Absolute Process Instruments API 4400 G User manual

DC to DC Math Function Transmitters, Isolated API 4400 G through API 4408 G
Input: 0-100 mV to 0-10 VDC or 0-1 mA to 0-20 mA
Output: 0-1 V to ±10 VDC or 0-1 mA to 4-20 mA
OAdd, Subtract, or Average up to 4 DC Inputs
OFactory Set Custom I/O Ranges
OEasy-to-Install Plug-In Design
OFull 2000 V Input/Output/Power Isolation
OInput and Output LoopTracker®LEDs
OOutput Test Button
QAdd, Subtract, Average Flow Signals
QAverage Multiple Signals
Applications
Description
The API 4400 G through API 4408 G are factory configured to
accept two to four DC voltage or current inputs and provide
an optically isolated DC voltage or current output that is pro-
portional to the sum, average and/or difference of the inputs
depending on the model.
The A, B, C, and D inputs should be the same type, and mixed
input ranges are allowable. Consult the factory when selecting
mixed input ranges.
Inputs are converted to a percentage and then the math
function is applied. Consult the factory if true voltage math
is required.
The API 4400 G series uses no transformers or choppers in the
signal path for best noise immunity and freedom from AC arti-
facts in the output. The inputs are not isolated from each other
and use the same signal common connection. The modules do
features full 3-way (input, output, power supply) isolation. A
wide bandwidth 1 millisecond response model is available for
high-speed applications.
Common ranges as well as custom ranges are possible.
Consult the factory for assistance with special ranges.
LoopTracker
API exclusive features include two LoopTracker LEDs (green for
input, red for output) that vary in intensity with changes in the
process input and output signals. These provide a quick visual
picture of your process loop at all times and can greatly aid in
saving time during initial startup and/or troubleshooting.
Output Test
An API exclusive feature includes the Functional Test Button
to provide a fixed output (independent of the input) when held
depressed. The output test level is adjustable from 0 to 100%
of output span.
The functional test button greatly aids in saving time during
initial startup and/or troubleshooting.
Installation
The API 4400 G through API 4408 G plug into an industry stan-
dard 11-pin octal socket sold separately. Sockets API 011 and
finger-safe API 011 FS allow either DIN rail or panel mounting.
The plug-in design, 3-way isolation, and robust electronics
allows the module to be quickly hot-swapped without removing
the power or I/O signals.
DC Input Ranges
Factory configured, please specify each input range
Minimum Maximum
Voltage: 0-100 mVDC 0-10 VDC
Bipolar voltage: ±100 mVDC ±10 VDC
Current: 0-1 mADC 0-20 mADC, 4-20 mA
Popular ranges: 0-1 VDC, 0-5 VDC, 1-5 VDC, 0-10 VDC,
±5 VDC, ±10 VDC, 0-20 mA, 4-20 mA
System voltages must not exceed socket voltage rating
Inputs are converted to a percentage and then the math
function is applied. Consult factory for mixed ranges, special
ranges or non-standard functions.
Input Impedance
Voltage: 100 kΩper volt nominal
Current: 50 Ωnominal
Input Voltage Burden (Current)
1.0 VRMS maximum
Balance Between Inputs
Better than ±0.5% of span
LoopTracker
Variable brightness LEDs indicate I/O loop level and status
DC Output Range
Factory configured, please specify output range or consult fac-
tory. See table on other side for common ranges.
Voltage, 10 mA max.: 0-1 VDC to 0-10 VDC
Bipolar voltage: ±1 VDC to ±10 VDC
Current: 0-1 mADC to 0-20 mADC
20 V compliance, 1000 Ωat 20 mA
Output Calibration
Multi-turn zero and span potentiometers for output
±15% of span adjustment range typical
Output Loop Power Supply
20 VDC nominal, regulated, 25 mADC, max. ripple <10 mVRMS
Output Test
Sets output to test level when pressed
Adjustable 0-100% of span
Output Ripple and Noise
Less than 10 mVRMS
Linearity
Better than ±0.1% of span
Ambient Temperature Range and Stability
–10°C to +60°C operating ambient
Better than ±0.02% of span per °C stability
Response Time
100 milliseconds typical, faster response times are available
DF option: 1 millisecond response time
Isolation
2000 VRMS minimum
Full isolation: power to input, power to output, input to output
Individual inputs are single-ended (common ground)
Housing and Sockets
IP 40, requires installation in panel or enclosure
API 011 or API 011 FS socket
Socket mounts to 35 mm DIN rail or can be surface mounted
Power
Standard: 115 VAC ±10%, 50/60 Hz, 2.5 W max.
Poption: 85-265 VAC 50/60 Hz, 60-300 VDC, 2.5 W
A230 option: 230 VAC ±10%, 50/60 Hz, 2.5 W max.
D option: 9-30 VDC, 2.5 W typical
Hot Swappable
Plug-In Design
Power options—add to end of model number
A230 230 VAC
P85-265 VAC or 60-300 VDC
D9-30 VDC
Options—add to end of model number
DF Fast response, 1 millisecond nom. response time
DF option will cause output noise levels greater
than standard specifications.
UConformal coating for moisture resistance
Accessories—order as separate line item
API 011 11-pin socket
API 011 FS 11-pin finger-safe socket
API CLP1 Module hold-down spring for high vibration or
mobile applications
Free Factory
I/O Setup!
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
Made in USA
API 011
300 V Rating
API 011 FS
300 V Rating API CLP1
1.75"
2.38"
Variable Brightness
Input LED
Output Test Button
Output Test Adjust
Output Span
Output Zero
Variable Brightness
Output LED
2.75"
Model Function Factory Configured Input Output Power
API 4400 G (A + B + C + D) / 4 Specify 4 input ranges
Factory configured,
specify output range
115 VAC
API 4401 G (A + B + C) / 3 Specify 3 input ranges 115 VAC
API 4402 G (A + B) / 2 Specify 2 input ranges 115 VAC
API 4403 G (A + B + C – D) / 3 Specify 4 input ranges 115 VAC
API 4404 G (A + B – C – D) / 2 Specify 4 input ranges 115 VAC
API 4405 G A – B – C – D Specify 4 input ranges 115 VAC
API 4406 G (A + B – C) / 2 Specify 3 input ranges 115 VAC
API 4407 G A – B – C Specify 3 input ranges 115 VAC
API 4408 G A – B Specify 2 input ranges 115 VAC
Quick Link
api-usa.com/4400
© 08-19
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
ABSOLUTE PROCESS INSTRUMENTS

Calibration
Input and output ranges as specified on your order are factory
pre-configured (at 24°C ±1°C). Top-mounted, Zero and Span
potentiometers can be used to calibrate the output to compen-
sate for load and lead variations.
1. Apply power to the module and allow a minimum 20 minute
warm up time.
2. Using an accurate calibration source, provide an input to
the module equal to the minimum input required for the
application.
3. Using an accurate measurement device for the output,
adjust the Zero potentiometer for the exact minimum output
desired. The Zero control should only be adjusted when the
input signal is at its minimum. This will produce the cor-
responding minimum output signal. For example: 4 mA for
a 4-20 mA output or –10 V for a ±10V output.
4. Next, set the input at maximum, then adjust the Span pot for
the exact maximum output desired. The Span control should
only be adjusted when the input signal is at its maximum.
This will produce the corresponding maximum output
signal. Example: for 4-20 mA output, the Span control will
provide adjustment for the 20 mA or high end of the signal.
5. Repeat adjustments for maximum accuracy.
Output Test Function
The test button may be used to drive the device on the output
(a panel meter, chart recorder, etc.) with a known good signal
that can be used as a system diagnostic aid during initial start-
up or during troubleshooting.
When depressed it will drive the output with a known good
signal. When released, the output will return to normal.
The Test Range potentiometer is factory adjusted to approxi-
mately 50% of the output span. It can be field adjusted if
required.
Press and hold the Test button and adjust the potentiometer
for the desired output level. When released, the output will
return to normal.
Operation
The API 4400 G through API 4408 G are factory configured
series to your exact input and output requirements.
Up to four inputs can be scaled and connected to either addi-
tive or subtractive amplifier inputs according to the model
designation.
The input signal is filtered, and cancels any offset of the input
relative to the output. 50 Ωshunts are used at the input for
current-to-voltage conversion if required.
The green LoopTracker®input LED provides a visual indication
that a signal is being sensed by the input circuitry of the mod-
ule. It also indicates the input signal strength by changing in
intensity as the process changes from minimum to maximum.
If the LED fails to illuminate, or fails to change in intensity as
the process changes, check the module power or signal input
wiring. Note that it may be difficult to see the LEDs under bright
lighting conditions.
The red LoopTracker output LED provides a visual indication
that the output signal is functioning. It becomes brighter as
the input and the corresponding output change from minimum
to maximum.
For current outputs, the red LED will only light if the output loop
current path is complete. For either current or voltage outputs,
failure to illuminate or a failure to change in intensity as the
process changes may indicate a problem with the module
power or signal output wiring.
Precautions
WARNING! All wiring must be performed by a qualified electri-
cian or instrumentation engineer. See diagram for terminal
designations and wiring examples. Consult factory for assis-
tance.
WARNING! Avoid shock hazards! Turn signal input, output, and
power off before connecting or disconnecting wiring, or removing
or installing module.
Précautions
ATTENTION! Tout le câblage doit être effectué par un élec-
tricien ou ingénieur en instrumentation qualifié. Voir le dia-
gramme pour désignations des bornes et des exemples de
câblage. Consulter l’usine pour assistance.
ATTENTION! Éviter les risques de choc! Fermez le signal
d’entrée, le signal de sortie et l’alimentation électrique avant
de connecter ou de déconnecter le câblage, ou de retirer ou
d’installer le module.
Socket and Mounting
Install module in a protective panel or enclosure. Allow space
around module for air flow. Use API 011 or API 011 FS socket.
See specifications for maximum allowable socket voltages. The
socket clips to a standard 35 mm DIN rail or can be mounted to
a flat surface.
Ranges
See the model/serial number label for module information,
module power requirements, options, and I/O range informa-
tion.
API 4400 G through API 4408 G input and output ranges are
factory configured as indicated on the serial number label.
Signal Inputs
Polarity must be observed when connecting the signal input.
Terminals 4, 5, 6, 7, 8 provide the appropriate connections for
the input signal. Polarity must be observed when connecting
the signal input.
The negative (–) connection for all inputs is connected to
terminal 5.
The positive (+) connection for input A is to terminal 4.
The positive (+) connection for input B is to terminal 6.
The positive (+) connection for input C is to terminal 7.
The positive (+) connection for input D is to terminal 8.
Signal Output
Polarity must be observed for output wiring connections. If the
output does not function, check wiring and polarity.
When a current output is ordered, it provides power to the
output current loop (sourcing).
Terminals 9 (+) and 10 (–) provide the connections for the
output. Note that the output provides power to the output loop.
Module Power
Check model/serial number label for module operating voltage
to make sure it matches available power.
AC power is connected to terminals 1 and 3.
For DC powered modules (D option), polarity MUST be observed.
Positive (+) is wired to terminal 1
Negative (–) is wired to terminal 3.
Installation and Setup API 4400 G through API 4408 G
API 011
11-Pin Socket
300 V Rating
TERMINAL LOCATION
TOP VIEW
87654
910
11 123
0.312 [7.92]
TYP.
2.060 [52.32]
0.165
[4.19]
TYP.
2.035
[51.69]
0.594
[15.08]
0.770
[19.56]
2
1
3
4
5
6
7
8
910
0.970
[24.64]
2.332 [59.22]
11
1.018
[25.84]
API 011 FS
11-Pin Finger
Safe Socket
300 V Rating
0.126
[3.20]
DIA.
TYP.
1.181 [30.00]
0.220 [5.60]
1.496 [38.00]
TERMINAL LOCATION
TOP VIEW
87654
9
10 11 12
3
1.063
[27.00]
8765
4
9
10 11 12
3
2.559
[65.00]
0.925
[23.50]
Input
Common
32111109
87654
PLC,
Display,
Recorder
Power
AC or
DC–
Power
AC or
DC+
(+) (–)
Output Module
power
20 V loop
power with
mA output
version
Socket
top view
Key down
when panel
mounting
A
BCD
Input
A
Input
B
Input
C
Input
D
+–+–+–+–
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
ABSOLUTE PROCESS INSTRUMENTS
API maintains a constant effort to upgrade and improve its products.
Specifications are subject to change without notice. See api-usa.com for
latest product information. Consult factory for your specific requirements.
WARNING: This product can expose you to chemicals includ-
ing lead and nickel, which are known to the State of California
to cause cancer or birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
To maintain full isola-
tion avoid combining
power supplies in
common with input,
output, or unit power.
* Do not make
connections to
unused terminals!
