BCP SKY5800 User manual

SKY5800
Ver. 1
INSTRUCTION
MANUAL
Chicken Coop with Wheels

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

HARDWARE
| 3
• Do not stand on or use any part of this item as a step ladder.
• Firmly secure all bolts, screws, and knobs before use.
• Reconfirm that all bolts, screws, and knobs are secure every 90 days.
• Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
• Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
• Be aware that some parts are heavy and have sharp edges.
• If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or
factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
Please retain these instructions for future reference.
NOTICE
TOOLS REQUIRED
UP TO 90 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER
SMALL
WRENCH
20mm DOWEL
J
12 PCS
I
8 PCS
M8 X 35mm
BOLT SET
LATCH
L
2 PCS
K
1 PC
50mm DOWEL
M6 X 45mm
BOLT SET
H
4 PCS
M3.5 X 25mm
SCREW
E
8 PCS
M3.5 X 50mm
SCREW
F
10 PCS
A
18 PCS
M3.5 X 40mm
SCREW B
12 PCS
M3 X 12mm
SCREW
M3 X 38mm
SCREW
D
4 PCS
M3 X 16mm
SCREW
C
10 PCS
M3 X 20mm
SCREW
G
4 PCS
ELECTRIC DRILL
(RECOMMENDED)

PARTS
1 PC
FRONT
1
1 PC
BACK
2
4
1 PC
RIGHT SIDE
1 PC
BACK FENCE
6
5
1 PC
FRONT FENCE
1 PC
LEFT SIDE
3
1 PC
CLEAR ROOF
7
2 PCS
ROOF
8
1 PC
BOX ROOF
9
1 PC
TRAY
10
1 PC
RAMP
11
1 PC
SIDE FENCE
12
4|

| 5
PARTS
1 PC
LEFT BOX SIDE
13
1 PC
RIGHT BOX SIDE
14
16
1 PC
BOX FLOOR I
1 PC
DIVIDER
18
17
1 PC
BOX FLOOR II
1 PC
BOX FRONT
15
1 PC
ROOF FRAME
19
1 PC
RAILING
20
2 PCS
RAILING ARM
21
2PCS
MIDDLE SUPPORT
22
2 PCS
SIDE SUPPORT
23
2 PCS
WHEEL
24

PRODUCT ASSEMBLY
Attach a part 23 side support to part 3 left side with two part J dowels and two part D screws.
1
2Attach two part 24 wheels with eight part I bolt sets.
6|
Dx2
Jx2
3
23
Ix8
24
24

| 7
PRODUCT ASSEMBLY
Attach part 1 front and part 2 back to the left side with six part A screws.
3
Ax6
2
1

PRODUCT ASSEMBLY
Attach a part 23 side support to part 4 right side with two part J dowels and two part D screws.
4
Attach part 4 right side with four part J dowels and four part A screws.
5
8|
Dx2
Jx2
4
23
Ax4
Jx4
4

| 9
PRODUCT ASSEMBLY
Attach part 11 ramp with two part C screws.
6
Cx2
11

10 |
PRODUCT ASSEMBLY
Attach part 5 front fence and part 6 back fence with four part F screws.
Insert two part J dowels.
Insert a part K dowel into the back fence to secure the ramp.
7
Jx2
Fx4
5
6
K

Attach the side fence with four part A screws.
10
| 11
PRODUCT ASSEMBLY
Attach two part 21 railing arms to part
20 railing with two part F screws.
8Attach the railing arms to part 12 side
fence with two part J dowels and four part
F screws.
9
Ax4
Fx2 20
21
21
Jx2
Fx4
12

12 |
PRODUCT ASSEMBLY
Attach part 7 clear roof with four part A screws.
NOTE: Insert the dowels into the roof.
11
7
Ax4

| 13
PRODUCT ASSEMBLY
Attach part 13 left box side and part 14 right box side with four part H bolt sets.
Attach part 15 box front with four part C screws.
12
Cx4
Hx4
13
14
15

14 |
PRODUCT ASSEMBLY
Place part 16 and 17 box floors.
Insert part 18 divider into the designated slot.
13
18
16
17

| 15
PRODUCT ASSEMBLY
Attach the hinges on the part 9 box roof with four part C screws.
14
Cx4
9

16 |
PRODUCT ASSEMBLY
Place two part 22 middle supports into the coop.
Slide in the part 10 tray.
15
22
10
22

| 17
PRODUCT ASSEMBLY
Attach two part 8 roofs with eight part E screws.
Attach part 19 roof frame with four part G screws.
16
Gx4
Ex8
8
8
19

18 |
PRODUCT ASSEMBLY
Attach two part L latches with twelve part B screws, six screws per latch.
17
L B x12
x2

Earn points while you shop. Join today!
bestchoiceproducts.com
Give your friends 15% o their first order! For each
successful referral you’ll receive 100 points.

All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long
as the item is returned in its original product packaging and all accessories from its original shipment are
included. All returned items will receive a full refund back to the original payment method. All returned
items will not be charged a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best
Choice Products Customer Service Representative when the return request is submitted. Items received
without an RA may not be accepted or may increase your return processing time. Once an item has been
received by Best Choice Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If
the reason for return is a result of an error by Best Choice Products then Best Choice Products will provide
a pre-paid shipping label via email. Boxes for return shipping will not be provided by Best Choice Products,
and is the customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items
returned are not considered undamaged until they are received by Best Choice Products and verified as
such. All damages to items are the customer’s responsibility until the item has been received by and
acknowledge by Best Choice Products as undamaged.
PRODUCT WARRANTY INFORMATION
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, unapproved modification, or neglect of this product.
HELP CENTER
