ABTECH SAFETY AB2.4T User manual

Designers, Manufacturers and Suppliers of
Personal Protective Equipment
Users Manual
English Version 2.3
TORQRange of Inertia Reel
Fall Arresters

Thank you for purchasing this TORQ Inertia Reel Fall Arrester. Please take time to familiarize yourself with the
correct use and operation.
It is imperative that this TORQ Inertia Reel Fall Arrester is only used for its intended purpose and that it is
subject to an annual recorded service by the manufacturer or an approved service agent.
To avoid personal injury, prior to using this TORQ Inertia Reel Fall Arrester or training others to use it,
CAREFULLY READ and understand these instructions. If there is anything you do not understand DO NOT use
the TORQ Inertia Reel Fall Arrester, contact the supplier or Abtech Safety for further details.
Certain information in this manual is governed by law and is subject to change without prior notice. Great care
has been taken to ensure that the information is correct at the time of publication. However, it is the user’s sole
responsibility to ensure that they fully comply with all legal requirements. Abtech Safety will not accept liability
for any inaccuracy or incorrectly stated legal requirements.
Abtech Safety operates a policy of continual improvement and reserve the right to change specifications without
notice. The Manufacturer and / or their recognised agents, directors, employees or insurers will not be held liable
for consequential or other damages, losses or expenses in the connection with or by reason of or the inability to
use the TORQ Inertia Reel Fall Arrester for any other purpose.
Note; training should only be delivered by a suitably qualified and competent person.
Warning
In order to obtain optimum safety and performance please
study and understand these instructions and receive adequate
training by a trained and competent person before using this
device. If in any doubt whatsoever about the safe use of this
device seek the advice/supervision of a trained and competent
person or contact the supplier. Please retain this information for
future reference.
The consequences of improperly using the device, not following
instructions or markings may be serious injury or death.
The TORQ Inertia Reel Fall Arrester is a component part of a
Fall Arrest System and may be issued to anyone who needs to
use it on a personal issue basis. These User Instructions must
be issued to the end user of this device who must maintain a
record of the annual thorough examination on the Inspection
Form provided.
Wire specification: 5mm 7X19 Galvanised Steel Wire to
BSEN12385:2002
Model Type Specifications:
Model No. AB2.4T AB6T AB10T AB15T AB15RT
Line length 2.4m 6m 10m 15m 15m
Line type 48mm Webbing Galv.
Wire
Galv.
Wire
Galv.
Wire
Galv.
Wire
Standards
BS EN360 2002
ANSI/ASSE
Z359.14-2012
BS EN360 2002
ANSI/ASSE
Z359.14-2012
BS EN360 2002
ANSI/ASSE
Z359.14-2012
BS EN360 2002
ANSI/ASSE
Z359.14-2012
BSEN360 2002
BSEN1496 2006
ANSI/ASSE
Z359.14-2012
Weight 1.00kg 4.75kg 6.25kg 8.75kg 10.40kg
Warning
All work at height including the use of Personal Protective
Equipment (PPE) as a control measure is subject to a
suitable and sufficient risk assessment.
System Requirements and Limitations of Use
This TORQ Inertia Reel Fall Arrester is intended for use as a
Fall Arrest (Fall Arrest Device) or Recovery (Rescue, Recovery
Winch) device and is not intended for use for work positioning.
Warning: This TORQ Inertia Reel Fall Arrester must not be
used where the terrain and/or anchorage point is unstable (e.g.
grain silo’s, shifting sand, powder, sludge, etc) as a slow
descent will not activate the braking system.
Maintenance
This TORQ Inertia Reel Fall Arrester has no user serviceable
parts and must not be disassembled or adjusted except by the
manufacturer or approved service agent. User maintenance is
limited to pre-use inspection, cleaning, drying and storage as
described in these User Instructions. When maintenance is
required consult the supplier/manufacturer. Do not tamper with
or adjust any part of the device.
Rescue Planning
The end user(s) should anticipate and plan rescue and recov-
ery activities before use as part of a planned Risk Assessment
for each use event and in the event of a fall or other scenario
where rescue and recovery may be required. Speed of rescue
and recovery must be considered as post fall injury can result if
suspension time following a fall is prolonged.

Temperature/Climatic Conditions
This TORQ Inertia Reel Fall Arrester may be used in normal
climatic conditions within a temperature range of +54ºC to -
40ºC; it is not intended for use outside these limits. Harsh
environments may produce a harmful effect.
Electrical Hazards
Due to the highly conductive nature of the materials used in the
construction of this TORQ Inertia Reel Fall Arrester use
Extreme Caution when working near unprotected high voltage
sources. If in doubt, ask!
Use caution when using the equipment around moving
machinery.
Chemical Contamination
Avoid prolonged exposure to corrosive chemical reagents. If
contamination occurs refer to Cleaning and Disinfection.
Sharp Edges, Abrasion, Cutting
Wire rope or webbing should not be allowed to pass over a
sharp edge without an edge protection device in place. In the
event of a fall arrest, the wire rope or webbing may be
damaged.
General Operation, TORQ Inertia Reel Fall Arrester
The mechanism in this device is activated by centrifugal force
acting on the brakes. This action is produced by the inertia of a
fall rapidly spinning the internal drum which in turn causes the
brakes to lock and arrest the fall. Slow reeling of the line will not
activate the brake. If the brake locks – due to a fall – the
mechanism will reset if the load is removed. In a fall arrest
situation the mechanism will limit the force acting on the body
to less than 6kN.
Compatibility of Components
This TORQ Inertia Reel Fall Arrester may only be used with
appropriate items approved to the requirements of CE certified
PPE in line with the requirements of the PPE Regulation (EU)
2016/425 and the American National Standards Institute
(ANSI). This device is not intended for use for any other
application other than the purpose for which it is designed.
The end user must read and understand the User Instructions
supplied with other items of PPE to be used in conjunction with
this device. If in doubt about the compatibility of other items of
PPE to be used, consult the supplier. Full body harnesses used
with this device must conform to BS EN361.
Anchorage Point
Select a stable anchorage point with a minimum strength of
12kN (e.g. I beam, RSJ, Eye Bolt or Tripod).
Pre-Use Inspection
If the TORQ Inertia Reel Fall Arrester is known to have
arrested a fall it must be removed from service immediately,
marked or tagged at 'UNUSABLE' and disposed of or serviced
in accordance with the manufacturers recommendations.
Before each use check (a) that the brake operates correctly (b)
that the block is securely anchored level with or above the user
(NEVER below) (c) that all components to be used in
conjunction with this device are approved and in good condition
(d) avoid where possible anchoring the device in such a
position that could result in a ‘pendulum/swing fall’ (this may
occur if the device is positioned at > 30º from the vertical in
relation to the end user).
Extend the wire rope or webbing fully (wearing suitable
protective gloves) and inspect along its length for damage,
such as (a) broken wires (b) frayed wires/webbing (c) soiling
and/or corrosion (d) kinks and twists in the wire (e) inspect the
swage/stitching for damage, cracks, etc. (f) check the
connector(s) being used as per the User Instructions supplied
with the connector (g) check that the Overload Indicator is not
exposed (red line on karabiner).
Retract the wire rope or webbing slowly; during retraction give
a sharp sudden tug in order to activate the braking mechanism.
This check should be carried out along the full length of the
rope or webbing at approximately 20% increments. If the
braking system is not activated or if any of the above criteria fail
then the device must be removed from service.
Check the device housing for signs of mechanical deformation,
cracks, or chemical contamination and/or other defects. Check
labels and tags for absence or illegibility.
In Use
Avoid the risk of a ‘pendulum/swing fall’ injury by working
wherever possible as close to and directly below the anchorage
point.
Ensure there is sufficient clearance below and around the user
so that in the event of a fall obstructions (such as the ground)
may be safely avoided (3m + height of user).
If used on the horizontal or incline, ensure the hazard of a
pendulum fall is considered and ensure sufficient fall distance
is correctly calculated. If in doubt contact the manufacturer.
This TORQ Inertia Reel Fall Arrester is of sturdy construction,
however, all items of PPE should be handled with care and not
dropped. When is use, care should be taken to avoid damage,
which may be caused by items coming into contact with the
device and the fall arrest system.
This TORQ Inertia Reel Fall Arrester is designed to protect
ONE person. Only ONE person may be connected to this Fall
Arrestor Block at any time.
Attach the TORQ Inertia Reel Fall Arrester line connector to
the D ring on the users harness marked with an ‘A’, either front
sternum or rear dorsal for fall arrest or extended overhead
attachment point for rescue and recovery operations.
Although this device will function horizontally extreme caution
must be practiced when using the device at more than 30º from
vertical (see above).
Uncontrolled reeling may result in lock up. The wire rope must
be paid back into the device slowly. In the event of the lockup
consult the supplier or manufacturer for advice.
Warning
This TORQ Inertia Reel Fall Arrester must be used by persons
who are medically fit to do so. If you have any
medical condition, are recovering from any medical condition or
suffer from any physical or mental disability you must seek
professional medical advice before using this arrestor block.

TORQ AB15RT
Release the winding handle docking mechanism.
Pull out the winding handle locking pin. Turn the winding handle
anticlockwise while pushing down on the handle shaft in order
to engage the winding gear.
Release the locking pin and ensure that the winding handle is
locked in gear.
The person can now be raised or lowered by winding the
handle clockwise or anticlockwise.
There should be direct or indirect visual contact or some other
means of communication with the person at all times during the
process.
The lifting/lowering function may be used for lifting/lowering
loads up to 150kg.
The lifting facility should only be used if an unhindered lifting
process is possible and that it shall not be used if obstacles
present as hazard.
Ensure there is no slack line when the device is in rescue
mode.
When retrieving an individual to an upper level ensure that the
anchor point allows clearance from the access point to enable
the retrieved individual to climb or be lifted clear of the access
point.
Cleaning, Drying, Storage and Transportation
The TORQ Inertia Reel Fall Arrester casing and wire should
be cleaned using water of domestic supply quality at <40ºC. A
mild, neutral pH soap/disinfectant may be used in the event of
extreme soiling, or if the device has been exposed to
hazardous environments (e.g. drains, biohazards, etc).
This device should be stored in a cool, dry, clean, chemically
neutral environment away form sources of heat and exposure
to UV light.
Care should be taken during transportation in order to avoid
hazards that may result in damage to the device or injury to
person(s).
Lifespan
This TORQ Inertia Reel Fall Arrester should be subject to a
service at least once a year by a trained and competent person
(this must be an Abtech Safety approved service agent). In the
event of an arrested fall the device should be immediately
removed from service and returned to the
supplier/manufacturer for service.
If the TORQ is regularly serviced, correctly stored and not
subject to extreme environments or working conditions then the
manufacturer recommends a 10 year life from date of first use.
In the event of any doubt whatsoever please seek the advice of
a trained and competent person or the supplier.
Product Details
This manual must be provided to and retained by the user.
The Product Code, Serial Number and date of Manufacture of
this TORQ Inertia Reel Fall Arrestor should be entered on the
back page of this manual for future reference and inspection
records.
Note: The device serial number is laser etched into the device
swivel connector, with the exception of the AB2.T, which has a
sewn label on.
About This Manual
This User Manual is for English speaking countries only. If you
require this manual in a different language, please Contact
Abtech Safety. When this item is sold on, this manual must
accompany it and be supplied in the language of the
destination country.
Product Conformance
TORQ Inertia Reel Fall Arrester all conform to BS
EN360:2002 Personal protective equipment against falls from a
height - retractable type fall arresters.
In addition the TORQ AB15RT conforms to BS EN1496:2006
Class A and B - rescue lifting device.
TORQ self retracting lifelines all conform to ANSI/ASSE
Z359.14.2012 American National Standard - Safety
Requirements for Self - Retracting Devices for Personal Fall
Arrest and Rescue Systems.
These devices must be used in accordance with national
regulations governing occupational safety.
The TORQ range is available in various line lengths to suit a
user’s specific requirement. The maximum working length is
designated by the model number i.e. a TORQ AB6T has a
maximum working length of 6m. The 15m device is also
available with a built in winch mechanism and is designated
15RT.
Average arresting force when dynamically tested in accordance
with the ANSI Z359.14-2012 section 4.2.1
TORQ AB2.4T - 2.85kN
TORQ AB6T - 2.60kN
TORQ AB10T - 2.96kN
TORQ AB15T - 5.25kN
TORQ AB15RT - 5.25kN
Abtech Safety Ltd,
1&2 Parkway Business Centre,
Sixth Avenue, Zone 2,
Deeside Industrial Estate,
CH5 2LE
Tel: [phone]
Fax: [phone]
[e-mail]
www.abtechsafety.com

Product Name
Product Code
Serial Number
Date of Manufacture
___________________________________________________________________________________
EC DECLARATION OF CONFORMITY
Notified Body Issuing EC Certification
Satra Quality Assurance Ltd
Wyndham Way
Kettering
Northamptonshire
NN16 8SD
Notified Body Number 0321
Explanation of Markings
CE Marking: Meets the requirements of PPE Regulation (EU) 2016/425.
0321CE Notified body number and CE mark
All Abtech Safety TORQ conform to:
BS EN360:2002 Personal Protective Equipment against Falls from a Height, Retractable Type Fall Arrestors.
ANSI/ASSE Z359.14-2012 - Safety Requirements for Self-Retracting Devices for Personal Fall Arrest and Rescue Systems
In addition to BS EN360: 2002 the ‘TORQ AB15RT’ conforms to BS EN1496:2006 Class A and B Lifting Device.
Production Code/Model Number (All Abtech Safety TORQ)
yydddXXXX year of manufacture and traceable batch code
e.g.(09 year, day of year, XXXX unique serial number)
Book Pictogram: reminder to read and understand these user instructions,
which should be retained for future reference
Production Code/Model ‘TORQ AB15RT’ BS EN1496:2006 Recovery Block,
Class A and B Lifting Device
150kg: Maximum working load/rated load
15m: Maximum lifting distance (line length)
This Manual and its contents © Abtech Safety Limited 2019
Abtech Safety TORQ Range of Fall Arrest Devices Manual
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior permission of
Abtech Safety Limited.
Abtech Safety Ltd, 1&2 Parkway Business Centre, Sixth Avenue, Zone 2, Deeside Industrial Estate, CH5 2LE
Tel: [phone] Fax: [phone]
[e-mail] www.abtechsafety.com
Registered in England No. 2656103
FEBRUARY 22-02-2019
Product Code
Contact Details
Conformance
Instructions
Warnings
Illustrations showing the location of markings on
the equipment:
Serial Number Location

DATE PASS/FAIL COMMENTS/ACTIONS NEXT
INSPECTION DUE PRINT NAME SIGNED
/ / / /
/ / / / / / / /
/ / / /
/ / / /
/ / / /
/ / / /
/ / / / / / / /
/ / / / / / / /
/ / / /
SUPPLIER:......................... DATE PURCHASED:......../......./........ USER NAME:................................. DATE FIRST USED:......../......./........
PRODUCT RECORD CARD
Type of Use Conditions Of Use Detailed Inspection Factory Service
Infrequent to Light Good storage, indoor, clean environment Bi Annual Annually
Moderate to Heavy Fair storage, extended outdoor use, dusty
environments Quarterly Annually
Severe to Continuous Poor storage, harsh conditions, prolonged outdoor
use, all temperatures, dirty environment Monthly Bi Annually
The inspection intervals shall be set by the program administrator and shall be equal to or exceed the following inspection intervals
recommended by Abtech Safety. (Documentation of the equipment inspections shall be maintained by the program administrator.)

DATE PASS/FAIL COMMENTS/ACTIONS NEXT
INSPECTION DUE PRINT NAME SIGNED
/ / / /
/ / / /
/ / / / / / / / / / / /
/ / / /
/ / / /
/ / / /
/ / / /
/ / / / / / / /
/ / / / / / / /
/ / / /
/ / / /
/ / / /
/ / / /
/ / / /

OWNER / HIRER DETAILS OR ADDITIONAL NOTES
