Accles & Shelvoke CASH Cowpuncher .22R User guide

CASH®Cowpuncher
Original Instruction Manual
DO NOT ATTEMPT TO USE THESE STUNNING TOOLS UNTIL
YOU HAVE READ AND UNDERSTAND THESE INSTRUCTIONS
©2017 Accles & Shelvoke Ltd

P2
SECTION DESCRIPTION PAGES
CONTENTS 2
1PRODUCT DESCRIPTION 3
2PRODUCT SPECIFICATION 4
3PRODUCT DIAGRAMS 5
4ANIMAL WELFARE 8
5EFFECTIVE STUNNING & CARTRIDGE SELECTION 9
6GENERAL SAFETY PRECAUTIONS 16
7SAFE OPERATING INSTRUCTIONS 20
8CLEANING & GENERAL MAINTENANCE 25
9TROUBLESHOOTING 27
10 SERVICING 29
11 SPARE PARTS LIST AND DIAGRAM 30
12 CONTACT DETAILS, WARRANTY AND RECYCLING 31
DECLARATION OF CONFORMITY CERTIFICATE 32
DISCLAIMER
This instruction manual is correct at the time of printing. However, because our policy is one of
constant development and improvement, details and images may vary slightly from those provided
in this publication.
©Copyright of Accles & Shelvoke Ltd 2016 - All rights reserved
Accles & Shelvoke”, “CASH”, and “CASH Cowpuncher” are all trademarks of Accles & Shelvoke Ltd
ONLY EVER USE GENUINE ACCLES & SHELVOKE REPLACEMENT PARTS. NOT USING
GENUINE PARTS MAY LEAD TO PREMATURE COMPONENT AND TOOL FAILURE, WHICH
COULD ENDANGER THE OPERATOR AND THOSE IN THE IMMEDIATE VICINITY. IT WILL
ALSO INVALIDATE OUR ORIGINAL EQUIPMENT WARRANTY.
ACCLES & SHELVOKE WILL ACCEPT NO LIABILITY IF ANY COMPONENTS OTHER THAN
THOSE SUPPLIED BY ACCLES & SHELVOKE ARE USED WITH OUR ORIGINAL EQUIPMENT.
THE RESULTANT LIABILITY WILL BE WITH THE END USER OR THE DISTRIBUTOR WHO
SUPPLIED THE UNAPPROVED REPLACEMENT PARTS.
CASH®Cowpuncher
CONTENTS
Accles & Shelvoke Ltd Instruction manual - PART No. 5763 V3.2
©

The CASH Cowpuncher range of stunners are cartridge powered, contact ring, cylindrical style
penetrative tools with automatic bolt return. They are available in both .22” and .25” calibre and can
be used to stun cattle, pigs and other large animals. These tools are intended for professional use.
CASH®Cowpuncher
PRODUCT DESCRIPTION
P3
The CASH Cowpuncher range of stunning tools are penetrative captive bolt devices which cause severe
and irreversible damage to the brain. These tools are designed to stun all designated animals prior to
slaughter or depopulation. They can be used in accordance with EU Council Regulation (EC) number
1099/2009 On the Protection of Animals at the Time of Killing.
The Cowpuncher range of tools are contact ring. This means that when the tool is in the cocked
position and ready to re, and the muzzle/barrel is depressed, the tool will re and the bolt will exit the
tool at a very rapid velocity.
The CASH Cowpuncher range of stunners have been on the market for many years, and in that time
have earned a reputation for being a reliable and effective tool. Long handled Cowpuncher stunning tools
(5430, 5432, 5432R) are suitable for use with long horned animals, this makes the stunning process safer as
it gives the operator a longer reach with the tool and lowers the risk of potential injury from the horns of
the animal. They may also be used when animals are down in the stun box.
To ensure the safety of the operator, and quality of products, all Accles & Shelvoke stunning tools are
proof tested in accordance with the Rules of Proof 2006. We have several ‘assistant proof masters’ who
are accredited by the British Proof House (formerly the Birmingham Proof House, www.gunproof .com).
We work to standards set by the Commission Internationale Permanente pour l’Epreuve des Armes á
Feu Portatives (CIP). All stunning tools are “Proofed” prior to the stunners being released to customers.
Proofed components are stamped with the mark of the British Proof House, so that users can be
assured of the quality and safety of the product.
SECTION 1
Accles & Shelvoke Ltd Instruction manual - PART No. 5763 V3.2
PRODUCT PRODUCT
CODE PRODUCT DESCRIPTION CALIBRE
MAXIMUM
PERMITTED
CARTRIDGE
CASH
Cowpuncher
5413R CASH Cowpuncher .22R 0.22R 4.5 GRAIN ( .22 BLACK )
5414 CASH Cowpuncher .25 0.25 4.5 GRAIN ( .25 GREEN )
5414R CASH Cowpuncher .25R 0.25R 4.5 GRAIN ( .25 GREEN )
5430 CASH Cowpuncher .22R LH 0.22R 4.5 GRAIN ( .22 BLACK )
5432 CASH Cowpuncher .25 LH 0.25 4.5 GRAIN ( .25 GREEN )
5432R CASH Cowpuncher .25R LH 0.25R 4.5 GRAIN ( .25 GREEN )
©

P4
ATTRIBUTE STUNNER MODEL NUMBER
5413R 5414 5414R 5430 5432 5432R
Length (mm) 265 265 265 835 835 835
Width (mm)
(At Widest Point) 60 60 60 60 60 60
Weight (kg) * 2.8kg 2.8kg 2.8kg 4.1kg 4.1kg 4.1kg
‘A’ weighted Sound Pressure
Level at workstation (dB) 86 86 86 86 86 86
‘A’ weighted Sound
Power Level (dB) 80 80 80 80 80 80
‘C’ weighted Peak
emissions (dB) 120 120 120 120 120 120
Calibre .22R 0.25 0.25R .22R .25 .25R
Chamber Reduced Straight Reduced Reduced Straight Reduced
CASH®Cowpuncher
PRODUCT SPECIFICATION
* Rounded to 1decimal place.
Sound values determined according to EN 15895 using EN ISO 3744, using the maximum rated
cartridge for a given tool. Tests conducted using simulated load (paper sheets and plasticine).
The A-weighted sound pressure level and A-weighted sound power level have been calculated
- and are hence valid - at the maximum number of driving processes in one second.
The maximum number of driving processes in the CASH Cowpuncher tool is one per second. This
applies to all of the tools in the range included in this instruction manual.
Information about vibrations
EN15895 states - for cartridge operated hand tools, the vibration total value to which the hand-arm
system is subjected does not exceed 2.5m/s². The generated mechanical recoil that is transmitted into
the hand and arm of the operator is not considered to be a vibration.
SECTION 2
©

CASH®Cowpuncher
PRODUCT DIAGRAMS
P5
CARTRIDGE CHAMBER
NEVER POINT THE MUZZLE END
OF THE STUNNING TOOL AT
YOURSELF OR ANY OTHER PERSON
SECTION 3
CASH COWPUNCHER
Fig. 3.01
DO NOT GRIND THE OUTSIDE
DIAMETER OF THE BOLT!
NEVER USE A MORE POWERFUL CARTRIDGE
THAN THE MAXIMUM PERMITTED CARTRIDGE
AS STAMPED ON YOUR STUNNING TOOL
©2016 Accles & Shelvoke
©
BARREL
POLEAXE END (OF BOLT)
Re-sharpen by reconing using
a countersink tool
118mm
BOLT
MUZZLE
FIRING PIN
BREECH
CAP
THE MAXIMUM GRAINS (GRN) AND
SERIAL NUMBER OF THE TOOL CAN BE
FOUND ENGRAVED ON THE BARREL
DANGER ZONE!
Assuming recuperator
sleeves and washers have
been mistakenly omitted
from the tool

P6
CASH®Cowpuncher
PRODUCT DIAGRAMS
SECTION 3
©
Fig. 3.02
©2016 Accles & Shelvoke
CUT-AWAY SECTION MODEL SHOWING BOLT FULLY RETRACTED
CARTRIDGE
BREECH
CAP
BOLT
FLANGE WASHER
RED ‘O’ RINGS (x2)
CLAW (x3) - NEVER USE THE
TOOLS WITHOUT THE CLAWS
RECUPERATOR SLEEVES (x8)
BARREL
STOP WASHERS (x3)
MUZZLE
DIAGRAM - SHOWING CAP AND BARREL SPLIT
- SHOWING LOBES ON BARREL
CAP
LOWER LOBES (2 of 3)
UPPER LOBES (2 of 3)
BARREL
Fig. 3.03
©2016 Accles & Shelvoke

CASH®Cowpuncher
PRODUCT DIAGRAMS
P7
SECTION 3
©
Fig. 3.04
©2016 Accles & Shelvoke
DIAGRAM SHOWING TOOL IN COCKED
AND READY TO FIRE POSITION
RED ‘O’ RINGS (x2)
RED INDICATOR DOT ON CLAW
CLAW (x3) - NEVER USE THE
TOOLS WITHOUT THE CLAWS
RED INDICATOR DOT ON BARREL
BARREL
WHEN RED DOTS ARE ALIGNED
AS SHOWN, TOOL IS COCKED
AND READY TO FIRE
Fig. 3.05
©2016 Accles & Shelvoke
DIAGRAM - INSIDE CAP SHOWING PHOSPHOR BRONZE BALLS
RED ‘O’ RINGS (x2)
RED INDICATOR DOT ON CLAW
CLAW (1 of 3) - NEVER USE THE
TOOLS WITHOUT THE CLAWS
PHOSPHOR BRONZE BALLS (2 OF 3)
CLAW (3 of 3)
CLAW (2 of 3)
LOWER LOBES (2 of 3)
UPPER LOBES (2 of 3)
BARREL

P8
CASH®Cowpuncher
ANIMAL WELFARE
Improving the protection of animals at the time of slaughter contributes to higher meat quality.
EU Only - in accordance with EU Council Regulation (EC) Number 1099/2009 on the protection of
animals at the time of killing, animals must be spared any avoidable pain, distress or suffering during their
killing and related operations.
Business operators shall in particular take the necessary measures to ensure that animals:
(a) Are provided with physical comfort and protection, in particular by being kept clean,
in adequate thermal conditions and prevented from falling or slipping;
(b) Are protected from injury;
(c) Are handled and housed taking into consideration their normal behaviour;
(d) Do not show signs of avoidable pain or fear or exhibit abnormal behaviour;
(e) Do not suffer from prolonged withdrawal of feed or water;
(f) Are prevented from avoidable interaction with other animals that could harm their welfare.
In addition:
4Introduce the animal into the stun box only when the operator is ready to stun it;
4Avoid excessive light and noise at the stun box to keep animal stress to a minimum;
4The operator should not have to concentrate on keeping his balance, or have to bend excessively
each time he stuns an animal, as this becomes tiring and can lead to inaccurate stunning.
Stun box and race design is therefore of utmost importance for both animal welfare and the
operator’s health and safety;
4The efciency of each stunner is essential to ensuring an effective stun. Ensure cleaning and
maintenance schedules detailed within this Instruction Manual are adhered to;
4Ensure at least 2 stunning tools are present near the stun box. If one stunner breaks down
in use, then there must be a working second tool available, to ensure there is always a means
of administering an effective stun to the target animal.
NOTE - we always advise you refer to any local regulations in force.
SECTION 4
©

This section provides a guide to the correct stunning position and direction for certain animals, and
helps you to select the correct cartridge for that animal.
The cartridge selection information provided within this section of this instruction manual is not
categorical and is hence supplied as guidance only.
GOOD PRACTISE
4Understand animal welfare - refer to the Animal Welfare section for further guidance
4Always ensure your stunning tool is in good working order
4Stunning tools should be cleaned and maintained in accordance with the
instructions within this manual
4Ensure at least 2 stunning tools are present near the stun box
4Stunning tools will require more maintenance if used with cartridges that are more powerful
than is necessary for the target animal
EFFECTIVE STUNNING
The cartridge selection and the blow being applied to the correct part of the skull and in the right
direction is important in ensuring an effective stun. Refer to the diagrams and selection charts within this
section as guidance towards selection. To obtain maximum effect, the muzzle of the tool must be struck
accurately on the target animals head.
The physical signs of an effective stun are:
Quadrupeds
4Animal collapses
4No rhythmic breathing
4Fixed, glazed expression in the eyes
4No corneal reex
4Relaxed jaw
4Tongue hanging loose
THE EFFECTIVENESS OF THE STUN MUST BE VERIFIED BEFORE THE ANIMAL IS SLAUGHTERED.
FAILURE TO STUN
If an animal is not properly stunned it must be re-stunned immediately. Using the second or an
alternative stunning tool, a repeat shot must always be placed so as to avoid the immediate area of
the rst shot.
STUN-TO-STICK TIMES
The humane killing of livestock using captive-bolt equipment is a two-stage procedure. After the animal
has been stunned, it must be bled (or pithed*) immediately to ensure rapid death.
The stun-to-stick interval is the time from the application of stunning equipment to the start of bleeding.
After stunning, sticking should be conducted without delay with a maximum stun-to-stick interval of 15
seconds recommended for all species in the eld. In the abattoir, all pigs, sheep and goats should also be
stuck within 15 seconds. However, on the majority of cattle lines, where the carcass must be hoisted
to a bleed area, maximum stun-to-stick intervals of 60 seconds for the penetrative captive-bolt are
acceptable. (These gures are obtained from the Humane Slaughter Association (HSA) website).
* Dependant upon localised regulations in force.
CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
P9
SECTION 5
©

P10
CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
CORRECT STUNNING POSITION
CATTLE
SECTION 5
SUGGESTED TOOLS AND CARTRIDGES
.22” RANGE .25” RANGE
CASH
COWPUNCHER
.22R
(5413R)
CASH
COWPUNCHER
.22R LH
(5430)
CASH
COWPUNCHER
.25
(5414)
CASH
COWPUNCHER
.25R
(5414R)
CASH
COWPUNCHER
.25 LH
(5432)
CASH
COWPUNCHER
.25R LH
(5432R)
CALVES N/S N/S N/S N/S N/S N/S
LIGHT ANIMALS PURPLE PURPLE YELLOW YELLOW YELLOW YELLOW
MEDIUM ANIMALS GREEN GREEN BLUE BLUE BLUE BLUE
HEAVY ANIMALS
& BULLS RED RED ORANGE ORANGE ORANGE ORANGE
VERY HEAVY
ANIMALS BLACK BLACK BLACK BLACK BLACK BLACK
EXTREMELY HEAVY
ANIMALS N/S N/S GREEN GREEN GREEN GREEN
N/S - NOT SUITABLE FOR DENOTED ANIMAL SIZE
Positioning imagery courtesy of J.K. Shearer, Iowa State University.
Fig. 5.01 Fig. 5.02
©

PIGS
CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
P11
CORRECT STUNNING POSITION
SECTION 5
SUGGESTED TOOLS AND CARTRIDGES
.22” RANGE .25” RANGE
CASH
COWPUNCHER
.22R
(5413R)
CASH
COWPUNCHER
.22R LH
(5430)
CASH
COWPUNCHER
.25
(5414)
CASH
COWPUNCHER
.25R
(5414R)
CASH
COWPUNCHER
.25 LH
(5432)
CASH
COWPUNCHER
.25R LH
(5432R)
CALVES N/S N/S N/S N/S N/S N/S
LIGHT ANIMALS PURPLE PURPLE YELLOW YELLOW YELLOW YELLOW
MEDIUM ANIMALS GREEN GREEN BLUE BLUE BLUE BLUE
HEAVY ANIMALS
& BULLS RED RED ORANGE ORANGE ORANGE ORANGE
VERY HEAVY
ANIMALS BLACK BLACK BLACK BLACK BLACK BLACK
EXTREMELY HEAVY
ANIMALS N/S N/S GREEN GREEN GREEN GREEN
SUGGESTED TOOLS AND CARTRIDGES
.22” RANGE .25” RANGE
CASH
COWPUNCHER
.22R
(5413R)
CASH
COWPUNCHER
.22R LH
(5430)
CASH
COWPUNCHER
.25
(5414)
CASH
COWPUNCHER
.25R
(5414R)
CASH
COWPUNCHER
.25 LH
(5432)
CASH
COWPUNCHER
.25R LH
(5432R)
PIGLETS
BELOW 5kg N/S N/S N/S N/S N/S N/S
WEANERS
& GROWERS PURPLE PURPLE YELLOW YELLOW YELLOW YELLOW
MARKET PIGS GREEN GREEN BLUE BLUE BLUE BLUE
HEAVY ANIMALS RED RED ORANGE ORANGE ORANGE ORANGE
HEAVY SOWS &
BOARS BLACK BLACK BLACK BLACK BLACK BLACK
EXTREMELY HEAVY
ANIMALS N/S N/S GREEN GREEN GREEN GREEN
N/S - NOT SUITABLE FOR DENOTED ANIMAL SIZE
Positioning imagery courtesy of J.K. Shearer, Iowa State University.
Fig. 5.03 Fig. 5.04
©

OTHER ANIMAL SPECIES
Although Accles & Shelvoke CASH Cowpuncher stunning tools are predominantly used for the stunning
of cattle and pigs for meat production, we know from our 100 year history that they are also used for
other animal species, such as, but not limited to:
Mammals such as:
Equines
Deer
Camelids
Etc
As conclusive test results are not available for these animals, we recommend you seek the advice of
an independent expert to understand the appropriate cartridge selection, head placement and tool
direction, prior to stunning.
P12
CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
SECTION 5
ACCLES & SHELVOKE CARTRIDGE RANGE
The following tables identify which cartridges from our range are suitable for use with a given tool from
the CASH Cowpuncher range of products. The cartridges are supplied in quantities of 50 in a metal tin,
or 1000 in a box. All of our products will be clearly branded as Accles & Shelvoke CASH cartridges.
It is a condition of Accles & Shelvoke’s product liability insurance that only CASH cartridges, in CASH
cartons and bearing “E” or “C” headmarks, be used in stunners manufactured by Accles & Shelvoke.
It follows therefore, that no liability whatsoever can be accepted for any claim, including injury, should
any other brand of cartridge be used.
Where cartridges other than these are used, Accles & Shelvoke will not accept responsibility for:
4The safety of the operator
4The humaneness of the stun
4The correct operation of the stunning tool
4The premature failure of parts
Cartridges must be stored in cool, dry conditions. Exposure to excessive amounts of moisture may
affect cartridge performance, which in turn will affect tool performance with the potential to create an
ineffective stun of the animal.
When not in use, cartridges should be locked away separately from any stunning tools.
NOTE - “N/S” - WITH REFERENCE TO THE COMPATABILITY TABLES IN THIS SECTION
OF THE MANUAL, “N/S” IDENTIFIES THAT THE CARTRIDGES HIGHLIGHTED ARE NOT
SUITABLE FOR USE IN THE STATED PRODUCT IN THE TABLE.
EXCEEDING THE PERMITTED STRENGTH OF CARTRIDGE COULD BE HAZARDOUS TO THE
OPERATOR, WILL REDUCE THE EXPECTED LIFE OF THE TOOL OR ITS COMPONENTS AND
WILL INVALIDATE OUR WARRANTY
©

CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
P13
SECTION 5
©
STUNNING TOOL & CARTRIDGE COMPATABILITY -: .22” CALIBRE
1
GRAIN
1.25
GRAIN
2.5
GRAIN
3
GRAIN
4
GRAIN
4.5
GRAIN
CALIBRE PRODUCT
CODE DESCRIPTION BROWN PINK PURPLE GREEN RED BLACK
.22”
5413R CASH Cowpuncher .22R N/S N/S YES YES YES YES
5430 CASH Cowpuncher .22 LH N/S N/S YES YES YES YES
To order your .22” calibre cartridges, please select the appropriate part number from the table below:
PART NUMBERS FOR .22” CARTRIDGES BY QUANTITY
SIZE COLOUR 50 IN A TIN 1000 IN A BOX
1 GRAIN BROWN 7505T 7505
1.25 GRAIN PINK 7585T 7585
2.5 GRAIN PURPLE 7565T 7565
3 GRAIN GREEN 7632T 7632
4 GRAIN RED 7645T 7645
4.5 GRAIN BLACK 7653T 7653

P14
CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
SECTION 5
©
STUNNING TOOL & CARTRIDGE COMPATABILITY -: .25” CALIBRE
1.25
GRAIN
2
GRAIN
3
GRAIN
3.5
GRAIN
4
GRAIN
4.5
GRAIN
CALIBRE PRODUCT
CODE DESCRIPTION PINK YELLOW BLUE ORANGE BLACK GREEN
.25”
5414 CASH Cowpuncher .25 N/S YES YES YES YES YES
5414R CASH Cowpuncher .25R N/S YES YES YES YES YES
5432 CASH Cowpuncher .25 LH N/S YES YES YES YES YES
5432R CASH Cowpuncher .25R LH N/S YES YES YES YES YES
To order your .25” calibre cartridges, please select the appropriate part number from the table below:
PART NUMBERS FOR .25” CARTRIDGES BY QUANTITY
SIZE COLOUR 50 IN A TIN 1000 IN A BOX
1.25 GRAIN PINK 4121KA 7760
2 GRAIN YELLOW 4121KB 7710
3 GRAIN BLUE 4121KC 7757
3.5 GRAIN ORANGE 4121KD 7748
4 GRAIN BLACK 7754T 7754
4.5 GRAIN GREEN 7725T 7725

CASH®Cowpuncher
EFFECTIVE STUNNING AND
CARTRIDGE SELECTION
P15
SECTION 5
KEY PARAMETERS FOR CARTRIDGE SELECTION
The tables on this page detail the key performance parameters for the CASH Cowpuncher range of
tools when used in conjunction with approved Accles & Shelvoke cartridges.
This information is issued to satisfy the requirements of EU Council Regulation (EC) Number 1099/2009
on the protection of animals at the time of killing. It provides guidelines to aid the selection of an
appropriate cartridge to perform effective stunning on a particular type and size of animal. Whilst we
believe this regulation is open to interpretation, these parameters have been published following years
of experience.
These gures may only be used when quoted with the associated notes. Accles & Shelvoke will not
accept responsibility for the reliability of these gures if used out of context.
©
PRODUCT
CODE CALIBRE
CARTRIDGE
GRAINS
(NOMINAL)
ACCLES & SHELVOKE
CARTRIDGE COLOUR
BOLT
DIAMETER
(MM)
AVERAGE
BOLT
VELOCITY*
(M/S)
MINIMUM
BOLT EXIT
LENGTH**
(MM)
ENERGY
GENERATED
(J)
5413R
& 5430 .22”
2.5 PURPLE
11.4
46.7
65
268
3GREEN 50.0 306
4RED 55.0 358
4.5 BLACK 59.8 418
5414, 5414R,
5432 & 5432R .25”
2YELLOW
11.4
47.2
65
273
3BLUE 50.8 316
3.5 ORANGE 53.1 345
4BLACK 60.2 445
4.5 GREEN 66.6 544
Notes
* When measured in air over a distance of 47mm, 15mm from the muzzle tip of the tool.
** When red in air
The velocity gures quoted are accurate within +/- 10%, when using a stunner that is in good condition and maintained in accordance with this instruction manual.

P16
CASH®Cowpuncher
GENERAL SAFETY PRECAUTIONS
SECTION 6
©
GENERAL SAFETY STATEMENT
4THE INTENDED USE OF THIS TOOL IS FOR THE STUNNING OF ANIMALS PRIOR TO
SLAUGHTER OR DEPOPULATION
4ANYONE GRANTED THE AUTHORITY TO USE ONE OF THESE TOOLS TO STUN ANIMALS SHOULD
HAVE READ THIS INSTRUCTION MANUAL SUCH THAT THEY ARE MADE FULLY AWARE OF THE
POTENTIAL RISKS
4THIS TOOL HAS THE POTENTIAL TO CAUSE SEVERE INJURY OR FATALITY IF USED IMPROPERLY
OR INAPPROPRIATELY OUTSIDE OF ITS INTENDED SCOPE OF USE
DANGER - The hazards listed in this section pose a high level of risk which, if not avoided
will result in death or serious injury
4NEVER POINT THE STUNNING TOOL AT YOURSELF OR ANY OTHER PERSON - THE BOLT WILL
PENETRATE BODY PARTS AND MAY LEAD TO SEVERE AND IRREVERSIBLE DAMAGE, POSSIBLY
LEADING TO FATALITY
4NEVER FIRE THE STUNNING TOOL IN AN AREA DESIGNATED AS FLAMMABLE
OR CONTAINING EXPLOSIVES
4NEVER PASS THE TOOL TO ANY OTHER PERSON WHEN IT IS COCKED AND READY TO
FIRE - ACCIDENTAL FIRING OF THE BOLT WILL PENETRATE BODY PARTS AND MAY LEAD TO
SEVERE AND IRREVERSIBLE DAMAGE POSSIBLY LEADING TO FATALITY
4NEVER LEAVE A CARTRIDGE, WHETHER LIVE OR FIRED, IN THE BREECH - TO PREVENT
ACCIDENTAL FIRING OF THE BOLT
4TOOLS SHOULD BE FIRED AS FAR AWAY FROM THE BODY AS IS COMFORTABLE AND ALWAYS
POINTING AWAY FROM THE OPERATOR - FIRING OF THE BOLT TOWARD BODY PARTS MAY
PENETRATE THE BODY AND MAY LEAD TO SEVERE AND IRREVERSIBLE DAMAGE, POSSIBLY
LEADING TO FATALITY
4NEVER MODIFY OR CUSTOMISE THE TOOL - THIS MAY RENDER THE TOOL UNSTABLE AND
UNSAFE FOR USE, WITH THE POTENTIAL TO FIRE ACCIDENTALLY. IT WILL ALSO INVALIDATE
YOUR WARRANTY
4ENSURE YOU ARE BALANCED AND STABLE PRIOR TO FIRING TO AID TOOL POSITIONING
ACCURACY. AVOID OVER-STRETCHING AND UNFAVOURABLE BODY POSITIONS - TO MINIMISE
THE RISK OF DROPPING THE TOOL AND/OR ACCIDENTAL FIRING
4CARTRIDGE MISFIRES - IF THE CARTRIDGE HAS MISFIRED (NOT FIRED), PUT THE TOOL DOWN
IMMEDIATELY AND WAIT FOR 30 SECONDS BEFORE FOLLOWING THE PROCEDURE IN
SECTION 9 OF THIS MANUAL - TO AVOID DELAYED FIRING OF THE CARTRIDGE - WHICH MAY
CAUSE SEVERE DAMAGE IF FIRING OCCURS WHILST BEING HANDLED
DO NOT ATTEMPT TO USE THIS STUNNING TOOL UNTIL YOU HAVE READ AND
UNDERSTOOD THESE INSTRUCTIONS.
ALWAYS WEAR THE CORRECT PERSONAL PROTECTIVE EQUIPMENT (PPE) WHENEVER YOU
ARE WORKING WITH, CLEANING OR MAINTAINING YOUR COWPUNCHER TOOL. ALWAYS
WEAR PROTECTIVE GLASSES AND HEARING PROTECTION. THE CORRECT FOOT PROTECTION
MUST BE WORN. THERE IS A RISK THAT IF THE TOOL IS DROPPED, THE BOLT MAY
PENETRATE THE FOOT OF THE TOOL USER.
DANGER
ONLY COCK THE TOOL READY FOR FIRING
IMMEDIATELY BEFORE USE
IF DROPPED WHEN COCKED THIS TOOL COULD
CAUSE SERIOUS INJURY OR DEATH

CASH®Cowpuncher
GENERAL SAFETY PRECAUTIONS
DANGER - If the tool is set in the cocked (ready to re) position and is dropped, there is a
potential risk to the operator and/or people within the immediate vicinity of the dropped tool. The
hazards listed in this section pose a high level of risk, which if not avoided will result in serious injury.
4IF IT LANDS ON THE BARREL, THE TOOL WILL FIRE AND THE BOLT WILL BE PROPELLED OUT OF
THE TOOL. IF THE BARREL LANDS ON THE FOOT OF THE OPERATOR, THE BOLT COULD
PENETRATE THE FOOT. OPERATORS MUST WEAR THE CORRECT FOOT PROTECTION
4IF IT LANDS ON THE BARREL THE TOOL WILL FIRE AND THE BOLT WILL BE PROPELLED OUT
OF THE TOOL. IF THE CONTACT SURFACE IS A HARD MATERIAL, THE IMPACT FROM THE BOLT
WILL CAUSE THE TOOL TO REBOUND BACK IN THE OPPOSITE DIRECTION TO THE BOLT. THE
TOOL COULD REBOUND BACK TOWARD THE OPERATOR AND HIT THE OPERATOR OR
SOMEONE IN THE VICINITY
4IF IT LANDS ON THE CAP, THE TOOL WILL FIRE AND THE BOLT WILL BE PROPELLED OUT OF THE
TOOL UPWARDS. IF THE OPERATOR TRIES TO CATCH THE TOOL AND THEIR HAND IS OVER THE
END OF THE BARREL AT THE POINT OF IMPACT, THE BOLT WILL PENETRATE THE HAND (OR ANY
BODY PART COVERING THE END OF THE BARREL THAT THE BOLT LEAVES)
OUR ADVICE TO MINIMISE THE RISK:-
4IF THE TOOL IS DROPPED, LET IT FALL, DO NOT TRY TO CATCH IT
4STEP AS FAR AWAY (AS IT IS SAFE TO) FROM THE TOOL AS IT FALLS, BUT WATCH IT HIT THE FLOOR
4TAKE APPROPRIATE AVOIDABLE ACTION IF TOOL REBOUNDS
4DO NOT APPROACH THE TOOL UNTIL IT IS STATIONARY
4AFTER BEING DROPPED, CHECK THAT THE POLEAXE END OF THE BOLT IS NOT DAMAGED
4ENSURE THE TOOL IS WORKING CORRECTLY BEFORE RECOMMENCING ANY STUNNING
4IF IN DOUBT, THE TOOL SHOULD BE CHECKED AND REPAIRED AS NECESSARY
WARNING - The hazards listed in this section pose a medium level of risk which,
if not avoided may result in recoverable injury
4DO NOT FIRE THE BOLT INTO HARD, BRITTLE OR IMPENETRABLE MATERIALS - AS THE BOLT MAY
FRAGMENT AND POSE A DANGER OF FLYING PARTICLES
4NEVER USE A MORE POWERFUL CARTRIDGE THAN THE MAXIMUM PERMITTED CARTRIDGE AS
STAMPED ON YOUR STUNNING TOOL - TO PREVENT CARTRIDGE BURST AND EXCESSIVE
NOISE IN OPERATION
4KEEP THE TOOL DRY AND CLEAN - TO ENSURE YOU HAVE AN ADEQUATE GRIP ON THE TOOL
DURING USE AND MINIMISE THE RISK OF DROPPING THE TOOL
4WHEN PLACING THE ASSEMBLED TOOL – OR IF THE TOOL HAS BEEN SEPARATED THE CAP
OR BARREL (REFER TO FIG 3.01) – DOWN ONTO A WORK SURFACE ENSURE THERE IS A MEANS TO
PREVENT THE TOOL OR TOOL PARTS FROM ROLLING OFF THE WORK SURFACE. IF THE TOOL
FALLS OR DROPS FROM THE WORK SURFACE, IT MAY DROP ONTO THE FOOT OF THE OPERATOR
OR OTHER PEOPLE IN THE VICINITY.
CAUTION - The hazards listed in this section pose a low level of risk which, if not avoided
may result in minor or moderate injury
4TO AVOID TRAPPING FINGERS OR OTHER PARTS OF THE HAND WHEN ASSEMBLING THE CAP
TO THE BARREL, HOLD THE CAP ABOVE THE RED ‘O’ RINGS IN THE KNURLED AREA, AND HOLD
THE BARREL BELOW THE BOTTOM LOBES SO THE RED DOTS ARE STILL VISIBLE (REFER TO FIG 7.01).
P17
SECTION 6
©
ALWAYS WEAR THE CORRECT PERSONAL PROTECTIVE EQUIPMENT (PPE) WHENEVER YOU
ARE WORKING WITH, CLEANING OR MAINTAINING YOUR COWPUNCHER TOOL. ALWAYS
WEAR PROTECTIVE GLASSES AND HEARING PROTECTION. THE CORRECT FOOT PROTECTION
MUST BE WORN. THERE IS A RISK THAT IF THE TOOL IS DROPPED, THE BOLT MAY
PENETRATE THE FOOT OF THE TOOL USER.

P18
CASH®Cowpuncher
GENERAL SAFETY PRECAUTIONS
SECTION 6
©
GENERAL PRECAUTIONS AND GOOD PRACTISE
IMPROPER USE
4ONLY EVER USE THIS TOOL FOR THE STUNNING OF LIVE ANIMALS
4ONLY EVER USE GENUINE ACCLES & SHELVOKE SUPPLIED CARTRIDGES AND SPARES
4DO NOT FIRE “AIR SHOTS”(FIRING OF THE BOLT INTO AIR) AS THIS WILL REDUCE THE WORKING
LIFE OF THE TOOL AND ITS COMPONENTS
WORKPLACE PRECAUTIONS
4THE TOOL SHOULD BE USED IN WELL ILLUMINATED AND WELL VENTILATED
WORKPLACE ENVIRONMENTS
4KEEP THE WORKPLACE CLEAN AND CLEAR OF UNNECCESSARY OBSTACLES OR TRIP HAZARDS
4ENSURE THE AREA SURROUNDING THE STUN BOX IS FREE OF SLIPPERY SUBSTANCES. THESE
ARE POTENTIAL SLIP HAZARDS TO THE OPERATOR WHICH COULD LEAD TO SERIOUS INJURY
OR FATALITY IF THE OPERATOR SLIPS WHILST HOLDING A COCKED TOOL
OPERATIONAL PRECAUTIONS
4ONLY LOAD CARTRIDGES WHEN THEY ARE READY TO BE USED
4IF A CARTRIDGE STICKS IN THE BREECH AND WILL NOT EJECT, DO NOT USE A SHARP
INSTRUMENT TO REMOVE. THE CARTRIDGE SHOULD BE REMOVED IN ACCORDANCE WITH
THESE INTRUCTIONS IN SECTION 9 - TROUBLESHOOTING
4TOOLS MAY BE USED IN AN ALTERNATING SYSTEM AS PART OF A PLANNED OPERATING CYCLE
4JOB ROTATION MAY HELP MAINTAIN THE APPROPRIATE HIGH LEVELS OF CONCENTRATION
REQUIRED AT THE WORKPLACE, HELPING TO MINIMISE ANY RISK DUE TO TIREDNESS OR FATIGUE
GOOD PRACTISE
4THE CLEANING AND MAINTENANCE SCHEDULE DETAILED IN THIS MANUAL SHOULD BE
ADHERED TO, TO ENSURE THE TOOL OPERATES SAFELY AND CORRECTLY TO PROVIDE
EFFECTIVE ANIMAL STUNNING
4AT THE END OF A WORKING SHIFT, OR IF THE TOOL IS NOT GOING TO BE USED FOR PROLONGED
PERIODS, THE UNCOCKED AND UNLOADED TOOL SHOULD BE STORED IN COOL DRY
CONDITIONS AND LOCKED SECURELY IN A WAY THAT NO UNAUTHORISED ACCESS TO THE
TOOL IS POSSIBLE
4CARTRIDGES SHOULD BE LOCKED AWAY SEPARATELY FROM THE STUNNING TOOL IN COOL,
DRY CONDITIONS
4EXPOSURE TO EXCESSIVE AMOUNTS OF MOISTURE MAY AFFECT CARTRIDGE PERFORMANCE
WHICH IN TURN WILL AFFECT TOOL PERFORMANCE, WITH THE POTENTIAL TO CREATE AN
INEFFECTIVE STUN OF THE ANIMAL. WET CARTRIDGES WILL NOT FIRE AND SHOULD
NOT BE USED
4ALWAYS WASH YOUR HANDS AFTER USING ANY STUNNING TOOL TO ENSURE CLEANLINESS
4IT IS ADVISABLE, BEFORE USING YOUR CASH COWPUNCHER TOOL FOR THE FIRST TIME, TO
FAMILIARISE YOURSELF WITH THE ASSEMBLY OF THE CAP TO THE BARREL AND THE
SUBSEQUENT ALIGNMENT OF THE RED DOTS TO COCK THE TOOL (MAKE READY FOR FIRING)
AND ALSO TO PRACTISE TARGET ALIGNMENT TO ASSIST WITH TOOL PLACEMENT ACCURACY.
NEVER HANDLE OR OPERATE ANY STUNNING EQUIPMENT WHILST UNDER THE INFLUENCE
OF ALCOHOL OR DRUGS. IF TAKING PRESCRIBED MEDICATION, SEEK THE ADVICE OF YOUR
DOCTOR PRIOR TO HANDLING OR OPERATING STUNNING EQUIPMENT.
ALWAYS WEAR THE CORRECT PERSONAL PROTECTIVE EQUIPMENT (PPE) WHENEVER YOU
ARE WORKING WITH, CLEANING OR MAINTAINING YOUR COWPUNCHER TOOL. ALWAYS
WEAR PROTECTIVE GLASSES AND HEARING PROTECTION. THE CORRECT FOOT PROTECTION
MUST BE WORN. THERE IS A RISK THAT IF THE TOOL IS DROPPED, THE BOLT MAY
PENETRATE THE FOOT OF THE TOOL USER.

P19
SECTION 7
CASH®Cowpuncher
GENERAL SAFETY PRECAUTIONS
©
ALWAYS WEAR THE CORRECT PERSONAL PROTECTIVE EQUIPMENT (PPE) WHENEVER YOU
ARE WORKING WITH, CLEANING OR MAINTAINING YOUR COWPUNCHER TOOL. ALWAYS
WEAR PROTECTIVE GLASSES AND HEARING PROTECTION. THE CORRECT FOOT PROTECTION
MUST BE WORN. THERE IS A RISK THAT IF THE TOOL IS DROPPED, THE BOLT MAY
PENETRATE THE FOOT OF THE TOOL USER.
TRANSPORTATION OF STUNNING TOOLS AND CARTRIDGES BETWEEN SITES
THIS TOOL HAS BEEN SUPPLIED TO YOU WITH THE INTENTION OF SINGLE SITE USE - SUPPLIED
WITHOUT A LOCKABLE STORAGE CONTAINER. SHOULD THERE BE A NEED TO TRANSPORT THIS TOOL
AND LIVE CARTRIDGES BY ROAD BETWEEN SITES, WE ADVISE:-
4PRIOR TO TRANSPORTATION, YOU SHOULD SEEK THE APPROPRIATE ADVICE CONCERNING
APPLICABLE LOCAL LAWS AND REGULATIONS IN FORCE ON THE TRANSPORTATION OF
CARTRIDGES TO BE USED FOR ANIMAL STUNNING
4THE TOOL AND CARTRIDGES ARE TRANSPORTED IN SEPARATE LOCKABLE CONTAINERS
4THEY ARE HIDDEN FROM PUBLIC VIEW, ie NO-ONE OUTSIDE OF THE VEHICLE CAN SEE THE
LOCKABLE CONTAINERS WITHIN THE VEHICLE.

P20
CASH®Cowpuncher
SAFE OPERATING
INSTRUCTIONS
SECTION 7
©
IT IS ADVISABLE, BEFORE USING YOUR CASH COWPUNCHER TOOL FOR THE FIRST TIME,
TO FAMILIARISE YOURSELF WITH THE ASSEMBLY OF THE CAP TO THE BARREL AND THE
SUBSEQUENT ALIGNMENT OF THE RED DOTS TO COCK THE TOOL (MAKE READY FOR FIRING)
AND ALSO TO PRACTISE TARGET ALIGNMENT TO ASSIST WITH TOOL PLACEMENT ACCURACY.
NOTE
4The maximum recommended usage rate for a CASH Cowpuncher tool is 60 shots per hour using the maximum specied cartridge
DO NOT ATTEMPT TO USE THIS STUNNING TOOL UNTIL YOU HAVE READ AND
UNDERSTOOD THESE INSTRUCTIONS.
ALWAYS WEAR THE CORRECT PERSONAL PROTECTIVE EQUIPMENT (PPE) WHENEVER YOU
ARE WORKING WITH, CLEANING OR MAINTAINING YOUR COWPUNCHER TOOL. ALWAYS
WEAR PROTECTIVE GLASSES AND HEARING PROTECTION. THE CORRECT FOOT PROTECTION
MUST BE WORN. THERE IS A RISK THAT IF THE TOOL IS DROPPED, THE BOLT MAY
PENETRATE THE FOOT OF THE TOOL USER.
WHEN PLACING THE ASSEMBLED TOOL – OR IF THE TOOL HAS BEEN SEPARATED THE CAP
OR BARREL (REFER TO FIG 3.01) – DOWN ONTO A STORAGE SURFACE ENSURE THERE IS A
MEANS TO PREVENT THE TOOL OR TOOL PARTS FROM ROLLING OFF THE STORAGE
SURFACE. IF THE TOOL FALLS OR DROPS FROM THE STORAGE SURFACE, IT MAY DROP
ONTO THE FOOT OF THE OPERATOR OR OTHER PEOPLE IN THE VICINITY.
1PREPARING
FOR LOADING
1.1 Hold the tool on the barrel, ensure your hand is below the bottom lobes so that the red dots
are visible (FIG 7.01)
1.2 Using other hand rotate cap through 60° so that the red dots are not aligned (FIG 7.02)
1.3 With the tool pointing cap downwards, slide cap away from barrel until the two separate
NOTE
4If spent cartridge is stuck in the chamber do not attempt to remove it by prising out with a sharp implement or
improvised extraction tool. ONLY use extraction tool provided.
4Ensure that the bolt is fully retracted before inserting a cartridge (FIG 7.03). If the bolt is not fully retracted, this will
reduce the stunning power of the tool causing an ineffective stun.
Fig. 7.01
©2016 Accles & Shelvoke
Fig. 7.02
©2016 Accles & Shelvoke
DANGER
ONLY COCK THE TOOL READY FOR FIRING
IMMEDIATELY BEFORE USE
IF DROPPED WHEN COCKED THIS TOOL COULD
CAUSE SERIOUS INJURY OR DEATH
ALWAYS POINT THE TOOL AWAY FROM YOUR BODY AND AWAY FROM ANY OTHER
PERSON IN THE VICINITY WHEN HANDLING OR OPERATING THE TOOL
