ab TereBox 2T User manual
1
Table&of&Contents&
1.&Front&and&Rear&Panel&...............................................&2&
1.1&Front&Panel&&.......................................................................................................................&4&
1.2&Rear&Panel& &.......................................................................................................................&4&
2.&Remote&Control&..........................................................&5&
2.1&Buttons& &.......................................................................................................................&5&
2.2&Installing&the&Battery&.......................................................................................................&6&
3. Connections&.................................................................&6&
4.&First&Installation&........................................................&6&
4.1&Channel& &.......................................................................................................................&7&
4.2&Installation& &.......................................................................................................................&8&
4.3&Language& &.......................................................................................................................&8&
4.5&Time& &.......................................................................................................................&9&
4.6&System& &.....................................................................................................................&10&
4.6.1&Standby&Setting&............................................................................................................&10&
4.7&Media&Center&....................................................................................................................&11&
5.Troubleshooting&......................................................&12&
6.Technical&Specifications&........................................&13&
&
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of
material resources. To return your used device,
please use the return and collection systems or
contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
2
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings, install in accordance with the
instructions.
8) Do not install near any heat sources such as radiations, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized plug. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the obsolete
outlet.
10) Protected the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Unplug this apparatus during lighting storms or when unused for long periods
of time.
13) Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
14) Mains plug is used as the disconnect device, the disconnect device shall
remain readily operable.
15) The ventilation should not be impeded by covering the ventilation openings
with items, such as newspapers, table-cloth, curtains, etc.
16) No naked flame sources, such as lighted candles, should be placed on the
apparatus.
17) Attention should be drawn to the environmental aspects of battery disposal.
18) The use of apparatus in moderate climate.
19) The apparatus shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the apparatus.
WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
WARNING: The batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
WARNING: You must peel off the membrane of the top cover before using.Or it
would harm
3
The symbol indicates that dangerous voltages constituting a risk of
electric shock are present within this unit.
The symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.
This symbol indicates that this product incorporates double insulation
between hazardous mains voltage and user accessible parts. When
servicing use only identical replacement parts.
CAUTION: When the apparatus was in electrostatic circumstance, it
may be malfunction and need to reset by user.
WARNING: The USB memory stick should be plugged in the unit
directly.
USB extension cable should not be used to avoid failing of data
transferring and interference caused.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm
to the environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse
of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
4
1. Front and Rear Panel
1.1 Front Panel
1. REMOTE CONTROL SENSOR: Used to receive the signal from the remote
control.
2. LED DISPLAY: Used to display the time or channel information.
3. CHANNEL UP: Selects the previous Channel without using the remote control.
4. CHANNEL DOWN: Selects the next Channel. without using the remote control.
5. STANDBY: Used to switch the set top box to on or standby.
1.1.1 Rear Panel
1. ANT IN: Used to connect the ANT to receive the signal
2. HDMI: This socket connects to HDMI in device.
3. SCART:This socket output RGB/CVBS and Audio L/R
4.S/PDIF:This socket output digital audio.
5.DC IN : Used to connect the 5V DC adapter.
6. IR: Used to connect the remote Sensor .
7. USB JACK: Used to connect to an external USB 2.0 device.
5
2. Remote Control
2.1 Buttons
1) MUTE: Mute or Restore Audio Output.
2) COLOUR BUTTONS:
①Blue: Selects an Audio Language or Audio Mode;
②Yellow: Displays Teletext Information.
③Green: Set video resolution.
④Red: Find program.
3) STOP: Stops media play.
4) F1: Timer setting.
5) RELOAD: Used to switch between the last
two viewed channels.
6) SHIFT: Start to do Timeshift.
7) INFO: Displays additional channel
information.
8) OK:Confirms an entry or selection. Displays
the list of channels.
9) RIGHT/LEFT: Navigates through the Menus.
Increases or decreases volume.
10) EXIT: Exits the current Menu or returns to the
previous Menu.
11) PAGE+/ -: Page up,Page down.
12) 0-9 (Numeric Buttons): Selects a channel or
setting.
13) TV/RADIO: Switches from TV function to
Radio function and from Radio to TV.
14) STANDBY: Switch the product to on or
standby.
15) FAST FORWARD: Searches forwards during
media play.
16) FAST REWIND: Searches backwards during
media play.
17) PAUSE: Pauses media play.
18) PLAY: Starts or resumes media play.
19) CH+/CH-: Channel up/down
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return
and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of
material resources. To return your used device, please
use the return and collection systems or contact the
retailer where the product was purchased. They can
take this product for environmental safe recycling.
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of
material resources. To return your used device, please
use the return and collection systems or contact the
retailer where the product was purchased. They can
take this product for environmental safe recycling.
This marking indicates that this product should not be
disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of
material resources. To return your used device, please
use the return and collection systems or contact the
retailer where the product was purchased. They can
take this product for environmental safe recycling.
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to
the environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of
material resources. To return your used device,
please use the return and collection systems or
contact the retailer where the product was
purchased. They can take this product for
environmental safe recycling.
6
20) SUB: Selects Subtitles Language.
21) EPG: (Electronic Program Guide) Turns the program guide on.
22) UP / DOWN: Navigates through the Menus. Selects the next or previous
Channel.
23) MENU: Turns on Main Menu
24) FAV: Opens the favorite group selection.
25) VOL+/-: Increases or decreases volume.
26) RECORD: Used to record the program
27) MEDIA: Goto local video manager.
2.2 Installing the Battery
Remove the battery cover from the Remote Control and put 2”AAA” size batteries
inside the compartment.
The diagram inside the Battery Compartment shows the correct way to install the
batteries.
3. Connections
Caution: Make sure to check the voltage specification of the wall outlet is the
same rating with the receiver. To prevent the risk of electric shock, do not open
the cover or the back of the receiver.
Note: When connecting the receiver to other equipment, e.g., TV, VCR and
amplifier, make sure to refer to relevant user manual for instruction. Also, make
sure you disconnect all the equipment’s from the mains supply before the
connection.
4. First Installation
After all connections have been made properly, switch on your TV. If you are
using the receiver for the first time or have restored to factory default, the First
Installation menu will appear on your TV screen. Press left/right key to select the
OSD language of your preference. As the same operate to select other setting,
then move to the Next Page , press OK to start search.
7
4.1 Channel
To access the Menu, press the MENU button and select [Channel list]. The Menu
provides options to adjust the Channel Settings. Select an option and press OK
or RIGHT to adjust that setting. Press the EXIT button to exit the Menu.
8
4.2 Installation
To access the menu, press MENU and select [channel search]. The Menu
provides options to adjust the Installation settings. Terrestrial is for DVB -
T2,Cable menu is for DVB-C.Select an option and press RIGHT/LEFT to adjust
the settings. Press EXIT to exit the Menu.
4.3 Language
To access the Menu, press MENU and select [Language]. The menu provides
options to adjust the OSD Language, First Audio and second Audio Language.
Select an option and press RIGHT/LEFT.
9
4.4 AV Setting
To access the Menu, press MENU and select [AV Setting].The menu provides
options to adjust the settings. Press the UP/DOWN key to select an option and
press RIGHT/LEFT to adjust the setting. Press EXIT to exit the Menu.
4.5 Time
To access the Menu, press MENU and select [Time].The menu provides options
to adjust the settings. Press the UP/DOWN key to select an option and press
RIGHT/LEFT to adjust the setting. Press EXIT to exit the Menu.
10
4.6 System
To access the Menu, press MENU and select [System].The menu provides
options to adjust the settings. Press the UP/DOWN key to select an option and
press RIGHT/LEFT to adjust the setting. Press EXIT to exit the Menu.
4.6.1 Standby Setting
To access the Menu, press the Media and select [System].Move to Standby
Setting item, press ok enter to set. The Auto Standby : to set how long will the
machine automatically stand by without operating the remote control. The Clock
In Standby : Select whether or not to display the time in the standby. Standby
Mode : select to deep or soft standby.
11
4.7 Media Center
To access the Menu, press the Media button on the remote control. The menu
provides options to Movie and playback Music and Photo files、Record Files; it
can support MP3 JPEG, BMP files.
STB will support USB device with NTFS and FAT32 file system.
12
5.Troubleshooting
Problem
Potential Reasons
What to do
No picture
Power isn't connected
Connect the power
The power switch is not
on
Switch on the power
Screen shows
No Signal
Not connect DVB-T
cable
Plug in the DVB-T
cable
Incorrect setting
Set up correct
parameter
No sound from
Speaker
No or incorrect
connection
with audio cable
Connect the audio
cable correctly
Mute the sound
Switch on the correct
volume control
Incorrect sound track
Try another sound track
Only sound,
no image on the
screen
No or incorrect
connection
with AV cable
Connect the audio
cable
correctly
The program is a radio
program
Press <TV/RADIO> key
to shift into TV mode
Remote control
unit is not
workable
The battery is
exhausted
Change new battery
Remote control unit is
not in the right opposite
of the front panel or too
far from it
Adjust the way of
holding remote control
unit and
near from the panel
The image stop
suddenly or
mosaic
The signal is too weak
Strengthen the signal
13
6.Technical Specifications
Item
Specification
Tuner
Frequency Range
VHF Band:174 MHz ~230MHz
UHF Band:470 MHz ~868MHz
Bandwidth
6MHz, 7MHz, 8MHz,
Input Impedance
75Ohm
Signal Input Level
-65 ~ -25dBm
RF Power Output
5V,Max 100mA
Demodul
ation
Demodulator
16QAM/64QAM/256QAM
Guard Intervals
1/4,19/256,1/8,19/128,1/16,1/32,1/1
28
Code Rate
DVB-T:Viterbi+ReedSolomon
1/2,2/3,3/4,5/6,7/8
DVB-T2:LPDC+BCH
1/2,3/5,2/3,3/4,4/5,5/6
Connecti
ons
ANT IN
IEC connector
SCART
RGB/CVBS VIDEO
USB
USB 2.0(5V,Max 500mA)
Power
Input
DC IN 5V/1.5A
Consumption
Max 7.5W
Display
Decoder Module
PAL,NTSC
Resolution
720X576(PAL),720X480(NTSC),72
0P,1080i
480i,480P,576i,576P,1080P
Decoding
Aspect Rate
4:3(Letterbox, Pan& Scan)16:9
Video
MPEG4 AVC/H.264/HP@L4//H.265
Audio
MPEG2 Audio Layer I&II
Others
Compliance
Standard DVB-T (EN 300 744) &
DVB-T2 (EN 302 755)
Sound Mode
Right, Left, Stereo
14
7. Accessories
Remote control unit, batteries, 2pin adapter, user’s manual
Table of contents
