Aaeon EPIC-KB07 User manual

EPIC Board
E P I C - KB07
EPIC-KB07
AMD®Embedded G-series
Quad/ Dual SoC APU
DDR3/DDR3L 1600 SODIMM
18/24-bit Single/Dual-channel LVDS LCD
5 USB2.0, 2 USB3.0, 6 COM
1 SATA, 1 mSATA
2 GbE, SIM Card, Mini Card
EPIC-KB07 Manual Rev. A 1st Ed.
July 15, 2014

EPIC Board
E P I C - K B 0 7
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the original
manufacturer assumes no responsibility for its use, or for any in-
fringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have been
made in the preparation of this document to assure its accuracy,
AAEON assumes no liabilities resulting from errors or omissions in
this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

EPIC Board
E P I C - K B 0 7
ii
Acknowledgments
All other products’name or trademarks are properties of their
respective owners.
AMD®is trademark of Advanced Micro Devices.
Microsoft Windows®is a registered trademark of Microsoft Corp.
ITE is a trademark of Integrated Technology Express, Inc.
IBM, PC/AT, PS/2, and VGA are trademarks of International
Business Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

EPIC Board
E P I C - K B 0 7
iii
Packing List
Before you begin installing your card, please make sure that the
following materials have been shipped:
1709070500 SATA Cable
1702150155 SATA Power Cable
9657666600 Jumper Cap
Heat Spreader (by model request )
DVD-ROM for manual (in PDF format) and drivers
EPIC-KB07
If any of these items are missing or damaged, please contact your
distributor or sales representative immediately.

EPIC Board
E P I C - K B 0 7
iv
Contents
Chapter 1 General Information
1.1 Introduction....................................................................1-2
1.2 Features ........................................................................1-3
1.3 Specifications ................................................................1-4
Chapter 2 Quick Installation Guide
2.1 Safety Precautions........................................................2-2
2.2 Location of Connectors and Jumpers ...........................2-3
2.3 Mechanical Drawing......................................................2-4
2.4 List of Jumpers..............................................................2-7
2.5 List of Connectors .........................................................2-8
2.6 Setting Jumpers ..........................................................2-10
2.7 LVDS1 Backlight Voltage Selection (JP1)...................2-11
2.8 LVDS1 Backlight Control Selection (JP2) ...................2-11
2.9 LVDS1 VCC Selection (JP3).......................................2-11
2.10 LVDS2 Backlight Voltage Selection (JP4).................2-12
2.11 LVDS2 Backlight Control Selection (JP5).................2-12
2.12 LVDS2 VCC Selection (JP6).....................................2-12
2.13 AT/ATX Selection (JP8) ............................................2-12
2.14 LPT_DIO Selection (JP9)..........................................2-13
2.15 COM2 Ring_12V_5V Selection (JP10).....................2-13
2.16 COM2 Slew Selection (JP11)....................................2-13
2.17 Touch Screen Selection (JP12) ................................2-14

EPIC Board
E P I C - K B 0 7
v
2.18 COM1 Slew Selection (JP13)....................................2-14
2.19 COM1 Ring_12V_5V Selection (JP14).....................2-14
2.20 Clear CMOS Selection (CN9) ...................................2-15
2.21 mSATA / PCIe Selection (CN37) ..............................2-15
2.22 Display setting Selection (SW1)................................2-15
2.23 Fan Connector (CN2)................................................2-16
2.24 SPI Flash Header (CN3) ...........................................2-16
2.25 LAN1 Ethernet RJ-45 Connector (CN5)....................2-17
2.26 LAN2 Ethernet RJ-45 Connector (CN6)....................2-17
2.27 DP0 Connector (CN7)...............................................2-18
2.28 1st Backlight Connector (CN10)..................................2-19
2.29 1st LVDS Connector (CN11).......................................2-19
2.30 2nd Backlight Connector (CN13).................................2-21
2.31 2nd LVDS Connector (CN14)......................................2-21
2.32 3G SIM Connector (CN15)........................................2-23
2.33 Dual USB3.0 Connector (CN16)...............................2-23
2.34 SATA CONNCETOR (CN17)....................................2-24
2.35 SATA CONNCETOR (CN18)....................................2-25
2.36 SATA Power Connector (CN19) ...............................2-26
2.37 RS-232 Serial Port Dual Connector (CN20) .............2-26
2.38 RS-232 Serial Port Connector (CN21)......................2-28
2.39 LPT_DIO Connector (CN22).....................................2-29
2.40 RS-232 Serial Port Connector (CN23)......................2-32
2.41 LPC Connector (CN24).............................................2-32
2.42 Touch Screen Connector (CN25)..............................2-33

EPIC Board
E P I C - K B 0 7
vi
2.43 Audio Connector (CN26)...........................................2-34
2.44 AMP-R Channel Connector (CN27)..........................2-35
2.45 AMP-L Channel Connector (CN28)...........................2-35
2.46 RS-232 Serial Port Connector (CN30)......................2-35
2.47 RS-232 Serial Port Connector (CN31)......................2-36
2.48 VGA CONNECTOR (CN32)......................................2-37
2.49 RTC Battery Connector (CN33) ................................2-38
2.50 Front Panel Connector (CN34) .................................2-38
2.51 4-Pin Power IN Connector (CN35)............................2-39
2.52 2-Pin Power IN Connector (CN36)............................2-39
2.53 1st MINI Card Slot (PCIE1A1)....................................2-40
2.54 2nd MINI Card Slot (PCIE1A2)....................................2-42
2.55 USB2.0 Connector (USB1) .......................................2-45
2.56 USB2.0 Connector (USB2) .......................................2-45
2.57 USB2.0 Connector (USB3) .......................................2-46
2.58 USB2.0 Connector (USB4) .......................................2-46
2.59 USB2.0 Connector (USB5) .......................................2-47
2.60 PS2 Keyboard and Mouse Connector (KB1) ............2-47
2.67 HDMI Connector (HDMI1).........................................2-48
Chapter 3 AMI BIOS Setup
3.1 System Test and Initialization. ......................................3-2
3.2 AMI BIOS Setup............................................................3-3
Chapter 4 Driver Installation
4.1 Installation .....................................................................4-3

EPIC Board
E P I C - K B 0 7
vii
Appendix A Programming The Watchdog Timer
A.1 Programming ............................................................A-2
A.2 F81866 Watchdog Timer Initial Program……………A-5
Appendix B I/O Information
B.1 I/O Address Map.......................................................B-2
B.2 Memory Address Map...............................................B-4
B.3 IRQ Mapping Chart...................................................B-5
B.4 DMA Channel Assignments......................................B-8
Appendix C Mating Connector
C.1 List of Mating Connectors and Cables......................C-2
Appendix D Electrical Specifications for I/O Ports
D.1 Electrical Specifications for I/O Ports .......................D-2
Appendix E DIO
E.1 DIO............................................................................E-2

EPIC Board
E P I C - K B 0 7
Chapter 1 General Information 1- 1
General
Information
Chapter
1

EPIC Board
E P I C - K B 0 7
Chapter 1 General Information 1- 2
1.1 Introduction
AAEON announces a brand new EPIC Board EPIC-KB07,
designed to fit in diverse applications that demand for fitting in
different space limitations and high performance.
EPIC-KB07 accommodates onboard AMD®Embedded G-series™
SoC APU and features DDR3/DDR3L (default) SODIMM 1600
system memory up to 8GB.
Moreover, EPIC-KB07 deploys Realtek®8111E Ethernet chip to
feature two RJ-45 ports onboard to display the transcendent
performance of network connections. The display chipset of
EPIC-KB07 supports 18/24-bit dual/single channel LVDS LCD and
optional DisplayPort/ HDMI function.
In addition to the SIM Card and Mini Card expansions, EPIC-KB07
also features one SATA, one mSATA for the storage and five
USB2.0, two USB3.0, six COM, 16-bit Digital I/O co-lay with LPT
function for flexible I/O expansion. EPIC-KB07 is an excellent
solution for your vital applications.

EPIC Board
E P I C - K B 0 7
Chapter 1 General Information 1- 3
1.2 Features
AMD Embedded G-series Quad/Dual Core SoC APU (BGA
based, ≦25W )
- AMD® GX-420CA Quad-core 2.0GHz SoC with AMD
Radeon™ HD 8400E Graphics
- AMD® GX-217GA Dual-core 1.65GHz SoC with AMD
Radeon™HD 8280E Graphics
1 x 204-pin Single Channel DDR3/DDR3L (default)
1600MHz SODIMM up to 8GB
Display Configuration ( supports dual displays and VGA
+DP0 default setting )
- VGA+DP1; VGA+LVDS1(18-bit Single Channel) or
LVDS2
- DP0 (Rear I/O) or HDMI + VGA ; DP0 (Rear I/O) or
HDMI + LVDS2(24-bit Dual Channel)
- LVDS1(18-bit Single Channel) +LVDS2(24-bit Dual
Channel)
- DP0 or HDMI + DP1(optional)
10/100/1000Base-TX, RJ-45 x 2
SATA6.0 Gb/s x 1, USB 3.0 x 2, USB2.0 x 5
RS-232 x 4, RS-232/422/485 x 2( COM 1,2)
Mini Card Socket x 2 (One for Mini Card, the other one for
mSATA/ Mini Card and selected by Jumper CN37)
Touch Panel Control Chip Supports 4/5/8-wire Touch Screen
(Optional)
1.8 mm PCB, 8-layer PCB Layout

EPIC Board
E P I C - K B 0 7
Chapter 1 General Information 1- 4
1.3 Specifications
System
Form Factor EPIC Board
Processor AMD®Embedded G-series™
Quad/ Dual Core SoC APU
System Memory SODIMM DDR3/DDR3L (default)
1600 MHz Up to 8 GB
Chipset AMD Embedded G-series Quad/
Dual Core SoC APU
I/O Chipset Fintek 81866D
Ethernet 10/100/1000Base-TX (Realtek®
8111E), RJ-45 x 2
BIOS AMI Plug & Play BIOS
Wake On LAN Yes
Watchdog Timer Generates a time-out system reset
H/W Status Monitoring Monitoring system temperature,
voltage, and cooling fan status
Expansion Interface Mini Card socket x 1, SIM Card
socket x 1
Battery Lithium battery
Power Requirement ATX 4-pin connector x 1 or
co-lay 2-pin block terminal;
12 V or DC9~24V DC input x 1;
SATA power with 2-pin wafer x 1
Smart fan with 4-pin wafer x 1

EPIC Board
E P I C - K B 0 7
Chapter 1 General Information 1- 5
Board Size 4.5" x 6.5" (115mm x 165mm)
Gross Weight 0.44 lb (0.2 Kg)
Operation Temperature 32°F ~ 140°F (0°C ~ 60°C)
Storage Temperature -4°F ~ 158°F (-20°C ~ 70°C)
Operation Humidity 10% ~ 80% relative humidity,
non-condensing
Display: Supports CRT/LCD/DP simultaneous/ dual view
displays
Chipset AMD®Embedded G-series SoC
integrated
Resolutions Up to 2048x1536 @ 75 Hz for
CRT; 1920x1200 @ 85Hz for
LCD; 1920x1200 @ 60Hz for
DisplayPort
LCD Interface VGA+DP1; VGA+LVDS1(18 bit
Single CH) or LVDS 2;
DP 0 or HDMI + VGA ; DP 0 or
HDMI + LVDS2(24 bit Dual CH)
LVDS1(18 bit Single CH) +
LVDS2 (24 bit Dual CH);
DP 0 or HDMI + DP 1(optional)
Note 1: VGA and DP0 are default display
Note 2: DP1 co-lay with LVDS2 controlled by BIOS setting
Note 3: Please refer to Chapter 2 2.22 Display Setting Selection
(SW1) for settings above.

EPIC Board
E P I C - K B 0 7
Chapter 1 General Information 1- 6
I/O
Storage SATA 6.0Gb/s x 1, mSATA x 1
Serial Port RS-232 x 4, RS-232/422/485 x 2
Parallel Port SPP/EPP/ECP Mode
USB USB2.0 x 5, USB3.0 x 2
PS/2 Port Keyboard x 1, Mouse x 1
Digital I/O Supports 16-bit (programmable),
Colay with LPT Port (default and
selected by Jumper JP9)
Audio Line-in, Line-out, & Mic-in
Touch Screen Supports 4/5/8-wire resistive touch
screen (optional)

EPIC Board
E P I C - K B 0 7
Chapter 2 Quick Installation Guide 2-1
Quick
Installation
Guide
Chapter
2

EPIC Board
E P I C - K B 0 7
Chapter 2 Quick Installation Guide 2-2
2.1 Safety Precautions
Always completely disconnect the power cord
from your board whenever you are working on
it. Do not make connections while the power is
on, because a sudden rush of power can
damage sensitive electronic components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap at
all times. Place all electronic components on a
static-dissipative surface or in a static-shielded
bag when they are not in the chassis

EPIC Board
E P I C - K B 0 7
Chapter 2 Quick Installation Guide 2-3
2.2 Location of Connectors and Jumpers
Component Side
Component Side Solder Side

EPIC Board
E P I C - K B 0 7
Chapter 2 Quick Installation Guide 2-4
2.3 Mechanical Drawing
Component Side
Component Side Solder Side
6-?3.26-?3.2

EPIC Board
E P I C - K B 0 7
Chapter 2 Quick Installation Guide 2-5
With Heat Spreader
3.0
b
b
b
b b
b
c
c
G
G
G
G
G
G
G
G
* 3.0
3.0
e e e
e e e
Solder Side
Component Side Solder Side
6-?3.26-?3.2

EPIC Board
E P I C - K B 0 7
Chapter 2 Quick Installation Guide 2-6
Heat spreader (just for one of design reference)
3.0
b
b
b
b b
b
c
c
G
G
G
G
G
G
G
G
* 3.0
3.0
e e e
e e e
