Abus TVVR33004 User manual

4-/8-Channel Analogue HD Digital Recorder
TVVR33004 / TVVR33008
User guide
Version 1.0

English
This user guide contains important information on starting
operation and using the device.
Make sure that this user guide is handed over when the
product is given to other persons.
Keep this user guide to consult later.
You will find a list of contents with the corresponding
page numbers in the contents.

Contents
68
Important safety information........................................................................................................................................71
Explanation of symbols..................................................................................................................................................71
Intended use ..................................................................................................................................................................71
General ..........................................................................................................................................................................71
Power supply .................................................................................................................................................................71
Overload/over voltage....................................................................................................................................................72
Cable..............................................................................................................................................................................72
Installation location/operating environment ...................................................................................................................72
Care and maintenance...................................................................................................................................................73
Accessories....................................................................................................................................................................73
Start-up ..........................................................................................................................................................................73
Children..........................................................................................................................................................................73
Introduction....................................................................................................................................................................74
General information .......................................................................................................................................................74
Unpacking the device.....................................................................................................................................................74
Recorder scope of delivery............................................................................................................................................74
Video surveillance sets scope of delivery......................................................................................................................74
Device overview.............................................................................................................................................................75
Front...............................................................................................................................................................................75
Rear of the 4-channel recorder......................................................................................................................................75
Rear of the 8-channel recorder......................................................................................................................................75
System displays / Systemoperation ............................................................................................................................76
Status displays...............................................................................................................................................................76
LED illumination.............................................................................................................................................................76
General ..........................................................................................................................................................................76
Operating with a mouse.................................................................................................................................................76
On-screen keyboard ......................................................................................................................................................76
Quickstart guide.............................................................................................................................................................77
Before you start..............................................................................................................................................................77
Connections at the back of the device...........................................................................................................................77
Installing the hard disk drive ..........................................................................................................................................77
Make the connections....................................................................................................................................................77
Starting the device .........................................................................................................................................................77
Configuring the device...................................................................................................................................................77
Switching off the device, locking, rebooting...................................................................................................................78
Setup wizard...................................................................................................................................................................79
Setting up the system ....................................................................................................................................................79
Administrator set up.......................................................................................................................................................79
System time and date....................................................................................................................................................79
Network settings ............................................................................................................................................................80
Hard disk drive management.........................................................................................................................................81
Setting up network cameras ..........................................................................................................................................81
Camera recording..........................................................................................................................................................81
Live view.........................................................................................................................................................................82
Overview........................................................................................................................................................................82
Status symbols...............................................................................................................................................................82
Pop-up menu with mouse operation..............................................................................................................................82
Selection bar in the camera image ................................................................................................................................83
Playback in live view .....................................................................................................................................................84
General ..........................................................................................................................................................................84

Contents
69
Playback screen.............................................................................................................................................................84
Control via the control panel..........................................................................................................................................84
Selecting playback type.................................................................................................................................................85
Device menu...................................................................................................................................................................86
Menu overview...............................................................................................................................................................86
Settings...........................................................................................................................................................................87
Menu description............................................................................................................................................................87
Configuration..................................................................................................................................................................88
Overview........................................................................................................................................................................88
General settings.............................................................................................................................................................88
Network layout ...............................................................................................................................................................90
Network configuration....................................................................................................................................................90
General tab ....................................................................................................................................................................91
PPPOE tab.....................................................................................................................................................................91
DDNS tab.......................................................................................................................................................................91
NTP tab..........................................................................................................................................................................92
Email tab........................................................................................................................................................................92
NAT tab..........................................................................................................................................................................93
More Settings tab...........................................................................................................................................................93
Alarm..............................................................................................................................................................................94
Alarm Status tab ............................................................................................................................................................94
Alarm Input tab...............................................................................................................................................................94
Alarm Output tab............................................................................................................................................................95
Live view ........................................................................................................................................................................96
Setting the camera output..............................................................................................................................................96
Warning..........................................................................................................................................................................97
User................................................................................................................................................................................97
Camera............................................................................................................................................................................99
Camera ..........................................................................................................................................................................99
OSD ...............................................................................................................................................................................99
Image...........................................................................................................................................................................100
PTZ ..............................................................................................................................................................................100
Motion ..........................................................................................................................................................................101
Private Zone.................................................................................................................................................................102
Video Tampering..........................................................................................................................................................103
Video Loss ...................................................................................................................................................................104
Videoquality diagnostics ..............................................................................................................................................104
Recording .....................................................................................................................................................................106
Schedule......................................................................................................................................................................106
Record tab ...................................................................................................................................................................106
Stream settings............................................................................................................................................................107
Record tab ...................................................................................................................................................................107
Substream tab..............................................................................................................................................................108
Advanced settings........................................................................................................................................................108
Holiday.........................................................................................................................................................................108
HDD ...............................................................................................................................................................................110
Hard disk drives ...........................................................................................................................................................110
Installing the hard disk drive ........................................................................................................................................110
General ........................................................................................................................................................................110
Advanced settings........................................................................................................................................................111
Manual...........................................................................................................................................................................113
Recording.....................................................................................................................................................................113

Contents
70
Alarm............................................................................................................................................................................113
Manual Video Quality Diagnostics...............................................................................................................................114
Video Export.................................................................................................................................................................115
Normal..........................................................................................................................................................................115
Event............................................................................................................................................................................116
Maintenance .................................................................................................................................................................117
System Info..................................................................................................................................................................117
Log Information............................................................................................................................................................117
Import/Export ...............................................................................................................................................................118
Upgrade .......................................................................................................................................................................118
Default..........................................................................................................................................................................119
Network........................................................................................................................................................................119
Traffic tab.....................................................................................................................................................................119
Network Detection tab..................................................................................................................................................120
Network Stat. tab .........................................................................................................................................................120
S.M.A.R.T.....................................................................................................................................................................121
Checking the hard disk drive status.............................................................................................................................121
Shutdown.....................................................................................................................................................................121
Fault rectification.........................................................................................................................................................122
Cleaning and care of the device.................................................................................................................................122
Note..............................................................................................................................................................................122
Technical data..............................................................................................................................................................123
Disposal........................................................................................................................................................................124
Notes on EC directives for waste electrical and electronic equipment........................................................................124
Notes on RoHS EU Directive.......................................................................................................................................124
Glossary........................................................................................................................................................................125
Technical terms used...................................................................................................................................................125
About the internal hard disk drive .............................................................................................................................127

Important safety information
71
Important safety information
Explanation of symbols
The following symbols are used in this manual and on the
device:
Symbol
Signal
word
Meaning
Warning
Indicates a risk of injury or health
hazards.
Warning
Indicates a risk of injury or health
hazards caused by electrical
voltage.
Important
Indicates possible damage to the
device/accessories.
Note
Indicates important information.
The following annotations are used in the text:
Meaning
1. …
2.
…
Required action to be carried out in a set order
…
…
List without a set order, given either in the text
or warning notice
Intended use
Only use the device for the purpose for which it was built
and designed. Any other use is considered unintended!
This device may only be used for the following
purpose(s):
When connected to video signal sources
(analogue/HD-TVI cameras) and video output
devices (TFT monitor), this 4-/8-Channel Analogue
HD Video Recorder is used to monitor objects.
Note
Data storage is subject to national data privacy
guidelines.
When carrying out the installation advise your
customers of the existence of this guideline.
General
Before using this device for the first time, please read the
following instructions carefully and observe all warning
information, even if you are familiar with the use of
electronic devices.
Warning
All guarantee claims are invalid in the event of
damage caused by non-compliance with this user
manual.
We cannot be held liable for resulting damage.
Warning
In the event of personal or material damage
caused by improper operation or non-compliance
with the safety information, we cannot be held
liable.
All guarantee claims are void in such cases.
Retain this handbook for future reference.
If you sell or pass on the device on to third parties, you
must include these instructions with the device.
This device has been manufactured in accordance with
international safety standards.
Power supply
Only operate this device through a power source
which supplies the mains power specified on the type
plate.
If you are unsure of the available power supply,
contact your utility company.
Warning
Prevent data loss.
Always use the device with an uninterruptable
power supply UPS with surge protection.
Disconnect the device from the power supply before
carrying out maintenance or installation work.
The on/off switch on this device does not fully
disconnect it from the mains supply.
To fully disconnect the device completely from the
mains, the mains plug must be withdrawn from the
mains socket. The device should therefore be
positioned so that there is always direct and
unimpeded access to the mains plug and the plug
can be removed immediately in the event of an
emergency.

Important safety information
72
To eliminate the risk of fire, the mains plug should be
removed from the mains socket prior to an extended
period of non-use. Prior to unstable weather and/or
when there is a danger of lightning strike, separate
the device from the mains network. Alternatively,
connect the device to a UPS.
Warning
Never open the device yourself! There is the
danger of electric shock.
Should it be necessary to open the device, refer to
trained technicians or your specialist installation
contractor.
The installation or replacement of a hard disk drive
should only be carried out by trained personnel or
your specialist installation contractor.
Warning
Installations or modifications not carried out by
trained technicians invalidate the warranty.
We recommend that the installation of a hard disk
drive is carried out by a specialist installation
contractor.
Improper installation of the hard disk drive
invalidates the warranty.
Overload/over voltage
Avoid overloading electrical sockets, extension
cables and adapters, as this can result in fire or
electric shock.
Use surge protection to prevent damage caused by
overvoltage (e.g. in electrical storms).
Cable
Always grasp all cables by the plug connector and do
not pull the cable itself.
Never grasp the power cable with wet hands, as this
can cause a short circuit or electric shock.
Do not place the device itself, items of furniture or
other heavy objects on the cable and ensure that it
does not become kinked, especially at the connector
plug and at the connection sockets.
Never tie a knot in the cable and do not bundle it
together with other cables.
All cable should be laid so that they cannot be
trodden on, or cause a hazard.
A damaged power cable can cause fire or electric
shock. Check the power cable from time to time.
Do not modify or manipulate the power cable or plug.
Do not use any adapter plug or extension cable that
do not conform to applicable safety standards and do
not interfere with the mains or power cables.
Installation location/operating environment
Place the device on a firm, level surface and do not
place any heavy objects on the device.
The device is not designed for operation in spaces
with high temperatures or humidity (e.g. bathrooms),
or excessive accumulation of dust.
Operating temperature and operating humidity:
-10°C to 55°C, maximum 85% relative humidity. The
device may only be operated in a temperate climate.
Ensure that:
adequate ventilation is always guaranteed (do not
place the device on a shelf, thick carpet, bed or
wherever ventilation slits may be covered. Always
leave a 10 cm gap on all sides)
no direct sources of heat (e.g. radiators) have an
impact on the device
the device must not be exposed to direct sunlight or
strong artificial light
the device is not in the immediate vicinity of magnetic
fields (e.g. loudspeakers)
no naked lights (e.g. lit candles) are on, or next to the
device
contact with sprayed or dripping water and caustic
fluids is prevented
the device is not operated in the vicinity of water, in
particular, the device should never be submerged (do
not place objects containing fluids, e.g. vases or
drinks on or near the device)
no foreign bodies penetrate the device
the device is not exposed to wide temperature
variations, as otherwise there may be condensation
from humidity causing electrical short circuits
the device is not exposed to excessive shock or
vibration.

Important safety information
73
Care and maintenance
Maintenance is necessary if the device has been
damaged (e.g. damage to the power cable and plug, or
the housing), or if liquids or foreign bodies have got into
the interior of the device, or if it has been exposed to rain
or damp, or if it does not work properly or has been
dropped.
When conducting maintenance work (e.g. cleaning),
disconnect the device from the mains.
If smoke, unusual noises or smells occur, switch the
device off immediately and unplug from the socket. In
such cases, the device should not be used until it has
been inspected by a qualified technician.
Have all maintenance tasks carried out by qualified
technicians only.
Never open the housing of the device or accessories.
If the housing is open there is the risk of fatal electric
shock.
Clean the device housing and the remote control with
a damp cloth.
Do not use solvents, white spirit, thinners etc. These
may damage the surface of the device.
Do not use any of the following substances:
Brine, insect spray, solvents containing chlorine or
acids (ammonium chloride), or scouring powder.
Rub the surface gently with the cotton cloth until it is
completely dry.
Warning
The device operates with a dangerous voltage
level. The device should therefore only be opened
by authorised technicians. All servicing and
maintenance tasks must be carried out by
authorised companies. Inadequate repair work
can cause a fatal hazard for the user.
Accessories
Only connect devices that are expressly suitable for
the intended purpose. Otherwise, hazardous
situations or damage to the device can occur.
Start-up
Observe all safety and operating instructions before
operating the device for the first time.
Only open the housing to install the hard disk drive.
Warning
When installing the device in an existing video
surveillance system, ensure that all devices have
been disconnected from the mains power circuit
and low-voltage circuit.
Warning
If in doubt, have a specialist technician carry out
assembly, installation and connection of the
device.
Improper or unprofessional work on the power
supply system or domestic installations puts both
you and others at risk.
Connect the installations so that the mains power
circuit and low-voltage circuit always run
separately from each other. They should not be
connected at any point or become connected as a
result of a malfunction.
Children
Do not allow electrical devices to be handled by
children. Do not allow children to use electrical
devices unsupervised. Children may not properly
identify possible hazards. Small parts may be fatal if
swallowed.
Also keep packaging film away from children. There
is the risk of suffocation.
This device is not intended for children. If used
incorrectly, parts under spring tension may fly out and
cause injury to children (e.g to eyes).

Introduction
74
Introduction
Dear Customer,
Thank you for purchasing this product.
This device complies with the requirements of the
applicable EU directives. The declaration of
conformity can be obtained from:
ABUS Security-Center GmbH & Co. KG
Linker Kreuthweg 5
86444 Affing
GERMANY
To ensure this condition is maintained and that safe
operation is guaranteed, it is your obligation to observe
this user manual.
Please read the entire user manual carefully before
putting the product into operation, and pay attention to all
operating instructions and safety information.
All company names and product descriptions are
trademarks of the corresponding owner. All rights
reserved.
If you have any questions, please contact your specialist
installation contractor or specialist dealer.
Disclaimer
This user manual has been produced with the
greatest of care. Should you identify any
omissions or inaccuracies, please contact us at
the address shown on the back of the manual.
ABUS Security-Center GmbH does not accept any
liability for technical and typographical errors, and
reserves the right to make changes to the product
and user manuals at any time and without prior
warning. ABUS Security-Center GmbH is not
liable or responsible for direct or indirect damage
resulting from the equipment, performance and
use of this product. No guarantee is made for the
contents of this document.
General information
To use the device properly, read this user handbook
thoroughly and retain it for later use.
This handbook contains instructions for the operation
and maintenance of the recorder. Please contact an
authorised specialist company for repair of the device.
Note
Be aware that alterations to the recorder carried
out via the software must be accepted by clicking
"Apply"/"Confirm" before leaving the tab or menu.
Unpacking the device
Handle the device with extreme care when unpacking it.
Packaging and packaging aids can be reused and as far
as possible should be sent for recycling.
We recommend that:
Paper, cardboard and corrugated cardboard, as well as
plastic packaging items should be placed in the
appropriate containers provided.
If no such facility exists in the area, then these materials
should be put into general household waste.
If the original packaging has been damaged, start by
inspecting the device. If the device shows signs of
damage, return it in the original packaging and contact
the manufacturer.
Recorder scope of delivery
ABUS 4/8-Channel Analogue HD Video Recorder
USB mouse
S-ATA cable and screws for hard drives
Power supply unit
Network cable
CD
User handbook
Quickstart guide
Video surveillance sets scope of delivery
ABUS 4/8-Channel Analogue HD Video Recorder
2/4 analogue HD cameras
2.5" 1 TB hard disk drive pre-installed
USB mouse
Power supply unit including 5-/9-way distribution
cable
2/4 combi cable
Network cable
CD
User handbook
Quickstart guide

Device overview
75
Device overview
Front
Rear of the 4-channel recorder
Rear of the 8-channel recorder













System displays / Systemoperation
76
System displays / Systemoperation
Status displays
The following status displays provide information about
the operating status:
LEDs on the top of the device
acoustic signal tones
icons (display elements) on the monitor.
Note
Note the remarks in the separate quickstart guide.
LED illumination
Note
Refer to the overview on page 75.
Status
Function
Lit blue without
flashing
System status OK
Off
The device is switched off or
the status display has been
manually deactivated in the
menu.
General
The device can be controlled using the following:
a USB mouse
Web interface
CMS software
Operating with a mouse
Note
The further descriptions contained in this user
guide involve using a mouse.
The device is suitable for use with a USB mouse.
Connect the mouse to the USB port.
Button
Function
Left
Single click:
Selection in the menu, activation of an input
field or a tab, display of the Quick Set
menu.
On-screen keyboard
If you click with the mouse in a text input field, the on-
screen keyboard appears:
For simple figure input, the following on-screen
keyboard appears:
The keys have exactly the same function as a
computer keyboard.
To input a figure, click on it with the left mouse key.
To finish the entry, click on Enter.
To delete the figure in front of the cursor, click on
.
To switch between upper and lower case text, click
on the framed a. The active setting is indicated
above the keyboard.
To cancel an entry, or to leave the field, click on
ESC.
Double click:
Switch between the screen display of single
and multiple images in the live view and
during playback.
Click and drag:
Set up private masks or zones.
Right
Single click:
Open the pop-up menu.
Return to the previous menu.
Scroll
wheel
In live view:
Display previous/next camera.

Quickstart guide
77
Quickstart guide
Before you start
The following preparations must be completed:
1.
Pay attention to the general information, safety
information as well as statements on placement and
connection.
2.
Check the contents of the package for completeness
and damage.
Note
Note the remarks in the separate quickstart guide.
Connections at the back of the device
Note
Refer to the overview on page 75.
No
Name
Function
1
VIDEO IN:
BNC input for HD-TVI and analogue cameras
2
HDMI
HDMI monitor connection
3
VGA:
VGA monitor connection (9-pin), video output
signal
4
USB:
USB connections for operating with a mouse and
data export
5
POWER SUPPLY
12 V DC
6
LAN:
Ethernet LAN connection
Installing the hard disk drive
Warning
Switch the device off and disconnect it from the
mains electricity.
Ensure proper earthing to avoid static discharge.
1.
Install a hard disk drive, see separate quickstart
guide.
2.
First make a connection to the motherboard with the
blue data cable (small connector).
3.
Connect the power cable (large connector, 5-core).
4.
Check that the connections are firmly in place.
5.
Close the housing.
Note
Only use hard disk drives that are authorised for
video recording and 24/7 operation.
Make the connections
Note
Observe the minimum radius when laying the
cables. Do not kink the cables.
1. Connect all cameras to the recorder.
2. Connect the recorder to the LAN via the network
cable.
3. Connect the monitor using the VGA or HDMI
connection.
4. Connect the mouse to the USB port.
5. Connect the device to the mains power supply, it will
then start automatically. The video surveillance sets
also include a distributor cable which enables
multiple cameras and the recorder to be operated
using a single power supply unit.
Note
During installation of the video surveillance sets,
ensure that the maximum power supplied by the
power supply unit will be sufficient for all the
devices connected. Please refer to the devices'
technical data for information about the maximum
power supplied.
If the power supply unit does not provide enough
power, please use suitable power supply units that
will supply enough voltage to the cameras.
Starting the device
Attention
The device may only be connected to a mains
voltage supply as specified on the type plate.
For security purposes, use an uninterruptible
power supply (UPS).
When the device is connected to the power supply, it
starts up automatically and the LED status bar glows.
1.
During the start-up procedure, the device carries out
a self-test.
2.
Finally, the setup wizard appears. End this, to go to
live view.
Configuring the device
Note
Note the remarks in the separate quickstart guide.
Carry out the individual steps in the "set-up wizard".
The following settings are configured one after the
other: (Sequence)
1. Select the operator console language
2. Administrator configuration

Quickstart guide
78
3. Time settings (date, time etc.)
4. Network settings
5. Hard disk drive management (initialisation etc.)
6. Camera settings
7. Recording settings
Note
From the ABUS home-page (www.abus.com),
find out if new firmware updates are available
for this device and install these.
Note
Later alteration of date and time can lead to loss of
data.
Note the explanation of:
Description
page 75
Live view
page 82
Playback
page 84
Network
page 90
Recording
page 106
Data export
page 115
Troubleshooting
page 122
Switching off the device, locking, rebooting
In the main menu, click on Shutdown. The overview
appears.
1.
To switch off, select the Shutdown option and
confirm the query with Yes. The device is switched
off. Now pull out the plug of the power supply unit.
3.
To lock the system, select the left hand symbol
Logout. The user interface is locked. To reach the
menu, a password must be entered.
4.
To reboot, select the right hand symbol Reboot. The
device carries out a reboot.
Switching on the device
Plug in the power supply unit to start the device.

Setup wizard
79
Setup wizard
Setting up the system
The setup wizard guides you through the required basic
settings for the system. The video recorder will then be
ready for recording and monitoring.
Note
All of the advanced settings can be found in the
device menu.
Following the first switch-on, the language selection
appears:
1.
Click on the input field and select your language from
the list. To proceed, click on . The following query
appears:
Click on Next to start the wizard.
Note
After the system has been set up the 'checkbox'
can be deactivated, the tick is hidden and the
wizard no longer starts automatically.
Administrator set up
Warning
Note down the admin password.
The preset password is:
"1 2 3 4 5".
1.
Click on the input field and enter the admin
password.
2.
To assign a new password, activate the 'checkbox' in
front of New Admin Password.
3.
Enter the new password and confirm the entry in the
field below.
4.
Click on Next.
System time and date
1. Enter the system time consisting of date and time.
2. Finish the setting by clicking
on Next.

Setup wizard
80
Network settings
Note
Ask the network administrator responsible
whether the DHCP can be selected or the IP
address and additional settings have to be done
manually.
1. DHCP active: if the DHCP has been set up in the
network router, enable the DHCP 'checkbox'. All
network settings are then completed automatically.
2. DHCP inactive: enter the data manually (IPv4
address, IPv4 subnet mask as well as the default set
up for the IPv4 Gateway = IPv4 address of the
router). Alternatively you can also enter the address
of the DNS server, which is required for email
dispatch.
A typical address assignment could appear as
follows:
IPv4 address: 192.168.0.50
IPv4 Subnet Mask: 255.255.255.0
IPv4 Default Gateway: 192.168.0.1
Preferred DNS Server: 192.168.0.1
Note
If at the time of the initial installation there is no
detailed data on port and DDNS configuration,
then use the default settings recommended by the
wizard.
1. Server Port: network port for remote access via
PC software and App
2. HTTP port: network port for remote access to the
web interface of the recorder.
3. Enable UPnP: enables the automatic
configuration of the port releases on the router
and device display in the windows network
environment.
4. Enable DDNS: enables the DDNS function for
comparison of the external IP addresses with a
DDNS provider.
5. DDNS Type: select the DDNS provider. There is
free DDNS access via abus-server.com.
6. Server address: enter the address data for the
DDNS provider here (not necessary for ABUS
server).
7. User name and password: enter the access data
for the DDNS provider here (not necessary for
ABUS server).
Note
When the device is accessed remotely via the
internet, it should be given a fixed network
address.

Setup wizard
81
Hard disk drive management
1. To set up a hard disk drive, enable the 'checkbox'
with a left click and then click on Init.
Warning
This will delete all data found on the disc.
2. Click on OK to acknowledge the security prompt.
The hard disk drive is set up for use. Progress is
shown on the status bar.
3. Finish the setting by selecting OK and then click on
Next.
Setting up network cameras
1. To set up network cameras, click on Search.
2. An overview of all detected network cameras will
then appear.
3. Activate the "checkbox" with a left-click to select the
network camera and then click on Add.
4. No more than one IP camera can be added.
5. Click on Next.
Camera recording
1. Select a "camera" from which to record.
2. Enable the check box "Start recording".
3. Select the recording type. It is possible to select
between "Continuous" and "Movement detection".
4. Press Copy to apply the setting to other cameras.
Select the cameras that appear in the new screen.
Enable the appropriate checkbox with a mouse click.
5. Complete the setting and the setup wizard with OK.

Live view
82
Live view
Overview
Live view starts automatically when the device is
switched on.
The following menus are found in the header:
Menu and
Playback
PTZ
The device date and time are displayed on the right-hand
side of the header. To the left, you will find multi view.
Click on the icon to open the pop-up menu of the
multi view.
Click on one of the icons in the pop-up bar that
appears in order to switch between the different
views.
The signals of the connected cameras are displayed on
the main screen.
By double clicking with the left mouse button, you can
display the selected camera image in full screen or
switch back to the original view.
Status symbols
The following symbols are displayed depending on
the operating status of the device:
Symbol
Meaning
R
R
Yellow: motion recording
recording only upon motion detection
Blue: recording
continuous recording
Pop-up menu with mouse operation
Note
Right click when the mouse pointer is positioned
on a live image.
The following settings can be made. The arrow pointing
to the right indicates that a sub-menu opens for selection:
Menu
Opens the main menu
Single Screen
Full-screen view of the selected
camera.
Multi-screen
Various camera layouts
Previous Screen
Displays the previous camera
Next Screen
Displays the next camera(s)
Start Auto-switch
Starts the camera sequence display
Start Recording
Overwrites the record schedule of all
cameras connected for continuous
or movement recording and initiates
this.
Quick Settings
Sets the output mode for the screen
display
Playback
Switch to playback view
PTZ
Enables the PTZ mode of the
selected camera.
Note
Start Auto-switch:
Specify the display sequence delay in the display
settings.

Live view
83
Selection bar in the camera image
In single or multi-screen, click on a camera image. A
selection bar will appear:
(1) (2) (3) (4) (5) (6) (7) (8)
No
Meaning of the symbol
(1)
Area for moving the miniature bar
(2)
Activate/deactivate manual recording
(3)
Instant playback of the last 5 minutes
(4)
Activate/deactivate the audio function
(5)
Open the PTZ control menu (for PTZ cameras
only)
(6)
Enable digital zoom.
(7)
Image display settings
(8)
Close the selection bar

Playback in live view
84
Playback in live view
General
There are three different options for playback:
Through the event search in the main menu
From the live display
Via Log Information in the maintenance menu.
Note
The "Previous/Next file/day/event" buttons are
allocated as follows, depending on the playback
mode:
Normal playback:
Pressing one of the buttons switches playback to
the previous/next day.
Event search:
Pressing one of the buttons switches playback to
the previous/next event.
Data export:
Pressing one of the buttons switches playback to
the previous/next file.
Note
It is possible to start playback on up to 16 camera
channels at the same time.
Playback screen
Playback is controlled via the control panel:
No
Area

Running playback with date and time

Selection of camera for playback

Calendar with recording type

Control panel with time bar (see right)

Selection of playback type
Control via the control panel
The control panel (4) is used to control running playback.
The symbols have the following meanings:
No
Meaning of the symbol
1
Time bar:
Click on the time bar with the mouse to continue
playback from another point.
Click on the slider and drag it to a specific time
to start playback from that point.
2
Enable/disable audio output.
3
Start/stop video clip export.
4
Save video clip.
5
Add tag (see "Tag" playback type).
6
Add user-defined tag (see "Tag" playback type).
7
Tag management.
8
Digital zoom
9
Reverse playback.
10
Stop playback
11
Start/pause playback.
12
Go back 30 seconds.
13
Go forward 30 seconds.
14
Go forward in slow-motion (8x 1x).
15
Fast forward (1x 8x).
16
Previous day.




(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
2
5
6
7
8
9
14

(20)
(21)

Playback in live view
85
17
Next day.
18
Reduce time bar section.
19
Increase time bar section.
20
Tag for continuous recording
21
Tag for event recording (movement, alarm)
Click on "Tag management" (6):
Click on the edit icon to change the description of
your tag. To remove a tag, click on the delete icon.
Selecting playback type
Selecting the playback type (5) allows various types of
recording and event to be displayed and filtered in the
playback view.
The following menus are available:
Type
Description
Normal
Playback of recorded video data.
Event
Search and playback of video data
recorded by means of motion detection or
alarm input.
Tag
Search and playback of video data
provided with a tag.
Smart
Search and playback of video data via pre-
defined full screen motion detection for all
recorded data.
External
File
Search and playback of video data found
on a connected external data storage
device (USB).
