Accell Thunderbolt 4 User manual
1
System Requirements
Introduction
Accell Thunderbolt™ 4 Docking Station is a full-featured Dock that supports Thunderbolt 4
technology. It expands multiple peripheral connections through one single connection to
your system. It also provides Power Delivery charging capability to your Thunderbolt 4 laptops
at a maximum output of 96W.
• Microsoft Windows 10 (RS4 and above) Thunderbolt™ 4 enabled laptops (Intel Evo Platforms)
• macOS 11 (Big Sur and newer) MacBooks Pro and MacBook Air with Thunderbolt 3 ports
(For Apple M1 MacBooks, only one video output is supported)
What’s in the Box
● Thunderbolt™ 4 docking station x 1
● Thunderbolt™ 4 cable x 1
● Power adapter [20V/6.75A - 135W] x 1
● US power Cord x 1
● EU power Cord x 1
● User guide x 1
Specifications
● 1 x Thunderbolt™ 4 Upstream port (96W)
● 2 x Thunderbolt™ 4 Downstream port (15W)
● 1 x DisplayPort 1.4 port
● 3 x USB 3.1 Gen 2 (10Gbps) Type-A Ports (4.5W)
● 1 x USB 2.0 Type-A Ports (7.5W)
● 1 x SD 4.0 UHS-II Card Slot
● 1 x 3.5mm Audio Jack
● 1 x Gigabit Ethernet
2
Product Feature
Ethernet
USB 3.1
USB2.0
Type A
Audio
Jack
USB-C
Thunderbolt™ 4
USB-C
Thunderbolt™ 4
DisplayPortPower In
SD 4.0
Slot
PD 96W
System Setup
1. Power on Your Dock
Connect the power adapter to your dock
3
2. Connect the Dock to your Laptop
Connect the dock with the included Thunderbolt™ 4 cable to your system
3. LED Indicator: Power on (Amber), Host Connected (Blue)
4. Connect and Expand with Other Devices
Connect your USB devices, Ethernet cable, audio headset, and up to two external monitors
using any two ports of the available DisplayPort or two Thunderbolt™ 4 ports.
4
Multiple Display Setup
Single Display
Maximum
Resolution
Dual Displays
Video Output 1 Video Output 2
8K@30Hz
-
-
4K@60Hz 4K@60Hz
8K@30Hz
Accell Thunderbolt™ 4 Docking Station will support up to two external monitors using any two
ports of the available DisplayPort 1.4 and the two Thunderbolt 4 ports, first come first serve.
For Apple M1 MacBooks, only one video output is supported.
Thunderbolt™ 4 Ports DisplayPort 1.4
5
Contact for Thunderbolt Information
https://thunderbolttechnology.net/
www.intel.com/content/www/us/en/io/thunderbolt/thunderbolt-technology-general.html
TM
Contact Accell Customer Support
or call toll free number 1-877-353-0772 (Monday to Friday 9am - 5pm PST)
Thunderbolt is a trademark of Intel Corporation or its subsidiaries.
Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation or its subsidiaries.
WARNING: Cancer or reproductive harm - www.P65Warnings.ca.gov
CAN ICES-003(B)/NMB-003(B)
E364109
I.T.E. ACCESSORY
