Access PCIe-COM232-8 User manual

10623 Roselle Street, San Diego, CA 92121 •[phone] •FAX [phone]
[email protected] •www.accesio.com
MODELS PCIe-COM232-8
and PCIe-COM232-4
PCI Express Multi-Port Low Profile Serial
Communications Cards
USER MANUAL
FILE: MPCIe-COM232-8.A1r

PCIe-COM232-8 User Manual
2
Notice
The information in this document is provided for reference only. ACCES does not assume any liability arising
out of the application or use of the information or products described herein. This document may contain or
reference information and products protected by copyrights or patents and does not convey any license under
the patent rights of ACCES, nor the rights of others.
IBM PC, PC/XT, and PC/AT are registered trademarks of the International Business Machines Corporation.
Printed in USA. Copyright 2009 by ACCES I/O Products Inc, 10623 Roselle Street, San Diego, CA 92121. All
rights reserved.
WARNING!!
ALWAYS CONNECT AND DISCONNECT YOUR FIELD CABLING WITH THE
COMPUTER POWER OFF. ALWAYS TURN COMPUTER POWER OFF
BEFORE INSTALLING A CARD. CONNECTING AND DISCONNECTING
CABLES, OR INSTALLING CARDS INTO A SYSTEM WITH THE
COMPUTER OR FIELD POWER ON MAY CAUSE DAMAGE TO THE I/O
CARD AND WILL VOID ALL WARRANTIES, IMPLIED OR EXPRESSED.

PCIe-COM232-8 User Manual
3
Warranty
Prior to shipment, ACCES equipment is thoroughly inspected and tested to applicable specifications. However,
should equipment failure occur, ACCES assures its customers that prompt service and support will be available.
All equipment originally manufactured by ACCES which is found to be defective will be repaired or replaced
subject to the following considerations.
Terms and Conditions
If a unit is suspected of failure, contact ACCES' Customer Service department. Be prepared to give the unit
model number, serial number, and a description of the failure symptom(s). We may suggest some simple tests
to confirm the failure. We will assign a Return Material Authorization (RMA) number which must appear on the
outer label of the return package. All units/components should be properly packed for handling and returned
with freight prepaid to the ACCES designated Service Center, and will be returned to the customer's/user's site
freight prepaid and invoiced.
Coverage
First Three Years: Returned unit/part will be repaired and/or replaced at ACCES option with no charge for labor
or parts not excluded by warranty. Warranty commences with equipment shipment.
Following Years: Throughout your equipment's lifetime, ACCES stands ready to provide on-site or in-plant
service at reasonable rates similar to those of other manufacturers in the industry.
Equipment Not Manufactured by ACCES
Equipment provided but not manufactured by ACCES is warranted and will be repaired according to the terms
and conditions of the respective equipment manufacturer's warranty.
General
Under this Warranty, liability of ACCES is limited to replacing, repairing or issuing credit (at ACCES discretion)
for any products which are proved to be defective during the warranty period. In no case is ACCES liable for
consequential or special damage arriving from use or misuse of our product. The customer is responsible for all
charges caused by modifications or additions to ACCES equipment not approved in writing by ACCES or, if in
ACCES opinion the equipment has been subjected to abnormal use. "Abnormal use" for purposes of this
warranty is defined as any use to which the equipment is exposed other than that use specified or intended as
evidenced by purchase or sales representation. Other than the above, no other warranty, expressed or implied,
shall apply to any and all such equipment furnished or sold by ACCES.

PCIe-COM232-8 User Manual
4
TABLE OF CONTENTS
Chapter 1: Introduction..................................................................................................................... 5
Features............................................................................................................................................. 5
Applications...................................................................................................................................... 5
Functional Description.................................................................................................................. 5
Figure 1-1: Block Diagram........................................................................................................ 6
Ordering Guide................................................................................................................................ 6
Model Options.................................................................................................................................. 7
Optional Accessories..................................................................................................................... 7
Special Order.................................................................................................................................... 7
Included with your board.............................................................................................................. 7
Chapter 2: Installation........................................................................................................................ 8
CD Software Installation................................................................................................................ 8
Hardware Installation..................................................................................................................... 9
Figure 2-1: Installed Cards with Stability Bracket Accessories..................................... 9
Chapter 3: Hardware Details.......................................................................................................... 10
Figure 3-1: Card Dimensions................................................................................................. 10
Fast RS-232 transceivers (-F) .................................................................................................... 10
Low-profile mounting bracket (-L)............................................................................................ 10
Remote Wake-Up (-W).................................................................................................................. 11
Extended temperature (-T).......................................................................................................... 11
RoHS compliance (-RoHS).......................................................................................................... 11
VHDCI connector........................................................................................................................... 11
Chapter 4: Address Selection........................................................................................................ 12
Chapter 5: Programming................................................................................................................. 13
Sample Programs.......................................................................................................................... 13
Windows COM Utility Program.................................................................................................. 13
Windows Programming............................................................................................................... 13
Table 5-1: Baud Rate Generator Setting............................................................................. 13
Table 5-2: Sample Baud Rate Setting.................................................................................. 14
Chapter 6: Connector Pin Assignments..................................................................................... 15
Input/Output Connections.......................................................................................................... 15
Table 6-1: Connector Pin Assignments.............................................................................. 15
Figure 6-1: Male DB9 Connector Pin Locations ............................................................... 15
VHDCI 68-Pin D-Connector......................................................................................................... 16
Table 6-2: VHDCI 68-Pin Female D-Connector Pin Assignments ................................ 16
Figure 6-2: VHDCI 68-Pin Female D-Connector Pin Locations..................................... 16
Chapter 7: Specifications ............................................................................................................... 17
Communications Interface......................................................................................................... 17
Environmental................................................................................................................................ 17
Customer Comments....................................................................................................................... 18

PCIe-COM232-8 User Manual
5
Chapter 1: Introduction
The PCI Express Multiport Serial cards were designed for RS232 asynchronous
communications for use in a variety of applications. These boards were designed to offer
compatibility with the PCI Express bus and to be used by system integrators and
manufacturers in the design of industrial and commercial communication systems. The card is
available in 8-port and 4-port versions and is compatible with all popular operating systems.
Each RS232 port is capable of supporting data rates up to 921.6kbps (460.8kbps version is
standard) and implements full modem control signals to ensure compatibility with a wide range
of serial peripherals. Existing serial peripherals can connect directly to the industry standard
DB9M connectors which are provided via an available cable. The board features a x1 lane
PCI Express connector which can be used in any x1, x2, x4, x8, x12 or x16 PCI Express slot.
.
Features
•Eight- or four-port PCI Express RS-232 serial communications
•Low profile MD1 form factor, MD1 defines the shortest standard card length available
•High performance 16C950 class UARTs with 128-byte FIFO for each TX and RX
•Supports data communication speeds up to 921.6kbps (standard model 460.8kbps)
•+/-15kV ESD protection on all signal pins
•Full modem control signals
•Software compatible with all operating systems
•Plug and Play, no jumpers to configure
•3’ breakout cable terminating with industry-standard DB9M connectors
Applications
•POS (Point-of-sale) Systems
•Gaming Machines
•Transportation Stations
•Telecommunications
•Industrial Automation
•ATM (Automated Teller Machine) Systems
•Multiple terminal control
•Office Automation
•Kiosks
Functional Description
These cards feature high performance 16C950 class UARTs which support the complete
register set of the standard 16C550-type devices. The UARTs support operations in 16C450,
16C550 and 16C950 modes. Each port is capable of data communication speeds up to
921.6kbps (standard model up to 460.8kbps) in asynchronous mode and has 128-byte deep
transmit and receive FIFOs to protect against lost data in multitasking operating systems, to
help reduce CPU utilization and to improve data throughput.

PCIe-COM232-8 User Manual
6
The card features a x1 lane PCIe connector which can be used in any available PCIe slot
width. The low profile MD1 form factor allows the card to be installed in small embedded
systems where a standard MD2 low profile card will not fit. The card can be used in both a
standard profile chassis or in a low profile chassis when used with the correct mounting
bracket. Our PCI Express RS-232 cards ship with a standard height PCIe mounting bracket
installed. This bracket also has threaded inserts above and below the VHDCI 68-pin
connector to facilitate installation of the strengthening bracket accessory. The industrialized
strengthening bracket accessory protects against damage to the very high density I/O card-
mounted connector when side-to-side tension can occur on the breakout cable.
A crystal oscillator is located on the card. This oscillator permits precise selection of standard
baud rates.
Figure 1-1: Block Diagram
Ordering Guide
•PCIe-COM232-8 PCI Express eight-port RS-232 card with standard height
mounting bracket and a 3’ DB9M breakout cable
•PCIe-COM232-8NC PCI Express eight-port RS-232 card with standard height
mounting bracket without cable
•PCIe-COM232-4 PCI Express four-port RS-232 card with standard height
mounting bracket and a 3’ DB9M breakout cable
•PCIe-COM232-4NC PCI Express four-port RS-232 card with standard height
mounting bracket without cable

PCIe-COM232-8 User Manual
7
Model Options
•-F Fast RS-232 transceivers (up to 921.6kbps)
•-L Low-profile mounting bracket
•-T Extended Operating Temperature of -40°C to +85°C
•-RoHS RoHS compliant version
•-W Wake-up enable (see Chapter 3: Hardware Details)
Optional Accessories
BRKT-551-SCB
Strengthening bracket
(for use with standard height PCIe bracket only)
ADAP9
Screw terminal adaptor DB9F to 9 screw terminals
ADAP9-2
Screw terminal adaptor with two DB9F connectors and 18
screw terminals
Special Order
Virtually any custom baud rate can be achieved with the standard card (see Table 5-2:
Sample Baud Rate Setting) and still be within the standard tolerance range for serial
communications. If that method doesn’t produce an exact enough baud rate a custom crystal
oscillator may be specified, contact factory with your precise requirement. Other specials:
conformal coating, custom software, RJ-45 connectivity, special breakout boxes, etc., we will
work with you to provide exactly what is required.
Included with your board
The following components are included with your shipment, depending on options ordered.
Please take the time now to ensure that no items are damaged or missing.
•Eight- or four-port card with standard height mounting bracket
•3’ breakout cable to DB9M connectors
•Software Master CD
•Quick-Start Guide

PCIe-COM232-8 User Manual
8
Chapter 2: Installation
A printed Quick-Start Guide (QSG) is packed with the card for your convenience. If you’ve
already performed the steps from the QSG, you may find this chapter to be redundant and
may skip forward to begin developing your application.
The software is provided with this card on the CD and must be installed onto your hard disk
prior to use. Perform the following steps as appropriate for your operating system.
A complete driver support package is provided including an easy-to-use Windows terminal
program for testing out your COM ports. This simplifies the verification of proper COM port
operating. The card installs as standard COM ports in all operating systems.
A software reference manual is installed as part of the software and support package for this
product. Please refer to this document for extensive information and guidance on software
tools and programming support at your disposal.
CD Software Installation
The following instructions assume the CD-ROM drive is drive “D”. Please substitute the
appropriate drive letter for your system as necessary.
DOS 1. Place the CD into your CD-ROM drive.
2. Type  to change the active drive to the CD-ROM drive.
3. Type  to run the install program.
4. Follow the on-screen prompts to install the software for this board.
Windows
1. Place the CD into your CD-ROM drive.
2. The system should automatically run the install program. If the install program does not
run promptly, click START | RUN and type , click OK or press .
3. Follow the on-screen prompts to install the software for this board.
Linux 1. Please refer to linux.htm on the CD-ROM for information on installing under linux.
Note: COM boards can be installed in virtually any operating system. We do support
installation in earlier versions of Windows, and are also likely to support future versions.

PCIe-COM232-8 User Manual
9
Hardware Installation
Caution! * ESD A single static discharge can damage your card and cause
premature failure! Please follow all reasonable precautions to
prevent a static discharge such as grounding yourself by touching
any grounded surface prior to touching the card.
1. Do not install the card into the computer until the software has been fully installed.
2. Turn OFF computer power AND unplug AC power from the system.
3. Remove the computer cover.
4. Carefully install the card in an available PCIe expansion slot (you may need to remove a
backplate first).
5. Inspect for proper fit of the card and install and tighten the mounting bracket screw. Make
sure that the card mounting bracket is properly screwed into place and that there is a
positive chassis ground.
6. Install a cable onto the card’s bracket mounted connector
7. If you purchased the optional DB9M breakout cable, you may have also purchased the
connector / cable stabilization bracket, which should be installed at this time
Figure 2-1: Installed Cards with Stability Bracket Accessories
.
8. Replace the computer cover and turn ON the computer.
9. Most computers should auto-detect the card (depending on the operating system) and
automatically finish installing the drivers.
10. Run one of the provided sample programs that was copied to the newly created card
directory (from the CD) to test and validate your installation.
Important: It is necessary to disable "hardware handshaking" (DTR) in your communication
program when operating in RS485 or RS422 mode.

PCIe-COM232-8 User Manual
10
Chapter 3: Hardware Details
There are no user-selectable options for this card, only factory options.
Figure 3-1: Card Dimensions
Fast RS-232 transceivers (-F)
The standard RS-232 transceivers used are capable of speeds up to 460.8kbps which is
adequate in many applications. For this factory option, the board is populated with high-speed
RS-232 transceivers enabling error-free communications at up to 921.6kbps.
Low-profile mounting bracket (-L)
For system designers where space is limited we offer a low profile mounting bracket option.
The strengthening bracket accessory can not be used with this option.

PCIe-COM232-8 User Manual
11
Remote Wake-Up (-W)
The “Remote Wake-Up” factory option is for use in applications where the host computer (the
one this card would be installed in) enters the L2 low-power state where it’s main power is
turned off though VAUX is still applied. When the Ring Indicator is received on serial port
channel A in the L2 power state, Wake-Up is asserted.
Extended temperature (-T)
This factory option is for use in harsh environments and is populated with all-industrial rated
components, specified at a minimum temperature range of -40°C to +85°C.
RoHS compliance (-RoHS)
For international customers and other special requirements, this factory option is available in
RoHS compliant versions.
VHDCI connector
These cards use an Amphenol 68-pin VHDCI (Very High Density Cable Interconnect)
connector. They are SCSI-III type, female, right-angle with screw locks and a 1.6mm pitch.

PCIe-COM232-8 User Manual
12
Chapter 4: Address Selection
The card uses one I/O address space PCI BAR[0].
COM A, COM B, COM C, COM D, COM E, COM F, COM G and COM H each occupy eight
consecutive register locations. These COM designations correlate to the corresponding DB9
on breakout cable, which are labeled as such.
Please note - for 4-port card versions, the ports will be installed as:
COM A, COM B, COM C and COM H.
The breakout cable will have the corresponding port labels near the DB9 connectors.
The Vendor ID for the card is 494F.
The Device ID for the 8-port card is 10A9h.
The Device ID for the 4-port card is 1098h.

PCIe-COM232-8 User Manual
13
Chapter 5: Programming
Sample Programs
There are sample programs with source-code provided with the card in a variety of common
languages. DOS samples are located in the DOS directory and Windows samples are located
in the WIN32 directory.
Windows COM Utility Program
WinRisc is a COM utility program provided on CD with the installation package for this card
that is very useful when working with any serial ports and serial devices. If you haven’t used
this program yet, do yourself a favor and run this program to test out your COM ports.
Windows Programming
The card installs into Windows as COM ports. Thus the Windows standard API functions can
be used. In particular:
►CreateFile() and CloseHandle() for opening and closing a port.
►SetupComm(), SetCommTimeouts(), GetCommState(), and SetCommState() to set
and change a port’s settings.
►ReadFile() and WriteFile() for accessing a port.
See the documentation for your chosen language for details.
In DOS the process is identical to programming 16550- compatible UARTs.
Baud Rate Generation
The built-in Baud Rate Generator (BRG) allows a wide range of input frequency and flexible
Baud Rate generation. To obtain the desired Baud Rate, the user can set the Sample Clock
Register (SCR), Divisor Latch Low Register (DLL), Divisor Latch High Register (DLH) and
Clock Prescale Registers (CPRM and CPRN). The Baud Rate is generated according to the
following equation:
The parameters in the equation above can be programmed by setting the “SCR”, “DLL”,
“DLH”, “CPRM” and “CPRN” registers according to the table below.
Setting
Description
Divisor
DLL + (256 * DLH)
Prescaler
2M-1*(SampleClock + N)
SampleClock
16 - SCR , (SCR = ‘0h’ to ‘Ch’)
M
CPRM, (CPRM = ‘01h’ to ‘02h’)
N
CPRN, (CPRN = ‘0h’ to ‘7h’)
Table 5-1: Baud Rate Generator Setting

PCIe-COM232-8 User Manual
14
To ensure the proper operation of the Baud Rate Generator, users should avoid setting the
value ‘0’ to Sample Clock, Divisor and Prescaler.
The following table lists some of the commonly used Baud Rates and the register settings that
generate a specific Baud Rate. The examples assume an Input Clock frequency of 14.7456
Mhz. The SCR register is set to ‘0h’, and the CPRM and CPRN registers are set to ‘1h’ and
‘0h’ respectively. In these examples, the Baud Rates can be generated by different
combination of the DLH and DLL register values.
Baud Rate
DLH
DLL
1,200
3h
00h
2,400
1h
80h
4,800
0h
C0h
9,600
0h
60h
19,200
0h
30h
28,800
0h
20h
38,400
0h
18h
57,600
0h
10h
115,200
0h
08h
921,600
0h
01h
Table 5-2: Sample Baud Rate Setting
We re-define the parameter of "Baudrate" on DCB structure,
Bit[30:28]: User Defined Baudrate, this value has to be non-zero
Bit[27:24]: to indicate the value of SCR (SampleClock)
Bit[23:16]: to indicate the value to put in DLH
Bit[15:8]: to indicate the value to put in DLL
Bit[7:3]: to indicate the value to put in M (CPRM)
Bit[2:0]: to indicate the value to put in N (CPRN)
If you want to set
DLL=1
DLH=0
SCR=12
then, the parameters of Baudrate in the DCB structure should be set to 0x1c000108. When
the driver finds the parameter "Baudrate" does not exist on the default baudrate table, and Bit
28 is set to "1", it will get the values of SCR, DLL, DLH, M and N from the Baudrate parameter
and set to the registers directly.

PCIe-COM232-8 User Manual
15
Chapter 6: Connector Pin Assignments
Input/Output Connections
The serial communications ports are available to the user via a female 68-pin VHDCI D-
connector. There is an available breakout cable terminating in eight (or four) individual D-sub
9-pin connectors.
The cable is permanently labeled near each DB9 connector with the port letter. Four port
cards ordered with a breakout cable will have four D-sub 9-pin connectors, labeled as COM A,
COM B, COM C and COM H.
The RS-232 specification allows for a maximum recommended length of 50’ due to the single-
ended signaling line drivers.
To ensure that there is minimum susceptibility to EMI and minimum radiation, it is important
that the card mounting bracket be properly screwed into place and that there be a positive
chassis ground. Also, proper EMI cabling techniques (cable connect to chassis ground at the
aperture, shielded twisted-pair wiring, etc.) should be used for the input/output wiring.
DB-9 Male Pin x=A-H
RS-232 Signal Names
Signal Descriptions
Ch x - 1
DCD
Data Carrier Detected
Ch x - 2
RX
Receive Data
Ch x - 3
TX
Transmit Data
Ch x - 4
DTR
Data Terminal Ready
Ch x - 5
GND
Signal Ground
Ch x - 6
DSR
Data Set Ready
Ch x - 7
RTS
Request To Send
Ch x - 8
CTS
Clear to Send
Ch x - 9
RI
Ring Indicator
Table 6-1: Connector Pin Assignments
For best results termination is recommended for any control signals not being used in your
application wherever possible. Typical applications accomplish this by connecting DSR and
DTR to DCD, as well as connecting the RI and CTS pins to the RTS pin.
Figure 6-1: Male DB9 Connector Pin Locations

PCIe-COM232-8 User Manual
16
VHDCI 68-Pin D-Connector
Connections will normally be made to the D-Sub 9-pin connectors through the breakout cable.
In case you wish to connect directly to the 68-pin connector, the pins translate as follows.
DB9 pins
To
VHDCI pins
Ch A
Ch B
Ch C
Ch D
Ch E
Ch F
Ch G
Ch H
1
37
41
45
49
53
57
61
65
2
1
5
9
13
17
21
25
29
3
2
6
10
14
18
22
26
30
4
3
7
11
15
19
23
27
31
5
331
331
331
331
672
672
672
672
6
38
42
46
50
54
58
62
66
7
35
39
43
47
51
55
59
63
8
36
40
44
48
52
56
60
64
9
4
8
12
16
20
24
28
32
Table 6-2: VHDCI 68-Pin Female D-Connector Pin Assignments
1Pin 33 on the 68-Pin connector is Ground, common to Pin 5 on each of the DB-9 connectors
associated with COM Channels A, B, C, and D.
2Pin 67 on the 68-Pin connector is Ground, common to Pin 5 on each of the DB-9 connectors
associated with COM Channels E, F, G, and H.
Pins 34 and 68 on the 68-Pin VHDCI D-Connector are Ground.
Figure 6-2: VHDCI 68-Pin Female D-Connector Pin Locations

PCIe-COM232-8 User Manual
17
Chapter 7: Specifications
Communications Interface
•I/O connection: 68-pin female VHDCI SCSI-Type III connector with screw locks
•Serial ports: 8 or 4 RS-232 ports
•Serial data rates: Up to 921.6k baud asynchronous (460.8k standard)
•UART: Octal type 16C950 with 128-byte transmit & receive FIFO,
16C550 compliant
•Character length: 5, 6, 7, or 8 bits
•Parity: Even, Odd, None, Space, Mark
•Stop interval: 1, 1.5, or 2 bits
•Flow control: RTS/CTS and/or DSR/DTR, Xon/Xoff
•ESD protection: ±15kV on all signal pins
•Cable: 3’ shielded breakout cable terminated with male D-sub 9-
pin connectors
Environmental
•Operating Temperature: Commercial: 0°C to +70°C
Industrial: -40°C to +85°C
•Storage temperature: -65°C to +150°C
•Humidity: 5% to 95%, non-condensing
•Power Required: +3.3VDC at 0.9W (typical)
•Size: 4.72 inches long x 2.20 inches high
(120mm long x 55.8mm high)

PCIe-COM232-8 User Manual
18
Customer Comments
If you experience any problems with this manual or just want to give us some feedback, please email
us at: [e-mail]. Please detail any errors you find and include your mailing address so
that we can send you any manual updates.
10623 Roselle Street, San Diego CA 92121
Tel. [phone] FAX [phone]
www.accesio.com
