Abode G2SMFP3001 User manual

IMPORTANT: RETAIN FOR FUTURE REFERENCE
G2SMFP3001
Multi Function Food Processor
User Guide
ASDA G2SMFP3001 Food processor.indd 1 22/06/2012 15:26

WARNINGS:
• IMPORTANT SAFETY INSTRUCTIONS
• PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USE
• RETAIN FOR FUTURE REFERENCE
• When using electrical appliances, basic safety precautions should always be
observed, including the following:
• Read all instructions.
• Avoid contact with moving parts.
• To protect against electrical shock do not immerse cord, plug, or appliance in
water or other liquid.
• Unplug from the mains outlet when not in use, before putting on and taking
off parts, before cleaning.
• Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or is dropped or damaged in any manner. The cord
supplied cannot be replaced. If the cord is damaged the appliance should be
scrapped.
• The use of accessory attachments not recommended by the appliance
manufacturermaycausere,electricshockorinjury.Onlyusethe
accessories supplied by the manufacturer.
• Do not let the cord hang over the edge of the work top, or touch hot surfaces.
• Warning: do not operate the Food Processor for extended periods of time.
The maximum operating time should not exceed 1 minute at a time without a
rest.
• Neverputanyobjectsintotheopeningsontheoutercase.
• Never remove parts from the appliance such as screws.
• Never operate the Food Processor when the bowl is empty and do not
remove the bowl lid before the blades come to a complete stop.
• Donottouchthecuttingbladesorinsertanyobject,suchasknives,forks,
spoons, etc in to the bowl while the Food Processor is in operation.
• Do not operate this appliance for anything other than its intended use.
• This product is intended for household use only. Do not use outdoors. This
product is only intended for preparing food.
• Warning: It is hazardous for anyone other than a competent person to carry
out any service or repair operation which involves the removal of a cover
which gives protection against exposure to electrical parts.
• Warning: Children should not use this appliance. Close supervision is
necessary when any appliance is used near children.
• Warning: This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their
safety. Children should be supervised to make sure they do not play with the
appliance.
2For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 2 22/06/2012 15:26

How to... recognise the parts of your food processor
3
Base
Bowl
Plunger
Drive shaft Rotor mount
Liquidiser
Cutter plate
Liquidiser cap
Steel blade
Slicing cutter
Spatula
Grating cutter
Blade cover
Plastic blade
Lid
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 3 22/06/2012 15:26

IMPORTANT SAFETY INFORMATION
Safety interlock mechanism
ForyoursafetythisFoodProcessorhasbeenttedwithasafetyinterlockmechanismand
will not operate unless correctly assembled.
Pleaseensurethebowlhasbeenpusheddownrmlyontothebaseassemblyandthe
plastic lever on the lid locates correctly into the slot in the base assembly.
The food processor is delivered with the steel blade
andcoverandplasticbladettedtotherotormount.
You will need to disassemble these items before using
the food processor.
Slide the plastic blade off the rotor mount.
Push the steel blade off the rotor mount, ensure the
coverisrmlyttedoverthebladesofthesteelcutter.
How to... disassemble the rotor mount
Before using your food processor: Remove all packaging and check for signs of
damage such as, misaligned or damaged parts, damaged bowl or base, damage to the
bladeorcuttersordamagedpowercordorplug.Ifyoundanydamagedonotusethe
food processor.
4
IMPORTANT SAFETY INFORMATION
CAUTION: The steel blade and slicing cutter both have very sharp blades.
Handlethesecomponentswithcaution.Ensureyoukeepyourngersclearofthecutting
edges when handling these items. When not in use place the steel blade cover over the
steel blade. Take care when washing these items, never leave in a sink or washing bowl
with other items. Always wash separately.
For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 4 22/06/2012 15:26

IMPORTANT: Wash all items apart from the base in hot soapy water before use.
Placethebaseonarmlevelworktopawayfrom
sources of high temperatures or steam.
Never place the food processor near or over a
cooker or other heat producing appliances. Never
place in a heated oven.
IMPORTANT: Always ensure the food processor
is not plugged in before assembling or
disassembling it.
1. Align the drive shaft with the mount on the top of
the base.
2. Push the drive shaft down into the mount on the
base.
3. Slot the bowl onto the base as shown.
Rotate the bowl clockwise until the arrow on the base
is aligned with the padlock symbol on the bowl.
The bowl is now locked on the base.
How to... tthedriveshaftandbowl
5
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 5 22/06/2012 15:26

6
These diagrams show attaching the steel blades
only. The same process can be used for the
plastic blades.
1. Place the rotor mount on a solid level surface. Slot
the blade over the top of the rotor mount.
2. Push the blade down until it locks onto the bottom
of the rotor mount.
Important: The bottom of the blades plastic case
mustbeushwiththebottomoftherotormount.
Your food processor comes with two types of blade.
Steel Blade
This is used to chop food into pieces.
Maximum quantity 300g.
Plastic Blade
This is used to mix liquids or batters.
Up to the maximum mark on the bowl.
How to... use the blades
For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 6 22/06/2012 15:26

4. Slot the lid onto the top of the bowl as shown.
3. Slot the rotor mount over the centre post of the
bowl.
Important: You may need to rotate the rotor mount to
get it to fully slot over the centre post.
5. Rotate the lid clockwise to lock it in place.
Ensure the tab with a padlock symbol on the back of
the lid slots into the recess in the top of the handle.
7
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 7 22/06/2012 15:26

8
7. Wash the food you wish to chop and cut into
suitable sized pieces.
Slot the food into the feeder tube in the top of the lid.
Slot the plunger into the top of the feeder tube on the
lid.
6. Put the food processors plug into a socket and
switch the power on.
8. Choose the speed that you wish to process your
food at.
P- Pulse: This will switch to 0(off) when released.
1- Low speed: Coarsely chopped.
2 - High speed: Finely chopped.
0- Off: Blades stop spinning.
For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 8 22/06/2012 15:26

9
10. Twist the lid anti-clockwise and lift off.
Pull the rotor mount out of the bowl.
9. Oncethefoodhasbeenchoppedtothe
consistency you require turn the power off and
remove the plug.
IMPORTANT: Always remove the plug before
removing the lid from the bowl.
11. Rinse any excess food off the blade and rotor
mount under a tap and shake dry.
Hold the rotor mount upside down and carefully push
thebladeoff,keepingyourngersawayfromthe
cutting edges.
Carefully wash the blade, rotor mount and bowl.
Ensure all of the parts are fully dried before storing
them.
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 9 22/06/2012 15:26

Your food processor comes with two types of cutters.
Slicing Cutter
Thisisusedtonelyslicefood.
Maximum quantity 300g.
Grating Cutter
This is used to grate food.
Maximum quantity 300g.
These diagrams show attaching the grating cutter
only. Follow the same process for attaching the
slicingcutter.Caremustbetakenwhenttingthe
slicing cutter because of the sharp blade.
1. Slot in the cutter over the post on the cutter disc so
the ridge on the back of the cutter locks under cutter
disc.
2. Push the front cutter down until it locks onto the
cutter disk.
How to... use the cutters
10 For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 10 22/06/2012 15:26

IMPORTANT: Always ensure the food processor
is not plugged in before assembling or
disassembling it.
3. Slot the cutter disk onto the top of the drive shaft.
4. Slot the lid onto the top of the bowl as shown.
5. Rotate the lid clockwise to lock it in place.
Ensure the tab with a padlock symbol on the back of
the lid slots into the recess in the top of the handle.
11
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 11 22/06/2012 15:26

6. Slot the food processors plug into a socket and
switch the power on.
7. Wash, if needed, the food you wish to slice or grate
and cut into suitably sized pieces.
Slotthefoodtotthroughthefeedertubeinthetop
of the lid.
8. Slot the plunger into the top of the feeder tube on
the lid. Push the plunger down until all of the food has
been sliced or grated.
12 For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 12 22/06/2012 15:26

9. Choose the speed that you wish to process your
food at.
P- Pulse: This will switch to 0(off) when released.
1- Low speed: Coarsely chopped.
2 - High speed: Finely chopped.
0- Off: Cutters stop spinning.
Now gently push down on the plunger until the food
has been sliced or grated.
10. Oncethefoodhasbeenchoppedtothe
consistency you require turn the power off and
remove the plug.
IMPORTANT: Always remove the plug before
removing the lid from the bowl.
11. Twist the lid clockwise and lift off.
Pull the rotor mount out of the bowl.
13
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 13 22/06/2012 15:26

14
12. Pull the tab on the front of the cutter over the lug
on the front of the cutter disk.
12. Grip the sides of the cutter and lift out of the
recess in the cutter disk.
13. Carefully wash the cutter, cutter plate and bowl.
For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 14 22/06/2012 15:26

15
IMPORTANT: Always ensure the food processor
is not plugged in before assembling or
disassembling it.
1. Removethedriveshaftifitisttedasitisnot
needed for the liquidiser.
How to... use the liquidiser
3. Slot the liquidiser onto the base as shown. Turn
the liquidiser clockwise until the arrow on the base is
aligned with the lock on the liquidiser
2. Slot the cap into the liquidisers lid. Align the tabs
on the sides of the cap with the slots in the lid, push
down and turn clockwise.
Onceyouhaveturnedtheliquidiseroff,thecapcan
be removed and additional food or liquid added.
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 15 22/06/2012 15:26

4. Choose the speed that you wish to liquidise your
food at.
P- Pulse: This will switch to 0(off) when released.
1- Low speed: Coarsely liquidised.
2 - High speed: Finely liquidised.
0- Off: Liquidiser blades stop spinning.
5. After liquidising your food, turn the food processor
off and remove the plug.
Grip the base and handle and turn the liquidiser anti-
clockwise and lift upwards to remove from the base.
6. To open the top of the liquidiser, push the white
thumb catch down and the lid will open.
The contents of the liquidiser can now be poured or
scooped out
Wash the liquidiser out with warn soapy water. Take
care of the blades in the bottom of the liquidiser.
16 For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
ASDA G2SMFP3001 Food processor.indd 16 22/06/2012 15:26

• Before cleaning your food processor always ensure the plug is removed from the power
socket.
• The food processor and liquidiser should never be run with nothing in them, as this may
damage the motor.
• Boiling water or extremely hot water should not be added to the liquidiser.
• Do not immerse the base, power cord or plug in water or any other liquid.
• All items supplied with your food processor, apart from the base, can be washed in
warm soapy water.
• Neverplaceanypartofthettingssuppliedwithyourfoodprocessorinadishwasheras
this could damage them.
• The base can be cleaned using a damp cloth.
• Do not use any abrasive cleaners or materials to clean any part of the food processor as
itmaydamagethenishoftheproduct.
• Never attempt to dry any part of the food processor by placing it near a source of high
heat, such as a cooker or radiator. Always allow the food processor to dry naturally after
wiping with a dry cloth.
How to... clean your food processor
How to... solve common problems
PROBLEM REASON SOLUTION
You have plugged the unit
in, switched the power on,
selected a cutting speed, but
the unit does not work.
The safety lock on the bowl lid
is not fully locked.
The liquidiser is not fully
locked onto the base.
The plug fuse may need
replacing.
Check the safety lock on the
bowl lid.
Check the liquidiser is locked
onto the base.
Change the fuse in the plug.
The blades or cutters are not
working normally.
There is too much food inside
the bowl/liquidiser.
Reduce the quantity of food
inside the bowl/liquidiser.
The unit stops suddenly whilst
in use.
The safety locks on the
bowl/liquidiser are not fully
engaged.
Check the safety lock on the
bowl lid.
Check the liquidiser is locked
onto the base.
Thebowl/liquidiseroverows
whilst in use.
There is too much food inside
the bowl/liquidiser.
The unit is not on a stable and
level surface.
Reduce the quantity of food
inside the bowl/liquidiser.
Place the unit on a stable and
level surface.
17
Visit us at: www.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 17 22/06/2012 15:26

18 For Customer Service & Spare parts call: 08452097461, Mon - Fri 9am to 5pm , Sat 9am to 1pm
Spare parts...
If any parts of your food processor are missing, damage or need replacing please contact
us:
Customer Service & Spare Parts helpline on: 08452097461.
Openingtimes:Monday-Friday9amto5pm&Saturday9amto1pm
Orvisitusat:www.productcareuk.com
Base
Bowl
Plunger
Drive shaft Rotor mount
Liquidiser
Cutter plate
Liquidiser cap
Steel blade
Slicing cutter
Spatula
Grating cutter
Blade cover
Plastic blade
Lid
ASDA G2SMFP3001 Food processor.indd 18 22/06/2012 15:26

19
Visit us at: www.productcareuk.com
Electrical information...
This appliance is designed to operate from a mains supply of AC230V ~ 50HZ.
Check the voltage marked on the product corresponds with your supply voltage.
Thisproductisttedwitha13AplugcomplyingwithBS1363andisttedwiththe
appropriate fuse complying with BS1362.
Always replace the fuse with one of the same rating.
If the plug is unsuitable for your mains socket or needs to be replaced, please note the
following:
IMPORTANT: The wires in the mains lead must be connected as per the following diagram:
Always ensure that the plug cord grip is fastened correctly.
Ifyourapplianceissuppliedwithanon-rewireableplug,youwillndthatitincorporatesa
fuse, the value of which is indicated either on the base of the plug or on the fuse carrier.
Always replace the fuse with one of the same rating. If you need to remove the plug, cut it
from the mains lead and dispose of it.
Never attempt to re-use this plug or insert it into a socket outlet, as there is a very great
risk of electrical shock.
For Customer Service & Spare Parts please call 08452097461
Openingtimes:Monday-Friday9am-5pm&saturday9am-1pm
Orvisitusatwww.productcareuk.com
13A
NEUTRAL
BLUE
CORDGRIP
FUSE
LIVE
BROWN
INSIDE VIEW
ASDA G2SMFP3001 Food processor.indd 19 22/06/2012 15:26

For Customer Services & Spare Parts
please call
08452097461
Openingtimes:Monday-Friday9am-5pm&
Saturday 9am - 1pm
Orvisitusat
www.productcareuk.com
Revision 1
This symbol is known as the ‘Crossed-out wheelie bin Symbol’. When this symbol is marked
on a product/batteries, it means that the product/batteries should not be disposed of with your
generalhouseholdwaste.Onlydiscardelectrical/electronic/batteryitemsinseparatecollec-
tion schemes, which cater for the recovery and recycling of materials contained within. Your
co-operation is vital to make sure the success of these schemes and for the protection of the
environment. For your nearest disposal facility, visit www.recycle-more.co.uk or ask in store
for details.
We reserve the right due to possible changes to design to alter the instruction manual without
prior notice.
For Customer Service & Spare Parts please call 08452097461
Openingtimes:Monday-Friday9am-5pm&saturday9am-1pm
Orvisitusatwww.productcareuk.com
ASDA G2SMFP3001 Food processor.indd 20 22/06/2012 15:26
