AccessPRO APEB100A User manual

PUSH BUTTON
DC
12V~24V
RED
SL-100
READER
ORANGE
Please switch on the appliance again to validate any adjustment of DIP switch value
0 SEC.
2.5 SEC.
5 SEC.
9 SEC.
Setting door lock delay timer :
BROWN
Page 1
APEB100A ( 5 PIN ) APEB100B ( 6 PIN )
Brown - GND Brown - GND
Red +DC12V Red +DC12V
Orange Push Button Orange Push Button
Yellow Door Position Sensor(N.C.) Yellow Door Position Sensor(N.C.)
Green Door Position Sensor(COM.) Green Door Position Sensor(COM.)
Bule Door Position Sensor(N.O.)
Power Supply 1A@DC12V
Current Operation Current 900mA, Holding Current 360mA
Operation Delay Time 0sec. 2.5sec. 5sec. 9sec.
Signal Output Door Sensor(250mA)
Face Plate 200 (L) X 32 (W) X 40 (H) mm
Strike Plate 90 (L) X 26 (W) X 2.5 (H) mm
Bolt 16mm (Throw) X 15.5mm (Diameter)
Safety Measures
(1)Fail-safe Type(Power to lock).
(2)Built-in photo couplers door open push button input contact.
Door will lock again automatically when dooris not open
within 5 seconds.
Connections
Model
Color Model Color
Wiring Diagram
Specifications
APEB100A Fail - safe Type Deadbolt Lock
Installation Manual
VER 15.02.03

※Accessories:
X 1 Lock body X 1 Strike plate
X 2 Shims(small)
For strike plate X 2 Shims (Large) for
Lock body
SCREWS:
5/6-PIN Connector
Lock body
templates
Faceplate
X 8 Small wood screws for strike
plate( 4 x 8 mm)
X 4 Large metal screws for lock
body and shims( 5 x 8 mm)
Strike plate template
X4 Small metal screws for strike plate
and shims( 4 x 15 mm)
X 2 Large wood screws for lock
body( 5 x 26 mm)
Door Lock
Delay Timer
Start
Stand-by
Door Close
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
65
60
55
40
50
45
35
30
25
70
Current
(mA)
Time (sec.)
Time (min.)
Temperature
(℃)
Door close
※Current and Temperature Chart:
(Measurement:Power Supply DC-12V, Room temperature 25℃, Humidity 60% Rh)
Page 2
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
900
800
700
400
600
500
300
200
100
~ ~
1000
VER 15.02.03
~ ~

※Installation:
For double doors For single doors For single doors
Important-For vertical
mounting, wires must come
out the top of the unit.
Instruction:
Diagram 1: Dimensions
Diagram 2: For double door mounting
Diagram 3: For single door mounting
Diagram 4: For vertical mounting
Diagram 1
Diagram 2 Diagram 3 Diagram 4
Page 3
VER 15.02.03

Strike plate
Faceplate
20mm
※Installation:
Please make sure the correct
direction of the shims when mounted
For hollow metal doors: For wood doors:
45mm
Drill hole for deadbolt
(If wood door)
Drill hole for magnet
(if wood door)
Door
◆The lock is hot?
The operating temperature of the lock is normally within 55℃.
◆No operation after installation?
1.Please check power supply. 2.Please check if the direction of
the template is being installed correctlly 3.Please check the
connection points(N.O or N.C)
◆
Lock will open when force is applied on the reader (eg. Hitting
hard or vibrating the reader).?
1.Please check all the connections .
2.Reader's N.C points might strike immediately when force is
being applied on it this eventually causes the fail-safe type of lock
to open when sudden power cut occured. Please refer to page 1
for wiring to prevent such case happen.
Question & Answer
Page 4
