A&D MC Series User manual

MC-1000
MC-6100
1WMPD4002204

This Manual and Marks
All safety messages are identified by the following, “ WARNING ” or “ CAUTION ”, of
ANSI Z535.4 (American National Standard Institute: Product Safety Signs and
Labels). The meanings are as follows:
WARNING
A potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
A potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
This is a hazard alert mark.
This manual is subject to change without notice at any time to improve the
product.
The contents of the product specifications and this manual are subject to
change without any obligation on the part of the manufacturer.
Under the copyright laws, the software (program) described in it are copyrighted,
with all rights reserved.
The software may be installed into one computer and may not be installed into
other computers without the prior written consent of A&D Company. Copying
includes translation into another language, reproduction, conversion, photocopy
and offer or loan to another person.
Microsoft, Windows, Word and Excel are registered trademarks of the Microsoft
Corporation.
2010 All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, or
translated into any language in any form by any means without the written
permission of A&D Company Ltd.

1
CONTENTS
Basic Operation
1. INTRODUCTION .............................................................................................................................3
1-1 About This Manual.............................................................................................................................. 3
1-2 Features ............................................................................................................................................. 3
1-3 Compliance......................................................................................................................................... 3
2. UNPACKING THE BALANCE ........................................................................................................4
2-1 MC-1000............................................................................................................................................. 4
2-2 MC-6100............................................................................................................................................. 7
2-3 Installing the Balance ....................................................................................................................... 10
3. PRECAUTIONS ............................................................................................................................10
3-1 Before Use........................................................................................................................................ 10
3-2 During Use.........................................................................................................................................11
3-3 After Use........................................................................................................................................... 12
3-4 Power Supply ................................................................................................................................... 12
4. DISPLAY SYMBOLS AND KEY OPERATION..............................................................................13
5. WEIGHING ....................................................................................................................................14
5-1 Selecting the Weighing Units (Modes) ............................................................................................. 14
5-2 Basic Weighing................................................................................................................................. 14
Adapting to the Environment
6. RESPONSE ADJUSTMENT / SELF CHECK FUNCTION ............................................................16
6-1 Automatic Response Adjustment / Self Check Function .................................................................. 16
6-2 Manual Response Adjustment.......................................................................................................... 17
7. CALIBRATION ..............................................................................................................................18
7-1 Calibration Group ............................................................................................................................. 18
7-2 Automatic Self Calibration (Calibration due to changes in temperature) ................................................ 19
7-3 Calibration Using the Internal mass (One-touch calibration)............................................................ 19
7-4 Calibration Using an External Weight............................................................................................... 20
7-5 Calibration Test Using an External Weight ....................................................................................... 22
7-6 Correcting the Internal Mass Value .................................................................................................. 24
Functions
8. FUNCTION SWITCH AND INITIALIZATION.................................................................................26
8-1 Permit or Inhibit ................................................................................................................................ 26
8-2 Initializing the Balance...................................................................................................................... 27
9. FUNCTION TABLE .......................................................................................................................28
9-1 Structure and Sequence of the Function Table ................................................................................28
9-2 Display and Keys.............................................................................................................................. 28
9-3 Details of the Function Table ............................................................................................................ 29

2
9-4 Description of the Class “Environment, Display” .............................................................................. 33
9-5 Description of the Item “Data output mode”...................................................................................... 34
9-6 Description of the Item “Data format” ............................................................................................... 35
9-7 Description of the Data Format Added to the Weighing Data........................................................... 37
9-8 Data Format Examples ..................................................................................................................... 38
10. ID NUMBER AND GLP REPORT ...............................................................................................39
10-1 Setting the ID Number .................................................................................................................... 39
10-2 GLP Report..................................................................................................................................... 40
RS-232C Serial Interface
11. RS-232C SERIAL INTERFACE / EXTERNAL INPUT.................................................................43
12. CONNECTION TO PERIPHERAL EQUIPMENT ........................................................................45
12-1 Connection to the AD-8121B Printer .............................................................................................. 45
12-2 Connection to a Computer.............................................................................................................. 46
12-3 Using Windows Communication Tools (WinCT)............................................................................. 46
13. COMMANDS...............................................................................................................................48
13-1 Command List................................................................................................................................. 48
13-2 Acknowledge Code and Error Codes ............................................................................................. 49
13-3 Control Using CTS and RTS .......................................................................................................... 50
13-4 Settings Related to RS-232C ......................................................................................................... 50
14. EXTENDED FUNCTION .............................................................................................................51
14-1 Description of "Averaging range" and "Averaging time" ................................................................. 52
Maintenance
15. MAINTENANCE..........................................................................................................................54
16. TROUBLESHOOTING ................................................................................................................54
16-1 Checking the Balance Performance and Environment................................................................... 54
16-2 Error Codes .................................................................................................................................... 55
16-3 Asking For Repair ........................................................................................................................... 58
17. SPECIFICATIONS.......................................................................................................................59
18. OPTIONS ....................................................................................................................................60
19. EXTERNAL DIMENSIONS .........................................................................................................61
20. TERMS/INDEX............................................................................................................................62

3
1. INTRODUCTION
This manual describes how the MC Series Mass Comparator Balances, MC-1000 and MC-6100,
work, and how to get the most out of them in terms of performance.
Read this manual thoroughly before using the balance and keep it at hand for future reference.
For other functions and operations that this manual does not describe, refer to the GX series
instruction manual.
1-1 About This Manual
This manual consists of the following five parts:
Basic operation ...............................Describes precautions on handling the balance, balance
construction and basic balance operation.
Adapting to the environment...........Describes response adjustment, calibration and calibration
test.
Functions ........................................Describes various functions of the balance.
RS-232C serial interface.................Describes the interface which transmits data and controls the
balance.
Maintenance ...................................Describes maintenance, error codes, troubleshooting,
specifications and options.
1-2 Features
zDisplay resolution, one digit greater than a standard balance. This allows management of
OIML class F1 weights.
zCapable of weighing small amounts of powdery or liquid material, even with a massive tare.
zWhen used as a mass comparator, the balance can achieve even more precise weighing, by
using the optional auto-centering pan (sold separately), which reduces eccentric loading
errors.
1-3 Compliance
Compliance with FCC Rules
Please note that this device generates, uses and can radiate radio frequency energy. This
device has been tested and has been found to comply with the limits of a Class A computing
device pursuant to Subpart J of Part 15 of FCC rules. These rules are designed to provide
reasonable protection against interference when this device is operated in a commercial
environment. If this unit is operated in a residential area, it may cause some interference and
under these circumstances the user would be required to take, at his own expense, whatever
measures are necessary to eliminate the interference.
(FCC = Federal Communications Commission in the U.S.A.)

4
2. UNPACKING THE BALANCE
zThe balance is a precision instrument. Unpack the balance carefully. Keep the packing
material to be used for transporting the balance in the future.
zThe packing contents depend on the balance model. See the illustrations to confirm that
everything is contained..
2-1 MC-1000
Note
Please confirm that the AC adapter
type is correct for your local
voltage and receptacle type.
Displa
y
Bubble spirit level
Ke
y
s
Reference card
Dust
g
uard
Wei
g
hin
g
pan
Leveling foot
RS-232C serial interface
(External input terminal)
Groundin
g
terminal
AC adapter jack
AC adapter
AC adapter
ID label
Main unit cover
Windows Communication Tools
WinCT
Main unit
Main unit rear
Glass breeze break
Breeze break
securing screw
(2 pieces)

5
Glass breeze break installation procedure
Caution: During installation, do not apply excessive force to the balance.
•When installing the pan support
receptors at the front right and
rear left, note the following:
Push in the pan support receptors so
that the shock absorber springs are
above the receptor head surface. If
the pan support receptors are hard to
push in, hold the head of the receptor
as shown below and push it in while
rotating the head to the right and left.
•Keep the removed dust guard and
dust guard securing screws (2
pieces).
•To reinstall the dust guard after
removing the breeze break, use
the two screws to secure the dust
guard.
•The dust guard securing screws
and breeze break securing screws
are different in length.
1. Remove the weighing pan, pan support
receptors, and dust guard from your balance.
To remove the dust guard, remove the two
screws that secure it to the balance.
2. Place the breeze break on the main unit
3. Secure the breeze break to the main unit using
two screws provided with the breeze break.
Replace the pan support receptors and
weighing pan.
Dust
g
uard
Wei
g
hin
g
pan
Pan support receptor
(
4
p
ieces
)
Dust guard securing
screw
(
2
p
ieces
)
Breeze break
Main uni
t
Shock absorber
Breeze break
securing screw
(2 pieces)
Front righ
t
Rear lef
t
Wei
g
hin
g
pan
Pan support receptor
(
4
p
ieces
)

6
Auto-centering pan (AX-MC1000PAN) installation procedure
Caution: During installation, do not apply excessive force to the balance.
zWhen used as a mass comparator, the balance can achieve even more precise weighing,
by using the auto-centering pan (sold separately), which reduces eccentric loading errors.
1. At step 2 of the glass breeze break installation procedure, secure the breeze break provided with
the AX-MC1000PAN option using the breeze break securing screws provided with the option. At
this time make sure that the side of the breeze break with the screws is placed at the back.
Attach the pan support receptors to the shock absorbers.
2. Place the auto-centering pan guide on the pan support receptors, and then place the
auto-centering pan on the guide.
Note
When replacing the weighing pan
with the auto-centering pan, be sure
to calibrate the balance before
weighing.
Refer to “7. CALIBRATION”.
Breeze break
securing screw
(2 pieces)
Option
AX-MC1000PAN
breeze break
Auto-centering pan guide
Auto-centering pan
Pan support
receptors
(4 pieces)
Side with screws

7
2-2 MC-6100
..
Note
Please confirm that the AC adapter
type is correct for your local
voltage and receptacle type
Displa
y
Bubble spirit level
Ke
y
s
Reference card
Dust
g
uard
Wei
g
hin
g
pan
Leveling foot
RS-232C serial interface
(External input terminal)
Groundin
g
terminal
AC adapter jack
AC adapter
AC adapter
ID label
Main unit cover
Windows Communication Tools
WinCT
Main unit
Main unit rear
Breeze rin
g
Glass breeze break
Breeze break
securing screw
(2 pieces)

8
Glass breeze break installation procedure
Caution: During installation, do not apply excessive force to the balance.
•When installing the pan support
receptors at the front right and
rear left, note the following:
Push in the pan support receptors so
that the shock absorber springs are
above the receptor head surface. If
the pan support receptors are hard to
push in, hold the head of the receptor
as shown below and push it in while
rotating the head to the right and left.
•Keep the removed dust guard,
dust guard securing screws (2
pieces) and breeze ring.
•To reinstall the dust guard after
removing the breeze break, use
the two screws to secure the dust
guard.
•The dust guard securing screws
and breeze break securing screws
are different in length.
1. Remove the weighing pan, breeze ring, pan support
receptors, and dust guard from your balance.
To remove the dust guard, remove the two screws that
secure it to the balance.
2. Place the breeze break on the main unit
3. Secure the breeze break to the main unit using two
screws provided with the breeze break.
Replace the pan support receptors and weighing pan.
Dust
g
uard
Wei
g
hin
g
pan
Pan support receptor
(
4
p
ieces
)
Dust guard securing
screw
(
2
p
ieces
)
Breeze break
Main uni
t
Shock absorber
Breeze break
securing screw
(2 pieces)
Front righ
t
Rear lef
t
Wei
g
hin
g
pan
Pan support receptor
(
4
p
ieces
)
Breeze rin
g

9
Auto-centering pan (AX-MC6100PAN ) installation procedure
Caution: During installation, do not apply excessive force to the balance.
zWhen used as a mass comparator, the balance can achieve even more precise weighing,
by using the auto-centering pan (sold separately), which reduces eccentric loading errors.
1. At step 2 of the glass breeze break installation procedure, secure the breeze break provided with
the AX-MC6100PAN option using the breeze break securing screws provided with the option. At
this time make sure that the side of the breeze break with the screws is placed at the back.
Attach the pan support receptors to the shock absorbers.
2. Place the auto-centering pan guide on the pan support receptors, and then place the
auto-centering pan on the guide.
Note
When replacing the weighing pan with
the auto-centering pan, be sure to
calibrate the balance before weighing.
Refer to “7. CALIBRATION”.
Breeze break
securing screw
(2 pieces)
Auto-centering pan
Option
AX-MC6100PAN
breeze break
Pan support
receptors
(4 pieces)
Auto-centering pan guide
When placing on the pan
support receptors, tilt the
auto-centering pan guide
to the left and right,
forward and backward.
Side with screws

10
2-3 Installing the Balance
Install the balance as follows:
1. Refer to “3-1 Before Use” for installing the balance. Place the balance on a solid weighing
table.
2. Assemble the balance as shown in “2. UNPACKING THE BALANCE”.
3. Adjust the leveling feet to level the balance. Confirm it using the bubble spirit level.
4. Confirm that the adapter type is correct for the local voltage and power receptacle type.
5. Connect the AC adapter to the balance. Warm up the balance for at least 30 minutes with
nothing on the weighing pan.
3. PRECAUTIONS
To get the optimum performance from the balance and acquire accurate weighing data, note the
following:
3-1 Before Use
zThe MC series is a high-precision balance with a resolution of
1/10000000. It is prone to changes in temperature and
pressure, static electricity, drafts and vibration of the installation
site. During calibration using an internal mass, it resolves up to
one digit lower than the minimum weighing value. Therefore, be
sure to place the balance in a stable environment.
zThe best operating temperature is about 20°C±2°C at 45-60%
relative humidity.
zInstall the balance where it is not exposed to direct sunlight and
it is not affected by heaters or air conditioners.
zInstall the balance where it is free of dust.
zInstall the balance away from equipment which produces
magnetic fields.
zInstall the balance in a stable place avoiding vibration and
shock. Corners of rooms on the first floor are best, as they are
less prone to vibration.
zThe weighing table should be solid and free from vibration,
drafts and as level as possible.
zLevel the balance by adjusting the leveling feet and confirm it
using the bubble spirit level.
zIf static electricity is a problem at the installation site, use the
electrostatic field meter and the static eliminator.
zEnsure a stable power source when using the AC adapter.

11
zWarm up the balance for at least 30 minutes. Plug in the AC
adapter as usual.
zCalibrate the balance periodically for accurate weighing.
zBefore using the balance for the first time or after having moved
it to another location, warm up the balance for six hours or
more to allow the balance to reach equilibrium with the room
temperature, and then calibrate the balance.
Caution
Do not install the balance where flammable or corrosive gas is present.
3-2 During Use
zStatic charge may cause weighing errors. When the
ambient humidity is less than 45% RH, insulators such as
plastic or glass are prone to static electricity. Discharge
static electricity from the material to be weighed
(hereinafter referred to as sample). Ground the balance
and try the following:
Eliminate the static electricity by using an optional
static eliminator, AD-1683,
Or try to keep the ambient humidity above 45%RH.
Or use a metal shield case.
Or wipe a charged plastic sample with the wet cloth.
zThis balance uses a strong magnet as part of the
balance assembly, so please use caution when
weighing magnetic materials such as iron. If there is a
problem, use the underhook on the bottom of the
balance to suspend the material away from the
influence of the magnet.
zCancel the temperature difference between a sample, tare and the environment. When a
sample is warmer (cooler) than the ambient temperature, the sample will be lighter (heavier)
than the true weight. This error is due to a rising (falling) draft around the sample.
zMake each weighing gently and quickly to avoid errors due to changes in the environmental
conditions.
zDo not drop things upon the weighing pan, or place a sample on the pan that is beyond the
balance weighing capacity. Place a sample in the center of the weighing pan.
zDo not use a sharp instrument such as a pencil to press the keys. Use your finger only.
zPress the RE-ZERO key before each weighing to prevent possible errors.
zTake into consideration the affect of air buoyancy on a sample when more accuracy is
required.
zKeep the balance interior free of dust and foreign materials.

12
3-3 After Use
zAvoid mechanical shock to the balance.
zDo not disassemble the balance. Contact the local A&D dealer if the balance needs service or
repair.
zDo not use organic solvents to clean the balance. Clean the balance with a lint free cloth that
is moistened with warm water and a mild detergent.
zProtect the internal parts of the balance from liquid spills and excessive dust.
3-4 Power Supply
zDo not remove the AC adapter while the internal mass is in motion, for example, right after the
AC adapter is connected, or during calibration using the internal mass.
If the AC adapter is removed under the conditions described above, the internal mass will be
left unsecured, that may cause mechanical damage when the balance is moved.
Before removing the AC adapter, press the ON:OFF key and confirm that zero is displayed.
zWhen the AC adapter is connected, the balance is in the standby mode if the standby indicator
is on (refer to “4. DISPLAY SYMBOLS AND KEY OPERATION”). This is a normal state and
does not harm the balance. For accurate weighing, warm up the balance for at least 30
minutes before use.

13
4. DISPLAY SYMBOLS AND KEY OPERATION
Display symbols
Key operation
Key operation affects how the balance functions. The basic key operations are:
z“Press and release the key immediately” or “Press the key” z“Press and hold the key”
= normal key operation during measurement
Key When pressed When pressed and held
Turns the display on and off. The standby indicator is displayed when the display is turned
off. The weighing mode is enabled when the display is turned on.
This key is available anytime. Pressing the key during operation will interrupt the operation
and turn the display off.
In the weighing mode, turns the
minimum weighing value on and off.
In the counting or percent mode, enters
the sample storing mode.
Enters the function table mode. Refer to “9.
FUNCTION TABLE”.
No function at the factory setting
Switches the weighing units when units other
than “g” are stored in the function setting.
Performs response adjustment and self check.
Performs calibration of the balance using
the internal mass.
Displays calibration-related menu.
Stores the weighing data in memory or
outputs to a printer or personal computer
using the RS-232C interface (Factory
setting), depending on the function settings.
No function at the factory setting
By changing the function setting:
Outputs “Title block” and “End block” for GLP report.
Displays the data memory menu.
Sets the display to zero.
Weight data or
stored data
Units
Interval memory
standb
y
indicato
r
Comparator indicators
A
nimal mode indicato
r
Response indicators (Weighing speed)
Displays the highest-order digit when placing a load of 1
kg or more on the MC-1000.
Displays data stored in memory.
Displays the weight data relative to the weighing capacity,
in percentage, in the weighing mode (Capacity indicator).
Processing indicator
Stabilization indicator
Standby indicator
Data number of the data
currently displayed
Processing indicator
Prior notice indicator
of automatic self
calibration
Interval memory
active indicato
r
点滅中
Blinking indicators

14
5. WEIGHING
5-1 Selecting the Weighing Units (Modes)
The unit “g” (gram) was set at the factory.
To use other units, select and store units and displaying order in the function setting of “ Unit ”.
For details on weighing unit selection procedure, refer to the GX series instruction manual, “5.
WEIGHING UNITS”.
5-2 Basic Weighing
When using as a mass comparator
zTo reduce the influence of drafts and vibration, set the following function settings as below.
“Condition ( Cond )” of “Environment, Display ( ba5fnc )” to “Slow ( 2)”
“Filter ( f1l )” of ““Environment, Display ( ba5fnc )” to “Used (1)”
For details, refer to “9. FUNCTION TABLE”.
zTo avoid eccentric loading errors, place the sample in the center of the weighing pan.
As an option, auto-centering pans are available: AX-MC1000PAN for the MC-1000 and
AX-MC6100PAN for the MC-6100.
Using an AD-8922A remote controller, which is sold separately, the balance can be controlled
remotely by the AD-8922A key operations in the same way as when the CAL or
RE-ZERO key of the balance is pressed. For the connection procedure between the balance
and the AD-8922A, refer to the AD-8922A instruction manual.
zTake measures against causes of weighing error at the installation site, such as changes in
temperature, atmospheric pressure, drafts, vibration and static electricity. Perform weighing
operations in a stable environment.
zThe table below lists the weight class and recommended measuring range for each model of
the MC series. The measuring range is determined so that the balance repeatability is to be
less than one third of the maximum permissible error for each weight class.
Weight class and recommended measuring range
Weight
(Displayed value)
Model
Class
5 kg
2 kg
1 kg
500 g
200 g
100 g
50 g
20 g
10 g
5 g
2 g
1 g
500 mg
200 mg
100 mg
F1 F2 M1 M2 F1 F2 M1 M2
MC-1000 MC-6100
F1 F2 M1 M2

15
When building into a system
zWhen a special weighing pan is to be designed, the weight of the pan and the material to be
weighed should not exceed the weighing capacity of the balance.
To reduce influences of static electricity and magnetism, use materials other than resin and
magnetic material such as iron.
zThere is a function available to maintain the previous weight value in non-volatile memory,
even if the AC adapter is removed.
When “Zero upon power-on ( p-tr )” of “Environment, Display ( ba5fnc )” is set to “ 1”, the
previous weight value is displayed upon power-on.
For details, refer to “Zero upon power-on” on page 33.
zThere is a function available to perform span calibration only, when performing calibration with
a tare on the weighing pan.
When “Span calibration ( 5pn )” of “Environment, Display ( ba5fnc )” is set to “ 1”, span
calibration using the internal mass is performed, with a tare on the weighing pan.
For details, refer to “Span calibration” on page 33.
zTo set a higher response rate or to batch-weigh small amounts of material, such as a powdery
material, refer to “14. EXTENDED FUNCTION”.

16
6. RESPONSE ADJUSTMENT / SELF CHECK FUNCTION
This function detects the influence on weighing that is caused by drafts and/or vibration at the place
where the balance is installed and sets the response characteristic automatically. When this function
is selected, the balance self-checks the performance at the same time.
Two modes of response adjustment are available: automatic and manual.
The function has three rates as follows:
Changing the response rate changes the display refresh rate.
Indicator Parameter Response characteristic Display refresh rate
FAST Cond 0
MID. Cond 1
SLOW Cond 2
Fast response, Sensitive value
Slow response, Stable value
If the response rate is changed as follows:
MID. or SLOW FAST =10 times/second
FAST MID. or SLOW = 5 times/second
Note
To set the refresh rate of 5 times/second when the response rate is FAST or 10 times/second
when the response rate is MID. or SLOW, change the “Display refresh rate ( 5pd )” parameter
of “Environment, Display ( ba5fnc )” in the function table. For details, refer to “9. FUNCTION
TABLE”.
6-1 Automatic Response Adjustment / Self Check Function
This function automatically updates the response adjustment by analyzing the influence of the
environment on the weighing data and also self-checks the balance performance using the internal
mass.
Operation
1 Press and hold the MODE key until RESPONSE is
displayed, then release the key.
2 The balance automatically starts to check the balance
performance and sets the response characteristic.
Caution
Do not allow vibration or drafts to affect the balance
during adjustment.
3 After automatic adjustment, the balance displays the
updated response indicator and returns to the
weighing mode. The response indicator remains
displayed for about 30 seconds.
e.g. “ MID. OK ”
The example above indicates that the result of the self check is good and MID. is selected as
the response rate.
Response indicators
Press and hold
the key
Release the key
Displays the results.

17
Notes
If improper performance is found in the self check, the
balance displays CH no . Contact the local A&D
dealer for repair.
If the automatic response adjustment fails, the
balance displays CH ng . Check the ambient
conditions such as breeze and vibration, also check
the weighing pan. Then, perform the adjustment again.
To return to the weighing mode, press the CAL key.
If the automatic response adjustment is awkward, try
to refine it using the manual response adjustment.
6-2 Manual Response Adjustment
This function manually updates the response adjustment.
Operation
1 Press and hold the MODE key until RESPONSE is
displayed, then release the key.
Press the MODE key again quickly.
2 Press the MODE key to select a rate of the response
adjustment. Either FAST, MID. or SLOW can be
selected.
3 After a few seconds of inactivity the balance displays
eend . Then, it returns to the weighing mode and
displays the updated response indicator. The
response indicator remains displayed for about 30
seconds.
Note
The response adjustment can be changed at “Condition
(Cond)” of “Environment, Display ( ba5fnc )” in the
function table. For details, refer to “9. FUNCTION
TABLE”.
Press and hold
the key
Each pressing
switches
the indicators
Release the key
and press again
After a while

18
7. CALIBRATION
7-1 Calibration Group
Calibration zAutomatic self calibration (calibration due to changes in temperature)
zCalibration using the internal mass (one-touch calibration)
zCalibration using an external weight
Calibration test zCalibration test using an external weight (Calibration test does not perform
calibration.)
Correction of the internal mass value
Terms
The following terms are defined as follows:
Internal mass = Built-in calibration weight
External weight = A weight that you have. Referred to as a calibration weight when used for calibration.
Calibration weight = A weight used for calibration
Target weight = An external weight used for calibration test
Caution
zCalibration adjusts the balance for accurate weighing.
Besides periodic calibration and before each use, perform calibration when:
• the balance is installed for the first time.
• the balance has been moved.
• the ambient environment has changed.
zDo not allow vibration or drafts to affect the balance during calibration.
zTo output the data for GLP using the RS-232C interface, set “GLP output ( info )” of “Data
output ( dout )”. For details, refer to “9. FUNCTION TABLE”. Time and date are added to the
GLP report. If the time or date is not correct, adjust them. For details, refer to the GX series
instruction manual, “10-9 Clock and Calendar Function”.
zCalibration test is available only when “GLP output ( info )” of “Data output ( dout )” is set to
“1” or “ 2”.
zThe calibration and calibration test data can be stored in memory. To store them, set “Data
memory ( data )” to “ 3”. For details, refer to the GX series instruction manual, “12. DATA
MEMORY”.
Caution on using an external weight
zThe accuracy of an external weight can influence the accuracy of weighing. Select an
appropriate weight as listed below:
Model Usable calibration weight Adjustable range
MC-1000 1000g, 900g, 800 g, 700 g, 600 g, 500 g,400 g,
300 g, 200 g -0.0150 g to +0.0159 g
MC-6100 6000 g, 5000 g, 4000 g, 3000 g, 2000 g -0.150 g to +0.159 g
The calibration weight in bold type: factory setting
The calibration weight value can be adjusted within the range above.
Display
zThis indicator means “the balance is measuring calibration data”. Do
not allow vibration or drafts to affect the balance while this indicator is
displayed.
