Aaeon ONYX-219 User manual

Smart Medical Terminal ONYX-219/217/215
ONYX-219/217/215
19”/17”/15”
SmartMedicalTerminal
ONYX-219/217/215 Manual
Nov. 2006

Smart Medical Terminal Onyx-219/217/215
i
Copyright Notice
This document is copyrighted, 2006. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties, which may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Smart Medical Terminal Onyx-219/217/215
ii
Acknowledgments
Intel®and Pentium®are registered trademarks of Intel®Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business Machines
Corporation.
Microsoft®Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
SiS is a trademark of Silicon Integrated Systems Corp.
VIA is a trademark of VIA Technology, Inc.
All other product names or trademarks are properties of their
respective owners.

Smart Medical Terminal Onyx-219/217/215
iii
Packing List
The Smart Medical Terminal comes with the following standard parts
shown as below. Check and make sure they are included and in good
condition. If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
1. Smart Medical Terminal x 1
2. User’s Manual CD-ROM x 1
3. VGA Cable 1.8 M x 1
4. USB Cable x 1
5. Audio Cable x 1
6. Medical Adapter x 1
It is better for you to keep the carton and the packing materials in case
you might need them for packing or moving in the future.

Smart Medical Terminal Onyx-219/217/215
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from anyAC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.

Smart Medical Terminal Onyx-219/217/215
v
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to
work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20° C (-4°F) OR ABOVE 60° C (140° F). IT MAY
DAMAGE THE EQUIPMENT.
16. External equipment intended for connection to signal
input/output or other connectors, shall comply with relevant
UL / IEC standard (e.g. UL 1950 for IT equipment and
UL 60601-1 / IEC 60601 series for systems – shall comply with
the standard IEC 60601-1-1, Safety requirements for medical
electrical systems. Equipment not complying with
UL 60601-1 shall be kept outside the patient environment, as
defined in the standard.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.

Smart Medical Terminal Onyx-219/217/215
vi
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IPX0
3. Equipment not suitable for use in the presence of a flammable
anesthetic mixture with air or with oxygen or nitrous oxide.
4. Mode of operation: Continuous
5. Type of protection against electric shock: Class I equipment

Smart Medical Terminal Onyx-219/217/215
vii
FCC Safety
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received
including interference that may cause
undesired operation.

Smart Medical Terminal Onyx-219/217/215
viii
UL Module Description
Onyx-219/217/215 modules are developed to
suitable for the Classification Mark
requirement

Smart Medical Terminal Onyx-219/217/215
ix
Safety Symbol Description
The following safety symbols are the further explanations for your
reference.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with UL 60601-1, and
CAN/CSA C22.2 NO. 601.1
Attention, consult ACCOMPANYING
DOCUMENTS.
Ground wire
Protective Ground wire.

Smart Medical Terminal Onyx-219/217/215
x
Contents
Chapter 1 General Information
1.1 Introduction......................................................................... 1-2
1.2 Feature............................................................................... 1-3
1.3 Specification....................................................................... 1-4
1.4 Dimension .......................................................................... 1-8
Chapter 2 Hardware Installation
2.1 Before Unpacking............................................................... 2-2
2.2 Connecting to the computer ............................................... 2-3
Chapter 3 On Screen Display Control
3.1 On Screen Display Controller ............................................ 3-2
3.2 Key Selection. .................................................................... 3-2
3.3 LED Function...................................................................... 3-3
3.4 OSD Main Menu: Push the MENU key............................... 3-3
3.5 Input Source Selection ....................................................... 3-4
3.6 Contrast/ Brightness-Submenu .......................................... 3-5
3.7 Geometry Menu.................................................................. 3-6
3.8 Color Temperature-Submenu............................................. 3-7
3.9 RGB Color-Submenu ......................................................... 3-8
3.10 Language-Submenu......................................................... 3-9
3.11 OSD Manager-Submenu.................................................. 3-10
3.12 Auto Config-Submenu...................................................... 3-11

Smart Medical Terminal Onyx-219/217/215
xi
3.13 Mode Information-Submenu............................................. 3-12
3.14 Memory Recall-Submenu................................................. 3-13
3.15 Exit menu-Submenu......................................................... 3-14
Chapter 4 Drivers Installation
4.1 Card Reader Driver Installation.......................................... 4-2
4.2 Smart Card Driver Installation ............................................ 4-2
4.3 Touch Screen Driver Installation ........................................ 4-2
4.4 Troubleshooting.................................................................. 4-2
4.5 Applicable Graphic Table ................................................... 4-3
Appendix A Miscellanea
A.1 General Cleaning Tips ....................................................A-2
A.2 Cleaning Tools................................................................A-3
A.3 Scrap Computer Recycling ............................................A-5

Smart Medical Terminal ONYX-219/217/215
Chapter1GeneralInformation1-1
General
Chapter
1
Information

Smart Medical Terminal ONYX-219/217/215
Chapter 1 General Information 1-2
1.1 Introduction
AAEON launches a series of smart Medical Terminals – the
Onyx-215, Onyx-217 and Onyx-219. The Onyx-215, Onyx-217
and Onyx-219 which are 15” XGA (1024 x 768), 17” SXGA (1280 x
1024) and 19” SXGA (1280 x 1024) respectively are rugged true
color TFT display panels that have been approved according to
EN60601-1 and UL60601-1 standards for limited power leakage
and electronic emission. These two medical level displays’
brightness, resolution, and contrast ratio are better than standard
LCD displays which cannot fulfill the DICOM requirement.
Onyx-215, Onyx-217 and Onyx-219 provide a DVI port for medical
images. This DVI port prevents signal distortion during
transmission. An On Screen Display (OSD) on the front panel
allows convenient operation.
These Medical Terminals feature a USB Hub for peripheral
connections. In addition, Onyx-215, Onyx-217 and Onyx-219
have an integrated smart card reader, all-in-one card reader, and
DVD-ROM to increase efficiency for patient use and medical
practitioners. For enhancing e-Health care communication,
Onyx-215, Onyx-217 and Onyx-219 can also be equipped with Web
CAM and USB photo accessory kits for medical practitioners to
communicate with patients more easily.

Smart Medical Terminal ONYX-219/217/215
Chapter1GeneralInformation1-3
For medical equipment, IP-65 certification is also important. The
Onyx-215, Onyx-217 and Onyx-219 are IP-65 certified and
Latex-free. These Smart Medical Terminals are designed to target
the medical market and are great for applications such as IPD
(Inside Patient Department) and medicinal distribution. If you are
looking for a smart medical display, the Onyx-215, Onyx-217 and
Onyx-219 definitely will be your best choice for medical market
applications.
1.2 Feature
The model provides broad range of19”/17”/15” LCD panels, long
lifetimeTFTLCDmonitors.
 19” SXGA/17” SXGA/15” XGA true color TFT LCD display
 Integrated USB HUB
 Integrated smart card reader
 Integrated all in one card reader
 Integrated Suck-in DVD-ROM
 Integrated Web CAM & USB phone (optional)
 OSD (On Screen Display) on the front panel for user friendly
operation
 Latex free
 Resistive Touchscreen (Optional)

Smart Medical Terminal ONYX-219/217/215
Chapter 1 General Information 1-4
1.3 Specification
Hardware Specifications
Display ONYX-219: 19” SXGA color TFT LCD
ONYX-217: 17” SXGA color TFT LCD
ONYX-215: 15” XGA color TFT LCD
Disk Drive
Space
Suck-in DVD-ROM
8 in 1 card reader
Smart Card reader
OSD Button Front
I/O 1 x DVI-D 24-pin connector
3 x USB 2.0 ports for Devices
--1 x on up side for Web CAM
--2 x on rear bracket
1 x USB 2.0 ports for PC
Sound:
1 x Line-in
2 x Speakers on back side
LCD Specifications
Model Name Onyx-219 series Onyx-217 series
O
nyx-215 series
Display Type 19” color TFT LCD 17” color TFT LCD 15” color TFT LCD
Max. Resolution 1280 x 1024 1280 x 1024 1024 x 768
Max. Colors 16.7M 16.7M 16.7M
Dot Size (mm) 0.294 x 0.294 0.297 x 0.297 0.297 x 0.297
Luminance
(cd/m2)
400 (TYP) 300 (TYP) 400 (TYP)

Smart Medical Terminal ONYX-219/217/215
Chapter1GeneralInformation1-5
140°(H) 150°(H) 170°(H)
Viewing Angle
135°(V) 130°(V) 170°(V)
Operating
Temperature
0˚C~40˚C
(32˚F~104˚F)
0°C~ 40˚C
(32˚F~104˚F)
0°C~ 40˚C
(32˚F~104˚F)
Brightness
Control
Yes Yes Yes
Back Light
MTBF
50,000 Hrs 40,000 Hrs 50,000 Hrs
Note:
All AAEON's LCD products are manufactured with High precision
technology. However, there are a small number of defective pixels
in all LCD panels that are not able to change color. This is a normal
occurrence for all LCD displays from all manufacturers and should
not be noticeable or objectionable under normal operation. AAEON
LCD panels are qualified for industry standard conditions in the
following: total 7 dead pixels on a screen or if there are 3 within 1
inch square area of each other on the display.

Smart Medical Terminal ONYX-219/217/215
Chapter 1 General Information 1-6
Mechanical Specifications
Architecture Close-frame
Front Bezel Plastic bezel with resistive touch screen
Color Blue-white (Sky series) and Green-white (Garden
series)
Mounting / Holder VESA 75/100mm, ONYX-215 supports VESA75 only
Construction 3mm ABS + PC TYPE Plastic housing
Dimension
(W x H x D)
ONYX-219/217: 460 x 385 x 97 mm (18.1”x97.8”x3.8”)
ONYX-215: 398 x 330 x 92.5 mm (15.7”x13”x3.6”)
Carton Dimension ONYX-219/217: 605x 230x 610mm (23.8”x 9.1”x 24”)
ONYX-215: 510x 213x465mm (20.1”x 8.4”x 18.3”)
Net Weight ONYX-219: 7.6 kg
ONYX-217: 6.16 kg
ONYX-215: 5.04 kg
Gross Weight ONYX-219: 10.6 kg
ONYX-217: 9.2 kg
ONYX-215: 6.5 kg
Packing Filler PE
Power Supply Specifications
Power Requirement DC 12V
 AC adapter (Input power rating)
90~264VAC, (115VAC @ 1.35A, 230VAC @ 0.7A),
47~63Hz
 DC output 12V @ 3.46A
MTBF 100,000 hrs operation at 25˚C

Smart Medical Terminal ONYX-219/217/215
Chapter1GeneralInformation1-7
Environmental Specifications
Operating Temperature 0˚C to 40˚C (32˚F ~104˚F)
Storage Temperature -20˚C to 60˚C (-4˚F ~140˚F)
Storage Humidity 5% to 95%@ 40˚C, non-condensing
Vibration 1G / 5 ~ 500Hz (Random) / operation
Shock 15G peak acceleration (11 msec. duration) /
operation
Drop 76cm (1 Corner, 3 Edge, 6 Surface)
EMI / Safety CE / FCC Class B/UL 60601-1/EN 60601-1
IP Front bezel meets IP-65 standard
Power Consumption 40W
TouchScreen (Optional)
Type 8-wire, Analog Resistive
Interface USB interface
Resolution 2048 x 2048
Light Transmission > 75%
Life Time 1 million activations

Smart Medical Terminal ONYX-219/217/215
Chapter 1 General Information 1-8
1.4 Dimension
303.55
385.0097.00
460.00
376.30
100.00
ONYX-219
177.50
75.00
112.50
UNIT : mm
