AAT KaDe KDA-LOCK180Z-II User manual

Electromagnetic locks and mounting brackets – Installation manual
AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved. 1
Installaon manual
ELECTROMAGNETIC LOCKS
AND MOUNTING BRACKETS
VERSION 3.0 07-07-2020

Electromagnetic locks and mounting brackets – Installation manual
2 AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved.
DIRECTIVES …………………………………………………………………………………………. 3
SAFEGUARDS AND WARNINGS …………………………………………………………... 4
1. INTRODUCTION ……………………………………….……………………………….……… 5
2. COMMERTIAL SIGN EXPLANATION ……...………………………………….….…. 5
3. ELECTROMAGNETIC LOCKS’ TECHNICAL PARAMETERS ………………...….….. 5
4. ELECTROMAGNETIC LOCKS’ ELECTRICAL CONNECTIONS ………..……….. 6
4.1. KDA-LOCK180Z-II ……………..………………………………………………………… 6
4.2. KDA-LOCK280DZC-II/350DZC/500DZC-II ………….…….………………. 6
5. KADE LOCKS AND COMPATIBLE BRACKETS LIST ……………….……………….. 6
6. ELECTROMAGNETIC LOCKS MOUNTING WAYS …………….………………….. 7
CONTENTS

Electromagnetic locks and mounting brackets – Installation manual
AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved. 3
THE PRODUCT MEETS THE REQUIREMENTS CONTAINED IN THE
FOLLOWING DIRECTIVES:
Direcve 2014/30/EU of the European Parliament and of the Council of 26 February
2014 on the harmonisaon of the laws of the Member States relang to electromag-
nec compability (recast) Text with EEA relevance.
Direcve 2012/19/EU of the European Parliament and of the Council of 4 July 2012
on waste electrical and electronic equipment (WEEE) Text with EEA relevance
Direcve 2011/65/EU of the European Parliament and of the Council of 8 June
2011 on the restricon of the use of certain hazardous substances in electrical and
electronic equipment Text with EEA relevance
Informaon
The device, as a part of professional intercom system used for surveillance and control, is not
designed for self-installaon in households by individuals without technical knowledge
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN PRODUCT IN US-
ER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR IF IT DOES NOT
ARISE FROM THE USUAL APPLICATION OF THE PRODUCT, MANUFACTURER MUST BE CONTACT-
ED UNDER THE RIGOR OF EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR THE RESULTS
OF SUCH AN ACTION.
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER DEVICE OP-
ERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH THE MANUAL PRIOR TO
INSTALLATION AND FURTHER DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO USER -SERVICEABLE
PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE PERSONNEL MAY OPEN THE UNIT INSTAL-
LATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE PERSONNEL AND
SHOULD CONFORM TO ALL LOCAL REGULATIONS

Electromagnetic locks and mounting brackets – Installation manual
4 AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved.
IMPORTANT SAFEGUARDS AND WARNINGS:
1. Prior to undertaking any acon please consult the following manual and read all the safety
and operang instrucons before starng the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this
manual is necessary;
3. All the safety precauons referred to in this manual should be strictly followed, as they have
a direct inuence on user’s safety and durability and reliability of the device;
4. All acons conducted by the servicemen and users must be accomplished in accordance with
the user’s manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of addional devices and components neither provided nor recommended by the pro-
ducer is forbidden;
7. Mounng the device on unstable surface or using not recommended mounts is forbidden.
8. Improperly mounted device may cause a fatal accident or may be seriously damaged itself.
Device must be mounted by qualied personnel with proper authorizaon, in accordance
with this user’s manual;
9. Device should be supplied only from a power sources whose parameters are in accordance
with those specied by the producer in the device’s technical datasheet. Therefore, it is for-
bidden to supply the device from a power sources with unknown parameters, unstable or not
meeng producer’s requirements;
10.Signal and power cables should be placed in a way excluding the possibility of damaging
them by accident. Special aenon must be paid to cables geng from the device and con-
necng the power supply;
11.Electric installaon supplying the device should be designed to meet the specicaons given
by the producer in such a way that overloading is impossible;
12.User cannot repair or upgrade the equipment himself. All maintenance acons and repairs
should be conducted only by qualied service personnel;
13. Unplug the device from the power source immediately and contact the proper maintenance
department when the following occurs:
• Damages to the power cord or to the plug itself;
• Liquids geng inside the device or exposure to strong mechanical shock;
• Device behaves in a way not described in the manual and all adjustments approved
by the
• manufacturer and possible to apply by user himself, seem not to have any eect;
• Device is damaged;
• Atypical behaviour of the device components may be seen (heard).
14.In necessity of repairs aenon to using only original replacement parts (with their parame-
ters in accordance with those specied by the producer) should be paid. Non-licensed service
and non-genuine replacement parts may cause re or electrocuon;
15. Aer maintenance acvies tests should be run to ensure proper operaon of all the func-
onal components of the device.

Electromagnetic locks and mounting brackets – Installation manual
AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved. 5
2. COMMERCIAL SIGN EXPLANATION
Commercial signs of KaDe locks contain informaon about technical parameters and addional properes.
Signs are explained below.
Properes
• D - door state sensor (magnet sensor)
• Z - lock state sensor (hallotron sensor)
• C - with me delay
KDA - LOCK XXX YYY
Holding force [kg]
• 180
• 280
• 350
• 500
1. INTRODUCTION
Electromagnec locks are one of the device types allowing door locking in physical access control sys-
tem. KaDe trademark oers wide range of locks with dierent parameters. Some models oer addional func-
onalies (e.g. built-in door state sensor). It allows to choose an equipment suitable for the customer.
3. ELECTROMAGNETIC LOCKS’ TECHNICAL PARAMETERS
Model
Current consumpon
[mA]
12 VDC power supply
Current consumpon
[mA]
24 VDC power supply
Dimensions
[mm]
L x H x W
KDA-LOCK180Z-II 280 240 170 x 39 x 24
KDA-LOCK280DZC-II 480 240 250 x 47 x 29
KDA-LOCK350DZC 480 240 288 x 55 x 29
KDA-LOCK500DZC-II 660 330 265 x 71 x 38

Electromagnetic locks and mounting brackets – Installation manual
6 AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved.
4. ELECTROMAGNETIC LOCKS’ ELECTRICAL CONNECTIONS
Electrical connecon schemes of KaDe electromagnec locks are shown in the pictures below.
5. KADE LOCKS AND COMPATIBLE BRACKETS LIST
The table below shows available electromagnec locks and compable mounng brackets in the oer.
Electromagnec lock „BZLC” type bracket „L” type bracket „ZL” type bracket
KDA-LOCK180Z-II - KDA-BL180-II KDA-BZL180-II
KDA-LOCK280DZC-II KDA-BZLC280-II KDA-BL280-II KDA-BZL280-II
KDA-LOCK350DZC - KDA-BL350 KDA-BZL350
KDA-LOCK500DZC-II - KDA-BL500-II KDA-BZL-500-II
4.2. KDA-LOCK280DZC-II/350DZC/500DZC-II Lock state sensor (Hallotron sensor)
Use NO & COM for normally open
circuit, and NC & COM for normally
closed circuit.
Power supply
12 VDC or
24 VDC
Power supply voltage
socket—connecon
from magnet coil
Connecon module
Door state sensor’s localizaon in lock
Magnet localizaon
Metal plate
Delay seng
0 s 9 s
280DZC-II, 350DZC,
500DZC-II only
Hallotron sensor socket
4.1. KDA-LOCK180Z-II
Red
Black
White
White
+12 VDC
GND
Lock state
sensor
(Hallotron sensor)

Electromagnetic locks and mounting brackets – Installation manual
AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
All rights reserved. 7
6. ELECTROMAGNETIC LOCKS MOUNTING OPTIONS
Depending on door construcon, doorframe width and door wing material there are dierent electro-
magnec locks’ mounng ways. In KaDe oer there are dierent types of brackets (L, ZL, ZLC), which allow to
install the lock on various doors.
STANDARD LOCKS MOUNTING
OUTSIDE
OUTSIDE
INSIDE
LOCK
DOORFRAME
DOORFRAME
DOORFRAME
LOCK
LOCK
METAL PLATE
METAL PLATE
METAL PLATE
DOOR WING
DOOR WING
DOOR WING
“L” BRACKET
“L” BRACKET
“Z” BRACKET
INSIDE
DOORFRAME LOCK
METAL PLATE
DOOR WING
“ZLC” BRACKET
“ZLC” BRACKET
