ABB AC500-S User manual

MANUAL
AC500-S
Safety user manual V1.2.0
Original instructions

—
Table of contents
1 Introduction..................................................................................................................................................... 5
1.1 Purpose..................................................................................................................................................... 5
1.2 Document history...................................................................................................................................... 5
1.3 Validity....................................................................................................................................................... 7
1.4 Important user information........................................................................................................................ 7
1.5 Definitions, expressions, abbreviations..................................................................................................... 8
1.6 Functional safety certification.................................................................................................................. 10
1.7 References / related documents.............................................................................................................. 11
1.8 Applicable standards............................................................................................................................... 11
2 Overview of AC500-S safety PLC................................................................................................................. 13
2.1 Overview................................................................................................................................................. 13
2.1.1 System..................................................................................................................................... 13
2.1.2 Safety components.................................................................................................................. 14
2.2 Intended use............................................................................................................................................ 16
2.3 Safety loop.............................................................................................................................................. 17
2.4 Safety values........................................................................................................................................... 17
2.5 Qualified personnel................................................................................................................................. 18
2.6 Lifecycle.................................................................................................................................................. 18
2.7 Installation of safety modules.................................................................................................................. 18
2.8 Exchange of modules.............................................................................................................................. 19
2.9 AC500-S restart behavior........................................................................................................................ 19
2.10 Replacing AC500-S safety PLC components........................................................................................ 19
2.11 Environmentally friendly disposal.......................................................................................................... 19
2.12 Safe communication.............................................................................................................................. 19
2.13 Safety function and fault reaction.......................................................................................................... 21
2.13.1 Safety CPU (SM560-S / SM560-S-FD-1 / SM560-S-FD-4).................................................... 22
2.13.2 Safety module with safety input channels (DI581-S, DX581-S and AI581-S)........................ 22
2.13.3 Safety module with safety output channels (DX581-S).......................................................... 23
2.14 Safety function test................................................................................................................................ 23
2.15 Troubleshooting..................................................................................................................................... 23
2.16 FAQ - AC500-S safety PLC................................................................................................................... 28
3 AC500-S safety modules.............................................................................................................................. 32
3.1 Safety CPU - SM560-S / SM560-S-FD-1 / SM560-S-FD-4..................................................................... 32
3.1.1 Purpose.................................................................................................................................... 32
3.1.2 Functionality............................................................................................................................. 32
3.1.3 Mounting, dimensions and electrical connection..................................................................... 39
3.1.4 Diagnosis and LED status display............................................................................................ 41
3.1.5 Safety CPU module states....................................................................................................... 43
3.1.6 Safety and non-safety CPU interaction.................................................................................... 47
3.1.7 Technical data.......................................................................................................................... 47
3.1.8 Ordering data........................................................................................................................... 50
3.2 Generic safety I/O module behavior........................................................................................................ 50
3.2.1 Overview.................................................................................................................................. 50
3.2.2 Safety I/O module states.......................................................................................................... 50
3.2.3 Undervoltage / overvoltage...................................................................................................... 59
3.2.4 Diagnosis................................................................................................................................. 60
3.3 DI581-S safety digital input module......................................................................................................... 61
3.3.1 Purpose.................................................................................................................................... 61
Table of contents
2020/06/193ADR025091M0208, 12, en_US2

3.3.2 Functionality............................................................................................................................. 62
3.3.3 Mounting, dimensions and electrical connection..................................................................... 65
3.3.4 Internal data exchange............................................................................................................. 69
3.3.5 I/O configuration....................................................................................................................... 69
3.3.6 Parameterization...................................................................................................................... 69
3.3.7 Circuit examples....................................................................................................................... 69
3.3.8 LED status display................................................................................................................... 81
3.3.9 Technical data.......................................................................................................................... 82
3.3.10 Ordering data......................................................................................................................... 85
3.4 DX581-S safety digital input/output module............................................................................................ 86
3.4.1 Purpose.................................................................................................................................... 86
3.4.2 Functionality............................................................................................................................. 87
3.4.3 Mounting, dimensions and electrical connection..................................................................... 91
3.4.4 Internal data exchange............................................................................................................. 95
3.4.5 I/O configuration....................................................................................................................... 95
3.4.6 Parameterization...................................................................................................................... 95
3.4.7 Circuit examples....................................................................................................................... 96
3.4.8 LED status display................................................................................................................. 101
3.4.9 Technical data........................................................................................................................ 102
3.4.10 Ordering data....................................................................................................................... 106
3.5 AI581-S safety analog input module..................................................................................................... 107
3.5.1 Purpose.................................................................................................................................. 107
3.5.2 Functionality........................................................................................................................... 108
3.5.3 Mounting, dimensions and electrical connection.................................................................... 110
3.5.4 Internal data exchange........................................................................................................... 113
3.5.5 I/O configuration..................................................................................................................... 113
3.5.6 Parameterization.................................................................................................................... 113
3.5.7 Circuit examples..................................................................................................................... 114
3.5.8 LED status display.................................................................................................................. 118
3.5.9 Technical data........................................................................................................................ 119
3.5.10 Ordering data....................................................................................................................... 122
3.6 TU582-S safety I/O terminal unit........................................................................................................... 123
3.6.1 Functionality........................................................................................................................... 123
3.6.2 Mounting, dimensions and electrical connection................................................................... 124
3.6.3 Technical data........................................................................................................................ 126
3.6.4 Ordering data......................................................................................................................... 127
4 Configuration and programming............................................................................................................... 128
4.1 Overview............................................................................................................................................... 128
4.2 Workflow................................................................................................................................................ 129
4.3 System configuration and programming................................................................................................ 130
4.3.1 Installation.............................................................................................................................. 130
4.3.2 License activation................................................................................................................... 130
4.3.3 Creation of new project and user management..................................................................... 130
4.3.4 Working with PROFINET/PROFIsafe F-Devices................................................................... 131
4.3.5 Instantiation and configuration of safety modules / definition of variable names................... 133
4.3.6 Programming of AC500-S safety CPU................................................................................... 141
4.3.7 Checking of program and system configuration..................................................................... 159
4.4 CODESYS Safety programming guidelines.......................................................................................... 172
4.4.1 Overview................................................................................................................................ 172
4.4.2 Framework............................................................................................................................. 172
4.4.3 Language-specific programming guidelines.......................................................................... 174
Table of contents
2020/06/19 3ADR025091M0208, 12, en_US 3

4.4.4 General programming guidelines........................................................................................... 180
4.4.5 Safety and non-safety parts of the application....................................................................... 181
4.5 Safety code analysis tool....................................................................................................................... 181
4.6 AC500-S libraries.................................................................................................................................. 182
4.6.1 Overview................................................................................................................................ 182
4.6.2 Safety_Standard.lib................................................................................................................ 183
4.6.3 SafetyBase_PROFIsafe_LV200_AC500_V22.lib................................................................... 187
4.6.4 SafetyBlocks_PLCopen_AC500_v22.lib................................................................................ 191
4.6.5 SafetyDeviceExt_LV100_PROFIsafe_AC500_V27.lib........................................................... 294
4.6.6 SafetyExt2_LV100_AC500_V27.lib........................................................................................ 298
4.6.7 SafetyExt_AC500_V22.lib...................................................................................................... 300
5 Safety times................................................................................................................................................. 317
5.1 Overview............................................................................................................................................... 317
5.2 Fault reaction time................................................................................................................................. 317
5.3 Safety function response time............................................................................................................... 317
6 Checklists for AC500-S commissioning................................................................................................... 326
6.1 Overview............................................................................................................................................... 326
6.2 Checklist for creation of safety application program.............................................................................. 326
6.3 Checklist for configuration and wiring.................................................................................................... 328
6.4 Checklist for operation, maintenance and repair................................................................................... 330
6.5 Verification procedure for safe iParameter setting in AC500-S safety I/Os........................................... 332
6.5.1 Verification procedure workflow............................................................................................. 333
6.5.2 Verification tables for iParameter settings in AC500-S safety I/Os........................................ 334
7 Safety application examples...................................................................................................................... 342
7.1 Overview............................................................................................................................................... 342
7.2 Example 1: diagnostics concept............................................................................................................ 343
7.2.1 Functional description of safety functions.............................................................................. 343
7.2.2 Graphical overview of safety application interface................................................................. 344
7.2.3 Declaration of used variables................................................................................................. 344
7.2.4 Program example................................................................................................................... 345
7.2.5 Additional notes...................................................................................................................... 345
7.3 Example 2: muting................................................................................................................................. 346
7.3.1 Functional description of safety functions.............................................................................. 347
7.3.2 Graphical overview of the safety application interface........................................................... 348
7.3.3 Declaration of used variables................................................................................................. 348
7.3.4 Program example................................................................................................................... 350
7.3.5 Additional notes ..................................................................................................................... 351
7.4 Example 3: two-hand control................................................................................................................. 352
7.4.1 Functional description of safety functions.............................................................................. 352
7.4.2 Graphical overview of the safety application interface........................................................... 353
7.4.3 Declaration of used variables................................................................................................. 353
7.4.4 Program example................................................................................................................... 354
7.4.5 Additional notes...................................................................................................................... 354
8 Index............................................................................................................................................................. 356
Appendix...................................................................................................................................................... 359
A System data for AC500-S-XC................................................................................................... 360
B Usage of safety CPU with V2 non-safety CPU PM5xx............................................................. 366
C Usage of safety CPU with V3 non-safety CPU PM56xx........................................................... 384
Table of contents
2020/06/193ADR025091M0208, 12, en_US4

—
1 Introduction
1.1 Purpose
This safety user manual describes AC500-S safety PLC system. It provides detailed information
on how to install, run, program and maintain the system correctly in functional safety applica-
tions up to SIL 3 according to IEC 61508:2010, SILCL 3 according to IEC 62061:2015 and per-
formance level e (cat. 4) according to ISO 13849-1:2015.
ABB’s AC500 series is a PLC-based modular automation solution that makes it easy to mix and
match safety and non-safety I/O modules to meet automation market requirements.
1.2 Document history
Rev. Description of version / changes Who Date
1.2.0 Various typos were corrected and various improvements in the texts and
illustrations were made. Layout was changed to current ABB branding.
Major changes:
● Chapter 4.3.7.1: New safety verification tool SVT was added.
● Safety modules are supported by AC500 V3 non-safety CPUs. Spe-
cific information on handling safety modules with non-safety CPUs
transferred to appendices B + C.
Appendix B contains all specific information about safety modules
with V2 non-safety CPUs PM5xx.
Appendix C contains all specific information about safety modules
with V3 non-safety CPUs PM56xx.
● Chapter 3.1.2.6: "Firmware, boot code and boot project update" was
updated.
● Assembly instructions of safety I/O modules were updated.
ABB 19.06.2020
1.1.0 Various typos were corrected. Various improvements in the text.
Major changes:
● Information about SM560-S-FD-1(-XC) and SM560-S-FD-4(-XC)
safety CPUs was added.
● Ch. 4.6.7: New PROFIsafe F-Device library SafetyDevi-
ceExt_LV100_PROFIsafe_AC500_V27.lib was added.
● Ch. 4.6.8: New Safety library SafetyExt2_LV100_AC500_V27.lib was
added.
● Detailed information about relevant standards was added.
● Checklists for AC500-S commissioning in Chapter 6 were updated.
ABB 16.03.2018
1.0.5 Various typos were corrected. Minor improvements in the text and
removal of screen shots for older versions of Automation Builder.
Major changes:
● New PROFIsafe F-Host library SAFETY-
BASE_PROFIsafe_LV200_AC500_V22.lib is used in the document.
● FAQ (Frequently Asked Questions) list was added.
● Ch. 2.4: Detailed safety values for AC500-S modules were provided.
● Ch. 4.3.6: "DANGER!" note was added to explain PROFIsafe
Device_Fault bit usage.
● Ch. 6.3: New checklist item 9 was added.
ABB 23.10.2017
Introduction
Document history
2020/06/19 3ADR025091M0208, 12, en_US 5

Rev. Description of version / changes Who Date
1.0.4 Various typos were corrected. Minor improvements in the text.
Major changes:
Licensing information was updated:
● Ch. 4.1: Notice Block with reference to PS501-S license installation
removed.
● Ch. 4.2: Figure 63 updated (Programming workflow, step 2) was
enhanced for the license handling of Automation Builder version
V2.0.2 (or higher).
● Ch. 4.3.2: "Licence activation" was extended with additional licensing
information for usage of Automation Builder version V2.0.2 (or
higher).
Additional information according to the new F-Host library "SAFETY-
BASE_PROFIsafe_AC500_V22_Ext.lib" was added:
● Ch 4.6.1: Table for library "SAFETY-
BASE_PROFIsafe_AC500_V22_Ext.lib" was updated.
● Ch. 4.6.3: The chapter was updated and renamed acc. to the new
library name "SAFETYBASE_PROFIsafe_AC500_V22_Ext.lib".
● Ch. 6.2: Checklist item 20 was updated according to the new library
name "SAFETYBASE_PROFIsafe_AC500_V22_Ext.lib".
ABB 27.03.2017
1.0.3 Various typos were corrected. Additional abbreviations were included in
the abbreviation list.
The entire document was re-styled:
● The yellow background on notices and recommendations was
replaced by a light-grey background because of document standardi-
zation.
● "DANGER" and "NOTICE" symbols were replaced by standard sym-
bols from German Standard DIN 4844-2 in text boxes.
The text was changed in the document:
● More standard terms are now used in the document.
● Values for storage and transport temperatures were extended.
● Vertical mounting option (with derating) is added for SM560-S Safety
CPU and corrected for DI581-S and AI581-S Safety I/O modules.
● LREAL is not supported by SM560-S Safety CPUs and was removed
from the document.
● POU SF_MAX_POWER_DIP_GET description was modified.
● "DANGER" text box was added for POU
SF_DPRAM_PM5XX_S_SEND to explain limitations for POU usage.
● F_WD_Time2 and Device_WD2 term definitions in Chapter 5.3 were
corrected.
● "F_Host_WD" was replaced with "the value set using
SF_WDOG_TIME_SET" inside of "NOTICE" box in Chapter 5.3
ABB 28.05.2015
1.0.2 Words "Original Instructions" have been added to document title ABB 17.04.2015
Introduction
Document history
2020/06/193ADR025091M0208, 12, en_US6

Rev. Description of version / changes Who Date
1.0.1 Minor typos were corrected. TÜV SÜD certificate was added.
The text was changed in the document:
● Safety I/O inputs and outputs are not electrically isolated from the
other electronic circuitry of the module.
● The safety values for safety outputs of DX581-S (-XC) module are
only valid if the parameter "Detection" is set to "On".
● DC (diagnostic coverage) for DX581-S (-XC) module shall be
≥ 94 %.
● The clarification was added that the boot project update on SM560-S
is possible only if no boot project is loaded on SM560-S.
● Not more than one communication error (CE_CRC or Host_CE_CRC
output signals become equal to TRUE) per 100 hours is allowed to
be acknowledged by the operator using OA_C input signal without
consulting the responsible safety personnel.
● SM560-S cycle time shall be included three times instead of two
times in Safety Function Response Time calculation.
● The values for input delay accuracy in Safety Function Response
Time calculation were updated.
● Update of Appendix A with system data for AC500-S-XC.
ABB 08.03.2013
1.0.0 First release ABB 19.12.2012
1.3 Validity
The data and illustrations found in this documentation are not binding. ABB reserves the right to
modify its products in line with its policy of continuous product development.
1.4 Important user information
This documentation is intended for qualified personnel familiar with functional safety. You must
read and understand the safety concepts and requirements presented in this safety user
manual prior to operating AC500-S safety PLC system.
The following special notices may appear throughout this documentation to warn of potential
hazards or to call attention to specific information.
DANGER!
The notices referring to your personal safety are highlighted in the manual by
this safety alert symbol, which indicates that death or severe personal injury
may result if proper precautions are not taken.
NOTICE!
This symbol of importance identifies information that is critical for successful
application and understanding of the product. It indicates that an unintended
result can occur if the corresponding information is not taken into account.
Introduction
Important user information
2020/06/19 3ADR025091M0208, 12, en_US 7

1.5 Definitions, expressions, abbreviations
1oo2 One-out-of-Two safety architecture, which means that it includes two channels
connected in parallel, such that either channel can process the safety function.
AC500 ABB non-safety PLC
AC500-XC ABB non-safety PLC suitable for extreme environmental conditions
AC500-S ABB safety PLC for applications up to SIL 3 (IEC 61508), SILCL 3 (IEC 62061)
and PL e (ISO 13849-1)
AC500-S-XC ABB safety PLC for applications up to SIL 3 (IEC 61508), SILCL 3 (IEC 62061)
and PL e (ISO 13849-1) suitable for extreme environmental conditions
ADC Analog to digital converter
AOPD Active opotoelectronic protective device
Automation
Builder
Integrated engineering suite for ABB PLCs, including IEC 61131-3 editor
CODESYS
CCF Common cause failure
Control
Builder Plus
PS501
Integrated engineering suite for ABB PLCs, including IEC 61131-3 editor
CODESYS, predecessor of Automation Builder
CPU Central processing unit
CRC Cyclic redundancy check. A number derived from and stored or transmitted
with a block of data in order to detect data corruption.
DC Diagnostic coverage
DPRAM Dual-ported random access memory
IEC International electro-technical commission standard
EDM External device monitoring signal, which reflects the state transition of an
actuator
EMC Electromagnetic compatibility
EN European norm (european standard)
EPROM Erasable programmable read-only memory
ESD Electro static discharge
ESPE Electro-sensitive protective equipment (for example a light curtain)
F-Host Data processing unit that is able to perform a special protocol and to service
the "black channel" Ä [3]
F-Device Passive communication peer that is able to perform the special protocol, usu-
ally triggered by the F-Host for data exchange Ä [3]
F-Parameter Fail-safe parameter as defined in
Ä [3]
FAQ Frequently asked questions
FB Function block
FBD Function block diagram (IEC 61131 programming language)
Flash
memory
Non-volatile computer storage chip that can be electrically erased and reprog-
rammed
FV Fail-safe value
GSDML Generic station description markup language
ID Identification
IO controller Controller that controls the automation task in PROFINET context
Introduction
Definitions, expressions, abbreviations
2020/06/193ADR025091M0208, 12, en_US8

IO device Field device, monitored and controlled by an IO controller in PROFINET con-
text
iParameter Individual safety device parameter
LAD Ladder logic diagram (IEC 61131 programming language)
Loop-back The programmable routing feature of a bus device re-routes unintentionally an
F-Host message back to the F-Host, which expects a message of the same
length (refer to www.profisafe.net for further details).
LSB Least significant bit
MSB Most significant bit
MTBF Mean time between failures
MTTF Mean time to failure
Muting Muting is the intended suppression of the safety function. This is required, e.g.
when transporting the material into the danger zone.
NC Break contact. Normally-closed contacts disconnect the circuit when the relay
is activated; the circuit is connected when the relay is inactive.
NO Make contact. Normally-open contacts connect the circuit when the relay is
activated; the circuit is disconnected when the relay is inactive.
OEM Original equipment manufacturer
OSSD Output signal switching device
Passivation The passivation is the special state of safety I/O modules which leads to the
delivery of safe substitute values, which are ‘0’ values in AC500-S, to the
safety CPU.
PC Personal computer
PELV Protective extra low voltage
PES Programmable electronic system (refer to IEC 61508)
PFD Probability of failure on demand
PFH Probability of failure per hour
PL Performance level according to ISO 13849-1
PLC Programmable logic controller
POU Program organization unit
PROFIsafe Safety-related bus profile of PROFIBUS DP/PA and PROFINET IO for commu-
nication between the safety program and the safety I/O in the safety system
PROFINET Industrial technical standard for data communication over Industrial Ethernet
Proof Test
Interval
The proof test is a periodic test performed to detect failures in a safety-related
system so that, if necessary, the system can be restored as close as possible
to its previous new state. The time period between these tests is the proof test
interval.
PS Programming system
PTC Positive temperature coefficient
RAM Random access memory
Reintegration It is the process of switching from substitute values "0" to the process data.
Safety vari-
able
It is a variable used to implement a safety function in a safety-related system
SCA Safety code analysis - ABB software tool to automatically check CODESYS
Safety programming rules
SD card Secure digital memory card
Introduction
Definitions, expressions, abbreviations
2020/06/19 3ADR025091M0208, 12, en_US 9

SELV Safety extra low voltage
SFRT Safety function response time
SIL Safety integrity level (IEC 61508)
SILCL SIL claim limit (IEC 62061)
ST Structured text (IEC 61131 programming language)
SVT Safety Verification Tool - ABB software tool to verify the AC500-S safety config-
uration in Automation Builder
TÜV Technischer Überwachungs-Verein (technical inspection association)
TWCDT Total worst case delay time
ULP Unit in the last place, which is the spacing between floating-point numbers, i.e.,
the value the least significant bit represents if it is 1 (refer to
http://en.wikipedia.org/wiki/Unit_in_the_last_place for more details).
WLAN Wireless local area network
1.6 Functional safety certification
The AC500-S safety modules are safety-related up to SIL 3 according to IEC 61508:2010,
SILCL 3 according to IEC 62061:2015 and performance level e according to ISO 13849-1:2015,
as certified by TÜV SÜD Rail GmbH (Germany).
The AC500-S is a safety PLC which operation reliability is significantly improved compared to a
non-safety PLC using 1oo2 redundancy in the hardware and additional diagnostic functions in
its hardware and software. The embedded safety integrity diagnostic functions are based on the
safety standards current at the time of certification Ä TÜV SÜD Rail Certification Report for
AC500-S [2]. These safety integrity tests include test routines, which are run during the whole
operating phase, making the AC500-S safety PLC suitable for the safety machinery and
process applications up to SIL 3 according to IEC 61508:2010, SILCL 3 according to
IEC 62061:2015 and performance level e according to ISO 13849-1:2015.
NOTICE!
Please refer to TÜV SÜD Rail Certification Report for AC500-S Ä [2] for a com-
plete list of standards and further details, like versions of standards, etc.
The proof test interval for the AC500-S safety PLC is set to 20 years.
PFH, PFD, MTTFd, category and DC values from IEC 61508:2010, IEC 62061:2015 and
ISO 13849-1:2015 for AC500-S safety modules satisfy SIL 3, SILCL 3 and PL e requirements
Ä Chapter 2.4 “Safety values” on page 17.
Introduction
Functional safety certification
2020/06/193ADR025091M0208, 12, en_US10

1.7 References / related documents
[1] - Creation of safety-oriented applications with CODESYS V2.3 - Document version 1.8
[2] - TÜV SÜD Rail Certification Report for AC500-S Safety PLC, Version - 2018 (or newer),
available at www.abb.com/plc
[3] - PROFIsafe - Profile for Safety Technology on PROFIBUS DP and PROFINET IO Profile
part, related to IEC 61784-3-3, Version 2.4, March, 2007 (or newer)
[4] - AC500 user documentation for Automation Builder / Control Builder Plus, available at
www.abb.com/plc
[5] - IEC 61131, 2003 (or newer), Programmable Controllers, Part 3 - Programming Lan-
guages
[6] - Computer Science and Engineering at University of California, Riverside, Chapter 14,
Ch14_Floating Point Calculations and its drawbacks.pdf
[7] - User Examples with PLCopen Safety Functions, Version 1.0.1, 2008 (or newer)
[8] - PROFIsafe System Description, Version - Nov. 2007 (or newer)
[9] - PLCopen Safety: Concepts and Function Blocks, Version 1.0, 2006 (or newer)
[10] - ISO 13849-1: Safety of machinery - Safety-related parts of control systems - Part 1: Gen-
eral principles for design, 2015 (or newer)
[11] - PROFIBUS Guideline: PROFIsafe - Environmental Requirements, V2.5, March 2007 (or
newer)
[12] - PROFIBUS Guideline: Communication Function Blocks on PROFIBUS DP and
PROFINET IO, V2.0, November 2005. Order No. 2.182 (or newer)
1.8 Applicable standards
Standard Date Title
IEC 61508 2010 Functional safety of electrical/electronic/programmable elec-
tronic safety-related systems
IEC 62061 2015 Safety of machinery - Functional safety of safety-related elec-
trical, electronic and programmable electronic control systems
ISO 13849-1 2015 Safety of machinery - Safety-related parts of control systems -
Part 1: General principles for design
IEC 60204-1 2016 Safety of machinery - Electrical equipment of machines - Part
1: General requirements
IEC 61496-1 2012 Safety of machinery - Electro-sensitive protective equipment
IEC 61511-1 2016 Functional safety - Safety instrumented systems for the
process industry sector - Part 1: Framework, definitions,
system, hardware and software requirements
IEC 61326-3-1 2017 EMC for functional safety
IEC 61131-2 2007 Programmable controllers - Part 2: Equipment requirements
and tests
ISA-71.04-2013
Harsh group A
2016 Environmental Conditions for Process Measurement and Con-
trol Systems - Airborne Contaminants
IEC 60721-3-3 2002 Classification of environmental conditions - Part 3-3: Classifi-
cation of groups of environmental parameters and their severi-
ties - Stationary use at weather protected locations
CISPR 16-1-2 2014 Specification for radio disturbance and immunity measuring
apparatus and methods - Part 1-2: Radio disturbance and
immunity measuring apparatus - Ancillary equipment - Con-
ducted disturbances
Introduction
Applicable standards
2020/06/19 3ADR025091M0208, 12, en_US 11

Standard Date Title
CISPR 16-2-1 2017 Specification for radio disturbance and immunity measuring
apparatus and methods - Part 2-1: Methods of measurement
of disturbances and immunity - Conducted disturbance meas-
urements
CISPR 16-2-3 2016 Specification for radio disturbance and immunity measuring
apparatus and methods - Part 2-3: Methods of measurement
of disturbances and immunity - Radiated
IEC 61000-4-2 2008 Electromagnetic compatibility (EMC) - Part 4-2: Testing and
measurement techniques - Electrostatic discharge immunity
test
IEC 61000-4-3 2010 Electromagnetic compatibility (EMC) - Part 4-3: Testing and
measurement techniques - Radiated, radio-frequency, electro-
magnetic field immunity test
IEC 61000-4-4 2012 Electromagnetic compatibility (EMC) - Part 4-4: Testing and
measurement techniques - Electrical fast transient/burst
immunity test
IEC 61000-4-5 2017 Electromagnetic compatibility (EMC) - Part 4-5: Testing and
measurement techniques - Surge immunity test
IEC 61000-4-6 2013 Electromagnetic compatibility (EMC) - Part 4-6: Testing and
measurement techniques - Immunity to conducted distur-
bances, induced by radio-frequency fields
IEC 61000-4-8 2009 Electromagnetic compatibility (EMC) - Part 4-8: Testing and
measurement techniques - Power frequency magnetic field
immunity test
EN 55011 2016 Industrial, scientific and medical equipment - Radio-frequency
disturbance characteristics - Limits and methods of measure-
ment (CISPR 11:2015, modified)
IEC 60715 2017 Dimensions of low-voltage switchgear and controlgear -
Standardized mounting on rails for mechanical support of
switchgear, controlgear and accessories
IEC 60068-2-1 2009 Environmental testing - Part 2-1: Tests - Test A: Cold
IEC 60068-2-6 2007 Environmental testing - Part 2-6: Tests - Test Fc: Vibration
(sinusoidal)
IEC 60068-2-27 2008 Environmental testing - Part 2-27: Tests - Test Ea and guid-
ance: Shock
IEC 60068-2-30 2005 Environmental testing - Part 2-30: Tests - Test Db: Damp heat,
cyclic (12 + 12 h cycle)
IEC 60068-2-52 2017 Environmental testing - Part 2-52: Tests - Test Kb: Salt mist,
cyclic (sodium chloride solution)
IEC 60068-2-64 2008 Environmental testing - Part 2-64: Tests - Test Fh: Vibration,
broadband random and guidance
IEC 60068-2-78 2012 Environmental testing - Part 2-78: Tests - Test Cab: Damp
heat, steady state
NOTICE!
Contact ABB technical support for further details.
Introduction
Applicable standards
2020/06/193ADR025091M0208, 12, en_US12

—
2 Overview of AC500-S safety PLC
2.1 Overview
The AC500-S is realized as 1oo2 system (both safety CPU and safety I/O modules) and can be
used to handle safety functions with SIL 3 (IEC 61508), SILCL 3 (IEC 62061) and PL e
(ISO 13849-1) requirements in high-demand systems of safety machinery applications and low-
demand systems of safety process applications. 1oo2 system includes two microprocessors.
Each of them executes the safety logic in its own memory area and both compare the results of
the execution at the end of each cycle. If a mismatch in the execution or an error is detected,
the system goes to a safe state, which is described for each of the safety modules separately.
2.1.1 System
The AC500-S safety PLC is an integrated part of AC500 platform with a real common look &
feel engineering approach. Due to a tight integration in AC500 PLC platform, the generic AC500
system characteristics (mechanics, programming, configuration etc.) are also valid for AC500-S
safety modules.
All non-safety AC500 modules are considered to be interference-free modules for AC500-S
safety PLC. In contrast to safety modules, interference-free modules are not used to perform
safety functions. A fault in one of these modules does not influence the execution of the safety
functions in a negative way.
The term "integrated safety" applied for AC500-S safety PLC and AC500 platform means:
● One PROFINET IO fieldbus is used for safety and non-safety communication.
● The same engineering environment with real look & feel is used for both safety and non-
safety programming.
● The same hardware and wiring look & feel is used within safety and non-safety modules.
● The same diagnostics concept is used for safety and non-safety modules.
Overview of AC500-S safety PLC
Overview > System
2020/06/19 3ADR025091M0208, 12, en_US 13

Fig. 1: Overview on ABB’s AC500 family with safety and non-safety modules
1Non-safety communication module
AC500 covers all common communications standards, such as Ethernet, EtherCAT,
PROFINET IO, PROFIBUS DP, CANopen, DeviceNet, Modbus TCP, Modbus serial, Serial,
ABB CS31 and PROFIsafe via PROFINET. Combinable to form optimally scaled network
nodes, ABB’s AC500 is suitable for both small-scale applications and large-scale industrial
systems.
2Safety CPU
Safety CPUs certified up to SIL 3 (IEC 61508), SILCL 3 (IEC 62061) and PL e
(ISO 13849-1). An array of features such as system diagnostics provided via LEDs and
onboard display of non-safety CPUs provides the added diagnostic concept required for
integrated safety.
3Non-safety CPU
ABB’s complete AC500 range of non-safety CPUs can be used with safety CPU to create
customized solutions - even for the most challenging requirements. The programming of
safety and non-safety applications is offered via a non-safety PLC interface.
4Safety I/O module
Safety I/O modules certified up to SIL 3 (IEC 61508), SILCL 3 (IEC 62061) and PL e
(ISO 13849-1). Features such as channel-wise error diagnostics and the flexibility to choose
between channel-wise or module switch-off in case of channel error make working safely
easier.
5Non-safety I/O module
With ABB’s non-safety I/O modules, the complete S500 and S500-eCo I/O module range
can be connected to the non-safety PLC. A wealth of functions in AC500 configurable I/O
modules allows getting the customized and low-priced solutions to optimize industrial appli-
cations.
2.1.2 Safety components
The AC500-S safety PLC includes the following safety-related hardware components.
Overview of AC500-S safety PLC
Overview > Safety components
2020/06/193ADR025091M0208, 12, en_US14

SM560-S
DIAG
PWR
RUN
I-ERR
E-ERR
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
ADDR
x10H
ADDR
x01H
Safety CPU (safety module) for up to SIL 3 (IEC 61508), SILCL 3 (IEC 62061) and PL e
(ISO 13849-1) safety applications.
DI581-S
UP 24VDC 5W 16SDI
Safety Digital Input 24VDC
3.8UP
3.9ZP
3.7
3.0T4
3.1
3.2T5
3.3
3.5
3.4T6
3.6T7
ERR2
4.9ZP
4.2I10
4.0I8
4.1I9
4.3I11
4.4I12
4.5I13
4.6I14
4.7I15
4.8UP
ERR1
2.9ZP
2.2I2
2.0I0
2.1I1
2.3I3
2.4I4
2.5I5
2.6I6
2.7I7
2.8UP
PWR
1.9ZP
1.8UP
1.7
1.0T0
1.2T1
1.3
1.1
1.5
1.4T2
1.6T3
ADDR
x01H
ADDR
x10H
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
Safety binary input module DI581-S with 16 safety input channels (up to SIL 2 or PL d) or 8
safety input channels (up to SIL 3 or PL e) with 8 test pulse output channels.
DX581-S
3.8UP
3.9ZP
3.7
3.0T2
3.1
3.2T3
3.3
3.5
3.4
3.6
UP 24VDC 100W 8SDI 8SDO
Safety Digital Input 24VDC
Safety Digital Output 24VDC 0.5A
ERR2
4.9ZP
4.2I6
4.0I4
4.1I5
4.3I7
4.4O4
4.5O5
4.6O6
4.7O7
4.8UP
ERR1
2.9ZP
2.2I2
2.0I0
2.1I1
2.3I3
2.4O0
2.5O1
2.6O2
2.7O3
2.8UP
PWR
1.9ZP
1.8UP
1.7
1.0T0
1.2T1
1.3
1.1
1.5
1.4
1.6
ADDR
x10H
ADDR
x01H
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
Safety binary input/output module DX581-S with 8 safety output channels (up to SIL 3 or PL e)
and 8 safety input channels (up to SIL 2 or PL d) or 4 safety input channels (up to SIL 3 or PL e)
with 4 test pulse output channels.
SM560-S /
SM560-S-FD-1 /
SM560-S-FD-4
DI581-S
DX581-S
Overview of AC500-S safety PLC
Overview > Safety components
2020/06/19 3ADR025091M0208, 12, en_US 15

AI581-S
UP 24VDC 2W 4SAI
Safety Analog Input
3.8UP
3.9ZP
3.4
3.7
3.0I2-
3.1FE
3.2I3-
3.3FE
3.5
3.6
ERR1
2.9ZP
2.8UP
2.3
2.4
2.5
2.1
2.7
2.6
2.2I1+
2.0I0+
ERR2
4.9ZP
4.8UP
4.7
4.2I3+
4.0I2+
4.6
4.5
4.4
4.3
4.1
PWR
1.9ZP
1.8UP
1.7
1.4
1.0I0-
1.2I1-
1.3FE
1.1FE
1.5
1.6
ADDR
x10H
ADDR
x01H
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
C
4
3
B
2
A
1
9
08
F
7
E
6
D
5
Safety analog input module AI581-S with 4 safety current input channels 0 ... 20 mA (up to
SIL 2 or PL d) or 2 safety current input channels (up to SIL 3 or PL e).
The following interference-free component shall be used for mounting safety I/O modules:
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
2.9
3.0
3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
3.9
4.0
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
Spring-type terminal unit TU582-S for safety I/O modules.
2.2 Intended use
The user shall coordinate usage of ABB AC500-S safety components in his applications with
the competent authorities and get their approval. ABB assumes no liability or responsibility for
any consequences arising from the improper use:
● Non-compliance with standards and guidelines
● Unauthorized changes to equipment, connections and settings
● Use of unauthorized or improper equipment
● Failure to observe the safety instructions in this guide
AI581-S
TU582-S
Overview of AC500-S safety PLC
Intended use
2020/06/193ADR025091M0208, 12, en_US16

2.3 Safety loop
The safety loop, to which the AC500-S safety PLC belongs, consists of the following three parts:
sensors, safety PLC and actuators.
~35 % of safety loop PFH ~1 5 % of safety loop PFH ~50 % of safety loop PFH
Safety loop
Safety PLC
Sensor Safety CPU
Module
Safety Input
Module
Safety Output
Module Actuator
Fig. 2: Typical safety loop with AC500-S safety PLC
For the calculation of the PFH/PFD values of an exemplary safety system, a maximum of 15 %
is assumed for the safety PLC.
2.4 Safety values
Table 1: The following safety values shall be used for AC500-S safety modules:
Type SIL(1)
SILCL(2)
PL(3) DC(4) MTTFd(5) PFHd(6) PFHd(7) PFDg(8) T1(9) SFF(10) b(11)
SM560-S(-XC) /
SM560-S-FD-1(-
XC) / SM560- S-
FD-4(-XC)
3 e 97 1280 1.90E-09 8.95E-11 7.90E-06 20 98 2
AI581-S(-XC) 3 e 97 920 2.95E-09 4.50E-10 3.80E-05 20 99 2
DI581-S(-XC) 3 e 95 2270 1.45E-09 4.40E-10 3.70E-05 20 98 2
Inputs of
DX581-S(-XC)
3 e 94 2250 1.45E-09 4.50E-10 3.80E-05 20 98 2
Outputs of
DX581-S(-XC)
with parameter
Detection =
"On"
3 e 94 1985 1.60E-09 4.50E-10 3.80E-05 20 99 2
Outputs of
DX581-S(-XC)
with parameter
Detection = "Off"
2 d 85 200 1.19E-08 1.08E-08 4.70E-04 20 on
request
2
Overview of AC500-S safety PLC
Safety values
2020/06/19 3ADR025091M0208, 12, en_US 17

(1) - SIL (safety integrity level) according to IEC 61508
(2) - SILCL (safety integrity level claim limit) according to IEC 62061
(3) - PL (performance level) according to ISO 13849-1
(4) - Diagnostic coverage, % (refer to ISO 13849-1)
(5) - Mean time to failures (years) dangerous according to ISO 13849-1
(6) - Probability of dangerous failure per hour according to IEC 62061
(7) - Probability of dangerous failure per hour according to IEC 61508 (High demand mode)
(8) - Average probability of failure to perform its design function on demand according to
IEC 61508 (Low demand mode)
(9) - Proof test interval - mission time - lifetime years
(10) - SFF (safe failure fraction), % according to IEC 61508
(11) -b (beta factor), % for common cause failures according to IEC 61508
DANGER!
The average temperature (MTBF calculation base) for both the extended tem-
perature range (-40 ... +70 °C) as well as for normal temperature range
(0 ... +60 °C) is defined to +40 °C.
Ensure that average operating temperature for used AC500-S modules does
not exceed +40 °C.
2.5 Qualified personnel
AC500-S safety PLC may only be set up and used in conjunction with this documentation.
Safety application engineer of AC500-S safety PLC
Commissioning and operation of AC500-S safety PLC may only be performed by the qualified
personnel who is authorized to commission safety devices, systems and circuits in accordance
with established functional safety practices and standards.
The following basic knowledge of AC500 system is required to correctly understand this
AC500-S safety user manual:
● AC500 automation system
● Automation Builder / Control Builder Plus programming environment (system configuration
and programming in ST, LAD and FBD programming languages).
2.6 Lifecycle
All AC500-S safety modules have a maximum life of 20 years. This means that all AC500-S
safety modules shall be taken out of service or replaced by new AC500-S safety modules at
least one week before the expiry of 20 years (counted from the date of delivery by ABB).
2.7 Installation of safety modules
The following rules shall be taken into account for installing safety modules:
● The installation must be done according to the documentation with appropriate facilities and
tools.
● The installation of the devices may be done only in de-energized condition and carried out
by the qualified personnel.
Overview of AC500-S safety PLC
Installation of safety modules
2020/06/193ADR025091M0208, 12, en_US18

● The general safety regulations and applicable national safety regulations shall be strictly
observed.
● The electrical installation shall be carried out in accordance with relevant regulations.
● Take the necessary protective measures against static discharge.
2.8 Exchange of modules
SM560-S / SM560-S-FD-1 / SM560-S-FD-4 safety CPU automatically detects an exchange of
safety I/O modules during the system start-up. The overall system (safety CPU and PROFIsafe
features of unique addresses for safety devices Ä [3]) provides a mechanism to automatically
ensure that exchanged safety modules are operated with correct parameters and incompatible
module types are rejected. No unsafe state is possible if wrong safety I/O module type is put on
the given terminal unit TU582-S.
2.9 AC500-S restart behavior
When SM560-S / SM560-S-FD-1 / SM560-S-FD-4 safety CPU is restarted using powering
off/on, the previously saved error information is lost. The safety I/O modules receive their
parameter sets each time during system start-up. The safety CPU is able to reintegrate safety
I/O modules using PROFIsafe start-up behavior
Ä [3]. If your process does not allow an
automatic start-up after powering off/on, you must program a restart protection in the safety pro-
gram. The safety process data outputs must be blocked until manually acknowledged. These
safety outputs must not be enabled until it is safe to do so and faults were corrected.
2.10 Replacing AC500-S safety PLC components
When replacing software components on your programming device or PC with a newer version,
you must observe the notes regarding upward and downward compatibility in the documentation
and readme files for these products.
Hardware components for AC500-S (safety CPU and safety I/Os) are replaced in the same way
as in a non-safety AC500 automation system.
2.11 Environmentally friendly disposal
All AC500-S safety components from ABB are designed with a minimal environment pollution
effect. To enable environmentally friendly disposal of AC500-S safety components, they can be
partially disassembled to separate various components from each other. Disposal of those
materials shall be done in accordance with applicable national and international laws.
2.12 Safe communication
Safety data are transferred between safety CPU and safety I/Os using PROFIsafe profile Ä [3].
SM560-S / SM560-S-FD-1 / SM560-S-FD-4 safety CPU needs a non-safety CPU to communi-
cate to safety I/O modules. All safety-related communication takes place through the non-safety
CPU using a "black channel" principle of data transmission
Ä [3].
The communication of safety CPU to remote safety I/O modules is done using PROFINET IO
field bus with a PROFIsafe profile for safe data transmission Ä [3]. Safety and non-safety I/O
modules can be mixed on a local I/O bus both in central and remote configuration. PROFINET
IO controller communication module (CM579-PNIO) shall be used on non-safety CPUs as a part
of the "black channel" to transfer safety data to PROFINET IO devices. PROFINET devices
CI501, CI502, CI504 and CI506 can be used to attach safety I/O modules in remote configura-
tions.
Overview of AC500-S safety PLC
Safe communication
2020/06/19 3ADR025091M0208, 12, en_US 19

Fig. 3: Possible AC500-S system setup with PROFINET/PROFIsafe for remote safety I/Os, sensors and actuators
PROFINET/PROFIsafe communication between AC500-S safety CPUs is supported using
CM589-PNIO(-XC) and/or CM589-PNIO-4(-XC) PROFINET IO device communication modules
together with SM560-S-FD-1(-XC) and/or SM560-S-FD-4(-XC) safety CPUs with F-Device func-
tionality on one side and CM579-PNIO(-XC) with any AC500-S safety CPU on the other side
(Fig. 4 on page 21). SM560-S-FD-1(-XC) and SM560-S-FD-4(-XC) safety CPUs are able to
exchange up to 384 bytes of safety data with F-Hosts (3rd party PROFIsafe F-Hosts are sup-
ported as well) using PROFINET/PROFIsafe. SM560-S-FD-1(-XC) with F-Device(s) supports
safe communication to maximum one F-Host. SM560-S-FD-4(-XC) with F-Device(s) supports
safe communication to maximum four F- Hosts. Fig. 4 shows that using SM560-S-FD-1 and
SM560-S-FD-4 safety CPUs with additional F-Device functionality one can establish safe CPU
to CPU communication between different control stations on PROFINET/PROFIsafe. SM560-S-
FD-4 safety CPUs can simultaneously communicate not only with 1 IO controller/F-Host
(Master) but with up to 4 IO controllers/F-Hosts (Masters). In addition to SM560-S-FD-1 and
SM560-S-FD-4 safety CPUs, CM589-PNIO and CM589-PNIO-4 PROFINET IO device commu-
nication modules are needed to establish PROFINET connectivity as "black channel", respec-
tively, to 1 or up to 4 PROFINET IO controllers.
Overview of AC500-S safety PLC
Safe communication
2020/06/193ADR025091M0208, 12, en_US20
