Accell K172B-002B User manual

USB 3.0 Docking Station
User Guide

2
Contents
• USB 3.0 docking station
• USB 3.0 A-B cable
• AC power adapter
• User guide
Specications
Input Ports
• 1 x USB 3.0 (Standard B Type)
• 1 x DC power
Output Ports
• 2 x USB 3.0
• 1 x USB 2.0 with BC 1.2 power charging*
• 1 x HDMI 1.3
• 1 x DisplayPort 1.2
• 1 x Gigabit Ethernet (RJ45)
• 1 x Combo audio (headphone/microphone)
*BC 1.2 can detect the correct charging current and battery level,
and provide the optimal level of charging, increasing lifespan of
charged devices.

3
Product Overview
Front View
Back View
1
23
445
6
7
8
9
10
1. Housing vents
2. Audio/Microphone
3. Power LED
4. USB 3.0
5. USB 3.0 BC 1.2
6. Power in
7. USB 3.0 Type-B
8. HDMI
9. DisplayPort
10. Ethernet

4
The Accell docking station uses the DisplayLink DL5900 chipset. For
the latest drivers, go to
Follow the steps below to quickly set up your docking station.
: Install driver before connecting docking station to
computer.
3 4
SS
SS
5
WWW
6
SS
HDD
1IMPORTANT: DO NOT connect
the Docking Stationuntil you
have installed the drivers on your
2
For network/IT administrators, please
visit thislink for a corporate installation
software package.
(*User registration required)

5
Setup using Windows
1. Download the latest drivers at www.displaylink.com/
downloads
• For network/IT administrators, please visit the following
link for a corporate installation software package. (User
registration required.)
• www.displaylink.com/corporateinstall
2. Install the DisplayLink driver.
3. Follow the screen instructions until the installation is complete.
4. Click “Reboot” to restart the computer.
5. Connect your docking station and peripherals to your computer.

6
Maximum Resolution and Refresh Rate
Connected Ports DisplayPort HDMI
Single 3840x2160 / 30Hz Not connected
Single Not connected 2560x1440 / 50Hz
Dual Displays 2048x1152 / 60Hz 2048x1152 / 60Hz
Recommended System Requirements
Processor Intel Core i5 or i7 2.0+ GHz,
AMD Llano or better
Memory 4 GB
Video Card Intel HD 4000,
ATI Radeon HD5/6xxx,
NVidia GeForce 4xxM or better*
USB USB 3.0 port
Operating System Windows 7 or newer (32/64-bit),
Mac OS 10.6 or newer
Operating Temperature
Operating temperature: 41°F to 104°F
Caution: Do not block housing vents.
Power LED Indication
Normal working mode: white light
Platform standby: amber light
Power off: light off

7
DisplayLink Manager Menu
Menu Option Description
DisplayLink Manager Displays the version of the installed
DisplayLink software.
Check for Updates Checks Windows update.
DisplayLink Devices Checks connected DisplayLink devices.
Audio Setup Opens the Windows Audio Conguration
window.
Video Setup Opens the Windows Screen Resolution
window.
Screen Resolution Displays a list of available resolutions.
Screen Rotation Rotates the screen clockwise or counter-
clockwise.
Extend To Extends the display to the right or left of the
main display.
Extend Extends the Windows desktop onto the
displays.
Set as Main Monitor Sets this screen as the main display.
Notebook Monitor Off Switches off the display of the notebook
and makes the DisplayLink display the main
display.
Mirror Copies what is on the main display and
reproduces it on this display.
Off Switches off the display.
Fit to TV Use this function to adjust the size of the
windows to t the TV screen.

8
Set Display to Extended Mode
1. Click on the DisplayLink icon.
2. Select Extend.
This device is now extended in the direction it was the last time
the display was in this mode. For more control, use the Extend To
submenu and select one of the options. This puts the device into
extend mode, and places it to the Left/Right/Above/Below the main
(primary) monitor.
Set Display to Mirror Mode
1. Click on the DisplayLink icon.
2. Select Mirror.
The resolution, color depth and refresh rate of the primary screens
are replicated on the monitor connected to the docking station.

9
Set Display to Fit TV
1. To congure Fit to TV, choose the option from the DisplayLink
graphical user interface (GUI). The following interface appears:
2. You will also see a red border on the DisplayLink screen.
The red border shows the size of the new Windows desktop. Use the
“+” and “-” controls on the Fit to TV GUI to change the size of the red
border until it ts on the TV screen.
Note: Finer conguration of the size of the border can be achieved
by holding down the CTRL key and click on the “+” and “-”.
3. Once the red border is at the edges of the TV screen, click Apply
to resize the Windows desktop.

10
Customer Support and Assistance
If you have questions please check out our web site at:
www.accellcables.com. Technical Support can be reached by
free at 1-877-353-0772 (M-F 9am-5pm PST).
FCC Compliance
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
CE Compliance
This equipment is in compliance with the requirements of the
following regulations: EN 55 022: CLASS B
Warranty Returns Procedure
To return an item under warranty, contact Customer Support by
obtain a Return Authorization (RMA) number. RMA numbers are
valid for 30 days from the date of issuance. We are unable to accept
returns without an RMA number. Returns without an Accell issued
RMA number clearly printed on the outside of the package will be
returned unopened. All returns must be shipped prepaid at the
expense of the shipper. All returns must include a copy of the dated
sales receipt.
The information above is believed to be accurate, however Accell
assumes no responsibility for any inaccuracies and liability for direct,
indirect, special, incidental, or consequential damages as a result. Due
to ongoing improvements, Accell reserves the right to make changes to
hardware, packaging and any documentation without prior written notice.

11
:DUUDQW\
Accell USB 3.0 Docking Station is warranted by Accell Corporation to
be free of defects in material and workmanship for 2 year from the
date of purchase. In the event of such defects, the Accell product will
be repaired without charge or, at our option, replaced with a new one
if delivered to Accell Corporation prepaid, together with a copy of the
dated sales receipt. This warranty excludes defects due to normal
ZHDUDEXVHVKLSSLQJGDPDJHPRGL¿FDWLRQRUIDLOXUHWRXVHWKH
cable in accordance with the instructions. ACCELL CORPORATION
SHALL NOT BE LIABLE FOR DAMAGES BASED UPON
INCONVENIENCE, LOSS OF USE OF THE CABLE OR OTHER
ACCELL PRODUCT, LOSS OF TIME, INTERRUPTED OPERATION
OR COMMERCIAL LOSS, OR ANY OTHER DAMAGES, WHETHER
INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
7KLVZDUUDQW\JLYHV\RXVSHFL¿FOHJDOULJKWVDQG\RXPD\KDYH
other rights that vary from state to state. Limitation of Liability: IN
NO EVENT SHALL ACCELL CORPORATION, ITS SUBSIDIARIES
OR AFFILIATES, OR THEIR RESPECTIVE PARTNERS,
OFFICERS, DIRECTORS, EMPLOYEES, SHAREHOLDERS,
REPRESENTATIVES OR AGENTS (COLLECTIVELY,
“ACCELL”) BE LIABLE FOR DIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL, PUNITIVE, OR INDIRECT DAMAGES
(INCLUDING BUT NOT LIMITED TO, LOSS OF DATA, USE OR
PROFITS), HOWEVER CAUSED, WHETHER FOR BREACH OF
CONTRACT, NEGLIGENCE, OR OTHERWISE, AND WHETHER
OR NOT ACCELL HAS BEEN ADVISED OF THE POSSIBILITY
OF ANY SUCH DAMAGES. YOU AGREE THAT ACCELL’S
MAXIMUM LIABILITY ARISING FROM ANY PRODUCT SOLD BY
ACCELL SHALL NOT EXCEED THE PRICE OF SUCH PRODUCT.
SOME JURISDICTIONS DO NOT ALLOW THE LIMITATION OF
EXCLUSION OF LIABILITY FOR CERTAIN DAMAGES, SO THE
ABOVE MAY NOT APPLY TO YOU TO THE EXTENT SUCH
JURISDICTION’S LAW IS APPLICABLE TO THIS AGREEMENT.
© 2017 Accell Corporation. All Rights Reserved. Accell is a registered
WUDGHPDUNVRI$FFHOO&RUSRUDWLRQ6SHFL¿FDWLRQVDUHVXEMHFWWR
change without notice.
3DUW.%%
2019
