Access Control Solutions Eternity 4 User manual

LAST REVISION 6/26/2012
Owners Manual and Software guide
Eternity 4 Eternity 5
ACCESS CONTROL SOLUTIONS

Page 2 of 56
TABLE OF CONTENTS
SECTION 1 - GENERAL OVERVIEW 4
I. Foreword.......................................................................................................................................................... 4
About This Manual............................................................................................................................................... 4
Safety Warnings and Cautions .............................................................................................................................. 4
Design Change Disclaimer ................................................................................................................................... 4
Reproduction Disclaimer ...................................................................................................................................... 4
Technical Support ................................................................................................................................................ 4
II. Important information ...................................................................................................................................... 4
Manufacture Default Code Setting:....................................................................................................................... 4
LED and Audio Indicator: .................................................................................................................................... 4
Important Keys:.................................................................................................................................................... 5
III. General Lock Spec ........................................................................................................................................... 6
IV. Eternity 4 Datasheet (Heavy Duty keypad Lock)............................................................................................. 7
Hardware Spec ..................................................................................................................................................... 7
Functions ............................................................................................................................................................. 7
Ordering Information............................................................................................................................................ 7
Door Prep............................................................................................................................................................. 9
Parts List.............................................................................................................................................................10
Eternity 4 Installation Instruction.........................................................................................................................11
V. Eternity 5 Datasheet (Medium Duty keypad Lock).........................................................................................12
Hardware Spec ....................................................................................................................................................12
Software Spec .....................................................................................................................................................12
Mortise Spec .......................................................................................................................................................12
Ordering Information:..........................................................................................................................................12
Eternity 5 Installation ..........................................................................................................................................14
Eternity 5 Mortise-Installation .............................................................................................................................16
SECTION 2 - IKEYPAD V3.7 SOFTWARE GUIDE 19
1. SOFTWARE SETUP................................................................................................................................................19
Operating System ................................................................................................................................................19
Installing 1-Wire USB Driver First ......................................................................................................................19
Installing the iKeypad Software...........................................................................................................................19
Login ..................................................................................................................................................................20
Change System Password ....................................................................................................................................20
2. ACCESS CONTROL MANAGEMENT I .....................................................................................................................21
I. Lock Setup ......................................................................................................................................................21
New Lock Set Up ................................................................................................................................................21
Edit An Existing Lock .........................................................................................................................................24
II. User Setup.......................................................................................................................................................25
Onsite User Setting..............................................................................................................................................25
¬Add/Edit user information........................................................................................................................25
¬Assigning User to lock to Locks...............................................................................................................27
Copy Lock Setting...............................................................................................................................................30
3. ACCESS CONTROL MANAGEMENT II ....................................................................................................................30
III. Time Setting....................................................................................................................................................30
Time Shift Setting ...............................................................................................................................................30
Timed Operation Setting......................................................................................................................................33
Activation / Expiration Date Setting ....................................................................................................................34
Exception Date Setting ........................................................................................................................................37
IV. Lock Management...........................................................................................................................................38
Set Parameter Key...............................................................................................................................................38
Set Time Key ......................................................................................................................................................39

Page 3 of 56
Get Information Key............................................................................................................................................40
Lockout Key .......................................................................................................................................................41
One-Off key/One-Off Code .................................................................................................................................42
¬One-Off Key............................................................................................................................................42
¬One-Off Code ..........................................................................................................................................43
V. Audit Trial ......................................................................................................................................................44
VI. History............................................................................................................................................................47
Lock Audit History..............................................................................................................................................47
Operator Log.......................................................................................................................................................48
SECTION 3 NON-SOFTWARE GUIDE 49
I. General Information: ......................................................................................................................................49
II. Manufacture Default Setting: ..........................................................................................................................49
III. Steps to setup a new lock: ...............................................................................................................................50
IV. Types to operate the lock:................................................................................................................................50
V. Terms:.............................................................................................................................................................50
VI. Functions: .......................................................................................................................................................50
Weekly Chart ......................................................................................................................................................53
•How to program schedule with an “user code” .........................................................................................53
SECTION 5 TROUBLE SHOOTING GUIDE 54
WARRANTY REGISTRATION FORM 55

Page 4 of 56
Section 1 General Overview
I. Foreword
About This Manual
This manual is designed for users of Eternity 4 and Eternity 5. All installation, setup, operational information, procedures,
screen captures, and other relevant materials are contained in this manual.
Safety Warnings and Cautions
When handling a printed circuit board (PCB), guard against possible static discharges by touching a grounded object
BEFORE touching the board. Static shock could cost unexpected damage of the board.
Design Change Disclaimer
Due to design changes and product improvements, information in this manual is subject to change without notice.
Uaccess LLC assumes no responsibility for any errors that may appear in this manual.
Reproduction Disclaimer
Neither this manual nor any part of it may be reproduced, photocopied, or electronically transmitted in any way without
the written permission of Uaccess LLC.
Technical Support
When you experience any difficulty installing or operating the Eternity software, please contact your local distributor or
Uaccess LLC at 1-972-492-0752.
II. Important information
Manufacture Default Code Setting:
1. Default Setting for Login User Name / Password is: dallas / ibutton
2. Operator Password: The default operator password is 00000000 (8 digit Zeros)
3. System Facility Code: The default System password is 000000 (6 digit Zeros) Once changed, it cannot be
changed back to the manufacturer's default.
LED and Audio Indicators:
1. Program Mode: LED indicating GREEN, audio end with two beeps (Successful)
2. Program Mode: LED indicating RED, audio end with one beep (Fail)
3. Key Access Mode: LED indicating GREEN, audio end with two beeps (Valid Access)
4. Key Access Mode: LED indicating Red, audio end with one beep (Fail)
5. Unlock Mode: LED flashing GREEN, lock is in unlock mode
6. Lock Mode: LED flashing RED, lock is in lock mode

Page 5 of 56
Important iButton Keys:
Overview:
iButtons are NOT normally magnetic and will not affect credit cards, watches, or pacemakers. They typically do not emit
radiation of any kind. Stainless steel iButtons are normally pressed into colored plastic tags at the factory to make
identification and use easier. Key-fob tag colors available are white, yellow, pink, red, orange, blue-green, dark-green,
purple, or black. Since all stainless steel iButtons are identical in size and shape they can be provided in any of the
available color key-fob tags by special order. However, there are various default colors for various key types if a
particular color isn't specified when ordered from the manufacturer or distributor.
If in doubt as to the actual key type, you can identify the iButton model number by looking on the metal end cap with a
magnifying glass. The model number beginning with 'DS-' is imprinted there. Some iButtons contain special functions
such as digital memory or real-time clocks, while others merely identify specific users.
The following list contains the most commonly used iButtons:
1. DS1990 - User Key, each key has a digital serial number that cannot be duplicated. Once programmed into lock
memory as a valid user, can be used to lock or unlock locks. (Default key-fob colors : red, yellow, black, orange,
dark-green, brown)
2. DS1904 or DS1994 - Contain an on board real time clock used to reset the lock internal clock. Either one can be
generally used interchangeably with the locks and software (Default key-fob color : Blue-Green)
3. DS1977- Program Key. Use to move programming to / from locks (Default key-fob color : Purple)

Page 6 of 56
III. General Lock Spec
This page shows the similar specifications of the Eternity 4 and Eternity 5.
Keypad: 12 key weather-resistant numeric keypad
Keypad Functions: Permanent codes, Temporary codes, one-time service codes
Power Supply: 4 standard AA batteries with an inside battery pack for all weather conditions
Power Supply Life Expectancy: 10,000 operations, low battery warning when system drops below 4.8 volts
Memory Retention: Flash memory never loses memory even without power (except current time and date)
Programming / Communication Method: iButton key-fob, no annoying wires
Functions: Timed lock functions, (automatically unlock or lock), fully programmable exception dates (holidays),
temporary dates, and time restrictions for keypad code users and iButton key-fobs.
Finishes: Brushed Chrome or Brushed Brass. (Brushed brass E5 only)
Handles: Reversible Levers, inner and outer
Audit Trail: 3000-event audit trail.
Users: 299, can be a mix of keypad codes and iButton key-fobs
Temporary Codes: 10 limit
One Time service code: 10
Anti-tamper: Red-warning light stays on for 60 seconds after 3 consecutive invalid code entries
Mechanical Key Bypass: Standard on all units
Door Preparation: Standard ANSI A115 Series Prep, optional by adding additional 5/8” through-bolt hole to add
stability to the lock and increase security.
Strike Plate: ANSI Standard 115.3. Square corner, 1-1/8 x 2-3/4 inch T strike with 1-1/4 lip-to-center dimension.
Latch: 2 3/4 inch backset standard (2 3/8 inch backset optional), solid brass with 1/2-inch throw 1-inch diameter bore is
required.
Materials: Zinc Alloy
Temperature: 0°F-120°F (-18°C-50°C)
Exposure: Limited direct rain or water conditions.
Accessibility Standard: Meets ADA standards (Americans with Disabilities Act)
Lock Back Time: 1 – 25 seconds (default is 5 seconds)
Working Voltage: 4.8-6.4V
Low Battery Warning: 4.8V or lower
Door Thickness: 1 3/8" to 2"
Keyway: Schlage C6 – (IC or Best compatible available as extra cost option for E5 only as handle option E5ICHDL.)

Page 7 of 56
Eternity 4 Datasheet (Heavy Duty keypad Lock)
Hardware Spec
Functions
Ordering Information
PART
DESCRIPTION
E4TKSC
E
-
4
TM +
Keypad Satin Chrome Lockset
Version
OPTIONAL
ACCESSORIES:
E-MT-L/R
Mortise Assembly (optional)
E4MMP
Mortise mounting
plate
kit (optional, used with E
-
MT
-
L
/
R)
K1977
DS1977 Programming Key
(optional)
K1994
DS190
4 Internal Clock Key
(optional)
K1990
DS1990 iButton User Key
(optional
)
UIBPCR
iButton Reader ('Blue
-
Dot' PC encoder
)
(optional)
USBPCA
USB PC Adapter
(optional)
ESWCD
Eternity Lock Management Software CD
(optional)
FTUK
First Time User Kit (has USBPCA, UIBPCR, K1977)
PARAMETER
DETAIL
Lock Weight
6 Lb
Working Current
<
250
mA
Idle Current
5 µA
Lock Back Time
5 (1
–
25) Seconds
Working Voltage
4.8
-
6.4V
Low Battery Warning
4.8V or lower
Power Source
4 AA Alkaline Batteries
Keypad
Weather Res
istant
Keypad
Handle
Reversible Lever
Door Thickness
1 3/8" to 2"
Keyway
Schlage C 6
Motor Run Time
.6 seconds
(adjustable)
Packed Size
Packed
Weight
CTN Size
DESCRIPTION
SOFTWARE
NON
-
SOFTWARE
Audit T
rail
Yes (3000 entries)
N/A
iButton Key Users
299
(Combine
d
iButton and code)
299
(Combine
d
iButton and code)
Keycode Users
See above
See above
Timed Operation
Yes
Yes
Auto Lock/Auto Unlock
16 time schedules
limited fixed time schedules
Passage Mode
16 time schedules
Single time schedule
Time Shift User
16 time schedules
Single time schedule
Remote Access
Yes
Yes
Storehouse/Classroom Mode
Yes
Yes
One Time Use
Yes
Yes
iButton User
Yes
Yes
Permanent Code User
Yes
Yes
Remote Code User
Yes
Yes
One
-
Touch Lock from Inside
Yes
Yes
Daylight Saving
Yes
Yes
Lock Out Function
Yes
Yes
User Key Assignment Method
Software + Programming Key
Keypad
Software Package
Yes
(Optional)
Pack List:
1. Front Handle
2. Back Handle
3. Front Lock
4. Back Lock
5. Accessory Box
•Standard Latch
•Mechanical Lock
Cylinder
•Screws

Page 8 of 56
MORTISE APPLICATIONS WITH THE ETERNITY 4 LOCK
NOTE: When ordering an E4 for a mortise application it is important to order the lock factory equipped for that use.
The E4 lock must have shallow back mounting plates installed instead of the standard back plates as well as a longer
power cable when used with the mortise latch. While it is possible to refit the shallow E4 back plates in the field, the
standard power cable is very short and is soldered in place inside the lock. When carefully placed the standard cable
will usually reach, but the installation is much more difficult. In addition, there are a number of small springs and
pins that are likely to fall out of place when the back plates are interchanged. The original factory warranty will be
void if a field retrofit is attempted on an E4 lock. If a retrofit to mortise use of an existing standard E4 lock is desired,
contact Uaccess LLC technical support at 972-492-0752 for assistance.
Unlike the E4 itself, the mortise latch must be ordered either left or right handed. This refers to the swing direction and
hinge locations of the door. If in doubt about which mortise type you need, contact your distributor or a factory
representative for advice. While the E5 lock does not need modification for mortise use, like the E4 the mortise used
must be ordered as either left or right handed. If in doubt as to which you need, contact your dealer or Uaccess LLC
technical support at 972-492-0752
Mortise Lock 'Handed' Definitions
Door Swings In
Left Handed Mortise Right Handed Mortise
This side is Outside view of the door
(Keypad and iButton side of door)
*************************************************
Right Handed Mortise Left Handed Mortise
Door Swings Out
This side is Outside view of the door
(Keypad and iButton side of door)

Page 9 of 56
Insert the mortise latch case into mortise pocket. Secure the lock case with two screws. If the mortise assembly has a wire
harness attached, you may use wire cutters to remove it if desired. It is not used for this type of installation and may
obstruct the mortise pocket.
Mortise Spec
3/4" throw heavy
duty deadbolt with anti
-
saw hardened pins
Rustproof heavy duty 2 3/8" backset lock case
Individual springs to prevent lever sag
Forged brass lever handles exceed requirements of ADA
Available in left or right hand versions
Heavy Duty 1/2" latch bolt
with anti
-
friction latch, easily reversible
Interconnected Deadbolt Mortise
:
While unlocked turn the handle up to enable (lock) the deadbolt, or
turn the handle down to disable (unlock) the deadbolt (E5 shown here)

Page 10 of 56
Standard (Non-Mortise applications) Door Prep
Distance between large hole center point and top of lock housing: 5 ¼"
Parts List
1
iButton Reader
9
Inside Mounting Plate
2
Keypad
10
Batteries Housing Cover
3
Outside Lock Housing
11
Inside Lock Hou
sing
4
Outside Lever
12
Inside lever
5
Override Cylinder
13
Spindle
(square bar)
6
Outside Gasket
14
Strike Plate
7
Latch
15
Dust Boot
8
Inside Gasket
