56-SERIES
Owner’s Manual and Parts Book
THIS MANUAL TO ACCOMPANY MACHINE
Part No: 56-MP-02
Print Date: June 2019
Stalk Shredder Puller
INTRODUCTION:
Thank you for purchasing your new KMC 5610 Stalk Shredder
Puller. It has been designed to reduce multiple trips through
crop. It pulls the root system of the plants to help control pests
loaded rear Rolling Crumblers assist at dislodging roots from the
are balanced with a high speed balancing machine to assure less
The Management of Kelley Manufacturing Co. is committed to
to reduce your costs in crop production. We welcome your calls
you!
KELLEY MANUFACTURING CO.
WARRANTY POLICY
KELLEY MANUFACTURING COMPANY (KMC) warrants that all goods sold to
the original purchaser of any KMC product shall be free of any defects in material and
workmanship if used under normal operating conditions. e warranty period begins
on the date of purchase by the retail customer and ends twelve (12) months thereaer.
KMC’s sole responsibility is to repair and/or replace the defective part(s) at no cost to
the purchaser. is remedy is the SOLE AND EXCLUSIVE REMEDY of the purchaser.
e purchaser must ll out and return the warranty registration form found in the
front of the operator’s manual. Failure to return the warranty registration form within 30
days shall result in the goods being sold “As Is”, and all warranties shall be excluded.
is warranty shall not apply to those items that are by nature worn in normal
service, including but not limited to belts, springs, teeth, chains, etc. Items such as
tires, tubes, gearboxes, and all other items warranted by the original manufacturer are
warranted only to the extent of their individual manufacturer warranty, as KMC is
not warranting any of said items. All warranty claims must be made through a KMC
licensed dealer, and a warranty form request must be submitted to KMC with 30 days of
failure, or the warranty provision shall be unenforceable against KMC.
No agent or person has authority to change or add to this warranty as written.
THE ABOVE IS THE ONLY WARRANTY MADE BY KMC AND IS MADE
EXPLICITLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED.
KMC MAKES NO WARRANTY OF MERCHANTABILITY AS TO ANY GOODS
MANUFACTURED BY KMC; FURTHERMORE, KMC DOES NOT WARRANT
ANY SUCH GOODS AS SUITABLE FOR ANY PARTICULAR PURPOSE TO THE
RETAIL CUSTOMER. THE SUITABILITY OF GOODS FOR ANY PURPOSE
PARTICULAR TO THE CUSTOMER IS FOR THE CUSTOMER, IN HIS OR HER
SOLE JUDGEMENT, TO DETERMINE. KMC MAKES NO FURTHER WARRANTIES
WITH RESPECT TO ITS MANUFACTURED GOODS THAT WOULD NORMALLY
BE DISCLOSED BY AN EXAMINATION. THIS IS THE FULL AND FINAL
EXPRESSION OF ALL WARRANTY LIABILITY OF KMC. NO OTHER WARRANTY,
EXPRESSED OR IMPLIED, SHALL BE ENFORCEABLE AGAINST KMC.
Kelley Manufacturing Co.
80 Vernon Drive, Tion, GA. 31794
P.O. Box 1467, Tion, GA. 31793
TABLE OF CONTENTS
TO THE PURCHASER ............................................................................................................................................................................... 1
PRE-OPERATIONAL CHECKLIST ........................................................................................................................................................ 2
SAFETY ............................................................................................................................................................................................................. 3
SYMBOL INFORMATION ........................................................................................................................................................................ 3
SAFETY DECALS........................................................................................................................................................................................ 4
CUSTOMER RESPONSIBILITY.............................................................................................................................................................. 5
SAFETY PROCEDURES........................................................................................................................................................................5-6
CUSTOMER OPERATION..........................................................................................................................................................................7
TRACTOR PREPARATION...................................................................................................................................................................... 7
FRONT END WEIGHTS............................................................................................................................................................................ 7
HORSE POWER REQUIREMENTS ....................................................................................................................................................... 7
SWAY BLOCKS............................................................................................................................................................................................ 7
WHEEL SPACING....................................................................................................................................................................................... 7
DRAWBAR POSITION.............................................................................................................................................................................. 7
4-ROW 36” STALK SHREDDER PULLER .......................................................................................................................................... 8
4-ROW 38” STALK SHREDDER PULLER .......................................................................................................................................... 9
4-ROW 40” STALK SHREDDER PULLER ....................................................................................................................................... 10
6-ROW 36” STALK SHREDDER PULLER ....................................................................................................................................... 11
6-ROW 38” STALK SHREDDER PULLER ....................................................................................................................................... 12
6-ROW 40” STALK SHREDDER PULLER ....................................................................................................................................... 13
ADJUSTING ROW SPACING ................................................................................................................................................................. 14
DEALER UNPACKING & SETUP.......................................................................................................................................................... 15
SPECIFICATIONS ...................................................................................................................................................................................... 15
HITCHING TO THE IMPLEMENT....................................................................................................................................................... 16
CAT IV NARROW QUICK COUPLER .................................................................................................................................................16
CAT III 3-POINT HITCH ........................................................................................................................................................................17
CAT III QUICK COUPLER/NARROW QUICK COUPLER ............................................................................................................17
IN THE FIELD.............................................................................................................................................................................................. 18
PREPARING FOR THE FIELD..............................................................................................................................................................18
DRIVELINE INSTALLATION................................................................................................................................................................18
LEVELING & ADJUSTMENTS ............................................................................................................................................................... 18
PARALLEL LINKAGE..............................................................................................................................................................................18
GAUGE WHEELS......................................................................................................................................................................................18
RIGID DISC STOP BOLT ........................................................................................................................................................................19
DISCS.....................................................................................................................................................................................................19-20
BALANCING PROCEDURES .................................................................................................................................................................. 20
MAINTENANCE PROCEDURES ........................................................................................................................................................... 20
LUBRICATION ..........................................................................................................................................................................................20
SPECIAL CONSIDERATIONS ................................................................................................................................................................ 20
STALK SHREDDER...............................................................................................................................................................................21-22
GAUGE WHEEL ASSEMBLY .....................................................................................................................................................................23
JACKSTAND ...................................................................................................................................................................................................23
ROTOR ASSEMBLY .....................................................................................................................................................................................24
TABLE OF CONTENTS CONTINUED
BLADE ASSEMBLY ......................................................................................................................................................................................25
COUPLER ASSEMBLY.................................................................................................................................................................................25
ROTOR ASSEMBLY RIGHT.......................................................................................................................................................................26
BLADE ASSEMBLY ......................................................................................................................................................................................26
DRIVELINE 1-3/4........................................................................................................................................................................................27
GEARBOX........................................................................................................................................................................................................28
LIGHTING HARNESS ..................................................................................................................................................................................29
LIGHT ASSEMBLY .......................................................................................................................................................................................29
PARALLEL LINKAGE..................................................................................................................................................................................30
DISC PULLER ASSEMBLY ..................................................................................................................................................................31-32
DISC ASSEMBLY, HUB ...............................................................................................................................................................................33
DISC ASSEMBLY, 28” PADDLE ...............................................................................................................................................................33
CRUMBLER ARM ........................................................................................................................................................................................34
CRUMBLER ASSEMBLY.............................................................................................................................................................................35
1
TO THE PURCHASER:
manual has been prepared to assist you during your use of this product. Please read
all instructions within this manual thoroughly in order to operate and maintain the
Some components of this machine are labeled left or right. The notations are
determined by standing behind the implement and facing the direction of forward
reference.
Model No.
Serial No.
Purchase Date
2
NOTES:
PRE-OPERATIONAL CHECKLIST:
•
• All hardware checked for tightness
•
•
• Machine fully lubricated
•
•
3
DANGER
WARNING
CAUTION
! IMPORTANT
!
SAFETY
Symbol Information:
This safety alert symbol is used throughout this manual to identify safety
messages. When seeing this symbol read the message that follows, as it will
advise you of possible injury.
This symbol indicates a hazardous situation that, if
not avoided, could result in minor or moderate
injury.
This symbol indicates a hazardous situation that, if
not avoided, could result in serious injury or death.
This symbol indicates a hazardous situation that, if
not avoided, will result in serious injury or death.
This symbol is used for instruction on operating,
adjusting, or servicing a machine.
(Yellow)
(Orange)
(Red)
(Green or Black)
THINK SAFETY!
REMEMBER
4
PATENT
APPLIED FOR
SAFETY DECALS
56-050-011
56-050-035
5
SAFETY PROCEDURES
PLEASE
2. Do not permit anyone to ride on the machine at any time.
and must be suitable to performing its task.)
in operation.
5. Do not allow children to operate the Stalk Shredder Puller. Only experienced
tractor operators should operate the tractor when using the Stalk Shredder Puller.
other parts.
machine to the KMC dealer from which it was purchased. Warranty repairs should be
submitted to the dealer within thirty (30) days of failure.
for by the retail customer. Any arrangement whereby the dealer agrees to absorb all or
part of this cost is strictly between the dealer and the retail customer.
6
(Maximum
speed of implement should never exceed 20 MPH on higher capacity highways and
should never exceed 10 MPH on lower capacity roads.)
7. Make sure hitch components are attached securely before operating or transporting.
by following the Safe Stop Procedure:
1. Handbrake/Footbrake on
2. Controls in Neutral/Park
3. Engine off
4. Key out
machine.
HIGH VOLTAGE SAFETY ACT
Utilities Protection Center (UPC) by
telephone at least 72 hours before commencing the work.
8111-800-282-7411http://
gadistrictupc.com.
Please contact your local power company in reference to their laws and regulations before
7
CUSTOMER OPERATION
WARNING
Before operating the implement, refer to the tractor’s Owner’s Manual for information
concerning safe methods of operation, hydraulics, hitch adjustment, tire inflation, wheel
adjustments, and tractor weights.
TRACTOR PREPARATION:
Please check the tractor’s brakes and warning lights in order to make sure they are in proper
working order. Please check the tractor hydraulics oil reservoir and add oil if needed.
Use front-end weights as needed to provide effective steering control and front-end stability. See
your tractor Owner’s Manual for recommendations on ballasting procedures.
Front End Weights:
The power requirement for this unit is 200HP (minimum), depending on the depth of
penetration and ground conditions. Select a tractor with sufficient power to operate and lift this
implement.
Horse Power Requirements:
Sway blocks should be used and adjusted to allow movement in operating position. This allows
the pullers to automatically track on the rows. Your implement should be permitted to sway
some while operating and should only be held rigid while transporting. Please refer to your
tractor Owner’s Manual.
Sway Blocks:
Set tractor wheels so they are equally spaced from the center of the tractor. If using the tool to
penetrate in fields for row crops, set tractor wheels so they are centered between the rows.
Please see your tractor Owner’s Manual for correct tire inflation pressure.
Wheel Spacing:
Remove or move the drawbar to one side to prevent driveline damage.
Drawbar Position:
Transporting the implement will add significant weight to your
tractor. Make sure the tractor is properly ballasted! DO NOT
EXCEED THE TRACTOR’S LIFT CAPACITY OR BALLAST
RECOMMENDATIONS!
8
18
C
L
54
36
4-Row 36” Stalk Shredder Puller
38
19
C
L
57
4-Row 38” Stalk Shredder Puller
10
40
60
C
L
20
4-Row 40” Stalk Shredder Puller
11
6-Row 36” Stalk Shredder Puller
72
90
54
C
L
18
12
6-Row 38” Stalk Shredder Puller
19
C
L
57
95
76
13
6-Row 40” Stalk Shredder Puller
80
100
60
C
L
20
14
C
L
36" ROW SPACING
38-40" ROW SPACING
36" ROW SPACING
38" ROW SPACING
40" ROW SPACING
36" ROW SPACING
38" ROW SPACING
40" ROW SPACING
36" ROW SPACING
38" ROW SPACING
40" ROW SPACING
DIVERTER
DIVERTER
DIVERTER
GAUGE WHEEL
Adjusting Row Spacing
NOTE: DIVERTERS
AND GUAGE
WHEELS MUST BE
MOVED TO ADJUST
ROW SPACING
C
L
36" ROW SPACING
38"-40" ROW SPACING
36" ROW SPACING
38" ROW SPACING
40" ROW SPACING
36" ROW SPACING
38" ROW SPACING
40" ROW SPACING
DIVERTER DIVERTER
ROW SPACING FOR
6-ROW IMPLEMENT
ROW SPACING FOR
4-ROW IMPLEMENT
15
Extra Hitch Bushings
Stored Here
UNPACKING & SETUP
The KMC Stalk Puller is shipped with all crumbler arms rotated upward. The springs holding the
arms in place will be constrained or taken off when shipping. Once the KMC Stalk Puller has been
original operating position. The springs can then be released of their restraints and placed back on the
implement.
on the pullers to disturb less soil. Front gauge wheels are a standard feature which can be utilized for a
Models:
•
•
•
•
•
•
SPECIFICATIONS
Other manuals for 56 Series
1
This manual suits for next models
1
Table of contents
Other KMC Controls Farm Equipment manuals
KMC Controls
KMC Controls 67 Series User manual
KMC Controls
KMC Controls 64 Series User manual
KMC Controls
KMC Controls 33 Series User manual
KMC Controls
KMC Controls 69 Series User manual
KMC Controls
KMC Controls 68 Series User manual
KMC Controls
KMC Controls 61 Series User manual
KMC Controls
KMC Controls 21 Series User manual
KMC Controls
KMC Controls 33 Series User manual
KMC Controls
KMC Controls 74 Series User manual
KMC Controls
KMC Controls 30 Series User manual
Popular Farm Equipment manuals by other brands
Kemper
Kemper 330 Series Operator's manual
Wiedenmann
Wiedenmann Terra Rake 460 Translation of original operating instructions
ABI Attachments
ABI Attachments TR35.5 Setup guide
Snapper
Snapper K50 Service manual
Dawn
Dawn 5036 Assembly and operation manual
Finn
Finn HydroSeeder TITAN280 Operator Instructions And Parts Manual
Alltech
Alltech KEENAN MechFiber345 Operator's manual
breviglieri
breviglieri B123 Series Operating and maintenance manual
Farmi Forest Corporation
Farmi Forest Corporation 90 OPERATION, MAINTENANCE AND SPARE PARTS MANUAL
Festool
Festool TSC 55 REB Original operating manual
Degelman
Degelman Signature 6000 manual
LEMKEN
LEMKEN Solitair 10 K operating instructions
