Abocom WG2000 User manual

Doc. No.:070703-01
802.11g Wireless LAN
CardBus PC Card
The 802.11g Wireless LAN CardBus PC Card incorporates the
IEEE802.11g standard‘s mandatory modulation schemes. With 11g,
it is backwards compatible with all the existing 802.11b products
already out there. Better yet, it provides high performance 54Mbps
operation which is required for today’s high-bandwidth.
The 802.11g Wireless LAN CardBus PC Card allows you to take full advantage of your PC’s
mobility with access to real-time information and online services anytime and anywhere. It slides
into the 32-bit CardBus slot to enable a wireless connection to your network. Plus, with the network
installation simplicity and flexibility, you eliminate the need to pull cable through walls and ceilings
and allow the network to go where wires cannot go. Exploring the web and augmenting networks
has never been easier.
FEATURES
 Adds 802.11g wireless capabilities to laptop computers, for faster wireless networking available
for home or office
 Fits any standard 32-bit CardBus slot
 Backward compatible with all
 Supports PC Card hot swap and true Plug & Play
 Capable of up to 128-Bit WEP Encryption
 54 Mbps High-Speed Transfer Rate
 Supports Window 98SE/2000/ME/XP
 Lower power consumption
 Easy to install and configure
SPECIFICATIONS
Standards IEEE 802.11g
Chipset Intersil Frisbee Chipsets
Host Interface 32-bit CardBus
Antenna Patch Antenna
Power Requirement
Operating Voltage: 3.3V
11g: TX: 480mA (Max), RX: 340Ma (Max)
11b: TX: 430mA (Max), RX: 340Ma (Max)
Operating Frequency
Range
USA: 2.412GHz-2.462GHz
Europe: 2.412 GHz-2.472GHz
Japan: 2.412 GHz-2.472GHz
Number of Selectable
Channels
USA, Canada: 11 channels
Europe: 13 channels
Japan: 14 channels
Modulation Technique 11g: 11g Orthogonal Frequency Division Multiplexing (64QAM, 16QAM, QPSK, BPSK)
11b: Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
Security 64/128 bit WEP
Physical Specifications Dimension: 117.6mm(L)*54.1mm(W)*7mm(H)
Weight: < 50 g
Supported OS Windows 98SE/ME/2000/XP
Environment
Specifications
Operating Temperature: 0~65℃ambient temperature
Storage Temperature: -20~75℃ambient temperature
Operating humidity: 95% maximum (non-condensing)
Storage humidity: 95% maximum (non-condensing)
