Absolute Process Instruments APD 6380 User manual

AC to DC Transmitters, Isolated, Field Rangeable APD 6380
Input: True RMS 0-40 mVAC to 0-300 VAC, 0-4 mAAC to 0-200 mAAC
Output: 0-1 V to 0-10 VDC, ±5 VDC, ±10 VDC, 0-2 mA to 20 mADC
OOne Minute Setup for Hundreds of I/O Ranges
OExternal Switches & Tables for Range Selection
OZero and Span Output Calibration Potentiometers
OFull 1200 V Input/Output/Power Isolation
OInput and Output LoopTracker®LEDs
OOutput Test Button
OBuilt-In Loop Power Supply for Sink/Source Output
QConvert, Boost, and Rescale Process Signals
QIsolate Single-Ended (Common Ground) PLC Inputs
QInterface Process Signals with Panel Meters, PLCs,
Recorders, Data Acquisition, DCS, & SCADA Systems
Applications
Options–add to end of model number
M01 Output reversal, such as 20-4 mA output
UConformal coating for moisture resistance
Accessory—order as separate line item
API BP4 Spare removable 4 terminal plug, black
Model Input Output Power
APD 6380 Field configurable—specify range if
factory is to set switches
Field configurable—specify range if
factory is to set switches
85-265 VAC or 60-300 VDC
APD 6380 D 9-30 VDC or 10-32 VAC
Description
The APD 6380 accepts an AC voltage or current input and
provides an optically isolated DC voltage or current output that
is linearly related to the input.
Typical applications include signal isolation, conversion, boost-
ing or a combination of the three. Full 3-way isolation (input,
output, power) makes this module useful for ground loop
elimination, common mode signal rejection or noise pickup
reduction.
Sink/Source Output Versatility
For maximum versatility a milliamp output can be selectively
wired for sinking or sourcing. This allows the APD 6380 mil-
liamp output to connect to a powered or unpowered current
loop. The 20 VDC output loop supply can be used to power a
passive mA device if required.
LoopTracker
API exclusive features include two LoopTracker LEDs (green for
input, red for output) that vary in intensity with changes in the
process input and output signals. These provide a quick visual
picture of your process loop at all times and can greatly aid in
saving time during initial startup and/or troubleshooting.
Output Test
An API exclusive feature includes the test button to provide a
fixed output (independent of the input) when held depressed.
The test output level is potentiometer adjustable from 0 to
100% of output span.
The output test button greatly aids in saving time during initial
startup and/or troubleshooting.
All models are field rangeable
For APD 6380, specify if UL version is required
Order options and accessories as required
Order D versions for operation on low voltage power
How to Order
Free factory setup. Please specify on your order
Input range
Output range
AC Input Ranges
Field selectable ranges via switch settings
Voltage: 0-40 mVAC to 0-300 VAC
Current: 0-4 mAAC to 0-200 mAAC
Measurements are true RMS
Input Impedance
Voltage (0-4 VAC): 1 MΩminimum
Voltage (>4 VAC): 220 kΩminimum
Current: 10 Ωtypical
Input Frequency
40 Hz to 1000 Hz sinusoidal
Common Mode Rejection
120 dB minimum
LoopTracker
Variable brightness LEDs indicate I/O loop level and status
DC Output Ranges
Field selectable ranges via switch settings
Voltage: 0-1 VDC to 0-10 VDC, 10 mA max
Bipolar voltage: ±1 VDC to ±10 VDC
Current: 0-2 mADC to 0-20 mADC
20 V compliance, 1000 Ωat 20 mA
Output offset: ±100% in 15% increments
Output Calibration
Multi-turn zero and span potentiometers
±15% of span adjustment range typical
Output Loop Power Supply
20 VDC nominal, regulated, 25 mADC
Max. ripple, less than 10 mVRMS
May be selectively wired for sinking or sourcing mA output
Output Test
Front momentary button sets output to test level
Potentiometer adjustable 0-100% of span
Output Ripple and Noise
Less than 10 mVRMS ripple and noise
Linearity
Better than ±0.1% of span
Ambient Temperature Range and Stability
–10°C to +60°C operating ambient
Better than ±0.02% of span per °C stability
Response Time
200 milliseconds nominal (0-90%)
Isolation
1200 VRMS minimum
Full isolation: power to input, power to output, input to output
Power
85-265 VAC, 50/60 Hz or 60-300 VDC, 2 W maximum
D versions: 9-30 VDC or 10-32 VAC 50/60 Hz, 2 W maximum
Housing and Connectors
IP 40, requires installation in panel or enclosure
For use in Pollution Degree 2 Environment
Mount vertically to a 35 mm DIN rail
Four 4-terminal removable connectors, 14 AWG max wire size
Dimensions
0.89" W x 4.62" H x 4.81" D
22.5 mm W x 117 mm H x 122 mm D
Height includes connectors
Connect mA Output
for Sink or Source
Output LoopTracker
LED
Input LoopTracker
LED
Adjustable Output
Test Function
Hundreds of Range
Selections
Adjustable Output
Offset
Universal
Power
Zero and Span for
Output
Removable Plugs
© 11-19
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
See Wiring
Diagrams on
Page 3
Quick Link: api-usa.com/6380
Minute
Setup!
1
Free Factory
I/O Setup!
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
Made in USA
File E145968
85-265 VAC, 60-300 VDC
model only
Applications Link
api-usa.com/apps
Pb Lead
Free

Precautions, Ranges, Input Switch Settings APD 6380
Output 0-1 V 0-2 V 0-4 V 1-5 V 0-5 V 0-8 V 2-10 V 0-10 V ±5 V ±10 V 0-2 mA 0-4 mA 0-8 mA 2-10 mA 0-10 mA 0-16 mA 4-20 mA 0-20 mA
Switches ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE
Input
0-40 mV VA60V VA68V VA61V VA66V VA69V VA62V VA67V VA63V VA64V VA65V VA60I VA68I VA61I VA66I VA69I VA62I VA67I VA63I
0-50 mV VA20V VA28V VA21V VA26V VA29V VA22V VA27V VA23V VA24V VA25V VA20I VA28I VA21I VA26I VA29I VA22I VA27I VA23I
0-75 mV V2E0V V2E8V V2E1V V2E6V V2E9V V2E2V V2E7V V2E3V V2E4V V2E5V V2E0I V2E8I V2E1I V2E6I V2E9I V2E2I V2E7I V2E3I
0-80 mV V260V V268V V261V V266V V269V V262V V267V V263V V264V V265V V260I V268I V261I V266I V269I V262I V267I V263I
0-100 mV V220V V228V V221V V226V V229V V222V V227V V223V V224V V225V V220I V228I V221I V226I V229I V222I V227I V223I
0-130 mV VA50V VA58V VA51V VA56V VA59V VA52V VA57V VA53V VA54V VA55V VA50I VA58I VA51I VA56I VA59I VA52I VA57I VA53I
0-160 mV VB60V VB68V VB61V VB66V VB69V VB62V VB67V VB63V VB64V VB65V VB60I VB68I VB61I VB66I VB69I VB62I VB67I VB63I
0-200 mV VB20V VB28V VB21V VB26V VB29V VB22V VB27V VB23V VB24V VB25V VB20I VB28I VB21I VB26I VB29I VB22I VB27I VB23I
0-250 mV V820V V828V V821V V826V V829V V822V V827V V823V V824V V825V V820I V828I V821I V826I V829I V822I V827I V823I
0-260 mV V250V V258V V251V V256V V259V V252V V257V V253V V254V V255V V250I V258I V251I V256I V259I V252I V257I V253I
0-300 mV V230V V238V V231V V236V V239V V232V V237V V233V V234V V235V V230I V238I V231I V236I V239I V232I V237I V233I
0-320 mV V360V V368V V361V V366V V369V V362V V367V V363V V364V V365V V360I V368I V361I V366I V369I V362I V367I V363I
0-375 mV V0E0V V0E8V V0E1V V0E6V V0E9V V0E2V V0E7V V0E3V V0E4V V0E5V V0E0I V0E8I V0E1I V0E6I V0E9I V0E2I V0E7I V0E3I
0-400 mV V060V V068V V061V V066V V069V V062V V067V V063V V064V V065V V060I V068I V061I V066I V069I V062I V067I V063I
0-500 mV V020V V028V V021V V026V V029V V022V V027V V023V V024V V025V V020I V028I V021I V026I V029I V022I V027I V023I
0-560 mV V8F0V V8F8V V8F1V V8F6V V8F9V V8F2V V8F7V V8F3V V8F4V V8F5V V8F0I V8F8I V8F1I V8F6I V8F9I V8F2I V8F7I V8F3I
0-650 mV V850V V858V V851V V856V V859V V852V V857V V853V V854V V855V V850I V858I V851I V856I V859I V852I V857I V853I
0-750 mV V830V V838V V831V V836V V839V V832V V837V V833V V834V V835V V830I V838I V831I V836I V839I V832I V837I V833I
0-800 mV V960V V968V V961V V966V V969V V962V V967V V963V V964V V965V V960I V968I V961I V966I V969I V962I V967I V963I
0-900 mV V3F0V V3F8V V3F1V V3F6V V3F9V V3F2V V3F7V V3F3V V3F4V V3F5V V3F0I V3F8I V3F1I V3F6I V3F9I V3F2I V3F7I V3F3I
0-1 V V920V V928V V921V V926V V929V V922V V927V V923V V924V V925V V920I V928I V921I V926I V929I V922I V927I V923I
0-1.125 V V0F0V V0F8V V0F1V V0F6V V0F9V V0F2V V0F7V V0F3V V0F4V V0F5V V0F0I V0F8I V0F1I V0F6I V0F9I V0F2I V0F7I V0F3I
0-1.5 V V030V V038V V031V V036V V039V V032V V037V V033V V034V V035V V030I V038I V031I V036I V039I V032I V037I V033I
0-1.75 V V140V V148V V141V V146V V149V V142V V147V V143V V144V V145V V140I V148I V141I V146I V149I V142I V147I V143I
0-2 V V120V V128V V121V V126V V129V V122V V127V V123V V124V V125V V120I V128I V121I V126I V129I V122I V127I V123I
0-2.5 V V990V V998V V991V V996V V999V V992V V997V V993V V994V V995V V990I V998I V991I V996I V999I V992I V997I V993I
0-3 V V930V V938V V931V V936V V939V V932V V937V V933V V934V V935V V930I V938I V931I V936I V939I V932I V937I V933I
0-4 V VE60V VE68V VE61V VE66V VE69V VE62V VE67V VE63V VE64V VE65V VE60I VE68I VE61I VE66I VE69I VE62I VE67I VE63I
0-5 V VE20V VE28V VE21V VE26V VE29V VE22V VE27V VE23V VE24V VE25V VE20I VE28I VE21I VE26I VE29I VE22I VE27I VE23I
0-7.5 V V6E0V V6E8V V6E1V V6E6V V6E9V V6E2V V6E7V V6E3V V6E4V V6E5V V6E0I V6E8I V6E1I V6E6I V6E9I V6E2I V6E7I V6E3I
0-10 V V620V V628V V621V V626V V629V V622V V627V V623V V624V V625V V620I V628I V621I V626I V629I V622I V627I V623I
0-15 V VE30V VE38V VE31V VE36V VE39V VE32V VE37V VE33V VE34V VE35V VE30I VE38I VE31I VE36I VE39I VE32I VE37I VE33I
0-20 V VF20V VF28V VF21V VF26V VF29V VF22V VF27V VF23V VF24V VF25V VF20I VF28I VF21I VF26I VF29I VF22I VF27I VF23I
0-25 V VC20V VC28V VC21V VC26V VC29V VC22V VC27V VC23V VC24V VC25V VC20I VC28I VC21I VC26I VC29I VC22I VC27I VC23I
0-40 V V460V V468V V461V V466V V469V V462V V467V V463V V464V V465V V460I V468I V461I V466I V469I V462I V467I V463I
0-50 V V420V V428V V421V V426V V429V V422V V427V V423V V424V V425V V420I V428I V421I V426I V429I V422I V427I V423I
0-60 V VF30V VF38V VF31V VF36V VF39V VF32V VF37V VF33V VF34V VF35V VF30I VF38I VF31I VF36I VF39I VF32I VF37I VF33I
0-75 V VC30V VC38V VC31V VC36V VC39V VC32V VC37V VC33V VC34V VC35V VC30I VC38I VC31I VC36I VC39I VC32I VC37I VC33I
0-90 V V7F0V V7F8V V7F1V V7F6V V7F9V V7F2V V7F7V V7F3V V7F4V V7F5V V7F0I V7F8I V7F1I V7F6I V7F9I V7F2I V7F7I V7F3I
0-100 V VD20V VD28V VD21V VD26V VD29V VD22V VD27V VD23V VD24V VD25V VD20I VD28I VD21I VD26I VD29I VD22I VD27I VD23I
0-117 V V4B0V V4B8V V4B1V V4B6V V4B9V V4B2V V4B7V V4B3V V4B4V V4B5V V4B0I V4B8I V4B1I V4B6I V4B9I V4B2I V4B7I V4B3I
0-120 V V470V V478V V471V V476V V479V V472V V477V V473V V474V V475V V470I V478I V471I V476I V479I V472I V477I V473I
0-125 V V490V V498V V491V V496V V499V V492V V497V V493V V494V V495V V490I V498I V491I V496I V499I V492I V497I V493I
0-175 V V540V V548V V541V V546V V549V V542V V547V V543V V544V V545V V540I V548I V541I V546I V549I V542I V547I V543I
0-200 V V520V V528V V521V V526V V529V V522V V527V V523V V524V V525V V520I V528I V521I V526I V529I V522I V527I V523I
0-250 V VD90V VD98V VD91V VD96V VD99V VD92V VD97V VD93V VD94V VD95V VD90I VD98I VD91I VD96I VD99I VD92I VD97I VD93I
0-260 V VD50V VD58V VD51V VD56V VD59V VD52V VD57V VD53V VD54V VD55V VD50I VD58I VD51I VD56I VD59I VD52I VD57I VD53I
0-300 V VD30V VD38V VD31V VD36V VD39V VD32V VD37V VD33V VD34V VD35V VD30I VD38I VD31I VD36I VD39I VD32I VD37I VD33I
Precautions
WARNING! All wiring must be performed by a qualified electrician
or instrumentation engineer. See diagram for terminal designa-
tions and wiring examples. Consult factory for assistance.
WARNING! Avoid shock hazards! Turn signal input, output, and
power off before connecting or disconnecting wiring, or remov-
ing or installing module.
mV and Voltage Input Table
Précautions
ATTENTION! Tout le câblage doit être effectué par un élec-
tricien ou ingénieur en instrumentation qualifié. Voir le dia-
gramme pour désignations des bornes et des exemples de
câblage. Consulter l'usine pour assistance.
ATTENTION! Éviter les risques de choc! Fermez le signal
d'entrée, le signal de sortie et l'alimentation électrique avant
de connecter ou de déconnecter le câblage, ou de retirer ou
d'installer le module.
Ranges
See tables below and on next page for switch settings.
For ranges not listed here or for ranges that fall between
the listed ranges see api-usa.com/APD6380 and download
apd6380ranges.pdf for the complete range table.
Electrical Connections
Polarity must be observed for output wiring connections. If the
module does not function, check switch settings and wiring.
See wiring diagrams at right.
*Do not make any connections to unused terminals or use
them as wiring junctions for external devices. This may cause
permanent damage to the module!
Input
Set switch A to "V" for a voltage input or "I" for a current input.
Connect the AC signal input to terminals 9 and 11 as shown at
right. Either polarity may be used.
Type of Input Device Terminal Terminal
Device with AC voltage or milliamp
output. 9 11
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
API maintains a constant effort to upgrade and improve its products.
Specifications are subject to change without notice. See api-usa.com for
latest product information. Consult factory for your specific requirements.
WARNING: This product can expose you to chemicals includ-
ing nickel, which are known to the State of California to cause
cancer or birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov

13 Power AC or DC +
14 Earth Ground
16 Power AC or DC –
1413 15 16
Input Switch Settings, Wiring APD 6380
65 7 8
Test Cal.
Span
Zero
Test
Output
Input
Loop
Tracker
APD 6380
AC to DC
Isolated Transmitter
Loop
Tracker
Output 0-1 V 0-2 V 0-4 V 1-5 V 0-5 V 0-8 V 2-10 V 0-10 V ±5 V ±10 V 0-2 mA 0-4 mA 0-8 mA 2-10 mA 0-10 mA 0-16 mA 4-20 mA 0-20 mA
Switches ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE ABCDE
Input
0-4 mA IA60V IA68V IA61V IA66V IA69V IA62V IA67V IA63V IA64V IA65V IA60I IA68I IA61I IA66I IA69I IA62I IA67I IA63I
0-5 mA IA20V IA28V IA21V IA26V IA29V IA22V IA27V IA23V IA24V IA25V IA20I IA28I IA21I IA26I IA29I IA22I IA27I IA23I
0-7.5 mA I2E0V I2E8V I2E1V I2E6V I2E9V I2E2V I2E7V I2E3V I2E4V I2E5V I2E0I I2E8I I2E1I I2E6I I2E9I I2E2I I2E7I I2E3I
0-10 mA I220V I228V I221V I226V I229V I222V I227V I223V I224V I225V I220I I228I I221I I226I I229I I222I I227I I223I
0-12 mA IA70V IA78V IA71V IA76V IA79V IA72V IA77V IA73V IA74V IA75V IA70I IA78I IA71I IA76I IA79I IA72I IA77I IA73I
0-15 mA IA30V IA38V IA31V IA36V IA39V IA32V IA37V IA33V IA34V IA35V IA30I IA38I IA31I IA36I IA39I IA32I IA37I IA33I
0-20 mA IB20V IB28V IB21V IB26V IB29V IB22V IB27V IB23V IB24V IB25V IB20I IB28I IB21I IB26I IB29I IB22I IB27I IB23I
0-25 mA I820V I828V I821V I826V I829V I822V I827V I823V I824V I825V I820I I828I I821I I826I I829I I822I I827I I823I
0-30 mA I230V I238V I231V I236V I239V I232V I237V I233V I234V I235V I230I I238I I231I I236I I239I I232I I237I I233I
0-40 mA I060V I068V I061V I066V I069V I062V I067V I063V I064V I065V I060I I068I I061I I066I I069I I062I I067I I063I
0-50 mA I020V I028V I021V I026V I029V I022V I027V I023V I024V I025V I020I I028I I021I I026I I029I I022I I027I I023I
0-60 mA IB30V IB38V IB31V IB36V IB39V IB32V IB37V IB33V IB34V IB35V IB30I IB38I IB31I IB36I IB39I IB32I IB37I IB33I
0-75 mA I830V I838V I831V I836V I839V I832V I837V I833V I834V I835V I830I I838I I831I I836I I839I I832I I837I I833I
0-80 mA I960V I968V I961V I966V I969V I962V I967V I963V I964V I965V I960I I968I I961I I966I I969I I962I I967I I963I
0-90 mA I3F0V I3F8V I3F1V I3F6V I3F9V I3F2V I3F7V I3F3V I3F4V I3F5V I3F0I I3F8I I3F1I I3F6I I3F9I I3F2I I3F7I I3F3I
0-100 mA I920V I928V I921V I926V I929V I922V I927V I923V I924V I925V I920I I928I I921I I926I I929I I922I I927I I923I
0-117 mA I0B0V I0B8V I0B1V I0B6V I0B9V I0B2V I0B7V I0B3V I0B4V I0B5V I0B0I I0B8I I0B1I I0B6I I0B9I I0B2I I0B7I I0B3I
0-120 mA I330V I338V I331V I336V I339V I332V I337V I333V I334V I335V I330I I338I I331I I336I I339I I332I I337I I333I
0-125 mA I090V I098V I091V I096V I099V I092V I097V I093V I094V I095V I090I I098I I091I I096I I099I I092I I097I I093I
0-150 mA I030V I038V I031V I036V I039V I032V I037V I033V I034V I035V I030I I038I I031I I036I I039I I032I I037I I033I
0-175 mA I140V I148V I141V I146V I149V I142V I147V I143V I144V I145V I140I I148I I141I I146I I149I I142I I147I I143I
0-200 mA I120V I128V I121V I126V I129V I122V I127V I123V I124V I125V I120I I128I I121I I126I I129I I122I I127I I123I
Voltage Output
Switch E set to “V” 21 3 4
– +
Voltage
Device
Current Sourcing Output
Switch E set to “I”
Current Sinking Output
Switch E set to “I”
AC Input
109 11 12
mVAC,
VAC or
mAAC
Voltage Input Range Selection
See table below (voltage inputs) and on the next page (current
inputs) to select I/O ranges for your application. It is generally
easier to select ranges before installation.
The module side label lists common ranges. See the model/
serial number label for module information, options, or if a
custom range was specified.
It may also be possible to use the next highest setting and trim
the output signal with the zero and span potentiometers.
Switch A: Set to "V" for voltage input
Switch B: Input range
Switch C: Input range
Switch D: Output range
Switch E: Set to "V" for voltage output or "I" for current
output
Note that when using a current shunt input, it measures a mV
drop across a fixed resistance, typically 50 mV, 75 mV or 100
mV. The correct input setting would be the appropriate mV
range for the shunt.
Current Input Range Selection
See table below to select I/O ranges when using a current
input. It is generally easier to select ranges before installation.
See the model/serial number label for module information,
options, or if a custom range was specified.
The module side label lists common ranges.
It may also be possible to use the next highest setting and trim
the output signal with the zero and span potentiometers.
Switch A: Set to "I" for current input
Switch B: Input range
Switch C: Input range
Switch D: Output range
Switch E: Set to "V" for voltage output or "I" for current
output
Voltage Output
Set switch E to "V" for a voltage output.
If your receiving device (such as a PLC or a display) uses a
voltage input, use terminals 3 and 4 as shown in the wiring
diagram.
Current Output
Set switch E to "I" for a current output.
Determine if your receiving device (such as a PLC or a display)
provides power to the current loop or if the loop must be pow-
ered by the APD module. Typical voltage may be 9-24 VDC at
your device's input terminals if it provides power to the loop.
If your device does not power the current loop, the APD can
provide power using terminals 3 and 4 as shown in the wiring
diagram.
If it provides power to the loop or an external supply provides
power to the loop, use terminals 2 and 3 aas shown in the
wiring diagram.
Module Power
Check model/serial number label for module operating voltage
to make sure it matches available power.
When using DC power, either polarity is acceptable, but for
consistency with similar API products, positive (+) can be wired
to terminal 13 and negative (–) can be wired to terminal 16.
Type of Device for Output – Terminal + Terminal
Measuring/recording device
accepts a voltage input. 3 (–)
4 (+)
switch E
set to “V”
Measuring/recording device
accepts a mA (current) input and
the input is unpowered or pas-
sive. APD module provides the
loop power.
3 (–)
4 (+20 V)
switch E
set to “I”
Measuring/recording device
accepts a mA (current) input and
provides power to the current loop.
2 (–)
3 (+)
switch E
set to “I”
To maintain full isolation
avoid combining power sup-
plies in common with input,
output, or unit power.
Cu 60/75°C
conductors
14 AWG
max.
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
12 3 4
5 6 7 8
9 10 11 12
13 14 15 16
Input
Not used
Output
Power
Wire terminal
torque
0.5 to 0.6 Nm or
4.4 to 5.3 in-lbs
2134
– +
+–– +
mA
Device
Ri
Loop
Power
Source
– +20V
mA
Device
Ri
21 3 4
Not used
Module powers mA output loop
Module mA output is unpowered
3- or 4-wire transmitter
or 2 wire transmitter with
external power supply
mA output: determine if receiving device has
a passive or powered input. The module can
be wired for a sinking or sourcing mA output.
* Do not make connections
to unused terminals!
* Do not make connections
to unused terminals!
* Do not make connections to unused terminals!

Installation/Removal, Calibration, Output Test, Operation APD 6380
Spring Clip
Upper Mount
Lower Mount
Mounting to a DIN Rail
Install module vertically on a 35 mm DIN rail in a protective
enclosure away from heat sources. Do not block air flow. Allow
1" (25 mm) above and below housing vents for air circulation.
1
2
Removal
Avoid shock hazards! Turn signal input, output, and power off
before removing module.
1. Push up on bottom back of module.
2. Tilt front of module downward to release Upper Mount from top
edge of DIN rail.
3. The module can now be removed
from the DIN rail.
Calibration
Input and output ranges, if specified on your order, are factory
pre-configured (at 24°C ±1°C).
Front-mounted Zero and Span potentiometers are used to
calibrate the output to compensate for load and lead variations.
Note: Perform the following calibration procedure any time
switch settings are changed.
1. Apply power to the module and allow a minimum 20 min-
ute warm up time.
2. Using an accurate calibration source, provide an input to
the module equal to the minimum input required for the
application.
3. Using an accurate measurement device for the output,
adjust the Zero potentiometer for the exact minimum
output desired. The Zero control should only be adjusted
when the input signal is at its minimum. This will produce
the corresponding minimum output signal. For example: 4
mA for a 4-20 mA output or –10 V for a ±10V output.
4. Set the input at maximum and adjust the Span pot for the
exact maximum output desired. The Span control should
only be adjusted when the input signal is at its maximum.
This will produce the corresponding maximum output
signal. Example: for 4-20 mA output, the Span control will
provide adjustment for the 20 mA or high end of the signal.
5. Repeat adjustments for maximum accuracy.
Output Test Function
When the Test button is depressed it will drive the output with a
known good signal that can be used as a diagnostic aid during
initial start-up or troubleshooting. When released, the output
will return to normal.
The Test Cal. potentiometer is factory set to approximately
50% output. It can be adjusted to set the test output from 0 to
100% of the output span. Press and hold the Test button and
adjust the Test Cal. potentiometer for the desired output level.
Operation
The APD 6380 accepts an AC voltage or current input and
provides an optically isolated DC voltage or current output that
is linearly related to the input.
The green LoopTracker®input LED provides a visual indication
that a signal is being sensed by the input circuitry of the mod-
ule. It also indicates the input signal strength by changing in
intensity as the process changes from minimum to maximum.
If the LED fails to illuminate, or fails to change in intensity as
the process changes, check the module power or signal input
wiring. Note that it may be difficult to see the LEDs under bright
lighting conditions.
The red LoopTracker output LED provides a visual indication
that the output signal is functioning. It becomes brighter as
the input and the corresponding output change from minimum
to maximum.
For current outputs, the red LED will only light if the output loop
current path is complete. For either current or voltage outputs,
failure to illuminate or a failure to change in intensity as the
process changes may indicate a problem with the module
power or signal output wiring.
Test Cal.
Span
Zero
Test
Output
Input
Loop
Tracker
APD 6380
AC to DC
Isolated Transmitter
Loop
Tracker
3. Push front of module
upward until Upper Mount
snaps into place.
1. Tilt front of module down-
ward and position against
DIN rail.
2. Clip Lower Mount to bot-
tom edge of DIN rail.
Installation
1
2
3
Output Test Level
Adjustment
Push to Test
Output
Output Span
Calibration
Output Zero
Calibration
Variable
Brightness Input
Indicator
Variable
Brightness Output
Indicator
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
