ACCO Brands Pinnacle 27 User manual

Pinnacle 27/27 EZload
Laminator
INSTALLATION & OPERATION MANUAL
Document Number: CBT10000 Rev B
Do not duplicate without written permission from ACCO Brands

ACCO Brands reserves the right to make changes to this publication and to the products described in it without
notice. All specifications and information concerning products are subject to change without notice. Reference
in this publication to information or products protected by copyright or patent does not convey any license
under the rights of ACCO Brands or others assumes no liability arising from infringements of patents or any
other rights of third parties.
This publication is copyrighted © 2016 by ACCO Brands. All rights reserved.

1. Safety
YOUR SAFETY, AS WELL AS THE SAFETY OF OTHERS IS
IMPORTANT TO GBC. IN THIS INSTRUCTION
MANUAL AND ON THE PRODUCT ARE IMPORTANT
SAFETY MESSAGES. BEFORE YOU INSTALL OR USE
THE MACHINE, READ AND FOLLOW ALL THE SAFETY
NOTICES CAREFULLY IN THIS CHAPTER.
Observe all the safety information provided.
Observe all safety warnings. Never remove safety
warnings or other information from the equipment.
Read all of the instructions and save these
instructions for further use.
The safety alert symbol precedes each safety
notice in this manual. The symbol indicates a
potential personal safety hazard to you or others, as
well as cause product damage or property damage.
This safety alert symbol indicates a potential
electrical shock. It warns you not to open the paper
cutter and expose yourself to hazardous voltage.
THE FOLLOWING WARNINGS ARE FOUND ON THE
ULTIMA 65 LAMINATOR.
This means you can be seariously hurt or killed if you
open the product and expose yourself to hazardous
voltage.
Do not open. No user servicable parts insides. Refer
servicing to qualitfied service personal.
CAUTION Hot Surface: Laminator
rollers can be in excess of 260° Fahrenheit.
Please use caution and do not touch the rollers.
Caution Moving Parts: Laminator
rollers are moving parts, please keep body parts
away from the rollers as they can be trapped
and/or crushed in rollers. Clothing, Jewelry, Long
hair and other wearables could be caught in roller
path and pull you into the
Caution Sharp Point: The laminator
trimmer has a sharp blade. Do not touch the
blade portion of the trimmer and use caution
when operating to prevent injury.
WARNING: Do not attempt to service or
repair the laminator.
WARNING: do not connect the laminator
to an electrical supply or attempt to operate the
laminator until you have completely read these
instructions. Maintain these instructions in a
convenient location for future reference.
General safeguards
•Use this laminator only for its intended
purposes as according to the
specifications outlined in the operating
instructions.
•Keep hands, long hair, loose clothing and
articles such as necklaces or ties away
from the front of the rollers to avoid
entanglement and entrapment.
•Avoid contact with the rollers during
operation or shortly after the laminator
has been turned off. The rollers can
reach temperatures in excess of 300ºF.

•Keep hands and fingers away from the path of
the sharp film cutter blade located at the film
exit.
Do not place the laminator on an unstable
cart, stand or table. An unstable surface may
cause the laminator to fall resulting in serious
bodily injury. Avoid quick stops, excessive
force and uneven floor surfaces when moving
the laminator on a cart or stand.
•Do not defeat or remove electrical and
mechanical safety equipment such as
interlocks, shields and guards.
•Do not insert objects unsuitable for
lamination.
•Do not expose laminator to liquids.
Electrical Safeguards
•The equipment should be connected to an
easily accessible and grounded (3-pin)
receptacle (socket outlet) near the
equipment.
•This laminator must be connected to a supply
voltage corresponding to the electrical rating
as indicated on the serial plate located on the
rear of the machine.
•Unplug the laminator before moving it, or
when it is not in use for an extended period
of time.
•Do not operate the laminator with a damaged
power supply cord or plug.
•Do not overload electrical outlets as this can
result in fire or shock.
•Do not alter the attachment plug. This plug is
configured for the appropriate electrical
supply.
•The unit is intended for indoor use only.
CAUTION: The receptacle must be
located near the equipment and easily
accessible. Do not use an extension cord.
•Disconnect the attachment plug from the
receptacle to which it is connected and keep
the power supply cord in your possession
while moving the laminator.
•Do not operate the laminator with a damaged
power supply cord or attachment plug, upon
occurrence of a malfunction, or after
laminator has been damaged. Contact an
authorized GBC service representative for
assistance.
GBC Technical Service
To order replacement accessories, service, parts,
or an Equipment Maintenance Agreement, please
contact GBC Technical Service and Support at:
United States
ACCO Brands GBC Technical Service and Support
4 Corporate Drive Lake Zurich, IL 60047-8997
1-800-723-4000
www.gbcconnect.com
Canada
Ontario and Quebec –1-800-268-3310
All other Provinces –1-800-268-3447
Local 905-595-3100
[e-mail]
Mexico
Circuito de la industria norte
No. 6 corredor industrial
Toluca Lerma, Lerma, México
C.P. 52004 R.F.C. AME640229-1W3
En México llame al 01 800 759.6825
Desde el extranjero 52.72.2265.65.01
www.accomexico.com
This equipment is not suitable for use in
locations where children are likely to be
present

2. Warranty
Limited 1 Year Labor Warranty; USA, Mexico, and
Canada
ACCO Brands USA LLC, ACCO Brands, 4 Corporate
Drive, Lake Zurich, IL 60047 (in Mexico, ACCO Brands
Mexicana, Neptuno 43, Fraccionamiento Nueva
Industrial Vallejo México 07700 D.F. México), (in
Canada, ACCO Brands Canada Inc., 7381 Bramalea
Road, Mississauga ON L5S1C4) (each, respectively,
“ACCO Brands”) warrants to the original purchaser
that this ACCO Brands product is free from defects in
workmanship and material under normal use and
service for a period of: one (1) year for parts and labor
after purchase.
ACCO Brands’ obligation under this warranty is limited
to replacement or repair, at ACCO Brands’ option, of
any warranted part found defective by ACCO Brands
without charge for material or labor. Any replacement,
at ACCO Brands’ option, may be the same product or a
substantially similar product that may contain
remanufactured or refurbished parts. This warranty
shall be void in the following circumstances:
(i) if the product has been improperly installed or
misused,
(ii) if the product has been damaged by negligence or
accident, or
(iii) if the product has been altered by anyone other
than ACCO Brands or ACCO Brands’ authorized agents.
Without limiting the generality of the previous
paragraph, ACCO Brands’ obligation under this limited
warranty does not include:
(iiii) damage caused to the rollers by knives, razors, or
other sharp tools; by any foreign objects falling into
the working area of the laminator; or by cleaning the
laminator with solutions or materials that harm its
surfaces;
For warranty execution, please contact ACCO Brands
at: 800-723-4000 or www.gbcconnect.com in the USA
905-595-3100 or www.gbccanada.com in Canada (55)
52.72.2265.65.01 or www.accomexico.com in Mexico
TO THE EXTENT ALLOWED BY APPLICABLE LAW,
THIS WARRANTY IS IN LIEU OF ALL OTHER
EXPRESSED WARRANTIES. REPRESENTATIONS OR
PROMISES INCONSISTENT WITH OR IN ADDITION
TO THIS WARRANTY ARE UNAUTHORIZED AND
SHALL NOT BE BINDING ON ACCO BRANDS. TO
THE EXTENT PERMITTED BY APPLICABLE LAWS,
ANY IMPLIED WARRANTIES (IF APPLICABLE) ARE
LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY. SOME STATES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION MAY NOT APPLY TO
YOU. TO THE EXTENT PERMITTED BY APPLICABLE
LAW, IN NO EVENT SHALL ACCO BRANDS BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, PUNITIVE,
EXEMPLARY, CONSEQUENTIAL OR SIMILAR
DAMAGES, WHETHER OR NOT FORESEEABLE.
SOME STATES AND JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF
SPECIAL, INCIDENTAL, PUNITIVE, EXEMPLARY,
CONSEQUENTIAL, OR SIMILAR DAMAGES, SO THE
ABOVE EXCLUSION OR LIMITATION MAY NOT
APPLY TO YOU.
FOR CONSUMERS WHO HAVE THE BENEFIT OF
CONSUMER PROTECTION LAWS OR
REGULATIONS IN THEIR JURISDICTION OF
PURCHASE OR, IF DIFFERENT, IN THEIR
JURISDICTION OF RESIDENCE, THE BENEFITS
CONFERRED BY THIS WARRANTY ARE IN
ADDITION TO ALL RIGHTS AND REMEDIES
CONVEYED BY SUCH CONSUMER PROTECTION
LAWS AND REGULATIONS.
To the extent permitted by law, this warranty is
not transferable and will automatically terminate
if the original product purchaser sells or
otherwise disposes of the product.
This warranty gives you specific legal rights. Other
rights, which vary from jurisdiction to jurisdiction,
may exist. In addition some jurisdictions do not
allow (i) the exclusion of certain warranties, (ii)
limitations on how long an implied warranty lasts
and/or (iii) the exclusion or limitation of certain
types of costs and/ or damages, so the above
limitations may not apply.
