Access Security Products KP-902 User manual

KP-902
ACCESS SECURITY PRODUCTS LTD

RoHS
IP65
ACCESS SECURITY PRODUCTS LTD

······················································································ 26-27
TABLE OF CONTENTS
2
INTRODUCTION
FEATURES
SPECIFICATIONS
INSTALLATION
Precautions
Package Contents
CONNECTION HARNESS
The On-Board LED Indicators
The PacifierTones & The LED Signals
FEATURE PROGRAMMING & OPERATION INSTRUCTIONS
Set System in Programming Mode with The Master Code
DirectAccess to Programming Mode withThe “DAP” Code - 8080
Refresh The System withThe “Refreshing Code” -- 9999
The Default Values of The Keypad
KEYPAD PROGRAMMING MAKE SIMPLE – For General Users
FEATURE PROGRAMMING -- KEY INAND STORE THE DESIRED VALUES
Programming Criteria for Codes
RecordAMaster Code
RecordASuper User PIN
OperationAnd Functions of The Super User PIN
Record The Common User PINs for Output 1 & 2
Record-Delete PINs or Cards for Output 1 & 2
Examples – ProgrammingAnd Operation
Visitor Codes (For Output 1 Only)
Configuration of The Output Modes of Output 1 & 2
Personal SafetyAnd System Lock-Out
User PIN Entry Mode -Auto or Manual
Pacifier Tones On-Off Selection
Output OperationAnnouncer ·
Status LED Flashing On-Off during Standby
Intelligent Egress Button –An Unique Feature ofAContemporary Keypad
WhereAnd Why “Going Out” NeedsAttention
Egress Delay and Warning
The Operation Modes
Keypad Operation Modes
Close The Programming Mode
PROGRAMMING SUMMARY CHART
························································································································ 4
······························································································································· 4
······················································································································ 5
························································································································· 6
····························································································································· 6
····················································································································· 6
········································································································ 7-8
······································································································· 8
···························································································· 8
··························································· 9
····································································· 9
······················································ 9-10
···································································· 10
······························································································· 10
················································· 11-12
····································· 13
······························································································ 13-14
·············································································································· 14
·········································································································· 14
··········································································· 15
············································································· 15
················································································· 16
··············································································· 17-18
··························································································· 19-20
··········································································· 20
··························································································· 21
·························································································· 21
··································································································· 21
······································································································ 22
···················································································· 22
················································ 23
··············································································· 23
····································································································· 24-25
··············································································································· 25
······································································································· 25
···································································································· 25
ACCESS SECURITY PRODUCTS LTD

···························································································································· 31
························································ 29-30
······················································································ 28
········································································································ 28
3
APPLICATION EXAMPLE
Basic Wirings ofAStandAlone Door Lock
APPLICATION HINTS FOR THEAUXILIARY TERMINALS
APPENDIX
ACCESS SECURITY PRODUCTS LTD

Ɣ)XOO3URJUDPPDEOH)URP7KH'LJLWDO.H\SDG
Ɣ'LH&DVW0HWDO.H\:LWK$XGLEOH9LVXDO.H\SUHVV
The K-02 has two versions. Version A comes with the Output Relays contacts 1 and 2 for door strike and
K-02 is an ideal keypad mainly for Door Strike or Alarm Arm-disarm control. It is also a programmable
The K-02 has been designed to work independently as a stand alone keypad or works together with an
The K-02 is a weatherproof, vandal resistant, mullion mount keypad. It combines the functions of digital
keypad and proximity EM card reader in one unit.
optional “ controller” to form a high security split-decoded keypad system.
The keypad comes with plenty of functions for owner’s selection via programming. Owners can take them freely
to tailor the desired features for their system.
industrial timer (with the timing of 1 second to over 24 hours) forAutomatic Operator systems.
Theunitis designed for surfacemountingon wall or door frame.The two relayoutputsare coming with N.C.and
N.O contacts.
auxiliary control respectively. The Version B comes with Output 1 for door strike and Output 2 for door bell
activation.
INTRODUCTION
FEATURES
Ɣ0XOOLRQ6XUIDFH0RXQW9DQGDO5HVLVWDQW+RXVLQJ
Ɣ2SHUDWHGZLWK3,1V(0&DUGV
Ɣ6HOIFRQWDLQHG6WDQG$ORQH2SHUDWLRQ
Ɣ&RPSDWLEOHZLWK)DLOVDIHDQG)DLOVHFXUH(OHFWULF/RFNV
Ɣ9HUVLRQ$5HOD\2XWSXW&RQWDFWVIRU'RRU6WULNHDQG$X[LOLDU\&RQWURO
Ɣ9HUVLRQ%5HOD\2XWSXW&RQWDFWVIRU'RRU6WULNHDQG'RRU%HOO$FWLYDWLRQ
4
ACCESS SECURITY PRODUCTS LTD

+;:;'PP
496g net
12V DC Nominal; 12-16V DC
SPECIFICATIONS
ƔOperating Voltage:
Ɣ
ƔOperating Current:
.60mA(quiescent) to 95mA(two relays active)
ƔOperation Temperature:
.-20°C to +70°C
ƔEnvironmental Humidity:
.5-95% relative humidity non-condensing
ƔWorking Environment & Ingress Protection:
.Indoor or Outdoor, IP-65 Weatherproof
ƔNumber of Users:
Ɣ2XWSXW3,1VDQGRU&DUGV
Ɣ2XWSXW9HUVLRQ$2QO\3,1VDQGRU&DUGV
ƔProximity Card:
ƔStandard EM Card or Keyfob, 125Khz
ƔNumber of Visitor Codes:
Ɣ50, programmable for one time or with the time limit
ƔTimings for Code Entry and Card Reading:
Ɣ10 seconds waiting for next digit entry
Ɣ30 seconds waiting for code entry after card reading
ƔThe Timer:
Ɣ6HFRQGV2YHU+RXUVSRVVLEOH3URJUDPPDEOH7LPHUIRU23
ƔEgress Button:
Ɣ3URJUDPPDEOHIRU,QVWDQW'HOD\ZLWK:DUQLQJDQGRU$ODUP
Ɣ0RPHQWDU\RU+ROGLQJ&RQWDFWIRUWKH([LW'HOD\
ƔOutput Contact Ratings:
Ɣ2XWSXW5HOD\±1&12'U\FRQWDFWV$9'&0D[
Ɣ2XWSXW5HOD\RU'RRU%HOO±121&'U\FRQWDFWV$9'&0D[
Ɣ7DPSHU6ZLWFK±1&GU\FRQWDFWP$9'&0D[
ƔDimensions:
Ɣ
ƔWeight:
Ɣ
ƔHousing:
Ɣ=LQF$OOR\'LH&DVWLQJ+RXVLQJ
Specifications are subject to change for modification without notice
5
ACCESS SECURITY PRODUCTS LTD

ACCESS SECURITY PRODUCTS LTD

8. BLACK
7. BROWN
2. GREY
KEY ACTIVE OUTPUT
EG IN N.O.
K-02B - Output contact controlled by the Bell Button
.$2XWSXWFRQWDFWFRQWUROOHGE\WKH3,16DQGRUFDUGVLQJURXS
CONNECTION HARNESS
1. GREY
6. BLACK
5. RED
4. ORANGE
3. PURPLE
12. BLUE
11. GREEN
10. YELLOW
9. WHITE
TAMPER N.C.
OUTPUT RELAY 2
OR
DOOR BELL
GND (–)
12V
DC IN(+)
N.O.
COM
N.C.
(–) GND
SELECTION JUMPER FOR OUTPUT 2
THE WIRE HARNESS
1 - 2 : TAMPER N.C. (Tamper Switch Normally Closed Contact)
A normally closed dry contact while the front cover is secured on the main box. It is open while the cover is
separated from the box. Connect this N.C. terminal to the 24 hour protection zone of an alarm system if
necessary.
3 - 4 : OUTPUT 2 (Version A) OR DOOR BELL (Version B)
$UHOD\RXWSXWGU\FRQWDFWZLWKPD[LPXPUDWLQJRI9'&$PSZKLFKLVVHOHFWDEOHIRU1&1RUPDOO\&ORVHG
or N.O. (Normally Open) output via jumper.
5 - 6 : 12V DC (Power Input Terminal)
Connect to 12V DC power supply. The (-) GND is the common grounding points of the system.
SELECTION JUMPER FOR OUTPUT 2
OUTPUT 2
OUTPUT
RELAY
1
7
TAMPER
SWITCH
23
N.O.N.C.
ACCESS SECURITY PRODUCTS LTD

It lights up while the output 1 is inhibited.
INHIBIT (RED)
7 : EG IN (Egress Input)
ANormally Open (N.O.) input terminal referring to (-) ground. With the help of connecting a normally opened
button to activate the Output 1 for electric door lock strike in the same manner of using the Group 1 User PINs
or Cards.
Egress button is usually put inside the house near the door. More than one egress buttons can be connected in
parallel to this terminal. Leave this terminal open if not used.
See Programming Location 90 for more information about the Egress Button with other features.
8 : GND (-) (Common Ground)
Acommon grounding point of the keypad, it is common to the Black wire, terminal 6.
10 - 11 - 12 : OUTPUT 1 (Output Relay 1)
2AmprelaydrycontactcontrolledbytheGroup 1userPINsorCardsforOutput1, recommendedfordoor strike.
Terminal 10 is Normally Closed (N.C.), terminal 12 is Normally Open (N.O.) and terminal 11 is the common point
of the two contacts. Use N.C. output for Fail-safe locking device; and N.O. output for Fail-secure locking device.
7KHUHOD\LVSURJUDPPDEOHIRU6WDUW6WRSWRJJOHPRGHRU0RPHQWDU\WLPLQJPRGH6HHSURJUDPPLQJ/RFDWLRQ
51 for the details.
THE ON-BOARD LED INDICATORS
MAINS (AMBER) ------ It flashes on Standby. It shows the system status in synchronization with
..............................................the beep tones. The standby flashing can be set to OFF in programming.
See Location 73 for the details.
DOOR (GREEN) -------- It lights up for Output 1 activation.
THE PACIFIER TONES & THE LED SIGNALS
The buzzer and the amber LED indicator give following tones and signals respectively for system status:
9) Card or PIN Already Stored in System -----
1 Long Beep
8) System Refreshing Fast Flashes for 2.5 Minutes
-----
7) On Standby *** 1 Flash in 1 Second Interval
-----
6) Output Relay Activation ** 1 Second Long Beep
5) Power Up Delay Continuous FlashesContinuous Beeps
4) Unsuccessful Code / Card Entry 5 Flashes5 Beeps
3) Successful Code / Card Entry 2 Flashes2 Beeps
2) Successful Key Entry 1 Flash1 Beep
1) On Programming Mode ON
-----
STATUS LED SIGNALSTONES *
NOTE:
* All Pacifier Tones can be ON or OFF through the programming option at Location 71
* * The Output RelayActivation beep can be selected through the programming option at Location 72
* * * The Standby flashing can be ON or OFF through the programming option at Location 73
8
--------
9:KEY ACTIVE OUTPUT
$Q 131 WUDQVLVWRU RSHQ FROOHFWRU RXWSXW ZLWK WKH PD[LPXP SRZHU UDWLQJ RI 9'&P$ VLQN ,W VZLWFKHV WR
JURXQG IRU VHFRQGV RQ HDFK NH\ WRXFK ,W FDQ EH XVHG WR WXUQ RQ OLJKW &&79 FDPHUD RUEX]]HUWRQRWLI\D
JXDUG
(-)
10 . , ,
.
ACCESS SECURITY PRODUCTS LTD

FEATURE PROGRAMMING & OPERATION INSTRUCTIONS
SET SYSTEM INTO PROGRAMMING MODE WITH THE MASTER CODE
IMPORTANT NOTE:
1) DO NOT TURN OFF POWER while the keypad is in Programming Mode. Otherwise, it may cause.data
.....ORVWHUURUWRWKHSURJUDPPHGIHDWXUHVLQWKHPHPRU\
2) The keypad beeps after power up. Wait 1 minute until the end of the power up delay, then key in the Master
.....Code for setting the system into programming mode.
3) For the owner’s convenience in programming at the first time, the factory has put a Master Code.0000into
.....thekeypad(It isNOTa default code).Tocompromisesecurity,inallcases,theownershouldprogramanew
.....Personal Master Code to invalidate the factory set Master Code after the keypad is owned.
4)The ButtonhastwofunctionsinthekeypadswithDoorBellbutton.Itisadoorbellbuttonwhilethekeypad
.....is in normal operation; and it is equivalent to a Button in programming mode.
MASTER CODE
ƔThe Master Code can be a factory set master code or the private master code
Ɣthat was set by the owner.
ƔValidate the master code with ** ( or ).
Ɣ2-beep confirms a valid master code. The Mains LED (Amber) is constantly ON after the system is set in the
....programming mode.
DIRECTACCESS TO PROGRAMMING MODE WITH THE “DAP” CODE – 8 0 8 0
Set System Into Programming Mode With DAP Code In Case Of The Master Code Is Forgotten !!
The owner requires to apply the following procedures precisely to set the system into programming mode with
the DAP code 8 0 8 0.
1) Switch OFF all the power for 1 minute to ensure that the system is fully discharged.
2) Swich ON power again. The system is in Power-up Mode for 1 minute and the buzzer gives beeps during
.....the whole period. This is the only time limit for setting the system to DirectAccess to Programming (DAP).
3) Press the Egress Button (EG IN) once first to enable the DAP function.
4)KeyintheDAPCode8080andvalidateitwith**( or ), the existing MasterCodeinthememory
....is erased andthepowerup beep stops.Thekeypadturns itself into programming mode like usingtheMaster
....Code and it is ready to accept the new programming data.
5) If the Egress Button is not pressed and the DAP code is not keyed in within the power up period, the system
.....will set itself to normal operation mode. To set it back to power-up mode, repeat procedures 1-4.
DAP CODE
Ɣ7KH'$3FRGHLVIL[HGRQ8080and it is valid only in the Power-up Period after the Egress Button is pressed.
Ɣ9DOLGDWHWKH'$3FRGHZLWKWKH**( or )
ƔEHHSFRQILUPVWKHV\VWHPLVLQWKH3URJUDPPLQJ0RGHDQGWKH0DLQV/('LVFRQVWDQWO\21
Ɣ6HH³5(&25'$0$67(5&2'(´DW³/RFDWLRQ´IRUWKHGHWDLOVRISURJUDPPLQJDQHZPDVWHUcode.
VALIDATION
MASTER CODE
PRESS ONCE
EGRESS BUTTON
DAP CODE
VALIDATION
9
ACCESS SECURITY PRODUCTS LTD

y (K-202A)
equired (K-202A)
REFRESH THE SYSTEM WITH THE “REFRESHING CODE” --- 9 9 9 9
The system can be refreshed to clear all the old data stored and back to its ex-factory default values.
IMPORTANT NOTE:
Make sure that you really want to clear ALL the OLD data before entering of the Refreshing Code. The keypad
will be back with its default values like a new unit. Re-program of the desired values are necessary.
REFRESHING CODE
The Code 9 9 9 9 is for refreshing of the system. Once it is keyed in and validated with #, all the values
programmed previously will be cleared EXCEPT the Master Code.
The refreshing takes around 2.5 minutes. During the keypad is being refreshed the Status LED (Amber) flashes
fast until the end.
REFRESHING CODE
VALIDATION
THE DEFAULT VALUES OF THE KEYPAD
PROGRAMMING
NOTE:
The DAP Code 8080and the Refreshing Code 9999are fixed in the operating system program. It can not be
changed in any ways or be influenced by the system in default setting.
10
LOCATION PARAMETERS DEFAULT FUNCTIONS & VALUES
0 1 Master Code 0 0 0 0 Factory Set, Not a default value *
0 2 Super User PINs Nil ----- User Program Required
0 3 Common User PIN 1 Nil ----- User Program Required
2 0 User PINs & Cards for O/P 2 Nil ----- User Program R
1 0 User PINs & Cards for O/P 1 Nil ----- User Program Required
4 0 Visitor Codes Nil ----- User Program Required
5 2 O/P Mode of The O/P 2 Time = 5 Sec, Momentar
5 1 O/P Mode of The O/P 1 Time = 5 Sec, Momentary
6 0 Personal Safety & Lock-out Code = 1, 10 False Code/Card Lock-out 60 Sec
7 0 User Code Entry Mode Code = 2, Manual Entry Mode
7 1 Pacifier Tones ON-OFF Selection Code = 1, Pacifier Tone ON
7 2 O/P Operation Announcer Code = 1 Sec, Notification Beep ON
7 3 Status LED Standby Flashing ON-OFF Code = 1, Flashing Enabled
9 0 Egress Delay & Warning Code 1 = 0, Instant, No Delay
Code 2 = 1, Momentary Contact without Warning
9 4 Operation Modes Code = 0, Stand Alone Keypad
ACCESS SECURITY PRODUCTS LTD

H 7KH8VHU3,1WREHXVHGZLWKWKH(0&DUGLVDQ8VHU3,1IRUH[DPSOHKHUHRQO\
G 7KH8VHU3,1WKDWLVSURJUDPPHGIRUGRRURSHQLVDQ8VHU3,1IRUH[DPSOHKHUHRQO\
---- 2 beeps, 9 8 2 3 is a Master Code for example here only 9 8 2 3 is the new
KEYPAD PROGRAMMING MAKE SIMPLE – For General Users
This multi purpose keypad has many functions for user’s selection. For those general users taking it for door
VWULNHRQO\PRVWRIWKHIHDWXUHVFDQEHNHSWLQWKHLU'HIDXOWYDOXHV2QO\WKH8VHU3,1V&DUGVDQGDSULYDWH
Master Code are necessary to program for the system.
The keypad accepts 1) Card only, 2) PIN only, 3) Card + PIN or 4) Card + Common User Code to operate its
outputs.
PROGRAMMING
NOTE:
a) The button is equivalent to thebutton in the keypad with bell button.
b) Wait 1 minute until the end of the power up delay.
1) Set System into Programming Mode with The Factory Set Master Code 0 0 0 0
---- 2 beeps, system is in Programming Mode
Note: If the Master Code is forgotten, use the DAP Code to set the system into programming mode. See DAP
...... CODE 8080 on the previous page for the details.
2) Change The Factory Set Master Code to Owner’s Private Master Code for Security Reason
.....Master Code and the 0000 is erased
3) Record an “EM Card” to Operate The Output 1 for Door Open
(a) (b) (c) (d) (e)
D 3URJUDPPLQJ/RFDWLRQIRU2XWSXW
E 3URJUDPPLQJRSWLRQIRU(0&DUGRQO\
F 2QHRIWKH8VHU,'VIRUWKH8VHU3,1&DUGIURP
G5HDG&DUG 3XWWKH&DUGFORVHWRWKHFDUGUHDGHU
H &RQILUPWKHFDUGLVUHDGEHHSV
4) Set an “User PIN” to Operate The Output 1 for Door Open
(a) (b) (c) (d) (e)
D 3URJUDPPLQJ/RFDWLRQIRU2XWSXW
E 3URJUDPPLQJRSWLRQIRU8VHU3,1RQO\
F 2QHRIWKH8VHU,'VIRUWKH8VHU3,1&DUGIURP
H &RQILUPWKH8VHU3,1EHHSV
5) Record an “EM Card + User PIN” to Operate The Output 1 for Door Open
(a) (b) (c) (d) (e) (f)
D 3URJUDPPLQJ/RFDWLRQIRU2XWSXW
E 3URJUDPPLQJRSWLRQIRU(0&DUG8VHU3,17KH8VHU3,1FDQEHUHSHDWHGXVHRUSURSULHWDU\
F 2QHRIWKH8VHU,'VIRUWKH8VHU3,1&DUGIURP
G5HDG&DUG 3XWWKH&DUGFORVHWRWKHFDUGUHDGHU
I &RQILUPWKH&DUG3,1LVVWRUHGEHHSV
READ CARD
READ CARD
11
ACCESS SECURITY PRODUCTS LTD

6) Record an “EM Card + Commom User Code” to Operate The Output 1 for Door Open
(a) (b) (c) (d) (e)
D 3URJUDPPLQJ/RFDWLRQIRU2XWSXW
E 3URJUDPPLQJRSWLRQIRU(0&DUG&RPPRQ8VHU&RGH
F 2QHRIWKH8VHU,'VIRUWKH8VHU3,1&DUGIURP
G5HDG&DUG 3XWWKH&DUGFORVHWRWKHFDUGUHDGHU
H &RQILUPWKHFDUGLVUHDGEHHSVWKH&RPPRQ8VHU&RGHJRHVWRWKLV8VHU,'DXWRPDWLFDOO\
(f ) A Common User Code (for example: 8 6 2 5) MUST be set at the Programming Location 03 first for this
.....operation mode. The code can be used for all the EM Cards in this operation mode.
REMARK:
IfmoreUserPINsandCardsarerequiredforOutput1,repeattheprocedures(3),(4),(5)or(6)abovewithother
UserIDs,such as005,006, 007---999etc.Total1,000 usersareallowed. SeeProgrammingLocation10forthe
details.
7) Close The Programming Mode
---- 2 beeps
The programming mode is closed. The keypad is back to normal operation mode
OPERATION
8) Open The Door with EM CARD
---- 2 beeps, the door is open
9) Open The Door with User PIN
---- 2 beeps, the door is open
10) Open The Door with EM CARD + User PIN
---- 2 beeps, the door is open
11) Open The Door with EM CARD + Common User Code
---- 2 beeps, the door is open
,QWKHQH[W6HFWLRQ³.(<,1$1'6725(7+('(6,5('9$/8(6´GHVFULEHVDOOWKHIHDWXUHVDQGIXQFWLRQVRI
the system in detail. Users can follow them to tailor the desired values for their access control systems. Suggest
the general users also spend some time on them to get acquaint with this powerful system for future expansion.
READ CARD
READ CARD
READ CARD
12
READ CARD
ACCESS SECURITY PRODUCTS LTD

Thefeature values canbe setandstored intothe systemone byone withthe desired Programming Locations.
Programming can be made continuously and it is not necessary to be in sequence order. Just go to the desired
programming location and key in the value for the desired feature.
IMPORTANT NOTE --- Programming Criteria for Codes:
a) The Prime Codes:
All the Private User PINs, Master Code, Duress Codes, Super User PIN, Common User Codes and the Visitor
User Codes belong to Prime Codes in the system. They have the priority to be read and they MUST be unique
and can not be repeated in the programming.APrime code also can NOT be duplicated for Secondary code to
work with the EM Card or vice versa.
b) The Prime Cards:
All the EM Cards used in this system are Prime Cards. The cards used for the Outputs 1, 2 and 3 MUST be
unique and can not be repeated use for different Outputs in the programming.The Card always has the priority
to be read when working in “EM Card + Secondary PIN” or "EM Card + Common User PIN”.
c) Warning for A Repeated Use of Prime Code or Card:
2QHORQJEHHSLVJLYHQLID&RGH3,1LVNH\HGLQRUD&DUGLVUHDG,WPHDQVWKDWD3ULPH&RGHRUD3ULPH&DUG
LVUHSHDWHG7KH&RGH3,1RU&DUGZDVDOUHDG\LQRQHRIWKH3,1RU&DUG/RFDWLRQVRU,'V7KHSURJUDPPLQJLV
LQYDOLG&KDQJHDQHZ&RGH3,1RU&DUGDQGSURJUDPLWDJDLQ
d) Secondary User PINs:
The Secondary User PINs are prepared to enhance security. It is put after a Card in “EM Card + Secondary
User PIN” programming. They can be a repeated code within the Secondary PINs but it is NOT allowed a
duplicate of the Prime Codes. The system will reject a duplicated Prime Code for Secondary User PIN or vice
versa.
e) GettingAdvantages from The Secondary User PINs:
TherepeatedSecondary PINscanbe usedasa GroupCommonUser CodeorcalledDepartmentUserCodefor
a group of EM Cards, which simplifies the programming of using large number of different User PINs. EM Card
withDepartmentCodepreventsalostcard usedby peopleofotherdepartment.Also,itwillbe easierto traceout
the department of the lost card belongs to. Of cause, the owner can use a proprietary Secondary User PIN for
each EM Card in the “EM Card + Secondary User PIN” programming to further increase the security if it is the
main concern.
f) Security Level Comparison of The Secondary User PIN/Code following Card Reading:
i) EM Card + Common User Code ---All EM Cards use the same User Code. Security level is better than just
....Card only.Alost Card picked up by any people can be used if he knows the Common User Code.
ii) EM Card + Department User Code --- The EM Cards are divided into groups with a Department User Code.A
....lost Card can be used only by the people in the same group who know the Department Code.
iii) EM Card + Secondary User PIN --- Each EM Card has its own proprietary User PIN.A lost Card can not be
....used by other people.
g) MakeA List Recording The User Names VS User Codes:
6XJJHVWWKHRZQHUWRPDNHDOLVWUHFRUGLQJRIWKH8VHU1DPHVFRUUHVSRQGLQJWRWKH&RGHV3,1V&DUGVWKDWDUH
going to store in the Locations and the IDs before the programming. It will be a useful tool for the owner to easily
program them smoothly and also to trace them from this multi-users system in the future.
Example: (Please see the following page)
FEATURE PROGRAMMING -- KEY IN AND STORE THE DESIRED VALUES
13
ACCESS SECURITY PRODUCTS LTD

Set a Super User PIN with the number of “2 0 8 5” ----
Set a Master Code with the number of “3 2 3 3” ----
Example:
User Name Location Function Code User ID PIN/Code Card # Remark
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
--
1,000
RECORDA MASTER CODE (Location 01)
MASTER CODE
ƔMaster Code is the authorization code for setting the system to programming mode. It is NOT an User Code
....operating of the output relays.
ƔThe Master Code can be 4 to 8 digits. Press # key to confirm code entry
ƔWhen a new master code is keyed in and confirmed, the old master code is replaced automatically.
ƔThe master code is also the Link-up Code between the keypad and the optional controller of the system in
....Split-decoded operation.
ƔExample:
RECORDA SUPER USER PIN (Location 02)
The Super User PIN has TWO functions. It is prepared for the owner to simply use only one User PIN to operate
WKHWKUHHRXWSXWVRIWKHNH\SDGDQGPDNHRSHUDWLRQLQKLELWHQDEOHGLVDEOHWRWKHV\VWHPRXWSXWV
SUPER USER PIN
ƔThe Super User PIN can be 4 to 8 digits.
ƔTwo beeps will be heard after pressing the # key to confirm code entry.
ƔWhen a new Super User PIN is keyed in and confirmed, the old one is replaced.
ƔExample:
ƔTo deleted a Super User PIN from memory: Key in just the Location number and #. ----
MASTER CODE
4 to 8 Digits
LOCATION
VALIDATION
SUPER USER PIN
4 to 8 Digits
LOCATION
VALIDATION
14
ACCESS SECURITY PRODUCTS LTD

Example: Set a Common User PIN with the number of “1 7 5 3” for Output 1 ----
OPERATION AND FUNCTIONS OF THE SUPER USER PIN
1) Operate Output 1 and 2
The operation of the Super User PIN is just like a normal User PIN. Simply key-in the PIN with a specific output
number for the desired Output. The Super User PIN can also be used to reset an operating output timer instantly.
---------- Output 1Activates or Output 1 Resets
---------- Output 2Activates or Output 2 Resets (VersionAOnly)
2) Inhibit The User PINs For Output 1
7KH6XSHU8VHU3,1FDQDOVREHXVHGWRLQKLELWWKHQRUPDO8VHU3,1V&DUGVIRUWKH2XWSXWXVXDOO\WKH\DUH
for door strike). It enhances the security level of the access control system, such as to stop a keypad after office
KRXURUZKLOHWKHKRXVHLVQRERG\LQVLGH2QFHWKH2XWSXWLVLQKLELWHGWKH8VHU3,1V&DUGVIRULWEHFRPH
invalidandthosepeopleevenknowthe UserPINs arerefusedduringthesystem isinhibited.The inhibitfunction
LVWRJJOHGLQ6WDUW6WRSPRGHZLWKWKHIROORZLQJFRGHHQWU\
---------- The Whole Group of User PINs & Cards for Output 1 are
............................................................. ..Disabled or Enabled in Toggle
NOTE:
Ɣ7KHLQKLELWIXQFWLRQVHWWLQJZLWKWKH6XSHU8VHU3,1DSSOLHVWRWKHZKROHJURXSRI8VHU3,1VDQG&DUGVIRU
....Output 1 ONLY, but not for Output 2.
Ɣ)RUVDIHW\UHDVRQWKHLQKLELWIXQFWLRQLQLWLDWHGZLWKWKH6XSHU8VHU3,1GRHVQRWJRYHUQWKH(JUHVV%XWWRQ7KH
....door still can be opened with it from inside.
Ɣ7KH6XSHU8VHU3,1VDUHDOZD\VYDOLG7KH\DUHQRWJRYHUQHGE\DQ\LQKLELWRUORFNRXWIXQFWLRQLQWKHV\VWHP
RECORD THE COMMON USER PINS FOR OUTPUT 1 & 2 (Locations 03 & 04)
The Common User PINs 1 and 2 are prepared for operating of the Output 1 and Output 2 respectively as an
enhancecode.The Common UserPINsMUST workintheform of “Card + Common PIN”tooperate the outputs
to increase the security of the access control system. See Locations 10 & 20 for more information.
NOTE : Common User PIN alone can NOT be used to operate the Outputs directly.
COMMON USER PIN LOCATIONS
Ɣ/RFDWLRQ6WRUHV7KH&RPPRQ8VHU3,1IRU2XWSXW
Ɣ -- Location Stores The Common User PIN for Output 2 (VersionAOnly)
COMMON USER PINS
Ɣ7KH&RPPRQ8VHU3,1FDQEHWRGLJLWV3UHVVNH\WRFRQILUPWKHFRGHHQWU\
ƔWhen a new Common User PIN is keyed in and confirmed, the old one is replaced.
Ɣ
ƔTo deleted a Common User PIN from memory: Key in just the Location number and #. ----
SUPER USER PIN
SUPER USER PIN
SUPER USER PIN
COMMON USER PIN
4 to 8 Digits
LOCATION
-
VALIDATION
15
ACCESS SECURITY PRODUCTS LTD

RECORD-DELETE PINS OR CARDS FOR OUTPUT 1 & 2 (Locations 10 & 20)
Total of 1,100 User PINs and/or Cards are available for the 2 user groups to control the 2 outputs.
1) 1,000 ---- for Output 1 (Group 1)
2) 100 ------ for Output 2 (Group 2) - VersionAOnly
The Private User PINs and Cards in the 2 user groups MUST be unique. Repeated PINs will be rejected.
Secondary User PINs in the “EM Card + Secondary User PIN” can be repeated. See the Important Note ---
Programming Criteria for Codes in page 14 for more information.
USER GROUP LOCATIONS
– Group 1 --For User PINs/Cards Controlling Output 1
................8VHUVDUHDOORZHGLQJURXSIRU23
– Group 2 --For User PINs/Cards Controlling Output 2
................8VHUVDUHDOORZHGLQJURXSIRU239HUVLRQ$2QO\
SELECTION OF OPERATION MEDIA
ƔNumber 1, 2, 3 or 4 represents the Media to be used to operate the keypad.
Ɣ1XPEHULVWKHDXWKRUL]DWLRQFRGHIRUGHOHWLQJRIDQ3,1DQGRU&DUGIURPLWV8VHU,'
(0&DUGRQO\ 3ULYDWH8VHU3,1RQO\
(0&DUG6HFRQGDU\8VHU3,1 (0&DUG&RPPRQ8VHU3,1
'HOHWHDQ8VHU3,1RU&DUGIURPWKHVHOHFWHG8VHU,'QXPEHU
Clear all the PINs & Cards from the selected Location. It takes
............................ few seconds to a minute to complete depending on the Location
............................ selected and the data stored.Please see the programming example
............................below for the details.
USER ID NUMBER
ƔA3-digit,'LVDQLGHQWLILHGQXPEHUIRUHDFK8VHU3,1DQGRU&DUG
ƔRepeated ID number will be rejected by the system
Ɣa) ID Number - for 1,000 User PINs/Cards to operate Output 1
Ɣb) ID Number - for 100 User PINs/Cards to operate Output 2
CARD &/OR USER PINS
ƔThe User PINs can be 4-8 digits. Key in the User PIN on each ID Number box, then confirm it with # key
ƔJustsimply put the EMcardclose to the reader window to read itoneachID Number box, then, confirm it with
....# key if it is a Card ONLY, or Card + Common User PIN entry. The Common User PIN is NOT required to
....key-in here. It will go into its location automatically after the Card is read.
ƔRead the Card first, then key in the Secondary User PIN on each ID Number box, then confirm it with # key if
....it is Card + Secondary User PIN. The Secondary User PINs can be duplicated or a proprietary User PIN but
....cannot beaduplicate ofaPrime Code.Owner canusethe samesecondaryUser PINfor a groupof Cardsas
....a group Common User Code (or called Department Code) for a specific relay output.
ƔCards (Operation Media # 1, 3, & 4) and Private User PINs (Operation Media 2) MUST be unique.Arepeated
....EM card or Private User PIN will be rejected and one long beep will be generated by the system to notify the
....owner.
USER ID
-
MEDIA
-
LOCATION
-
VALIDATION
ClearallthePINs&CardsfromtheselectedLocation.Ittakes
few seconds to a minute to complete depending on the
Location selected and the data stored.Please see the
programming example below for the details.
CARD &/OR USER PIN
CARD &/OR USER PIN
16
ACCESS SECURITY PRODUCTS LTD

(d) Put Private User PIN “3 2 4 1” into the storage location
(b) Key in the Secondary User PIN “8 0 4 2 6”
(e) Put Secondary User PIN “8 0 4 2 6 ” into the storage location
(a) Key in the Private User PIN “3 2 4 1”
EXAMPLES – PROGRAMMINGAND OPERATION
1) Example 1 -- EM Card Only :
i) Programming :
(a) (b) (c) (d) (e)
(a) The card is programmed for operating of the Output 1
(b) The operation is EM Card only
(c) Take ID number 001 in Group 1 to store the card, which is one of the IDs in 000-999
(d) Put the card close to the reader to read it, one beep confirms the reading
(e) Press # to store the “Card” into memory, two-beep confirms a valid entry
ii) Operation : (while the system is back to operation mode)
(a)
(a) Put the EM card close to the reader. Two-beep confirms the card is read and the Output 1 activates
2) Example 2 -- Private User PIN Only :
i) Programming :
(a) (b) (c) (d) (e)
(a) The Private User PIN is programmed for operating of the Output 2 (VersionAOnly)
(b) The operation is Private User PIN only
(c) Take ID number 001 in Group 2 to store the Private User PIN, which is one of the IDs in 001-100
(e) Press # to confirm and store the “Private User PIN” into memory, two-beep confirms a valid entry
ii)Operation : (while the system is back to operation mode)
(a) (b)
(b) Confirm it with the # key. Output 2 activates
3) Example 3 -- EM Card + Secondary User PIN :
i) Programming :
(a) (b) (c) (d) (e) (f )
(a) The card is programmed for operating of the Output 1
(b) The operation is EM Card + Secondary User PIN
(c) Take the ID number 002 in Group 1 to store the Card & PIN, which is one of the IDs in 000-999
(d) Put the card close to the reader. One beep confirms the reading
(f ) Press # to store the “Card + Secondary User PIN” into memory, two-beep confirms a valid entry
ii) Operation : (while the system is back to operation mode)
(a) (b) (c)
(a) Put the EM card close to the reader. Two-beep confirms the reading and 30 seconds waiting time is given for
.....the entry of the User PIN, theAmber LED keeps flashing
(c) Confirm it with the # key. Output 1 activates
READ CARD
READ CARD
READ CARD
READ CARD
17
ACCESS SECURITY PRODUCTS LTD

4) Example 4 -- EM Card + Common User PIN :
i) Programming :
(a) (b) (c) (d) (e)
(a) The card is programmed for operating of the Output 1
(b) The operation is “EM Card + Common User PIN”
(c) Take ID number 003 in Group 1 to store the card, which is one of the IDs in 000-999
(d) Put the card close to the reader. One beep confirms the reading. (No need to key in a Common User PIN but
.....there MUSTEHD&RPPRQ8VHU3,1DOUHDG\UHFRUGHGLQ/RFDWLRQRULIIRU23
(e) Press # to store the “Card” into memory. Two-beep confirms a valid entry
ii) Operation : (while the system is back to operation mode)
(a) (b) (c)
(a) Put the EM card close to the reader. One-beep confirms the reading and 30 seconds waiting time is given for
.....the entry of the Common User PIN, theAmber LED keeps flashing
(b)Keyin theCommonUserPIN“1357” (thenumberprogrammed in“Location03”forOutput1in theprevious
.....Example)
(c) Confirm it with the # key. Output 1 activates
5) Example 5 -- Delete an User PIN & / or EM Card (for O/P 1 or 2) :
i) DeleteAn User PIN or ALost EM Card
(a) (b) (c) (d)
(a) Key in the User Group that the User ID belongs to. “10” for the Group 1 and “20” for the Group 2
(b) Key in “5” that is the Command Code for making a deletion here
(c) Key in the User ID that stored the User PIN, the lost EM card or the EM Card+User PIN
G3UHVVWKHNH\7ZREHHSFRQILUPVDYDOLGHQWU\DQGWKH3,1DQGRU&DUGLQWKDW8VHU,'LVFOHDUHG
ii) Delete an EM Card
(a) (b) (c) (d)
(a) Key in the User Group that the EM Card belongs to. “1 0” for the Group 1 and “2 0” for the Group 2
(b) Key in “5” that is the Command Code for making a deletion here
(c) Put the EM card close to the reader. One-beep confirms the reading. Read the Card only also makes a valid
.....deletion to the Card working with the Common User PIN or the Secondary User PIN
(d) Press the # key. Two-beep confirms a valid entry. The EM Card in that User ID is cleared. Key in the User ID
.....is not required.
6) Example 6 – Clear The Whole Group of Users :
Whole group of users including the PINs and Cards can be cleared with the following command.
(a) (b) (c)
(a) The User Group 1 – “10” is selected to be cleared. “20” for Group 2
(b) Key in the Group Deletion Command, 0 9 9 9
(c) Confirm the deletion with #.All the User PINs and Cards in the Group 1 are cleared. It takes few seconds to
.....a minute to complete depending on the data stored.
READ CARD
COMMON USER PIN
READ CARD
USER ID
READ CARD
18
ACCESS SECURITY PRODUCTS LTD

Set a “Visitor Code” with number of “7 8 1 3” that is valid for three hours for Output 1
Set a “One Time Visitor Code” with number “6 8 2 2” for Output 1
VISITOR CODES (FOR OUTPUT 1 ONLY) (Location 40)
The Visitor Codes are the temporary user codes for operating of the Output 1 (mainly for door strike in access
control). They can be programmed as “One Time Codes” or “Codes with Time Limit”. The Visitor Codes will
be cleared automatically after use if they are one time codes, or, when the allowed time expires.
VISITOR ID
50 Visitor IDs for storing the codes.They are represented by a
Two-digit ID Number of to .
Clear all the Visitor Codes from Location 40.
Please see the Programming example below for
the details.
VALID PERIOD
The codes in this box MUST be two digits and they represent the time of the operation.
--- One Time Code
....One Time Code has no time limit but it can only be used for ONCE.
....It is cleared by the system automatically after use.
--- Time Limit in Hour(s)
....7KH9LVLWRU&RGHFDQEHVHWZLWKWKHYDOLGWLPHOLPLWRI+RXUWR+RXUVZLWKD
....two-digit number of 01 to 99. The visitor code is cleared by the system when
....the time limit reaches.
VISITOR CODES
ƔWhen a new Visitor Code is put in the same Code box, the old code is replaced.
ƔThe Visitor Codes can be 4-8 digits for the Manual Mode code entry.
ƔThe Visitor Codes MUST be in the same digit length with the Master Code forAuto Mode code entry.
ƔThe Visitor Codes can not reset Duress Output.
NOTE: All Visitor Codes will be cleared after power down to prevent extension/confusion of their valid
............time limit.
EXAMPLES:
Example 1:
(a) (b) (c) (d) (e)
(a) Visitor Code Programming, (b) The Visitor ID, (c) An One Time Code, (d) The Visitor Code, (e) Entry
......Confirmation
Example 2:
(a) (b) (c) (d) (e)
(a) Visitor Code Programming, (b) The Visitor ID, (c) 9DOLG IRU +RXUV (d) The Visitor Code, (e) Entry
......Confirmation
VISTOR PERIOD
OR -
VISTOR ID
-
LOCATION
or
VISITOR CODE
4 to 8 Digits
VALIDATION
19
ACCESS SECURITY PRODUCTS LTD
Table of contents
Other Access Security Products Keypad manuals
