ABB RELION 650 SERIES Quick start guide

Relion® 650 SERIES
Line differential protection RED650
Version 2.2 IEC
Commissioning manual

Document ID: 1MRK 505 395-UEN
Issued: May 2019
Revision: C
Product version: 2.2
© Copyright 2017 ABB. All rights reserved

Copyright
This document and parts thereof must not be reproduced or copied without written
permission from ABB, and the contents thereof must not be imparted to a third party, nor
used for any unauthorized purpose.
The software and hardware described in this document is furnished under a license and may
be used or disclosed only in accordance with the terms of such license.
This product includes software developed by the OpenSSL Project for use in the OpenSSL
Toolkit. (http://www.openssl.org/) This product includes cryptographic software written/
developed by: Eric Young ([email protected]) and Tim Hudson ([email protected]).
Trademarks
ABB and Relion are registered trademarks of the ABB Group. All other brand or product names
mentioned in this document may be trademarks or registered trademarks of their respective
holders.
Warranty
Please inquire about the terms of warranty from your nearest ABB representative.

Disclaimer
The data, examples and diagrams in this manual are included solely for the concept or product
description and are not to be deemed as a statement of guaranteed properties. All persons
responsible for applying the equipment addressed in this manual must satisfy themselves that
each intended application is suitable and acceptable, including that any applicable safety or
other operational requirements are complied with. In particular, any risks in applications where
a system failure and/or product failure would create a risk for harm to property or persons
(including but not limited to personal injuries or death) shall be the sole responsibility of the
person or entity applying the equipment, and those so responsible are hereby requested to
ensure that all measures are taken to exclude or mitigate such risks.
This document has been carefully checked by ABB but deviations cannot be completely ruled
out. In case any errors are detected, the reader is kindly requested to notify the manufacturer.
Other than under explicit contractual commitments, in no event shall ABB be responsible or
liable for any loss or damage resulting from the use of this manual or the application of the
equipment.

Conformity
This product complies with the directive of the Council of the European Communities on the
approximation of the laws of the Member States relating to electromagnetic compatibility
(EMC Directive 2004/108/EC) and concerning electrical equipment for use within specified
voltage limits (Low-voltage directive 2006/95/EC). This conformity is the result of tests
conducted by ABB in accordance with the product standard EN 60255-26 for the EMC directive,
and with the product standards EN 60255-1 and EN 60255-27 for the low voltage directive. The
product is designed in accordance with the international standards of the IEC 60255 series.

Table of contents
Section 1 Introduction........................................................................................................ 9
1.1 This manual......................................................................................................................................... 9
1.1.1 Presumptions for Technical Data...............................................................................................9
1.2 Intended audience............................................................................................................................. 9
1.3 Product documentation................................................................................................................. 10
1.3.1 Product documentation set...................................................................................................... 10
1.3.2 Document revision history......................................................................................................... 11
1.3.3 Related documents......................................................................................................................11
1.4 Document symbols and conventions........................................................................................... 12
1.4.1 Symbols..........................................................................................................................................12
1.4.2 Document conventions...............................................................................................................13
1.5 IEC 61850 edition 1 / edition 2 mapping..................................................................................... 13
Section 2 Safety information............................................................................................17
2.1 Symbols on the product..................................................................................................................17
2.2 Warnings............................................................................................................................................ 17
2.3 Caution signs.................................................................................................................................... 18
2.4 Note signs..........................................................................................................................................19
Section 3 Available functions........................................................................................... 21
3.1 Main protection functions.............................................................................................................. 21
3.2 Back-up protection functions........................................................................................................21
3.3 Control and monitoring functions................................................................................................22
3.4 Communication................................................................................................................................25
3.5 Basic IED functions.......................................................................................................................... 27
Section 4 Starting up.........................................................................................................29
4.1 Factory and site acceptance testing............................................................................................29
4.2 Commissioning checklist............................................................................................................... 29
4.3 Checking the power supply........................................................................................................... 30
4.4 Energizing the IED........................................................................................................................... 30
4.4.1 Checking the IED operation...................................................................................................... 30
4.4.2 IED start-up sequence................................................................................................................ 30
4.5 Setting up communication between PCM600 and the IED..................................................... 31
4.6 Writing an application configuration to the IED........................................................................35
4.7 Checking CT circuits........................................................................................................................35
4.8 Checking VT circuits........................................................................................................................ 36
4.9 Using the RTXP test switch............................................................................................................36
4.10 Checking the binary input/output circuits................................................................................. 37
4.10.1 Binary input circuits.................................................................................................................... 37
4.10.2 Binary output circuits................................................................................................................. 37
4.11 Checking optical connections....................................................................................................... 37
Table of contents
Line differential protection RED650 1
Commissioning manual
© Copyright 2017 ABB. All rights reserved

Section 5 Configuring the IED and changing settings..................................................39
5.1 Overview............................................................................................................................................ 39
5.2 Configuring analog CT inputs....................................................................................................... 39
5.3 Supervision of input/output modules........................................................................................ 40
Section 6 Establishing connection and verifying the SPA/IEC communication........41
6.1 Entering settings..............................................................................................................................41
6.1.1 Entering SPA settings................................................................................................................. 41
6.1.2 Entering IEC settings.................................................................................................................. 41
6.2 Verifying the communication........................................................................................................ 42
6.2.1 Verifying SPA communication...................................................................................................42
6.2.2 Verifying IEC communication....................................................................................................42
6.3 Fiber optic loop................................................................................................................................ 42
6.4 Optical budget calculation for serial communication with SPA/IEC ................................... 43
Section 7 Establishing connection and verifying the LON communication...............45
7.1 Communication via the rear ports .............................................................................................. 45
7.1.1 LON communication...................................................................................................................45
7.1.2 The LON Protocol........................................................................................................................ 46
7.1.3 Hardware and software modules............................................................................................ 46
7.2 Optical budget calculation for serial communication with LON ...........................................48
Section 8 Testing IED operation...................................................................................... 49
8.1 Preparing for test............................................................................................................................ 49
8.1.1 Requirements...............................................................................................................................49
8.1.2 Preparing the IED to verify settings........................................................................................ 50
8.2 Activating the test mode................................................................................................................ 51
8.3 Preparing the connection to the test equipment......................................................................51
8.4 Connecting the test equipment to the IED.................................................................................52
8.5 Releasing the function to be tested.............................................................................................53
8.6 Verifying analog primary and secondary measurement..........................................................54
8.7 Testing the protection functionality........................................................................................... 54
8.8 Forcing of binary input/output signals for testing..................................................................54
8.8.1 Forcing concept...........................................................................................................................54
8.8.2 How to enable forcing................................................................................................................ 55
8.8.2.1 Enable forcing by using LHMI................................................................................................ 55
8.8.2.2 Enable forcing using TESTMODE function block...............................................................55
8.8.3 How to change binary input/output signals using forcing................................................ 55
8.8.3.1 Forcing by using LHMI.............................................................................................................55
8.8.3.2 Forcing by using PCM600.......................................................................................................57
8.8.4 How to undo forcing changes and return the IED to normal operation.......................... 58
8.8.4.1 Undo forcing by using TESTMODE component.................................................................59
8.8.4.2 Undo forcing by using LHMI.................................................................................................. 59
8.8.4.3 Undo forcing by using PCM600............................................................................................ 59
Section 9 Testing functionality by secondary injection............................................... 61
9.1 Testing disturbance report............................................................................................................ 61
Table of contents
2Line differential protection RED650
Commissioning manual
© Copyright 2017 ABB. All rights reserved

9.1.1 Introduction.................................................................................................................................. 61
9.1.2 Disturbance report settings...................................................................................................... 61
9.1.3 Disturbance recorder (DR)......................................................................................................... 61
9.1.4 Event recorder (ER) and Event list (EL)................................................................................... 62
9.2 Identifying the function to test in the technical reference manual ...................................... 62
9.3 Differential protection....................................................................................................................62
9.3.1 Line differential protection LT3CPDIF.................................................................................... 62
9.3.1.1 Verifying the settings..............................................................................................................63
9.3.1.2 Completing the test................................................................................................................ 64
9.4 Impedance protection.................................................................................................................... 64
9.4.1 Distance protection zones, quadrilateral and mho characteristic ZMFPDIS.................. 64
9.4.1.1 Measuring the operating limit of set values.......................................................................67
9.4.1.2 Measuring the operating time of distance protection zones.........................................68
9.4.1.3 Completing the test................................................................................................................ 68
9.4.2 Power swing detection ZMRPSB ............................................................................................. 68
9.4.2.1 Verifying the signal and settings..........................................................................................68
9.4.2.2 Completing the test.................................................................................................................74
9.4.3 Automatic switch onto fault logic ZCVPSOF......................................................................... 74
9.4.3.1 Activating ZCVPSOF externally..............................................................................................74
9.4.3.2 Initiating ZCVPSOF automatically and setting mode to impedance.............................75
9.4.3.3 Initiating ZCVPSOF automatically and setting mode to UILevel ...................................75
9.4.3.4 Completing the test.................................................................................................................75
9.5 Current protection...........................................................................................................................75
9.5.1 Instantaneous phase overcurrent protection 3-phase output PHPIOC .......................... 75
9.5.1.1 Measuring the operate limit of set values...........................................................................76
9.5.1.2 Completing the test.................................................................................................................76
9.5.2 Directional phase overcurrent protection, four steps OC4PTOC......................................76
9.5.2.1 Verifying the settings..............................................................................................................76
9.5.2.2 Completing the test.................................................................................................................77
9.5.3 Instantaneous residual overcurrent protection EFPIOC .....................................................77
9.5.3.1 Measuring the operate limit of set values...........................................................................78
9.5.3.2 Completing the test.................................................................................................................78
9.5.4 Four step residual overcurrent protection, (Zero sequence or negative sequence
directionality) EF4PTOC ............................................................................................................78
9.5.4.1 Four step directional earth fault protection.......................................................................78
9.5.4.2 Four step non-directional earth fault protection.............................................................. 79
9.5.4.3 Completing the test.................................................................................................................79
9.5.5 Thermal overload protection, one time constant, Celsius/Fahrenheit
LCPTTR/LFPTTR...........................................................................................................................79
9.5.5.1 Measuring the operate and time limit of set values......................................................... 79
9.5.5.2 Completing the test................................................................................................................ 80
9.5.6 Breaker failure protection, phase segregated activation and output CCRBRF..............80
9.5.6.1 Checking the phase current operate value, IP> ................................................................. 80
9.5.6.2 Checking the residual (earth fault) current operate value IN> set below IP> .............. 81
9.5.6.3 Checking the re-trip and back-up times.............................................................................. 81
9.5.6.4 Verifying the re-trip mode...................................................................................................... 81
Table of contents
Line differential protection RED650 3
Commissioning manual
© Copyright 2017 ABB. All rights reserved

9.5.6.5 Verifying the back-up trip mode........................................................................................... 82
9.5.6.6 Verifying instantaneous back-up trip at CB faulty condition..........................................82
9.5.6.7 Verifying the case RetripMode = Contact ........................................................................... 82
9.5.6.8 Verifying the function mode Current/Contact ................................................................... 83
9.5.6.9 Completing the test.................................................................................................................83
9.5.7 Pole discordance protection CCPDSC.....................................................................................83
9.5.7.1 Verifying the settings..............................................................................................................84
9.5.7.2 Completing the test................................................................................................................ 84
9.6 Voltage protection.......................................................................................................................... 84
9.6.1 Two step undervoltage protection UV2PTUV .......................................................................84
9.6.1.1 Verifying the settings..............................................................................................................84
9.6.1.2 Completing the test................................................................................................................ 86
9.6.2 Two step overvoltage protection OV2PTOV ......................................................................... 86
9.6.2.1 Verifying the settings..............................................................................................................86
9.6.2.2 Extended testing......................................................................................................................86
9.6.2.3 Completing the test................................................................................................................ 86
9.6.3 Two step residual overvoltage protection ROV2PTOV ....................................................... 87
9.6.3.1 Verifying the settings..............................................................................................................87
9.6.3.2 Completing the test.................................................................................................................87
9.7 Frequency protection......................................................................................................................87
9.7.1 Underfrequency protection SAPTUF ...................................................................................... 87
9.7.1.1 Verifying the settings..............................................................................................................87
9.7.1.2 Completing the test................................................................................................................ 88
9.7.2 Overfrequency protection SAPTOF ........................................................................................ 88
9.7.2.1 Verifying the settings..............................................................................................................88
9.7.2.2 Completing the test................................................................................................................ 89
9.7.3 Rate-of-change frequency protection SAPFRC .................................................................... 89
9.7.3.1 Verifying the settings..............................................................................................................89
9.7.3.2 Completing the test................................................................................................................ 90
9.8 Secondary system supervision..................................................................................................... 90
9.8.1 Current circuit supervision CCSSPVC......................................................................................90
9.8.1.1 Verifying the settings..............................................................................................................90
9.8.1.2 Completing the test................................................................................................................ 90
9.8.2 Fuse failure supervision FUFSPVC........................................................................................... 90
9.8.2.1 Checking that the binary inputs and outputs operate as expected ............................. 91
9.8.2.2 Measuring the operate value for the negative sequence function ................................91
9.8.2.3 Measuring the operate value for the zero-sequence function .......................................92
9.8.2.4 Measuring the operate value for the dead line detection function............................... 93
9.8.2.5 Checking the operation of the du/dt and di/dt based function ...................................93
9.8.2.6 Completing the test................................................................................................................ 94
9.9 Control............................................................................................................................................... 94
9.9.1 Synchrocheck, energizing check, and synchronizing SESRSYN......................................... 94
9.9.1.1 Testing the synchronizing function..................................................................................... 95
9.9.1.2 Testing the synchrocheck functionality.............................................................................. 96
9.9.1.3 Testing the energizing check.................................................................................................97
9.9.1.4 Testing the voltage selection................................................................................................ 99
Table of contents
4Line differential protection RED650
Commissioning manual
© Copyright 2017 ABB. All rights reserved

9.9.1.5 Completing the test................................................................................................................ 99
9.9.2 Autorecloser for 1/2/3-phase operation SMBRREC ............................................................ 99
9.9.2.1 Preparation of the verification ............................................................................................101
9.9.2.2 Switching the auto recloser to On and Off On and Off .................................................. 101
9.9.2.3 Verifying the auto recloser .................................................................................................. 102
9.9.2.4 Checking the auto reclosing conditions............................................................................102
9.9.2.5 Completing the test.............................................................................................................. 104
9.9.3 Apparatus control APC............................................................................................................. 104
9.9.4 Single command, 16 signals SINGLECMD.............................................................................104
9.10 Scheme communication...............................................................................................................104
9.10.1 Scheme communication logic for distance or overcurrent protection ZCPSCH .........104
9.10.1.1 Testing permissive underreaching..................................................................................... 105
9.10.1.2 Testing permissive overreaching........................................................................................105
9.10.1.3 Testing blocking scheme......................................................................................................105
9.10.1.4 Testing delta blocking scheme........................................................................................... 105
9.10.1.5 Checking of unblocking logic...............................................................................................106
9.10.1.6 Completing the test.............................................................................................................. 106
9.10.2 Current reversal and Weak-end infeed logic for distance protection 3-phase
ZCRWPSCH .................................................................................................................................106
9.10.2.1 Current reversal logic............................................................................................................ 107
9.10.2.2 Weak end infeed logic............................................................................................................107
9.10.2.3 Completing the test.............................................................................................................. 108
9.10.3 Local acceleration logic ZCLCPSCH.......................................................................................108
9.10.3.1 Verifying the settings............................................................................................................108
9.10.3.2 Completing the test.............................................................................................................. 108
9.10.4 Scheme communication logic for residual overcurrent protection ECPSCH ...............108
9.10.4.1 Testing the directional comparison logic function.........................................................109
9.10.4.2 Completing the test...............................................................................................................110
9.10.5 Current reversal and weak-end infeed logic for residual overcurrent protection
ECRWPSCH ................................................................................................................................. 110
9.10.5.1 Testing the current reversal logic....................................................................................... 110
9.10.5.2 Testing the weak-end infeed logic......................................................................................110
9.10.5.3 Completing the test............................................................................................................... 112
9.11 Logic..................................................................................................................................................112
9.11.1 Tripping logic, common 3-phase output SMPPTRC ........................................................... 112
9.11.1.1 3 phase operating mode........................................................................................................112
9.11.1.2 1ph/3ph operating mode...................................................................................................... 112
9.11.1.3 1ph/2ph/3ph operating mode............................................................................................. 113
9.11.1.4 Circuit breaker lockout.......................................................................................................... 114
9.11.1.5 Completing the test............................................................................................................... 115
9.12 Monitoring....................................................................................................................................... 115
9.12.1 Gas medium supervision SSIMG............................................................................................. 115
9.12.1.1 Testing the gas medium supervision for pressure alarm and pressure lockout
conditions................................................................................................................................ 115
9.12.1.2 Testing the gas medium supervision for temperature alarm and temperature
lock out conditions.................................................................................................................115
9.12.1.3 Completing the test............................................................................................................... 116
Table of contents
Line differential protection RED650 5
Commissioning manual
© Copyright 2017 ABB. All rights reserved

9.12.2 Liquid medium supervision SSIML......................................................................................... 116
9.12.2.1 Testing the liquid medium supervision for level alarm and level lockout
conditions................................................................................................................................ 116
9.12.2.2 Testing the liquid medium supervision for temperature alarm and
temperature lock out conditions.........................................................................................116
9.12.2.3 Completing the test............................................................................................................... 117
9.12.3 Breaker monitoring SSCBR.......................................................................................................117
9.12.3.1 Verifying the settings.............................................................................................................117
9.12.3.2 Completing the test............................................................................................................... 118
9.12.4 Event function EVENT............................................................................................................... 118
9.12.5 Fault locator LMBRFLO............................................................................................................. 119
9.12.5.1 Measuring the operate limit................................................................................................. 119
9.12.5.2 Completing the test...............................................................................................................120
9.12.6 Limit counter L4UFCNT............................................................................................................120
9.12.6.1 Completing the test...............................................................................................................120
9.12.7 Voltage harmonic monitoring VHMMHAI............................................................................. 120
9.12.7.1 Verifying the signals and settings...................................................................................... 120
9.12.7.2 Completing the test............................................................................................................... 121
9.13 Metering........................................................................................................................................... 121
9.13.1 Pulse-counter logic PCFCNT.................................................................................................... 121
9.13.2 Function for energy calculation and demand handling ETPMMTR.................................. 121
9.13.2.1 Verifying the settings.............................................................................................................121
9.13.2.2 Completing the test............................................................................................................... 122
9.14 Station communication................................................................................................................ 123
9.14.1 Multiple command and transmit MULTICMDRCV / MULTICMDSND...............................123
9.15 Remote communication................................................................................................................123
9.15.1 Binary signal transfer................................................................................................................ 123
9.16 Basic IED functions........................................................................................................................ 124
9.16.1 Parameter setting group handling SETGRPS.......................................................................124
9.16.1.1 Verifying the settings............................................................................................................ 124
9.16.1.2 Completing the test...............................................................................................................124
9.17 Exit test mode.................................................................................................................................125
Section 10 Checking the directionality........................................................................... 127
10.1 Overview...........................................................................................................................................127
10.2 Testing the directionality of the distance protection............................................................ 127
Section 11 Commissioning and maintenance of the fault clearing system............... 129
11.1 Commissioning tests.................................................................................................................... 129
11.2 Periodic maintenance tests......................................................................................................... 129
11.2.1 Visual inspection........................................................................................................................130
11.2.2 Maintenance tests..................................................................................................................... 130
11.2.2.1 Preparation..............................................................................................................................130
11.2.2.2 Recording.................................................................................................................................130
11.2.2.3 Secondary injection............................................................................................................... 130
11.2.2.4 Alarm test................................................................................................................................. 131
11.2.2.5 Self supervision check............................................................................................................131
Table of contents
6Line differential protection RED650
Commissioning manual
© Copyright 2017 ABB. All rights reserved

11.2.2.6 Trip circuit check.....................................................................................................................131
11.2.2.7 Measurement of service currents........................................................................................131
11.2.2.8 Restoring.................................................................................................................................. 132
Section 12 Troubleshooting..............................................................................................133
12.1 Checking the self supervision signals........................................................................................133
12.1.1 Checking the self supervision function................................................................................. 133
12.1.1.1 Determine the cause of an internal failure........................................................................ 133
12.1.2 Self supervision HMI data........................................................................................................ 133
12.1.2.1 General IED status.................................................................................................................. 133
12.2 Fault tracing....................................................................................................................................134
12.2.1 Internal fault indications.......................................................................................................... 134
12.2.2 Using front-connected PC........................................................................................................135
12.2.3 Diagnosing the IED status via the LHMI hint menu............................................................ 136
12.2.4 Hardware re-configuration...................................................................................................... 137
12.3 Repair instruction.......................................................................................................................... 138
12.4 Repair support................................................................................................................................ 139
12.5 Maintenance....................................................................................................................................139
Section 13 Glossary............................................................................................................141
Table of contents
Line differential protection RED650 7
Commissioning manual
© Copyright 2017 ABB. All rights reserved

8

Section 1 Introduction
1.1 This manual
GUID-AB423A30-13C2-46AF-B7FE-A73BB425EB5F v19
The commissioning manual contains instructions on how to commission the IED. The manual
can also be used by system engineers and maintenance personnel for assistance during the
testing phase. The manual provides procedures for the checking of external circuitry and
energizing the IED, parameter setting and configuration as well as verifying settings by
secondary injection. The manual describes the process of testing an IED in a station which is
not in service. The chapters are organized in the chronological order in which the IED should be
commissioned. The relevant procedures may be followed also during the service and
maintenance activities.
1.1.1 Presumptions for Technical Data GUID-1E949E38-E04D-4374-A086-912C25E9F93C v2
The technical data stated in this document are only valid under the following circumstances:
1. Main current transformers with 1 A or 2 A secondary rating are wired to the IED 1 A rated
CT inputs.
2. Main current transformer with 5 A secondary rating are wired to the IED 5 A rated CT
inputs.
3. CT and VT ratios in the IED are set in accordance with the associated main instrument
transformers. Note that for functions which measure an analogue signal which do not
have corresponding primary quantity the 1:1 ratio shall be set for the used analogue inputs
on the IED. Example of such functions are: HZPDIF, ROTIPHIZ and STTIPHIZ.
4. Parameter
IBase used by the tested function is set equal to the rated CT primary current.
5. Parameter
UBase used by the tested function is set equal to the rated primary phase-to-
phase voltage.
6. Parameter SBase used by the tested function is set equal to:
• √3 × IBase × UBase
7. The rated secondary quantities have the following values:
• Rated secondary phase current Ir is either 1 A or 5 A depending on selected TRM.
• Rated secondary phase-to-phase voltage Ur is within the range from 100 V to 120 V.
• Rated secondary power for three-phase system Sr = √3 × Ur × Ir
8. For operate and reset time testing, the default setting values of the function are used if
not explicitly stated otherwise.
9. During testing, signals with rated frequency have been injected if not explicitly stated
otherwise.
1.2 Intended audience
GUID-C9B8127F-5748-4BEA-9E4F-CC762FE28A3A v11
This manual addresses the personnel responsible for commissioning, maintenance and taking
the IED in and out of normal service.
The commissioning personnel must have a basic knowledge of handling electronic equipment.
The commissioning and maintenance personnel must be well experienced in using protection
equipment, test equipment, protection functions and the configured functional logics in the
IED.
1MRK 505 395-UEN C Section 1
Introduction
Line differential protection RED650 9
Commissioning manual
© Copyright 2017 ABB. All rights reserved

1.3 Product documentation
1.3.1 Product documentation set GUID-3AA69EA6-F1D8-47C6-A8E6-562F29C67172 v16
IEC07000220-4-en.vsd
Planning & purchase Engineering Installing Commissioning Operation Maintenance Decommissioning Deinstalling & disposal
Application manual
Operation manual
Installation manual
Engineering manual
Communication
protocol manual
Cyber security
deployment guideline
Technical manual
Commissioning manual
IEC07000220 V4 EN-US
Figure 1: The intended use of manuals throughout the product lifecycle
The engineering manual contains instructions on how to engineer the IEDs using the various
tools available within the PCM600 software. The manual provides instructions on how to set
up a PCM600 project and insert IEDs to the project structure. The manual also recommends a
sequence for the engineering of protection and control functions, as well as communication
engineering for IEC 61850.
The installation manual contains instructions on how to install the IED. The manual provides
procedures for mechanical and electrical installation. The chapters are organized in the
chronological order in which the IED should be installed.
The commissioning manual contains instructions on how to commission the IED. The manual
can also be used by system engineers and maintenance personnel for assistance during the
testing phase. The manual provides procedures for the checking of external circuitry and
energizing the IED, parameter setting and configuration as well as verifying settings by
secondary injection. The manual describes the process of testing an IED in a station which is
not in service. The chapters are organized in the chronological order in which the IED should be
commissioned. The relevant procedures may be followed also during the service and
maintenance activities.
The operation manual contains instructions on how to operate the IED once it has been
commissioned. The manual provides instructions for the monitoring, controlling and setting of
the IED. The manual also describes how to identify disturbances and how to view calculated
and measured power grid data to determine the cause of a fault.
Section 1 1MRK 505 395-UEN C
Introduction
10 Line differential protection RED650
Commissioning manual
© Copyright 2017 ABB. All rights reserved

The application manual contains application descriptions and setting guidelines sorted per
function. The manual can be used to find out when and for what purpose a typical protection
function can be used. The manual can also provide assistance for calculating settings.
The technical manual contains operation principle descriptions, and lists function blocks, logic
diagrams, input and output signals, setting parameters and technical data, sorted per
function. The manual can be used as a technical reference during the engineering phase,
installation and commissioning phase, and during normal service.
The communication protocol manual describes the communication protocols supported by
the IED. The manual concentrates on the vendor-specific implementations.
The point list manual describes the outlook and properties of the data points specific to the
IED. The manual should be used in conjunction with the corresponding communication
protocol manual.
The cyber security deployment guideline describes the process for handling cyber security
when communicating with the IED. Certification, Authorization with role based access control,
and product engineering for cyber security related events are described and sorted by
function. The guideline can be used as a technical reference during the engineering phase,
installation and commissioning phase, and during normal service.
1.3.2 Document revision history GUID-BD82A13A-6FA0-4E33-BDBF-23B5A0CF968F v1
Document
revision
Date Product revision History
- 2017–05 2.2.0 First release for product version 2.2
A 2017-10 2.2.1 Ethernet ports with RJ45 connector added.
enhancements/updates made to GENPDIF, ZMFPDIS and
ZMFCPDIS.
B 2018-03 2.2.1 Document enhancements and corrections
C 2019-052.2.1 PTP enhancements and corrections
1.3.3 Related documents GUID-94E8A5CA-BE1B-45AF-81E7-5A41D34EE112 v7
Documents related to RED650 Document numbers
Application manual 1MRK 505 393-UEN
Commissioning manual 1MRK 505 395-UEN
Product guide 1MRK 505 396-BEN
Technical manual 1MRK 505 394-UEN
Type test certificate 1MRK 505 396-TEN
650 series manuals Document numbers
Operation manual 1MRK 500 128-UEN
Engineering manual 1MRK 511 420-UEN
Installation manual 1MRK 514 027-UEN
Communication protocol manual, DNP3 1MRK 511 413-UUS
Communication protocol manual, IEC 60870-5-103 1MRK 511 416-UEN
Communication protocol manual, IEC 61850 Edition 1 1MRK 511 414-UEN
Communication protocol manual, IEC 61850 Edition 2 1MRK 511 415-UEN
Table continues on next page
1MRK 505 395-UEN C Section 1
Introduction
Line differential protection RED650 11
Commissioning manual
© Copyright 2017 ABB. All rights reserved

650 series manuals Document numbers
Communication protocol manual, LON 1MRK 511 417-UEN
Communication protocol manual, SPA 1MRK 511 418-UEN
Point list manual, DNP3 1MRK 511 419-UUS
Accessories guide IEC: 1MRK 514 012-UEN
ANSI: 1MRK 514 012-UUS
Cyber security deployment guideline 1MRK 511 421-UEN
Connection and Installation components 1MRK 513 003-BEN
Test system, COMBITEST 1MRK 512 001-BEN
Application guide, Communication set-up 1MRK 505 382-UEN
1.4 Document symbols and conventions
1.4.1 Symbols GUID-2945B229-DAB0-4F15-8A0E-B9CF0C2C7B15 v13
The electrical warning icon indicates the presence of a hazard which could
result in electrical shock.
The warning icon indicates the presence of a hazard which could result in
personal injury.
The caution hot surface icon indicates important information or warning about
the temperature of product surfaces.
Class 1 Laser product. Take adequate measures to protect the eyes and do not
view directly with optical instruments.
The caution icon indicates important information or warning related to the
concept discussed in the text. It might indicate the presence of a hazard which
could result in corruption of software or damage to equipment or property.
The information icon alerts the reader of important facts and conditions.
The tip icon indicates advice on, for example, how to design your project or
how to use a certain function.
Although warning hazards are related to personal injury, it is necessary to understand that
under certain operational conditions, operation of damaged equipment may result in
Section 1 1MRK 505 395-UEN C
Introduction
12 Line differential protection RED650
Commissioning manual
© Copyright 2017 ABB. All rights reserved

degraded process performance leading to personal injury or death. It is important that the
user fully complies with all warning and cautionary notices.
1.4.2 Document conventions GUID-96DFAB1A-98FE-4B26-8E90-F7CEB14B1AB6 v8
• Abbreviations and acronyms in this manual are spelled out in the glossary. The glossary
also contains definitions of important terms.
• Push button navigation in the LHMI menu structure is presented by using the push button
icons.
For example, to navigate between the options, use and .
• HMI menu paths are presented in bold.
For example, select Main menu/Settings.
• LHMI messages are shown in Courier font.
For example, to save the changes in non-volatile memory, select Yes and press .
• Parameter names are shown in italics.
For example, the function can be enabled and disabled with the
Operation setting.
• Each function block symbol shows the available input/output signal.
• the character ^ in front of an input/output signal name indicates that the signal
name may be customized using the PCM600 software.
• the character * after an input signal name indicates that the signal must be
connected to another function block in the application configuration to achieve a
valid application configuration.
