Aaeon IMBA-H61A User manual

Industrial Motherboard
IMBA-H61A

ii
E7929
First Edition
February 2013
Copyright Notice
This document is copyrighted, 2013. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described
in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use,
or for any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the preparation
of this document to assure its accuracy, the original manufacturer assumes no
liabilities resulting from errors or omissions in this document, or from the use of the
information contained herein.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
Acknowledgments
All other products’ name or trademarks are properties of their respective owners.
AMI is a trademark of American Megatrends Inc.
Intel®, Core™ are trademarks of Intel®Corporation.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
All other product names or trademarks are properties of their respective owners.
•
•
•
•
•

iii
Contents
Chapter 1
Product overview
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specications............................................................................... 1-2
Chapter 2
Motherboard information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Screw size..................................................................................... 2-4
2.3.1 Component side.............................................................. 2-4
2.3.2 Solder side ...................................................................... 2-5
2.4 Central Processing Unit (CPU) ................................................... 2-6
2.4.1 Installing the CPU ........................................................... 2-7
2.4.2 CPU heatsink and fan assembly installation................... 2-9
2.5 System memory ......................................................................... 2-11
2.6 Jumpers ...................................................................................... 2-12
2.7 Connectors ................................................................................. 2-14
2.7.1 Rear panel connectors.................................................. 2-14
2.7.2 Internal connectors ....................................................... 2-16
Chapter 3
BIOS setup
3.1 BIOS setup program .................................................................... 3-1
3.2 BIOS menu screen ....................................................................... 3-2
3.3 Main menu .................................................................................... 3-4
3.3.1 System Language [English] ............................................ 3-4
3.3.2 System Date [Day xx/xx/xxxx]......................................... 3-4
3.3.3 System Time [xx:xx:xx] ................................................... 3-4
3.3.4 Security ........................................................................... 3-4

iv
Contents
3.4 Advanced menu ........................................................................... 3-6
3.4.1 Trusted Computing.......................................................... 3-6
3.4.2 CPUConguration .......................................................... 3-7
3.4.3 PCHConguration .......................................................... 3-8
3.4.4 SATAConguration ......................................................... 3-8
3.4.5 SystemAgentConguration ........................................... 3-9
3.4.6 USBConguration ........................................................ 3-10
3.4.7 SIO GPIO...................................................................... 3-10
3.4.8 OnboardDevicesConguration.....................................3-11
3.4.9 APM ...............................................................................3-11
3.4.10 Network Stack............................................................... 3-12
3.5 Monitor menu ............................................................................. 3-13
3.5.1 CPU Temperature / MB Temperature [xxxºC/xxxºF]...... 3-13
3.5.2 CPU / Chassis Fan Speed ........................................... 3-13
3.5.3 CPU Q-Fan Control [Enabled] ...................................... 3-14
3.5.4 Chassis Q-Fan Control [Enabled] ................................. 3-14
3.5.5 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage .. 3-14
3.6 Boot menu .................................................................................. 3-15
3.6.1 Full Screen Logo [Enabled]........................................... 3-15
3.6.2 Post Delay Time [3 sec] ................................................ 3-15
3.6.3 Bootup NumLock State [On] ......................................... 3-15
3.6.4 Wait for ‘F1’ If Error [Disabled] ...................................... 3-16
3.6.5 Option ROM Messages [Force BIOS]........................... 3-16
3.6.6 CSM (Compatibility Support Module)............................ 3-16
3.6.7 Boot Option Priorities .................................................... 3-17
3.6.8 Boot Override................................................................ 3-17
3.7 Tools menu ................................................................................. 3-17
3.7.1 EZ Flash 2 Utility........................................................... 3-17
3.7.2 SPD Information............................................................ 3-17
3.8 Exit menu.................................................................................... 3-18
Appendix
Notices.......................................................................................................A-1

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x Industrial Motherboard
2 x Serial ATA 3.0Gb/s cables
1 x I/O Shield
1 x Support DVD (Drivers and manual)
1 x COM Port cable
If any of the above items is damaged or missing, contact your distributor or
sales representative immediately.
1.2 Features
Intel®Socket 1155 For 3rd/2nd Generation Core™ i7 / Core™ i5 / Core™ i3 /
Pentium®/ Celeron®Processors
Two 240-pin Dual Channel DDR3 1333 / 1066 /800 MHz DIMM slots
supporting up To 16GB of non-ECC unbuffered memory
Graphics multi-display: VGA x 1, DVI x 1
10/100/1000Base-TX Ethernet x 2
SATA 3.0 Gb/s x 4, USB2.0 x 9, COM x 6
PCI Express[x16] x 1, PCI Express[x1] x 2, PCI Express Mini-card x1, PCI x4
Onboard parallel port connection
EuP/ErP Compliance
•
•
•
•
•
•
•
•
Chapter 1
Product overview

IMBA-H61A
1-2
1.3 Specications
SYSTEM
Form factor ATX Form Factor
CPU LGA1155 socket for Intel®3rd/2nd Generation Core™ i7 / Core™ i5 /
Core™ i3 / Pentium®/ Celeron®processors
Supports Intel®22nm / 32nm CPU
Supports Intel®Turbo Boost Technology 2.0
• The Intel®Turbo Boost Technology 2.0 support depends on the CPU types.
Memory 2 x DIMM (8GB per DIMM), max. 16GB, DDR3 1333 / 1066 / 800MHz
Dual-channel memory architecture
Chipset
Intel®H61 Express Chipset
I/O Chipset
NCT6776F
Ethernet
Realtek®8111F, 10/100/1000Base-TX
2 x RJ-45 ports
BIOS
64Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, SM BIOS, ACPI
2.0a
Manageability
WOL/WOR by LAN, PXE
OS
Windows®XP 32-bit, Windows®7 32/64-bit, Windows®8 32/64-bit
H/W Status Monitor
Monitors CPU/system temperature
Monitors Vcore, 5V/VBAT/12V
Monitors CPU/chassis fan speed
Expansion slot
1 x PCI Express 2.0 x16 slot
2 x PCI Express 2.0 x1 slot
4 x PCI slots
1 x PCI Express Mini-card
Battery
Lithium battery
Power requirement
1 x 24-pin ATX connector
1 x 4-pin ATX 12V power connector
Fan
1 x 4-pin CPU fan
2 x 4-pin Chassis fan
Board size 12” x 9.6” (305mm x 244mm)
Gross weight
1.45 lb (0.66 Kg)
Operating
temperature
32oF~140oF (0oC~60oC)
Storage temperature
-40oF~176oF (-40oC~80oC)
Operating humidity
0%~90% relative humidity, non-condensing
Power compliance
Compliant with Eup/ErP
AT/ATX power mode support
EMI
CE (include CE-LVD), FCC
(continued on the next page)

1-3
Chapter 1: General information
DISPLAY
Chipset
Intel®Graphics Media Accelerator
Resolution
Up to 1920x1200@60Hz for VGA
Up to 1920x1200@60Hz for DVI
Output interface
1 x VGA port
1 x DVI port
I/O
Storage
4 x SATA 3.0Gb/s ports
Serial port
1 x RS232 DB-9 connector (COM1)
1 x RS232/422/485 on rear I/O (COM2)
4 x RS232 box header (COM3~COM6)
USB
9 x USB2.0 ports (5 ports at mid-board, 4 ports at rear panel)
DIO
1x 8-bit Digital I/O interface (optional)
LPT
1 x LPT connector
TPM
1 x TPM header (TPM/FW3.19)
RTC
Internal RTC
Keyboard/Mouse
2 x PS/2 Keyboard/Mouse connector
Audio
Realtek®ALC8877.1-channelhighdenitionaudioCODEC
3 x audio jacks (Line-in, Mic-in, Line-out)
Ethernet
2 x RJ-45 ports on rear I/O
Display
1 x VGA port on rear I/O
1 x DVI port on rear I/O
Others
1 x Front panel connector (Pin header)
1 x CMOS jumper
Specicationsaresubjecttochangewithoutnotice.

IMBA-H61A
1-4

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
• Unplug the power cord from the wall socket before touching any
component.
• Before handling components, use a grounded wrist strap or touch a safely
grounded object or a metal object, such as the power supply case, to avoid
damaging them due to static electricity.
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic
pad or in the bag that came with the component.
• Before you install or remove any component, ensure that the ATX power
supply is switched off or the power cord is detached from the power
supply. Failure to do so may cause severe damage to the motherboard,
peripherals, or components.
Standby Power LED
This motherboard comes with two standby power LEDs that light up to indicate
that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that
you should shut down the system and unplug the power cable before removing or
plugging in any motherboard component. The illustration below shows the location
of the onboard LED.
SB_PWR1
ON
Standby Power Standby Power Off
OFF
SB_PWR2
ON
Main Power Main Power Off
OFF
IMBA-H61A Onboard LED

IMBA-H61A
2-2
2.2 Motherboard layout
Place eight screws into the holes indicated by circles to secure the motherboard
to the chassis.
Do not overtighten the screws! Doing so can damage the motherboard.
Place
this side
towards
the rear
of the
chassis
PCIEX16_1
PCI1
PCI2
PCI3
PCI4
DIO1
PCIEX1_1
PCIEX1_1
EATX_PWR1
CPU_FAN1
CHA_FAN1
CHA_FAN2
Lithium Cell
CMOS Power
Super
I/O
BZ1
ALC
887
ASM
1083
ASM
1442
EPU
KBMS1
SB_PWR1
SB_PWR2
ATMODE
CLRTC1
CHASSIS1
DRCT1
24.4cm(9.6in)
30.5cm(12in)
Intel®
H61
DDR3 DIMM_A1 (64bit, z240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_4SATA3G_3SATA3G_2SATA3G_1
USB89
USB10
USB45
MINI_CARD1
AUDIO
LAN1_USB12
LAN2_USB34
LPT1
TPM1
COM2_V1
DVI_D VGA1
COM1 COM2
LGA1155
F_PANEL1
COM4COM5COM6 COM3
COMBH2
RTL
8111F
RTL
8111F
EATX_PWR2
321 34 5 6 4
1213143151617
1
8
9
10
11
7

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. Serial port connectors (10-1 pin COMBH2, COM3~6) 21
2 COM2_V1 Ring/+5V/+12V selection (6-pin) 13
3. CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN) 17
4. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V) 16
5. Intel®LGA1155 CPU socket 6
6. DDR3 DIMM slots 11
7. Standby Power LEDs (SB_PWR1/2) 1
8. Clear RTC RAM (3-pin CLRTC) 12
9. Chassis intrusion connector (4-1 pin CHASSIS1) 20
10. Direct connector (2-pin DRCT1) 22
11 AT Mode selection (3-pin ATMODE) 13
12. System panel connector (10-1 pin F_PANEL) 18
13. Intel®H61 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~4) 19
14. USB 2.0 connectors (10-pin USB89, USB45; 5-pin USB10) 20
15. Digital I/O connector (10-pin DIO1) 21
16. LPT connector (26-1 pin LPT) 17
17. TPM connector (20-1 pin TPM1) 19

IMBA-H61A
2-4
2.3 Screw size
2.3.1 Component side

2-5
Chapter 2: Motherboard information
2.3.2 Solder side

IMBA-H61A
2-6
Unplug all power cables before installing the CPU.
• Upon purchase of the motherboard, ensure that the PnP cap is on
the socket and the socket contacts are not bent. Contact your retailer
immediately if the PnP cap is missing, or if you see any damage to the
PnP cap/socket contacts/motherboard components. The manufacturer will
shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. The manufacturer will
process Return Merchandise Authorization (RMA) requests only if the
motherboard comes with the cap on the LGA1155 socket.
• The product warranty does not cover damage to the socket contacts
resulting from incorrect CPU installation/removal, or misplacement/loss/
incorrect removal of the PnP cap.
2.4 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1155 socket designed for the
Intel®3rd/2nd Generation Core™ i7 / Core™ i5 / Core™ i3 / Pentium®/ Celeron®
processors.
IMBA-H61A CPU socket LGA1155

2-7
Chapter 2: Motherboard information
2.4.1 Installing the CPU
1
The LGA1156 CPU is incompatible with the LGA1155 socket. DO NOT install a
LGA1156 CPU on the LGA1155 socket.
A
B
2 3

IMBA-H61A
2-8
A
B
C
4
5

2-9
Chapter 2: Motherboard information
2.4.2 CPU heatsink and fan assembly installation
Apply the Thermal Interface
Material to the CPU heatsink
and CPU before you install the
heatsink and fan if necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

IMBA-H61A
2-10
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1

2-11
Chapter 2: Motherboard information
2.5 System memory
Installing a DIMM
To remove a DIMM
1
2
3
A
B

IMBA-H61A
2-12
2.6 Jumpers
1. Clear RTC RAM (CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in
CMOS. You can clear the CMOS memory of date, time, and system setup
parameters by erasing the CMOS RTC RAM data. The onboard button
cell battery powers the RAM data in CMOS, which include system setup
information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on
pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup
to reenter data.
Never remove the cap from the CLRTC jumper default position except when
clearing the RTC RAM. Removing the cap will cause system boot failure!
• If the steps above do not help, remove the onboard battery and move the
jumper again to clear the CMOS RTC RAM data. After clearing the CMOS,
reinstall the battery.
• You do not need to clear the RTC when the system hangs due to
overclocking. For system failure due to overclocking, use the CPU
Parameter Recall (C.P.R) feature. Shut down and reboot the system so the
BIOS can automatically reset parameter settings to default values.
IMBM-H61A Clear RTC RAM
1223
Normal
(Default)
Clear RTC1
CLRTC1
