Abtus CAT-GA11T User manual

CAT-GA SERIES
CAT-5
VGA Extender (T/R)
USER MANUAL
SINGAPORE
SINGAPORE
Transmitter
CAT-GA11T/A
CAT-GA14MT/A
Receiver
CAT-GA11R/A

CAT-GA SERIES
SINGAPORE
CAT-5 Extender VGA 1 X 4 T nsmitter
Max Resolution 1600 x 1200
FEATURES
INPUT : VGA / PC Audio
OUTPUT : 1. Monitor with Audio,
2. 4 X CAT5 UTP on an R -45 Connector
POWER ADAPTER (min.) : DC 12V 500mA
DESCRIPTION
The ABtUS CAT5-GA14MT/A splits computer video and PC audio into 4 identical
outputs and transmit up to 492FT (150 meter) via CAT 5e twisted pair (UTP/STP)
cables. The ABtUS CAT5-GA14MT/A transmits to 4 ABtUS CAT-GA11R/A receiver
with no loss of signal quality. A/V professionals enjoy more flexibility and lower cost
of CAT5e UTP/STP cables for their A/V installations.
VGA
CAT5 - RJ45
VGA Stereo Audio
Ethernet C ble
492ft
(150 meter)
Typic l Applic tion
* Specifications are subject to change without notice.
GA Series
Configuration Diagram
(CAT-GA11T/A) (CAT-GA14MT/A) (CAT-GA11R/A)
CAT-GA SERIES
Transmitter
Technic l Specific tions CAT-GA11T/A CAT-GA14MT/A
VGA (D-Sub 15 pin) 11
RJ-45 CONNECTOR 14
MON TOR VGA OUT (D-Sub 15 pin) -1
ADJUSTMENT --
MAX RESOLUT ON 1600 x 1200 1600 x 1200
POWER ADAPTER DC 12V 500mA DC 12V 500mA
HOUS NG Metal Metal
D MENS ONS (LXWXH) mm 99 X 54 X 26 80 X 150 X 30
Receiver
Technic l Specific tions CAT-GA11R/A
VGA (D-Sub 15 pin) 1
RJ-45 CONNECTOR 1
MON TOR VGA OUT (D-Sub 15 pin) -
ADJUSTMENT 2
MAX RESOLUT ON 1600 x 1200
POWER ADAPTER DC 12V 500mA
HOUS NG Metal
D MENS ONS (LXWXH) mm 99 X 54 X 26
