ABC Kliima ELK 9M User guide

01.12.2017
ELK 9M
Installer manual
Immersion heater

List of contents
Important information________________________ 4
General __________________________________ 4
Assembly_________________________________ 5
Component positions________________________ 5
Pipe connections___________________________ 6
Electrical connection ________________________ 8
Activating ELK 9M_________________________ 10
Technical data ____________________________ 11

4ELK 9M
Important information
Recovery
Leave the disposal of the packaging to
the installer who installed the product or to
special waste stations.
Do not dispose of used products with nor-
mal household waste. It must be disposed
NOTE
This symbol indicates danger to machine or person.
CAUTION
This symbol indicates important information about
what you should observe when maintaining your in-
stallation.
TIP
This symbol indicates tips on how to facilitate using
the product.
WARNING
This symbol indicates serious danger to person or ma-
chine.
of at a special waste station or dealer who provides
this type of service.
Improper disposal of the product by the user results
in administrative penalties in accordance with current
legislation.
General
ELK 9M is an electric heater that can be used to sup-
plement the heating capacity of your MHI climate unit.
When the heating demand is greater than the climate
unit’s capacity, the electric heater connects automat-
ically. The electrical equipment is adapted to the cli-
mate unit’s function.
The electric heater is in principle an immersion heat-
er mounted in a water container or an electric boiler
without a water heater. The steel electric coils and
electric boiler tube are made of steel which gives a
very good service life.
Thanks to a small water volume and a well-insulated
electrical heater, ELK 9M has very small heat losses.
Compatible products
Connection is di󰀨erent depending on which product
ELK 9M is to be used with.
These products can be connected directly to ELK 9M:
• RC-HY 20
• RC-HY 40
Contents
1 x Immersion heater

5ELK 9M
Assembly
The electric heater must be installed upright (see im-
age below).
Free space of 500 mm is required in front of the water
heater for service. If this is not possible, detachable
connections must be used.
Component positions
Component list
EB1 Immersion heater
FD1 Overheat protection
X1 Terminal block
QA1 Contactor 3,0 kW(-K1)
QA2 Contactor 6,0 kW(-K2)
BT30 Emergency mode thermostat
XL1 Connection supply line, G 32
XL2 Connection return line, G 32
UB1, UB2 Cable gland
QM60 Venting
PF1 Rating plate
XL1
EB1
XL2
UB1
UB2
PF1
X1
QA1
QA2
BT30
FD1
QM60

6ELK 9M
Pipe connections
General
The pipe installation must be carried out in accor-
dance with applicable standards.
A circulation pump must be used to ensure the ow
over the immersion heater. If the heating system
valves can close the circulation completely, the by-
pass valve must be installed so that the ow through
the electric heater does not stop. In closed installa-
tions an approved safety valve and pressure expan-
sion vessel must be used.
NOTE
The pipe work must be ushed before the electric
heater is connected, so that any contaminants do not
damage the component parts.
CAUTION
Also see the installer manual for your heat pump/in-
door module.
Draining
The system is most easily drained by installing a
drainage valve at the lowest point on the pipe instal-
lation. The remaining water in ELK 9M is drained
through the return line connection (XL2), see “Com-
ponent location” on page 5. If the return line connec-
tion on ELK 9M is normally used for draining the unit,
a drain valve can be installed here.
Pressure drop diagram ELK 9M
Flow (l/s)
(kPa)
07,04,03,02,01,00
0,5
1,0
1,5
2,0
2,5
(kPa)
(l/s)
0,60,5

7ELK 9M
System diagram
Explanation
EB1 Electric heater ELK 9M
CM4 Expansion vessel
FL2 Safety valve
QM40 - QM41 Shut o󰀨 valves
RN11 Control valve
GP10 Circulation pump
RM5 Non-return valve
BT25 Flow line sensor
BT71 Return line sensor
Designations in component locations according to
standard IEC 81346-1 and 81346-2.
System diagram
-BT25
-BT71 -GP10
-RM5-QM41
-QM40
-FL2
-CM4
-EB1
Värmepump/
Inomhusmodul
-RN11
Heat pump/
Indoor module
NOTE
This is an outline diagram. Actual installations must be
planned according to applicable standards.

8ELK 9M
Electrical connection
NOTE
All electrical connections must be carried out by an au-
thorised electrician.
Electrical installation and wiring must be carried out in
accordance with the stipulations in force.
The climate unit must not be powered when installing
ELK 9M.
ELK 9M must be installed via a circuit breaker with a
minimum breaking gap of 3mm.
ELK 9M contains overheat protection and two con-
tactors to control the two power steps 3 kW and 6 kW
respectively. For best function the power should be
binary controlled, that is to say 3, 6 and 9 kW.

9ELK 9M
RC-HY 20 and RC-HY 40
Terminal block X1 in ELK 9M connects to the termi-
nal blocks X1 and AA7-X2 in the control module as
illustrated.
9 kW electric heater step active.
Without thermostat, two active power steps
LEK
X1
1 1 0 PE
-X2
1
654321
23456
-X1
AA7- X2
LN234
SMO
ELK
2 3 41 0 PE
J1,2J1,1 J2,2
X9
X1 AA7:X2
ELK
9M
Contr
ol module
X1
X1 AA7- X2
1 2 3 4 5 6
9 kW electric heater step active.
6 kW electric heater step active in emergency mode.
With thermostat, two active power steps
SMO
ELK
2 3 41 0 PE
J1,2J1,18 J2,2
X9
X1 AA7:X2
ELK
9M
Contr
ol module
X1
X1 AA7- X2
1 2 3 4 5 6

10 ELK 9M
Activating ELK 9M
The menu setting of ELK 9M can be performed via
the start guide or directly in the menu system.
CAUTION
Also see the Installer manual for the product that ELK
9M will be connected to.
Start guide
The start guide appears upon rst start-up after heat
pump installation, but is also found in menu 5.7.
Menu system
RC-HY 20 and RC-HY40
Menu 4.9.3 - degree minute setting
Here you select when the additional heat is to start
and the degree minute intervals.
Menu 5.1.12 - addition
Setting:
• Max. number of permitted additional steps
• If binary stepping is to be used.

11ELK 9M
Technical data
Dimensions
All dimensions in mm.
181
128
56
111
244
28
604
144,5
350

12 ELK 9M
Technical specications
IP 44
ELK 9M
Electrical data
Rated voltage V 3 x 400 V ~ 50 Hz
Output immersion heater kW 9
Immersion heater fuse A 13
Enclosure class IP21
Heating medium circuit
Max permitted pressure in the boiler MPa/bar 0,7/7
Min ow l/h 650
Max ow l/h 2600
Dimensions and weight
Width mm 244
Depth mm 111
Height mm 604
Weight kg 10,5
Volume litre 1,5
Miscellaneous
Material immersion heater SIS 2333 EN 1.4301
Material tube P235GH PN-EN 10216-2
Part No. MCD291A015

13ELK 9M
Energy labelling
Information sheet
Supplier MHI
Model ELK 9M
Energy e󰀩ciency class for space heating D
Rated heat output (Pdesignh) kW 9
Annual energy consumption space heating kWh 33 850
Seasonal space heating energy e󰀩ciency % 36,7
Sound power level LWA indoors dB 35
Technical documentation
Model ELK 9M
Condensing boiler Yes No
Low-temperature boiler Yes No
B11 boiler Yes No
Cogeneration space heater Yes No
Combination heater Yes No
Rated heat output Prated 15 kW Seasonal space heating energy ef-
ciency
ƞs36,7 %
For boiler space heaters and boiler combination heaters: Useful
heat output
For boiler space heaters and boiler combination heaters: Useful
eciency
At rated heat output and high-temperatu-
re regime
P415 kW At rated heat output and high-tempe-
rature regime
ƞ440 %
At 30%of rated heat output and low-tem-
perature regime
P1kW At 30%of rated heat output and low-
-temperature regime
ƞ1%
Auxiliary electricity consumption Other items
At full load elmax kW Standby heat loss Pstby 0,2 kW
At part load elmin kW Ignition burner power consumption Pign kW
Standby mode PSB kW Annual energy consumption QHE 33 850 kWh
Sound power level, indoors LWA 35 dB
For combination heaters
Declared load prole for water heating Water heating energy e󰀩ciency ƞwh %
Daily energy consumption Qelec kWh Daily fuel consumption Qfuel kWh
Annual energy consumption AEC kWh Annual fuel consumption AFC GJ

14 ELK 9M
Electrical circuit diagram
-K1 -K2
3x1.5kW +3x1.5kW
Immersion heater
FD1
98-8 °C
400V 3~ 50Hz
L3
L2
L1
PE
K2
K1
J1:2
J1:1
8
J2:1
BT30
5-80 °C
A1A2
A1A2
N
1
3
5
2
4
6
1
3
56
4
2
8 7
X1
