Accentrics Home DS-D475-700-1 User manual

Residential Use Only Made in China / Fabriqué au Chine / Hecho en China
* Replaceable Part
x1 Left Arm Panel
x1 Panneau du bras gauche
x1 Panel del brazo izquierdo
x1 Right Arm Panel
x1 Panneau de bras droit
x1 Panel del brazo derecho
x1 Seat Panel
x1 Panneau de siège
x1 Panel de asiento
x1 Back Panel
x1 Panneau arrière
x1 Panel posterior
x2 Seat Cushion
x2 Coussin de siege
x2 Cojín del asiento
x2 Back Cushion
x2 coussin de dos
x2 Amortiguador trasero
x5(Extra 1) M6*50mm Bolt *
x5(Extra 1) Boulon M6*50mm
x5(Extra 1) Perno M6*50mm
x9(Extra 2) M6 Washer *
x9(Extra 2) Rondelle M6
x9(Extra 2) Lavadora M6
x1 M6 Allen Wrench *
x1 Clé Allen M6
x1 Llave Allen M6
x4(Extra 1) M6*15mm Bolt *
x4(Extra 1) Boulon M6*15mm
x4(Extra 1) Perno M6*15mm
DESCRIPTION / DESCRIPCIÓN : / / X Frame 4 pcs Set(1 of 3) Cadre X Quatre pièces(1 sur 3) Marco X Juego de cuatro(1 de 3)
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D475-700-1
C
D
E
G
H
J
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
Page 1 of 3
F
I
B

Step 1.
Lay Right Arm Panel (B) and Seat
Panel (C) on a soft dry surface.
Add Washer (I) to 50mm Bolt
(H).Do this for two bolts. Align the
holes on the two panels and insert
the bolts. Use the Allen Wrench (J)
to tighten, but do not
tightencompletely.
Step 2.
Add Washer (I) to 15mm Bolt
(G).Do this for two bolts. Align the
holes in Back Panel (D) with the
holes in Right Arm Panel (B). Use
the Allen Wrench (J) to tighten.
Steps 3 & 4.
Add Washer (I) to 50mm Bolt
(H).Do this for two bolts. Insert
the bolts and washers into the
holes of the Seat Panel (C). Use
the Allen Wrench (J) to tighten,
but do not tighten completely.
Now add Washer (I) to 15mm Bolt
(G). Do this for two bolts. Insert
the bolts into the holes in Back
Panel (D) and tighten using Allen
Wrench (J).Make sure all panels
are aligned properly and tighten
all bolts completely. Add Seat
Cushions (E)& Back Cushions
(F).
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
Residential Use Only
* Replaceable Part
D
B
G
II
H
J
I
c
FF
EE
J
J
J
C
B
B
D
DD
C
A
II
G
II
H
DESCRIPTION / DESCRIPCIÓN : / / X Frame 4 pcs Set(1 of 3) Cadre X Quatre pièces(1 sur 3) Marco X Juego de cuatro(1 de 3)
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D475-700-1
Step3
Step1 Step2
Step3 Step4
Made in China / Fabriqué au Chine / Hecho en China
Page 2 of 3

Residential Use Only
x1 RDS-D475-700-HWKIT - Hardware Kit *
Liste des pièces de quincaillerie
Lista del kit de materiales
Made in China / Fabriqué au Chine / Hecho en China
Page 3 of 3
* Replaceable Part
REPLACEABLE PARTS / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE
DESCRIPTION / DESCRIPCIÓN : / / X Frame 4 pcs Set(1 of 3) Cadre X Quatre pièces(1 sur 3) Marco X Juego de cuatro(1 de 3)
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D475-700-1
