Luminator LED Trio Light Kit
Model 12.5063MS
General Information:
The Luminator LED Trio Light is equipped with an internal flasher. It comes from the factory in a random flash mode.
Product Specifications:
Optimum Operation Voltage: +13.8 VDC
Operating Current: .75 - 1.5 amps
Recommended Fuse: 5 amp
Flash Pattern Selection:
To change flash patterns, momentarily apply +12v to the Yellow "Sync-Mode" Wire for less than 5 seconds.
To reset to factory default pattern, apply +12v to the Yellow "Sync-Mode" Wire for more than 5 seconds.*
Do Not ground YELLOW
When changing flash patterns, you may have to re-start before patterns will sychronize.
Synchronization:
Connect all yellow wires together to synchronize. When wired as shown, the Luminator LED Trio Lights will be
synchronized.
Group Selection:
The White "Group Selection" Wire will determine which lights flash at the same time when you have 2 or more lights.
For Group 1, connect White "Group Selection" wire with Red Power wire.
For Group 2, DO NOT connect White "Group Selection" wire to anything.
Group 1 & Group 2 will alternate.
*Do Not use white wire if using only one light.*
Wiring Instructions:
When wiring, always connect ground wire first and power wire last.
Flash Patterns
1. Single Flash - 134 FPM
2. Double Flash - 268 FPM
3. Quad Flash - 536 FPM
4. Super Flash - 1070 FPM
5. Single-On - 134 FPM
6. Quad-On - 536 FPM
7. Triple Flash - 401 FPM
8. Hyper Flash - 1873 FPM
9. Steady
10. Random 1-8 (Default)
Wire*
09-10-08

Installation Instructions
1a. Luminator LED Trio Light Installation With Bracket (Diagram A)
Drill out the mounting hole, Point A, on each end of the Luminator LED Trio Light to 11/64".
Attach the bracket to desired location using the (2) longer screws.
Then place the Trio Light into the bracket and attach it using the
shorter screws and locknuts. The gasket will not be needed.
1b. Luminator LED Trio Light Installation Without Bracket (Diagram A)
Use Point B. Drill the 2 holes on the mounting surface for the Luminator LED Trio Light using the
Trio Light as a guide. Place the gasket under the Trio Light. Attach the Trio Light using (2)
longer screws provided.
2. Mount Micro Switch in desired location, using double stick tape provided.
3. Connect wires to Micro Switch as shown in "Diagram B".
"A"
End View
"B"
Front View
Diagram "A"
Diagram "B"
SHO-ME
®
Group 2
Group 1
SHO-ME
POWERMODE
Model11.1012
90.6729 AMP CONNECTOR
Red to +12v power source
Black to - ground
SHO-ME ® 11.1012
90.6728
AMP CONNECTOR
SHO-ME ®
Black Wire
White
Wire
Red Wire
Black Wire
YellowWire
Red Wire White Wire
SHO-ME ®
YellowWire
Black Wire Red Wire
White Wire
SHO-ME
Parts Included in Trio Light Kit
Gasket
Part # 90.6743
(2)
Trio Light
Part # 12.5003
(2)
Bracket
Part # 90.4477
(2) Micro Switch
Part # 11.1012
(1)
#90.4590
(4) #90.4140 (4) #90.4021 (4) #90.4410 (2)
®
SHO-ME
POWERMODE
Model11.1012
Double Stick Tape
(2)
