CASH®Small Animal Tool
Original Instruction Manual
DO NOT ATTEMPT TO USE THESE STUNNING TOOLS UNTIL
YOU HAVE READ AND UNDERSTAND THESE INSTRUCTIONS
©2016 Accles & Shelvoke Ltd

P2
SECTION DESCRIPTION PAGES
CONTENTS 2
1PRODUCT DESCRIPTION 3
2PRODUCT SPECIFICATION 4
3PRODUCT DIAGRAM 5
4ANIMAL WELFARE 6
5EFFECTIVE KILLING & CARTRIDGE SELECTION 7
6GENERAL SAFETY PRECAUTIONS 13
7SAFE OPERATING INSTRUCTIONS 17
8CLEANING & GENERAL MAINTENANCE 19
9TROUBLESHOOTING 21
10 SERVICING 23
11 SPARE PARTS LIST AND DIAGRAM 24
12 CONTACT DETAILS, WARRANTY AND RECYCLING 25
DECLARATION OF CONFORMITY CERTIFICATE 26
DISCLAIMER
This instruction manual is correct at the time of printing. However, because our policy is one of
constant development and improvement, details and images may vary slightly from those provided
in this publication.
©Copyright of Accles & Shelvoke Ltd 2016 - All rights reserved
“Accles & Shelvoke”, “CASH”, and “CASH Small Animal Tool” are all trademarks of Accles & Shelvoke Ltd
ONLY EVER USE GENUINE ACCLES & SHELVOKE REPLACEMENT PARTS. NOT USING
GENUINE PARTS MAY LEAD TO PREMATURE COMPONENT AND TOOL FAILURE, WHICH
COULD ENDANGER THE OPERATOR AND THOSE IN THE IMMEDIATE VICINITY. IT WILL
ALSO INVALIDATE OUR ORIGINAL EQUIPMENT WARRANTY.
ACCLES & SHELVOKE WILL ACCEPT NO LIABILITY IF ANY COMPONENTS OTHER THAN
THOSE SUPPLIED BY ACCLES & SHELVOKE ARE USED WITH OUR ORIGINAL EQUIPMENT.
THE RESULTANT LIABILITY WILL BE WITH THE END USER OR THE DISTRIBUTOR WHO
SUPPLIED THE UNAPPROVED REPLACEMENT PARTS.
CASH®Small Animal Tool
CONTENTS
Accles & Shelvoke Ltd Instruction manual - PART No. CPK110 V2.9
©

The CASH Small Animal Tool is a cartridge powered, trigger operated, concussive, cylindrical style tool
with automatic bolt return. It is available in .22” calibre and is designed for use on small animals such as
piglets, kids, lambs and poultry. These tools are intended for professional use.
CASH®Small Animal Tool
PRODUCT DESCRIPTION
P3
The CASH Small Animal Tool is a captive bolt device which kills the target animal by means of a blow
to the head (and brain). These tools are designed to kill all designated animals in accordance with EU
Council Regulation (EC) number 1099/2009 On the Protection of Animals at the Time of Killing.
The CASH Small Animal Tool has been on the market for many years, and in that time has earned a
reputation for being a reliable and effective tool.
To ensure the safety of the operator, and quality of products, all Accles & Shelvoke
tools are proof tested in accordance with the Rules of Proof 2006. We have several
‘assistant proof masters’ who are accredited by the British Proof House (formerly
the Birmingham Proof House, www.gunproof .com). We work to standards set by the
Commission Internationale Permanente pour l’Epreuve des Armes á Feu Portatives
(CIP). All tools are “Proofed” prior to being released to customers. Proofed
components are stamped with the mark of the British Proof House, so that users can
be assured of the quality and safety of the product.
7KHWRROKDVEHHQGHVLJQHGWREHHDV\WRXVHE\LPSOHPHQWLQJDSDOPÀQJHUWULJJHU
SECTION 1
PRODUCT PRODUCT
CODE PRODUCT DESCRIPTION CALIBRE
MAXIMUM
PERMITTED
CARTRIDGE
CASH Small
Animal Tool CPK200 CASH Small Animal Tool 0.22 1 GRAIN ( .22 BROWN )
©

P4
ATTRIBUTE STUNNER MODEL NUMBER
CPK200
Length (mm) 315
Width (mm)
(At Widest Point) 50
Weight (kg) * 1.5kg
‘A’ weighted Sound Pressure
Level at workstation (dB) 83
‘A’ weighted Sound
Power Level (dB) 77
‘C’ weighted Peak
emissions (dB) 119
Calibre .22
Chamber Straight
CASH®Small Animal Tool
PRODUCT SPECIFICATION
* Rounded to 1decimal place.
Sound values determined according to EN 15895 using EN ISO 3744, using the maximum rated
cartridge for a given tool. Tests conducted using simulated load (paper sheets and plasticine).
The A-weighted sound pressure level and A-weighted sound power level have been calculated - and are
hence valid – at the maximum number of driving processes in one second.
The maximum number of driving processes in the CASH Small Animal Tool is one per second.
This applies to all of the tools in the range included in this instruction manual.
Information about vibrations
EN15895 states - for cartridge operated hand tools, the vibration total value to which the hand-arm
system is subjected does not exceed 2.5m/s². The generated mechanical recoil that is transmitted into
the hand and arm of the operator is not considered to be a vibration.
SECTION 2
©

CASH®Small Animal Tool
PRODUCT DIAGRAM
P5
NEVER POINT THE MUZZLE END
OF THE STUNNING TOOL AT
YOURSELF OR ANY OTHER PERSON
SECTION 3
CASH SMALL ANIMAL TOOL
Fig. 3.01
NEVER USE A MORE POWERFUL
CARTRIDGE THAN THE MAXIMUM
PERMITTED CARTRIDGE AS STAMPED
ON YOUR STUNNING TOOL
©2016 Accles & Shelvoke
©
BREECH
TRIGGER
'HSUHVVWRÀUHWRRO
FIRING PIN PULL
* NOTE - Every tool in the CASH range is stamped with the
maximum permitted (PROOF) cartridge, showing the maximum
grains (GRN) that should be used.
THE MAXIMUM GRAINS (GRN) AND
SERIAL NUMBER OF THE TOOL CAN BE
FOUND ENGRAVED ON THE BARREL
OF THE STUNNER
# CONCUSSION
HEAD (CONVEX)
BARREL
MUZZLE
BREECH CAP
# NOTE - THE SMALL ANIMAL TOOL IS SUPPLIED WITH 2 CONCUSSION HEADS:-
- CONVEX HEAD FOR LARGE POULTRY AND QUADRUPEDS
- FLAT HEAD FOR SMALL POULTRY
DANGER ZONE
UP TO 50MM

P6
CASH®Small Animal Tool
ANIMAL WELFARE
Improving the protection of animals at the time of slaughter contributes to higher meat quality.
EU Only - in accordance with EU Council Regulation (EC) Number 1099/2009 on the protection of
animals at the time of killing, animals must be spared any avoidable pain, distress or suffering during their
killing and related operations.
Business operators shall in particular take the necessary measures to ensure that animals:
(a) Are provided with physical comfort and protection, in particular by being kept clean,
in adequate thermal conditions and prevented from falling or slipping;
(b) Are protected from injury;
(c) Are handled and housed taking into consideration their normal behaviour;
(d) Do not show signs of avoidable pain or fear or exhibit abnormal behaviour;
(e) Do not suffer from prolonged withdrawal of feed or water;
(f) Are prevented from avoidable interaction with other animals that could harm their welfare.
In addition:
Avoid excessive light and noise at the area to keep animal stress to a minimum.
The operator should not have to concentrate on keeping his balance, or have to bend excessively
each time the tool is used, as this becomes tiring and can lead to inaccurate shot placement.
7KHHIÀFLHQF\RIHDFKWRROLVHVVHQWLDOWRHQVXULQJDQHIIHFWLYHNLOO(QVXUHFOHDQLQJDQG 
maintenance schedules detailed within this Instruction Manual are adhered to.
Always ensure there is another (second) means to deliver an effective kill to the target animal.
NOTE - we always advise you refer to any local regulations in force.
SECTION 4
©

This section provides a guide to the correct stunning position and direction for certain animals, and
helps you to select the correct cartridge for that animal. The cartridge selection information provided
within this section of this instruction manual is not categorical and is hence supplied as guidance only.
GOOD PRACTISE
Understand animal welfare – refer to the Animal Welfare section for further guidance
Always ensure your CASH Small Animal Tool is in good working order
Tools should be cleaned and maintained in the accordance with the instructions within this manual
Ensure there is another (second) means to deliver an effective stun or kill to the target animal
Tools will require more maintenance if used with cartridges that are more powerful than is
necessary for the target animal
EFFECTIVE KILLING
The blow being applied to the correct part of the skull and in the right direction is important in ensuring
an effective kill shot. The tool will crush the skull and the operator can be assured that death will follow.
Refer to the diagrams and selection charts within this section for guidance. To obtain maximum effect,
WKHPX]]OHRIWKH&$6+6PDOO$QLPDO7RROPXVWDOZD\VEHKHOGÀUPO\DJDLQVWWKHKHDG
The Physical Signs of an Effective kill are:
Quadrupeds
Animal collapses
No rhythmic breathing
Fixed, glazed expression in the eyes
1RFRUQHDOUHÁH[
Relaxed jaw
Tongue hanging loose
FAILURE TO KILL
If the target animal is not killed after the shot is applied, it should be immediately killed by an
alternative method.
CASH®Small Animal Tool
EFFECTIVE KILLING AND
CARTRIDGE SELECTION
P7
Poultry
8QFRQWUROOHGVHYHUHZLQJÁDSSLQJ
No rhythmic breathing immediately after stun
No control over neck movement
/HJÁH[LRQDQGH[WHQVLRQ
Fixed, glazed expression in the eyes
SECTION 5
©

PIGLETS
CORRECT TOOL POSITION
P8
CASH®Small Animal Tool
EFFECTIVE KILLING AND
CARTRIDGE SELECTION
SECTION 5
SUGGESTED TOOLS AND CARTRIDGES
.22” RANGE
CASH SMALL ANIMAL TOOL
(CPK200)
PIGLETS BROWN
WEANERS
& GROWERS BROWN
MARKET PIGS N/S
HEAVY ANIMALS N/S
HEAVY SOWS &
BOARS N/S
N/S - NOT SUITABLE FOR DENOTED ANIMAL SIZE
Fig. 5.01
©
NOTE - ALIGN TOOL AS INDICATED BY THE BLACK ARROW,
CENTRALLY ON THE TARGET ANIMAL’S HEAD
©2016 Accles & Shelvoke

CASH®Small Animal Tool
EFFECTIVE KILLING AND
CARTRIDGE SELECTION
P9
SECTION 5
©
SUGGESTED TOOLS AND CARTRIDGES
.22” RANGE
CASH SMALL ANIMAL TOOL
(CPK200)
LAMBS & KIDS BROWN
EWES N/S
RAMS N/S
GOATS N/S
N/S - NOT SUITABLE FOR DENOTED ANIMAL SIZE
LAMBS
CORRECT TOOL POSITION
Fig. 5.02 Fig. 5.03
KIDS
NOTE - ALIGN TOOL AS INDICATED BY THE BLACK ARROW,
CENTRALLY ON THE TARGET ANIMAL’S HEAD
PUSH CHIN
INTO CHEST
©2016 Accles & Shelvoke ©2016 Accles & Shelvoke

P10
CASH®Small Animal Tool
EFFECTIVE KILLING AND
CARTRIDGE SELECTION
SECTION 5
©
SUGGESTED TOOLS AND CARTRIDGES
.22” RANGE
CASH SMALL ANIMAL TOOL
(CPK200)
POULTRY BROWN
POULTRY
CORRECT TOOL POSITION
Fig. 5.04
©2016 Accles & Shelvoke
