A&D GX-AE Series User manual

Quick Start Guide
GX-AE/GX-A/GF-A Series
Multi-Function Balance
Guide de démarrage rapide
Séries GX-AE/GX-A/GF-A
Balance multifunction
Schnellstartanleitung
Serie GX-AE/GX-A/GF-A
Multifunktions-Waage
Guía de inicio rápido
Series GX-AE/GX-A/GF-A
Báscula multifunción
Guida introduttiva
Serie GX-AE/GX-A/GF-A
Bilancia multifunzione
快速入門指南
GX-AE / GX-A / GF-A 系列
多功能天平
1WMPD4004249
English (EN)
Français (FR)
Deutsch (DE)
Español (ES)
Italiano (IT)
中文 (CT)

© 2020 A&D Company, Limited. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, or translated into
any language in any form by any means without the written permission of A&D Company,
Limited.
The contents of this publication and the specifications of the instrument covered by this
publication are subject to change for improvement without notice.

3
Quick Start Guide – GX-AE/GX-A/GF-A Series
Multi-Function Balance ……………………………………………...4
Guide de démarrage rapide – Séries GX-AE/GX-A/GF-A
Balance multifonction ………………………………………………15
Schnellstartanleitung – Serie GX-AE/GX-A/GF-A
Multifunktions-Waage ………………………………………………26
Guía de inicio rápido – Series GX-AE/GX-A/GF-A
Báscula multifunción ……………………………….……………….37
Guida introduttiva – Serie GX-AE/GX-A/GF-A
Bilancia multifunzione ……………………………………….……..48
快速入門指南– GX-AE / GX-A / GF-A 系列
多功能天平 ………………………………………………………..…59
EN
FR
DE
ES
IT
CT

EN
4
1.Introduction
This manual describes the basic functions and operations of the balance.
For more details, refer to each manual listed in "1-1. List of Functions Explained in Separate Manuals".
1-1 List of Functions Explained in Separate Manuals
The functions and operating procedures of the balance are explained in detail in other documents
besides this manual.
The following three manuals can be downloaded from our website https://www.aandd.jp.
1. [Communication Manual]
Using the communication function of the balance, a personal computer (PC) or printer
This is a supplementary manual for connecting to peripheral devices.
2. [GX-AE Series/GX-A Series/GF-A Series Instruction Manual]
This is an instruction manual for understanding and fully utilizing the precision electronic balance
GX-AE/GX-A/GF-A series.
3. [Flow Rate Display (FRD) Function]
This is a supplementary manual for using the flow rate measurement function
(FRD: Flow rate display).
2. Installation And Precautions
The balance is a precision instrument. Unpack it carefully. Keep the packing material to be used for
transporting the balance in the future. The packing contents depend on the balance model. See the
illustrations to confirm that everything is contained.

EN
5
Note
□ Please confirm that the AC adapter type is correct for your local voltage and receptacle type.
□ Please use the specified dedicated AC adapter for the balance.
□ Do not use the included AC adapter for models that are not considered compatible with the AC
adapters.
□ If you use the wrong AC adapter, the balance and other equipment may not operate properly.
GX-AE/GX-A/GF-A 0.0001g models
GX-A/GF-A 0.001g models
GX-A/GF-A
GX-AE
GX-AE
GX-AE
GX-A/GF-A 0.01g/0.1g models

EN
6
2-1 Precautions
To get the optimum performance from the balance and acquire accurate weighing data, note the
following:
□ Install the balance in an environment where the temperature and humidity are not excessive.
The best operating temperature is about 20°C±2°C at about 45 ~ 60%RH relative humidity.
□ Install the balance where it is free of dust.
□ The weighing table should be solid, free from vibration and drafts, and as level as possible.
(An anti-vibration table or stone table is ideal)
□ Install the balance in a stable place avoiding vibration and shock. Corners of rooms on the first floor
are best, as they are less prone to vibration.
□ Install the balance where it is not affected by heaters or air
conditioners.
□ Install the balance where it is not exposed to direct sunlight.
□ Install the balance away from equipment which produces magnetic fields.
□ Level the balance by adjusting the leveling feet and confirm it using
the bubble spirit level.
□ Warm up the balance for at least 30 minutes. Plug in the AC adapter
as usual.
□ Calibrate the balance before use or after moving it to another
location. Refer to the separate instruction manual "7. Calibration".
Caution
Do not install the balance where flammable or corrosive gas is present.
How to adjust the bubble spirit level
Leveling
foot Bubble spirit level
OK Not OK
When the bubble is off to the left:
Turn the leveling foot on the front right in the clockwise
direction.
When the bubble is off to the right:
Turn the leveling foot on the front left in the clockwise
direction.
When the bubble is off to the backward position:
Turn both leveling feet on the front in the clockwise
direction at the same time.
When the bubble is off to the forward position:
Turn both leveling feet on the front in the counter
clockwise direction at the same time.
Red circle
Bubble
UP DOWN
Leveling
foot
UPDOWN
OK Not OK
Leveling
foot

EN
7
3. Display Symbols And Key Operation
Display symbols
Blinking display contents
Processing indicator
Interval output mode
active indicator
Data number being displayed
Auto calibration notice
Blinking
Key operation
Key operations affect how the balance functions. Normal key operation during measurement is “Press
and release the key immediately” or “Press the key”. Please do not “Press and hold the key (for 2
seconds)” unless is required.
Press the key Press and hold the key
(Press and release the key immediately.) for 2 seconds.
Stabilization indicator
Processing indicator
Response indicators
Standby indicator
Comparator indicators
Interval output mode
standby indicator
Number of statistical data
(Statistical calculation mode)
Displays the weight data relative to the
weighing capacity, in percentage, in the
weighing mode (Capacity indicator)
NET G PT
Preset tare mark
Gross mark
Net mark
USB connecting mark
Unit display
gross zero mark
Shock indicators
Animal weighing mark
Display the measured value,
stored data, setting item name
(ISD)

EN
8
Key When pressed and released When pressed and held
(for 2 seconds)
Turns the display ON:OFF . The standby indicator is displayed when the display is
turned off. The weighing mode is enabled when the display is turned on.
When password function is enable, password input display will be displayed. Refer
to the separate instruction manual "19-4 How to Input The Password At The Start Of
Weighing"
This ON:OFF key is available anytime. Pressing the ON:OFF key during
operation will interrupt operation and turn the display OFF. *
In the weighing mode, turns the digit for
readability on and off.
In the counting or percent mode, enters the
sample storing mode.
- Enters the function table mode.
Please refer to the separate
instruction manual "9. Function
Table".
- Runs the repeatability check
function when pressed and held for
another 2 seconds after the function
table menu is displayed.
Please refer to the separate
instruction manual "20.
Repeatability Check Function".
(GX-AE / GX-A series only)
Switches the weighing units stored in the
function table. Refer to “4. Weighing”.
Displaying of the unit mg is available for
0.0001g models only.
Displays other items of the calibration
menu. Please refer to the separate
instruction manual "6-2 Self Check
Function/Automatic Setting Of
Minimum Weighing Value by ECL".
Performs calibration of the balance using
the internal mass. (GX-AE / GX-A series)
Displays other items of the calibration
menu.
Stores the weighing data in memory or
outputs to a printer or personal computer
depending on the function table settings.
(Factory setting = output)
Enters mode to change the unit mass
registration number in counting mode.
By changing the function table:
- Outputs "Title block" and "End
block" for GLP, GMP report.
- Displays the data memory menu.
- Enters mode for reading density
number in flow measurement.
Sets the display to zero.
* When the "Gross net tare function" is selected, the display is turned off by pressing and holding
(for 2 seconds). Please refer to the separate instruction manual "14. Gross Net Tare Function".

EN
9
4. Calibration
Since the balance's resolution is high, weighing values may change due to gravity and daily
environmental changes.
4-1 Automatic Calibration (GX-AE/GX-A Series Only)
The GX-AE/GX-A series automatically adjusts the balance sensitivity using the built-in weight
according to the temperature change of the operating environment or the set time and interval time. For
details, refer to "7-1 Auto calibration" in the separate instruction manual.
4-2 One-Touch Calibration (GX-AE/GX-A Series Only)
This function calibrates the balance using the internal mass.
1. Connect the AC adapter and warm up the balance for at least 30 minutes with nothing on the
weighing pan.
2. Press the CAL key. The balance displays .
3. The balance performs calibration using the internal mass. Do not allow vibration or drafts to affect the
balance.
4. After the calibration, If the "GLP output ( )" parameter of the function table is set, the balance outputs a
sensitivity adjustment execution record.
5. The balance will automatically return to weighing mode after calibration.
4-3 Calibration Using An External Weight
This function calibrates the balance using an external weight.
1. Connect the AC adapter and warm up the balance for at least 30 minutes with nothing on the
weighing pan.
2. Press and hold the CAL key for 2 seconds until is displayed, then release the key.
3. Make sure that nothing is on the weighing pan and press the PRINT key to weigh the zero point.
Do not apply vibration, etc.
4. Place the external weight on the weighing pan and press the PRINT key. Do not apply vibration
etc.
5. Remove the external weight from the weighing pan.
6. After calibration, if GLP output is set, "sensitivity adjustment execution record" is output or stored in
data memory.
7. The display automatically returns to weighing display.
8. Place the external weight again and check that the set value is ± 2 digits.
If it is out of range, pay attention to the surrounding environment and start from "1".

EN
10
4-4 Error Codes
Display Error code Description
EC, E11 Stability error
The balance cannot stabilize due to an environmental problem.
Check around the pan. Prevent vibration, drafts, temperature
changes, static electricity and magnetic fields, from influencing
the balance. Refer to "7-1 During Use".
To return to the weighing mode, press the CAL key.
Out of the setting range
The data to be stored is out of the setting range.
Malfunction of the internal memory element of the
balance
If this error continues to be displayed, repair is necessary.
Please contact your dealer.
EC, E16 Internal mass error
Applying the internal mass does not yield a change in the mass
value as specified.
Confirm that there is nothing on the pan and perform the
weighing operation from the beginning again.
EC, E17
Internal mass error
The internal mass application mechanism does not function
properly. Perform the weighing operation from the beginning
again.
Abnormality in the internal memory data of the balance
If this error continues to be displayed, repair is necessary.
Please contact your dealer.
Abnormality in the internal memory data of the balance
If this error continues to be displayed, repair is necessary.
Please contact your dealer.
EC, E20 Calibration weight error (Positive value)
The calibration weight is too heavy. Confirm the calibration mass
value. Press the CAL key to return to the weighing mode.
EC, E21 Calibration weight error (Negative value)
The calibration weight is too light. Confirm the calibration mass
value. Press the CAL key to return to the weighing mode.
Overload error
A sample beyond the balance weighing capacity has been
placed on the pan. Remove the sample from the pan.
Weighing pan error
The mass value is too light.
Confirm that the weighing pan is properly installed and calibrate
the balance.
