23”(L) x 1.97”(W) (82mm x 50mm)
Gross Weight
Operating
Temperature
Standard: 32°F ~ 140°F (0°C ~ 60°C)
Optional: -40°F ~ 185°F (-40°C ~ 80°C)
Storage Temperature -4°F ~ 158°F (-20°C ~ 70°C)
Operating Humidity 0% ~ 90% relative humidity,
non-condensing
Display
Chipset Intel®Atom™ SoC
Graphic Engine Supports Simultaneous Dual View
Display
Resolution HDMI: 1920 x 1200
LVDS Interface Supports 18/24-bit Single Channel Up
to 1920 x 1080
I/O
Storage SATA II x 2
eMMC x 1 (Available by SKU)
Serial Port UART x 2 (one 4-wire
TX/RX/RTS#/CTS#, one 2-wire
Chapter 1 General Information 1 - 5

SMARC Module μCOM-BT
TX/RX)
USB USB 3.0 x 1
USB 2.0 x 2
Audio High Definition Audio x 1
GPIO 12 bit, 1.8V (1 share with HDA , 2
share with MiPi)
Chapter 1 General Information1- 6

SMARC Module
μC O M - BT
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Guide
Chapter
2

SMARC Module
μC O M - BT
Chapter 2 Quick Installation Guide 2 - 2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

SMARC Module
μC O M - BT
Chapter 2 Quick Installation Guide
2 - 3
2.2 Mechanical Drawings
Component Side
1.20
74.00
82.00
34.00 4.00
4.00
50.00
39.00 43.00
?2.70
0.00
4.00
39.00
56.51
78.00
82.00
3.32
14.61
38.10
56.30
0.00
6.95
12.00
23.11
25.78
45.09
29.59
38.46
42.42 46.00
50.00
29.59
42.42
14.61
0.00
0.00
SW1
U1
BAT1
SW1
U1
(3.60)
5.10
Keep Out Area uCOM- BT Module 82x50m m
(TOP and Bottom Side)
BAT1
1.20
74.00
82.00
34.00 4.00
4.00
50.00
39.00 43.00
?2.70
0.00
4.00
39.00
56.51
78.00
82.00
3.32
14.61
38.10
56.30
0.00
6.95
12.00
23.11
25.78
45.09
29.59
38.46
42.42 46.00
50.00
29.59
42.42
14.61
0.00
0.00
SW1
U1
BAT1
SW1
U1
(3.60)
5.10
Keep Out Area uCOM- BT Module 82x50m m
(TOP and Bottom Side)
BAT1
1.20
74.00
82.00
34.00 4.00
4.00
50.00
39.00 43.00
?2.70
0.00
4.00
39.00
56.51
78.00
82.00
3.32
14.61
38.10
56.30
0.00
6.95
12.00
23.11
25.78
45.09
29.59
38.46
42.42 46.00
50.00
29.59
42.42
14.61
0.00
0.00
SW1
U1
BAT1
SW1
U1
(3.60)
5.10
Keep Out Area uCOM- BT Module 82x50m m
(TOP and Bottom Side)
BAT1

SMARC Module
μC O M - BT
Chapter 2 Quick Installation Guide 2 - 4
Solder Side
1.20
74.00
82.00
34.00 4.00
4.00
50.00
39.00 43.00
?2.70
0.00
4.00
39.00
56.51
78.00
82.00
3.32
14.61
38.10
56.30
0.00
6.95
12.00
23.11
25.78
45.09
29.59
38.46
42.42 46.00
50.00
29.59
42.42
14.61
0.00
0.00
SW1
U1
BAT1
SW1
U1
(3.60)
5.10
Keep Out Area uCOM- BT Module 82x50m m
(TOP and Bottom Side)
BAT1
Cooler
Cable Out

SMARC Module
μC O M - BT
Chapter 2 Quick Installation Guide
2 - 5
Heat Sink

SMARC Module
μC O M - BT
Chapter 2 Quick Installation Guide 2 - 6
Heat Spreader
