Subject: LSR118 Manual

Revision: 1.2

Issue Date: 12/08/2020

LSR118

1D/2D IP67 Barcode Imager

and NFC Reader

Product Manual

Warnings

This manual contains important information regarding the installation and operation of the LSR118 1D/2D

Barcode Imager and NFC reader. For safe and reliable operation of the imager, installers must ensure that

they are familiar with, and fully understand, all instructions contained herein.

Warranty

Access Ltd warrants that this product shall be free from defects in workmanship and materials for a period of

one year from the date of original purchase. If the product should fail to operate correctly in normal use during

the warranty period, Access will replace or repair it free of charge. No liability can be accepted for damage

due to misuse or circumstances outside Access’control. Access will not be responsible for any loss, damage

or injury arising directly or indirectly from the use of this product. Access’total liability under the terms of this

warranty shall in all circumstances be limited to the replacement value of this product.

Radio Frequency Energy

European EMC directive 89/336/EEC

This equipment has been tested and found to comply with the limits for a class A computing

device in accordance with the specifications in the European standard EN 55022. These

limits are designed to provide reasonable protection against harmful interference. This

equipment generates, uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions may cause harmful interference to radio or

television reception. However, there is no guarantee that harmful interference will not occur in a particular

installation. If this equipment does cause interference to radio or television reception, which can be

determined by turning the equipment on and off, the user is encouraged to correct the interference with one or

more of the following measures: (a) Reorient or relocate the receiving antenna. (b) Increase the separation

between the equipment and the receiver. (c) Connect the equipment to an outlet on a circuit different from that

to which the receiver is connected. (d) Consult the supplier or an experienced radio / TV technician for help.

FCC Compliance Statement (United States)

This equipment generates, uses and can radiate radio frequency energy and if not installed and used

properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio

communication. It has been tested and found to comply with the limits for a class A computing device in

accordance with the specifications in Subpart J of part 15 of FCC rules, which are designed to provide

reasonable protection against such interference when the equipment is operated in a commercial

environment. Operation of this equipment in a residential area may cause interference, in which case the user

at his own expense will be required to take whatever measures may be necessary to correct the interference.

Changes or modifications not expressly approved by the manufacturer could void the user’s authority to

operate the equipment.

Canadian Department of Communications RFI statement

This equipment does not exceed the class A limits for radio noise emissions from digital apparatus set out in

the radio interference regulations of the Canadian Department of Communications.

Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux

appareils numériques de la classe A prescrites dans le règlement sur le brouillage radioélectriques publié par

le ministère des Communications du Canada.

Page 3of 77 Copyright © Access-IS 2020
Contents
Overview............................................................................................................................. 6
Specifications..................................................................................................................... 7
1 Part numbers.............................................................................................................8
Installation.......................................................................................................................... 9
1 Unpack the LSR118..................................................................................................9
2 Connection................................................................................................................9
3 Mounting................................................................................................................. 10
4 Barcode interface options........................................................................................ 10
5 NFC interface options..............................................................................................11
6 Barcode module installation (serial device).............................................................. 12
7 Barcode module installation (USB device)...............................................................12
8 NFC module installation (serial device) ................................................................... 12
9 NFC module installation (USB device).................................................................... 13
10 Test the device........................................................................................................13
11 Barcode configuration software............................................................................... 13
12 Communicate with the NFC module........................................................................13
13 Troubleshooting.......................................................................................................14
14 Maintenance............................................................................................................ 14
Barcode operating modes ............................................................................................... 15
1 Mode summary ....................................................................................................... 15
2 Dumb mode............................................................................................................. 16
3 Host mode...............................................................................................................17
4 Interactive mode......................................................................................................19
Barcode command reference .......................................................................................... 21
1 Basic configuration..................................................................................................22
2 Prefix and suffix solutions........................................................................................ 23
3 LSR118 illumination ................................................................................................24
4 Indicator control....................................................................................................... 26
5 Development commands......................................................................................... 27
6 Triggering................................................................................................................29
7 Counter...................................................................................................................30
NFC operation................................................................................................................... 31
1 Summary of operation............................................................................................. 31
2 Serial communication..............................................................................................33
3 Notifications and data exchanges (serial connection).............................................. 34
4 MIFARE cards......................................................................................................... 37
5 Contactless microprocessor smartcards.................................................................. 38

Page 4of 77 Copyright © Access-IS 2020
7. MIFARE media commands and responses..................................................................... 39
7.1 MIFARE get media type .......................................................................................... 39
7.2 MIFARE load key .................................................................................................... 40
7.3 MIFARE authenticate block (key A or key B)........................................................... 41
7.4 MIFARE read block (key A or key B)....................................................................... 42
7.5 MIFARE write block (key A or key B).......................................................................43
7.6 MIFARE create value block (key A or key B)........................................................... 45
7.7 MIFARE increment value block (key A or key B) ..................................................... 46
7.8 MIFARE decrement value block (key A or key B)....................................................47
7.9 MIFARE Ultralight read block .................................................................................. 49
7.10 MIFARE Ultralight write block.................................................................................. 50
7.11 MIFARE Ultralight-C authenticate - part 1................................................................51
7.12 MIFARE Ultralight-C authenticate - part 2................................................................52
7.13 MIFARE transceive direct........................................................................................ 54
7.14 MIFARE failure status codes...................................................................................55
8. NFC management interface commands.......................................................................... 56
8.1 Get firmware version............................................................................................... 56
8.2 Get bootloader version............................................................................................ 57
8.3 Switch to bootloader................................................................................................ 58
8.4 Get serial number....................................................................................................58
8.5 Set NFC timings...................................................................................................... 59
8.6 Get NFC timings......................................................................................................60
8.7 Enter sleep mode....................................................................................................61
8.8 Exit sleep mode.......................................................................................................62
8.9 Get NFC kernel version...........................................................................................63
8.10 Get media serial number......................................................................................... 63
8.11 Disable media arrival and removal notifications....................................................... 65
8.12 Set serial interface baud rate................................................................................... 65
A. NFC module serial number matching ............................................................................. 67
B. HID reports –barcode only.............................................................................................. 68
B.1 Receive data........................................................................................................... 68
B.2 Send commands ..................................................................................................... 69
B.3 Trigger controls.......................................................................................................70
C. NFC module example code and API functions............................................................... 71
C.1 Initialise smartcard sub-system ...............................................................................71
C.2 Poll for card arrival .................................................................................................. 71
C.3 Connect to the card................................................................................................. 71
C.4 Get ATR of the card ................................................................................................72
C.5 Communicate with card........................................................................................... 72
C.6 Determine if ATR indicates MIFARE type................................................................72

C.7 Disconnect the card................................................................................................. 72

D. ASCII character reference................................................................................................ 73

E. Document history............................................................................................................. 77

1. Overview

The Access-IS LSR118 is a compact 1D/2D barcode imager with near field communication (NFC)

contactless capabilities.

The device is purpose-designed for use in kiosk and gate applications and its rugged, water-

resistant construction, with no moving parts, enables it to withstand years of indoor and outdoor

public access use.

The device reads all popular linear, PDF417 and 2D barcode symbologies, including QR and Aztec

codes, from smartphones, tablets and printed-paper documents.

The LSR118’s advanced recognition barcode imager is omnidirectional and has near-zero latency. It

captures barcodes within a fraction of a second of presentation in any orientation.

The LSR118 also supports mobile ticketing and mobile wallet payment systems for NFC-enabled

smartphones and tablets, as well as reading contactless smart, credit and debit cards.

•Omnidirectional reading –present the barcode at any angle.

•Reads barcodes and NFC cards, labels and devices from a single point of presentation.

•Red and green indicators to

show good and bad reads.

•Robust unit with a small

footprint; easily integrated

into kiosks and gates.

•Fully sealed, water-resistant

housing suitable for

integration in indoor or

outdoor kiosks, gates and

turnstiles.

•Quick plug-in design reduces

cost of kiosk integration.

•RS232 and USB (serial or

keyboard) interface options.

•Fully configurable output data

formats.

•Interactive mode allows host

application to control barcode

reader functions.

Figure 1. LSR118 1D/2D Barcode Imager and NFC reader

2. Specifications

Specification

Details

Dimensions (L x H x W)

109.8 mm x 67.4 mm x 105.9 mm

Weight

592 g (with cable)

Environmental

Operating temperature: -25ºC to 50ºC

Storage temperature: -30ºC to 70ºC

Humidity: 95% RH, non-condensing

IP67

Body

Black ABS

Glass

4 mm Toughened White Soda Lime; BS EN60068-2-75 & IEC

62262:2002, rated to 3.5 J impact

Power requirements

5 V DC

Requires USB power injector cable or independent power supply

Electrical interface

Serial (RS232C) and 5 V USB

Barcode reading

Reads barcodes from mobile phones, tablets and paper

Linear: Code 2 of 5, Interleaved 2 of 5, EAN13, Code 3 of 9,

Code 128 (plus others)

2D: PDF417, QR, Aztec, DataMatrix, (plus others)

NFC

EMV: Certified to Level 1

Supported media: ISO14443 type A and B cards (Java cards);

max baud 424K (extendable to 848K)

MIFARE UL, Classic 1K, Classic 4K, UL-C, MIFARE Plus; max

baud 106K

MTBF

85,000 hours

Approvals

CE EMC Class B

•EN 55022

•EN 55024

CE Low Voltage Directive

•EN 60950-1

•IEC 62471: 2006 - Exempt Class

CE R&TTE Directive

•ETSI EN 301 489

•ETSI EN 302 291

FCC 47CFR Part 15 Subpart B Class A

FCC 47CFR Part 15 Subpart C

IEC 60825-1 LED Safety Class 1

2.1 Part numbers

Product

Part Number

Serial connected LSR118

AKEGEOSA941

USB power injector cable

5KBD133402

USB connected LSR118

AKEGEOSA902

Serial cable

5KBD387302

USB cable

5KBD386301

An external power supply is available, if required.

Please contact the Access-IS sales team: [email protected].

3. Installation

3.1 Unpack the LSR118

Unpack the LSR118 and ensure that you have the following items:

•Advisory notice card.

•LSR118 device with attached serial cables or USB cable.

•USB power injector cable or power supply (IEC cable not supplied).

Report any missing items or damage immediately to your Sales Representative.

3.2 Connection

Connect the LSR118 directly to two RS232 ports or a USB port depending on the product version.

Note: The cable is sealed into the unit to prevent entry of water, moisture and dust. Cable length is

2 m for serial and USB versions.

3.2.1 Connection to RS232

Figure 2. Connection to RS232

3.2.2 Connection to a USB port

Figure 3. Connection to USB

Serial and power cables connected to LSR118 device

USB power injector cable to a powered USB port

on host PC (or connection to an external power

supply)

To COM ports on the host PC

To a USB port on the host PC

USB and power cables connected to LSR118 device

USB power injector cable to a powered USB port

on host PC (or connection to an external power

supply)

3.3 Mounting

Mount the LSR118 into a kiosk, gate or similar device, if required. Refer to Figure 4 for the

LSR118’s dimensions (in millimetres) and mounting points.

For optimum performance, do not position the LSR118 in direct sunlight.

NFC INSTALLATION WARNING

To optimise the performance, DO NOT install the LSR118 so that its NFC antenna is within 40 mm

of a large metal or electrically conductive component or structure.

Failure to observe this instruction may lead to the product’s NFC performance deteriorating or even

failing completely.

Figure 4. LSR118 dimensions and mounting points

Use three M3 screws (not provided) to mount the unit. Maximum insertion depth is 6 mm; minimum

recommended insertion depth is 2 mm.

3.4 Barcode interface options

3.4.1 Serial connection

Connect a serial LSR118 device using an RS232 interface directly into a COM port. You must

specify the baud rate, parity, data bits and stop bits.

Note: A serial LSR118 communicates directly with the COM port and does not require any

additional drivers to be loaded.

3.4.2 USB connection

Connect a USB LSR118 device using one of three possible options. These options are compatible

with all Linux and Windows operating systems from XP onwards.

3.4.2.1 Keyboard interface

Virtual keyboard using Windows or Linux drivers

This option allows the device to operate without additional drivers, with the LSR118 emulating a

keyboard. This is one-way communication; it is not possible to control the device directly in this

mode. This mode will be slower than the other options as it adds an inter-character delay when

typing the barcode data.

3.4.2.2 CDC interface

Virtual serial mode using the Windows CDC driver

This option assigns a COM port and the device communicates as a virtual serial device. Due to the

nature of CDC serial port drivers, the COM port disappears if the unit is unplugged.

3.4.2.3 HID interface

Access-IS recommend the use of the HID interface for reliability. A HID interface recovers properly

in the event of accidental disconnects or system power fluctuations; a CDC interface may not

recover in these situations.

HID interface using the Access driver (Windows only)

The Access Serial Ports Service driver is fully configurable and outputs data in virtual serial or

virtual keyboard. The output can be parsed and reformatted. The serial port is permanent and does

not disappear if you unplug or hot swap the unit. This is one-way communication and the only

command that you can send to the device is AIS_BO to enable or disable barcode reading. Refer

to page 27 for more information.

HID interface without the Access driver

This method is only suitable is you are familiar with HID programming.

It is possible to communicate directly with the LSR118 using the operating system’s built-in HID

drivers. In this instance, HID reports, exactly 64 bytes in length, are sent between the host and the

LSR118.

The implementation of this driver and the method of interaction will depend on the version of the

host operating system. You should refer to the HID programming guide for the operating system you

are using.

Refer to HID reports –barcode only on page 67 for the details of the HID reports used with the

LSR118.

3.5 NFC interface options

3.5.1 Serial connection

Connect the NFC module using an RS232 interface directly into a COM port.

Note: A serial LSR118 communicates directly with the COM port and does not require any

additional drivers to be loaded.

3.5.2 USB connection

The NFC module enumerates as a standard chip card interface device (CCID) smartcard reader.

When you connect the device to the host, the NFC module uses the default Windows CCID drivers.

It is not necessary to install custom drivers when running Windows XP and above.

3.6 Barcode module installation (serial device)

A serial LSR118 communicates directly with the COM port and does not require any additional

drivers to be loaded. Serial connectors are labelled: CONN1 = Barcode , CONN2 = NFC module.

1. Switch off the computer.

2. Connect the serial cables to COM ports on the computer and finger-tighten the two thumbscrews

to secure the connectors to the port.

3. If using a USB power injector cable, plug the injector cable into the coaxial power connector on

the splitter cable and then plug the USB connector into a powered USB port on the computer.

If using an Access-supplied power supply, plug the power cable into the coaxial power

connector on the splitter cable and then connect the external power supply to an AC outlet.

4. Once the device is connected, switch on the computer.

3.7 Barcode module installation (USB device)

Note: If you intend to use the Access driver, ensure that you install the driver before you connect

the LSR118 to the computer.

3.7.1 Driverless keyboard output

There is no additional driver required for this mode. Connect the USB cable from the LSR118 to a

USB port on the computer.

3.7.2 CDC Windows driver

This method of USB installation uses the Windows CDC drivers.

For this method to operate, you must install the CDC drivers using the file, AccessISUSBCDC.inf,

which you can download from http://www.access-is.com/gettingstarted/.

The download (USB Driver for CDC Mode) includes full instructions for use.

Windows assigns a virtual COM port to the LSR118 device. You can find out the COM port number

in Device Manager. You will require the port number to configure the LSR118.

3.7.3 Custom HID

3.7.3.1 HID interface using the Access serial driver (Windows only)

The recommended method for using a USB LSR118 is to configure the device to operate in HID

mode. This allows the device to communicate with the Access driver.

For this method to operate, you must install first the Access driver (Access Serial Ports Service

(ASPS)). Download ASPS from http://www.access-is.com/gettingstarted/.

The download (ASPS Software) includes full instructions for use.

Ensure that you install the driver before connecting the LSR118 to the host.

3.7.3.2 HID interface without the Access driver

There is no additional driver required for this mode. Connect the USB cable from the LSR118 to a

USB port on the computer.

3.8 NFC module installation (serial device)

A serial LSR118 communicates directly with the COM port and does not require any additional

drivers to be loaded. Serial connectors are labelled: CONN1 = Barcode , CONN2 = NFC module.

Refer to Barcode module installation (serial device) on page 12 for installation instructions.

3.9

NFC module

installation

(USB device)

When you connect

a USB-connected

LSR118 device to the host, Windows

automatically detects the

hardware and installs the standard CCID smartcard reader drivers.

Some versions of Windows may

prompt you to search automatically for a driver.

The

NFC module

also exposes a HID interface for

configuration and control.

Refer to

NFC

management interface commands

on page

for the

command set and its responses.

In Device Manager, the smartcard reader and HID-compliant device represent the

NFC module. The

barcode

device appears under Ports (COM & LPT).

Figure 5. NFC module and barcode device in Device Manager (other device types not shown)

3.10 Test the device

Once you have connected the device and installed the relevant drivers, if applicable, you can test

the device. To do this, wave a piece of paper in front of the glass; the reader’s LEDs should

illuminate. If the device fails to respond when connected to the host, refer to the Troubleshooting

section in this document.

3.11 Barcode configuration software

Connect to, and configure, the LSR118 using your own configuration tool, a terminal emulation

program or the Access-IS configuration tool, which you can download from http://www.access-

is.com/gettingstarted/.

Refer to the Barcode command reference on page 21 for details of the barcode commands, which

you can use to configure the LSR118.

3.12 Communicate with the NFC module

Once the NFC module is enumerated, it registers itself with the Windows Smartcard Resource

Manager. Since the NFC module is Personal Computer/Smart Card (PC/SC) compatible, you can

use standard Windows smartcard functions to communicate with the module through the Windows

Smartcard Resource Manager API. Refer to the Microsoft website for more detailed information on

the Smartcard Resource Manager API.

For more information on the operation of the LSR118’s NFC reader, see page 31. Refer to page 39

for MIFARE media commands and responses and page 56 for NFC management interface

commands.

3.13 Troubleshooting

If the LSR118 does not appear to be working, refer to Table 1 to help identify and resolve the

problem. For further assistance, contact support@access-is.com.

Alternatively, use the Contact Customer Support Team page on the Access-IS website.

Note: Do not attempt to disassemble the LSR118 if it does not operate correctly.

Table 1. Troubleshoot the LSR118

Problem

Solution

LSR118 not transmitting data to host

Check that all cable connections between the LSR118 and

host are secure.

Ensure that the unit has power.

LSR118 cannot scan barcode

Ensure that the unit is configured to read the barcode that

you are scanning.

If scanning a document, ensure that the print quality is good.

If scanning a barcode on a mobile phone, ensure that you

set the screen backlight on the phone to its brightest setting.

3.14 Maintenance

3.14.1 Cleaning

Clean the glass with a lint-free cloth. If the glass is dirty, wipe the glass with a lint-free cloth

moistened with isopropyl alcohol or use an alcohol wipe. Do not use abrasive cleaners.

3.14.2 Storage

Store the unit in its original box, at a temperature of -30°C to 70°C.

4. Barcode operating modes

The LSR118 operates in one of three ways, as defined by the AISOMD command. Refer to the

Barcode command reference on page 21 for a list of commands that you can send to configure the

LSR118.

4.1 Mode summary

4.1.1 Dumb mode

The LSR118 is a one-way communication device.

The device detects the media and activates the imager and illumination. When the LSR118 reads

the barcode, it sends the data to the host, activates the ‘Good Read’indicators, and disables the

imager and illumination. The imager and illumination do not reset until the LSR118 sensor fails to

detect any media for 0.5 seconds.

4.1.2 Host mode

The LSR118 is a two-way communication device that reads barcodes and waits for a host to accept

or reject the barcodes.

The device detects the media and activates the imager and illumination. When the device reads the

barcode, it sends the data to the host and disables the imager and illumination. The LSR118 waits

for a response from the host to accept or reject the data, which activates the ‘Good Read/Bad Read’

indicators on the device. The LSR118 waits for up to two seconds for an ‘Accept/Reject/Ignore’

command to activate indicators. The host sends an ‘Ignore’ command to reset the imager if no

response from the indicators is required. The imager and illumination do not reset until the LSR118

sensor fails to detect any media for 0.5 seconds.

The ‘Ignore’ command requires version 1.0.21 (or later) of the firmware.

4.1.3 Interactive mode

Note: This is not the recommended mode for new installations.

The LSR118 is a two-way communication device, controlled fully by a host.

The LSR118 detects the media and sends a command to the host with this information. If the media

is removed, a second command is sent telling the host that the media is no longer detected.

If the media is present, the host sends a command to activate the imager and illumination. When the

LSR118 reads the barcode, it sends data to the host. The imager and illumination are not disabled.

The LSR118 waits for a response from the host to accept or reject the data, which activates the

‘Good Read/Bad Read’indicators and disables the imager and illumination. An ‘Ignore’ command

may also be used, although untriggering the unit is more useful in most cases.

At any time, the host can send ‘Good Read’ or Bad Read’ commands activate or deactivate the

imager and illumination.

4.2 Dumb mode

Figure 6 shows the process for a LSR118 in Dumb mode.

Media Detected

Imager and

Illumination

Activated

Barcode Read

Data Sent to Host

Lights ‘Good

Read’ (as Settings

Instruct)

Reader Idle

Imager and

Illumination

Deactivated

Reader Idle

Figure 6. Dumb mode process flow

4.2.1 Dumb mode example

Comments

LSR Command to Host

Host Command to LSR

Media placed in front of

LSR118.

Imager activated and

barcode scanned.

Illumination activated as

defined in the settings.

Data sent as configured (USB/Serial)

No media detected for 0.5

seconds; LSR118 resets.

4.3 Host mode

Figure 7 shows the process for an LSR118 in Host mode.

Media Detected

Imager and

Illumination

Activated

Barcode Read

Data Sent to Host.

Imager and

Illumination

Deactivated

Accept or Reject?

Lights ‘Bad Read’

(as Settings

Instruct)

Lights ‘Good

Read’ (as Settings

Instruct)

Reject Accept

Reader Idle

Ignore Command or

No Response within Timeout

Figure 7. Host mode process flow

4.3.1 Host mode example

4.3.1.1 Accept

Comments

LSR Command to Host

Host Command to LSR

Media placed in front of

LSR118.

Imager activated and

barcode scanned.

Illumination activated as

defined in the settings.

Data sent as configured (USB/Serial)

Host decides to accept or

reject the data.

‘Good Read’:

AISXXR0

Lights activated as defined

in the ‘Good Read’ settings.

No media detected for 0.5

seconds; LSR118 resets.

4.3.1.2 Reject

Comments

LSR Command to Host

Host Command to LSR

Media placed in front of

LSR118.

Imager activated and

barcode scanned.

Illumination activated as

defined in the settings.

Data sent as configured (USB/Serial)

Host decides to accept or

reject the data.

‘Bad Read’:

AISXXR1

Lights activated as defined

in the ‘Bad Read’ settings.

No media detected for 0.5

seconds; LSR118 resets.

4.3.1.3 Ignore

Comments

LSR Command to Host

Host Command to LSR

Media placed in front of

LTR118.

Imager activated and

barcode scanned.

Illumination activated as

defined in the settings.

Data sent as configured (USB/Serial)

Host decides to accept or

reject the data.

‘Ignore and Continue’:

AISXXR2

No media detected for 0.5

seconds; LTR118 resets.

4.4 Interactive mode

Figure 8 shows the process for an LSR118 in Interactive mode. The host can send ‘Good Read’ and

‘Bad Read’commands to the LSR118 at any time.

Media Detected,

Message Sent

Requesting

Trigger

Send Trigger?

Imager and

Illumination

Activated

Trigger

Barcode Read

Data Sent to Host

Accept or

Reject?

Lights ‘Bad Read’

(as Settings

Instruct)

Lights ‘Good

Read’ (as Settings

Instruct)

Imager and

Illumination

Deactivated

Reject Accept

Reader Idle

Untrigger

Force Trigger

Reader Idle

Force Untrigger

Ignore Command

Figure 8. Interactive mode process flow

4.4.1 Interactive mode example

4.4.1.1 ‘Good Read’initiated by LSR detecting media

Comments

LSR Command to Host

Host Command to LSR

Media placed in front of

LSR118. LSR118 sends

commands to host notifying

of media.

[0x16][0x0D]TRIG:1[0x16][0x0A]

Host sends a command to

trigger the imager.

[0x16][0x74][0x0D]

Imager activated and

barcode scanned.

Illumination activated as

defined in the settings.

Data sent as configured (USB/Serial)

Host decides to accept or

reject the data.

‘Good Read’:

AISXXR0

Lights activated as defined

in the ‘Good Read’ settings.

No media detected for 0.5

seconds; LSR118 resets.

4.4.1.2 ‘Good Read’initiated by host sending trigger command

Comments

LSR Command to Host

Host Command to LSR

Host sends a command to

trigger the imager. This

could be due to a second

sensor.

[0x16][0x74][0x0D]

Imager activated, it remains

activated until untriggered or

a ‘Good Read/Bad Read’

command is received. Lights

activated as defined in the

settings.

Data read by imager.

Data sent as configured (USB/Serial)

Host decides to accept or

reject the data.

‘Good Read’:

AISXXR0

Lights activated as defined

in the ‘Good Read’ settings.

No media detected for 0.5

seconds; LSR118 resets.

Table of contents

Access IS LSR118 User manual

Popular Barcode Reader manuals by other brands
