Contents
Introduction ........................................................................................................................ 1
Chapter 1: Your New System .............................................................................................. 3
Chapter 2: Blood Glucose Tests ........................................................................................... 7
Chapter 3: Meter Memory, Setup, and Data Transfer ......................................................... 15
Chapter 4: Control Tests .................................................................................................... 25
Chapter 5: Maintenance and Troubleshooting ................................................................... 29
Chapter 6: Technical Information ...................................................................................... 35
Chapter 7: The Accu-Chek FastClix Finger Pricker ............................................................ 41
Index ................................................................................................................................ 48
This file may not print or view at 100%.
Die lines and color breaks do not print.
“Holding Area” text, box and rules do not print.
Roche USA – 53134
V2/1 – 07019505001(02) – Black
Roche USA – 53134
V2/2 – 07019505001(02) – PMS 287 CVC 30%
53134_07019505001_02.indb 2 1/5/15 10:49 AM

1
Introduction
The Accu-Chek Aviva System
The Accu-Chek Aviva meter is designed to be used with the Accu-Chek Aviva test strip to quantitatively
measure glucose in fresh venous, arterial, neonatal, and capillary whole blood as an aid in monitoring the
eectiveness of glucose control. Capillary whole blood for testing of blood glucose can be obtained from
fingertip and approved alternative sites (for example, forearm). Refer to the Alternative Site Testing (AST)
section of this manual for approved alternative sites and associated limitations. The Accu-Chek Aviva meter
with the Accu-Chek Aviva test strips provide a complete test system that is meant for in vitro diagnostic use
by people with diabetes at home. The system is not for use in diagnosis or screening of diabetes mellitus.
Healthcare professional blood sample collection and preparation is described in the test strip package insert.
For use only with the Accu-Chek Aviva test strips and control solutions.
Suitable for self-testing.
The system includes:
• Accu-Chek Aviva meter with battery
• Accu-Chek Aviva test strips*
• Accu-Chek Aviva control solutions*
*Some items may not be included in the kit. They are a separate purchase.
53134_07019505001_02.indb 1 1/5/15 10:49 AM

2
Introduction
w WARNING
The Accu-Chek FastClix finger pricker is intended for patient self-monitoring by an individual person
only. It must not be used to collect blood from more than one person as it does not incorporate any
features to guard against cross-infection.
w WARNING
Any object coming into contact with human blood is a potential source of infection (see: Clinical and
Laboratory Standards Institute: Protection of Laboratory Workers from Occupationally Acquired
Infections; Approved Guideline – Third Edition; CLSI document M29-A3, 2005).
Why Regular Blood Glucose Testing Is Important
Testing your blood glucose regularly can make a big dierence in how you manage your diabetes every day.
We have made it as simple as possible.
Important Information About Your New Meter
• The meter comes with a preset time and date. You may need to change the time to your time zone.
• If you follow the steps in this manual but still have symptoms that do not seem to match your test results,
or if you have questions, talk to your healthcare professional.
53134_07019505001_02.indb 2 1/5/15 10:49 AM

3
Your New System 1
1. Power/Set Button
Turns meter on or o and sets options.
2. Display
Shows results, messages, and test results stored
in memory.
3. Right Arrow and Left Arrow Buttons
Press to enter memory, adjust settings, and
scroll through test results.
4. Test Strip Slot
Insert test strip here.
5. Battery Door
6. Infrared (IR) Window
Transfers data from meter to computer.
The Accu-Chek Aviva Meter
1
2
5
3
16
4
53134_07019505001_02.indb 3 1/5/15 10:49 AM

4
Your New System
1
7
9
10
7. Test Strip Container*
8. Insert this end into meter.
9. Yellow Window
Touch blood drop or control solution here.
10. Control Solution Bottle*
11. Battery
(for example)
11
*Some items may not be included in the kit. They are a separate purchase.
8
53134_07019505001_02.indb 4 1/5/15 10:49 AM

5
Your New System 1
Using the Accu-Chek Aviva System
• Use only Accu-Chek Aviva test strips.
• Use the test strip immediately after removing it from the test strip container.
• Do not apply blood or control solution to the test strip before inserting it into the meter.
• Close the test strip container tightly immediately after removing a test strip to protect the test strips from
humidity.
• Store the unused test strips in their original test strip container with the cap closed.
• Check the use by date on the test strip container. Do not use the test strips after that date.
• Store the test strip container and meter in a cool, dry place such as a bedroom.
• Refer to the test strip package insert for test strip storage and system operating conditions.
w WARNING
Do not store test strips in high heat and moisture areas (bathroom or kitchen)! Heat and moisture can
damage test strips.
53134_07019505001_02.indb 5 1/5/15 10:49 AM

6
Your New System
1
Button Functions
Here are the functions of the power/set and arrow buttons on the meter. These functions are used
throughout this manual. For more information on using these buttons during meter setup, see Chapter 3,
Meter Memory, Setup, and Data Transfer.
Button Function Action
(power/set
button)
Turn the meter on or o. Press and release .
Enter the set-up mode. Turn the meter on. Press and hold until set-up
appears on the display.
Set the chosen feature. Press and release .
Exit the set-up mode at any time. Press and hold until the flashing test strip
symbol appears on the display.
Check the display segments. Turn the meter o. Press and hold to see the
complete display.
If one of the segments is missing or looks dierent
from the picture, do not use the meter. Contact
the Accu-Chek Customer Careline on
0800 701 000 (UK) or 1 800 709 600 (ROI).
(right arrow
and left
arrow
buttons)
Adjust settings for time and date,
beeper, test reminders, and
hypoglycaemic alert.
Press and release or .
Press and hold or to scroll faster.
Enter memory. Press and release or .
Mark a blood glucose result. Press and release or .
53134_07019505001_02.indb 6 1/5/15 10:49 AM

7
Blood Glucose Tests 2
w WARNING
Blood glucose results can be displayed in either
mg/dL or mmol/L. The back label of the meter
shows the unit of measurement. If the meter
shows the wrong unit, contact the Accu-Chek
Customer Careline on 0800 701 000 (UK) or
1 800 709 600 (ROI). If you do not know which
unit of measurement is correct for you, contact
your healthcare professional. Using the wrong
unit of measurement may cause
misinterpretation of your actual blood glucose
level and may lead to improper therapy.
Performing a Blood Glucose Test with Blood from Your Fingertip
NOTE
Blood samples taken from the palm are equivalent to blood samples taken from the fingertip. To
receive Alternative Site Testing (AST) instructions and an AST cap for obtaining blood from the palm,
contact the Accu-Chek Customer Careline on 0800 701 000 (UK) or 1 800 709 600 (ROI).
mg/dL or mmol/L
is printed here
53134_07019505001_02.indb 7 1/5/15 10:49 AM

8
Blood Glucose Tests
2
Before you perform your first blood glucose test, set up the meter correctly. You need the meter, a test strip,
a finger pricker, and a lancet.
1
Wash and dry your hands.
2
Prepare the finger pricker.
See Chapter 7, The
Accu-Chek FastClix Finger
Pricker.
3
Check the use by date on
the test strip container.
Do not use test strips
past the use by date.
4
Insert the test strip into
the meter in the direction
of the arrows.
The meter turns on and
beeps.
5
When the blood drop
symbol flashes, obtain a
blood sample with the aid
of a finger pricker.
6
With your hand facing
downwards, gently
squeeze your finger to
assist the blood flow.
This helps you get a
blood drop.
7
Touch the blood drop to the front edge of the yellow
window of the test strip.
Do not put blood on top of the test strip.
The meter beeps and flashes when there is enough
blood in the test strip.
53134_07019505001_02.indb 8 1/5/15 10:49 AM

9
Blood Glucose Tests 2
8
The test result appears on the display.
To assign a marker to the test result, leave the test
strip in the meter. See Chapter2, Marking Blood
Glucose Results and Setting the Post-Meal Test
Reminder.
Otherwise, remove and discard the used test strip.
After a successful test, the meter turns itself o
5seconds after the test strip is removed.
53134_07019505001_02.indb 9 1/5/15 10:49 AM

10
Blood Glucose Tests
2
Performing a Blood Glucose Test with Blood from Your Palm, Forearm, or Upper
Arm (Alternative Site Testing)
You have the option of obtaining a blood sample from other sites on your body besides the fingertip.
Alternative sites include the palm, forearm, and upper arm.
Blood obtained from the fingertip can be used at any time to perform a blood glucose test.
If blood from the palm, forearm, or upper arm is used, there are certain times when testing is not
appropriate. This is because your blood glucose level changes faster in your fingertip than in the palm,
forearm, and upper arm. These dierences may cause you to misinterpret your actual blood glucose level,
leading to improper therapy and potential adverse health eects.
Read the next section before you try testing from the palm, forearm, or upper arm.
53134_07019505001_02.indb 10 1/5/15 10:49 AM

11
Blood Glucose Tests 2
w WARNING
Do not change your therapy because of just one blood glucose result.
NEVER ignore symptoms of low or high blood glucose.
If your blood glucose result does not match how you feel, perform a fingertip or palm* test to
confirm your test result. If the fingertip or palm test result still does not match how you feel,
contact your healthcare professional.
You may perform
a palm, forearm,
or upper arm test
• immediately before a meal.
• while fasting.
You may NOT
perform a palm,
forearm, or upper
arm test
• up to 2hours following a meal, when blood glucose values can rise quickly.
• after injecting bolus insulin, when blood glucose values can decrease rapidly.
• after exercise.
• if you are sick.
• if you think your blood glucose is low (hypoglycaemia).
• if you are sometimes unaware of your blood glucose being low.
If you are interested in AST, talk to your healthcare professional first.
*For samples from the palm you will need an AST converter cap, which can be obtained by contacting the
Accu-Chek Customer Careline on 0800 701 000 (UK) or 1 800 709 600 (ROI).
53134_07019505001_02.indb 11 1/5/15 10:49 AM

12
Blood Glucose Tests
2
Symbol Function
Pre-Meal Marker
Marking blood glucose results with a pre-meal marker provides more information about
your test results to help you and your healthcare professional in the management of
your diabetes.
Pre-Meal Marker with Post-Meal Test Reminder
When a pre-meal result is marked with a post-meal test reminder, the meter beeps 1 or
2hours after you test to remind you to do a post-meal test.
Post-Meal Marker
Marking blood glucose results with a post-meal marker provides more information
about your test results to help you and your healthcare professional in the management
of your diabetes. The post-meal marker automatically appears with the test result if a
test is performed 15minutes before or after the post-meal test reminder is
programmed to beep. Set the post-meal test reminder time to 1 or 2hours in the
set-up mode. The meter will beep 1 or 2hours after the pre-meal test to remind you to
do a post-meal test.
General Marker
You might want to use the general marker to mark an event such as an AST result or
exercise.
Marking Blood Glucose Results and Setting the Post-Meal Test Reminder
You can mark a blood glucose result to indicate a special event. If you select a test result marker, it is
automatically stored in memory. When you review the test results in memory, these markers can help you
remember what was dierent about the test result.
53134_07019505001_02.indb 12 1/5/15 10:49 AM

13
Blood Glucose Tests 2
Here is how to mark a test result and initiate a post-meal test reminder:
1. Perform a blood glucose test. The blood glucose result appears on the display.
2. Leave the test strip in the meter. Press and release or to toggle through the test result markers and
post-meal test reminder.
3. When the marker or test reminder that you wish to select appears on the display, remove the test strip
from the meter.
Unusual Blood Glucose Results
If your blood glucose result does not match how you feel, check this list to help solve the problem.
Troubleshooting Checks Action
1. Have the test strips expired? Discard the test strips if they are past the use by date.
Repeat the blood glucose test with an unexpired test
strip.
2. Was the cap on the test strip container
closed tightly?
Replace the test strips if you think the test strip
container was uncapped for some time. Repeat the
blood glucose test.
3. Was the test strip used immediately after it
was removed from the test strip container?
Repeat the blood glucose test with a new test strip.
4. Were the test strips stored in a cool, dry
place?
Repeat the blood glucose test with a properly stored
test strip.
5. Did you follow the directions? See Chapter 2, Blood Glucose Tests, and repeat the
blood glucose test. Contact the Accu-Chek Customer
Careline on 0800 701 000 (UK) or
1 800 709 600 (ROI) if you still have problems.
6. Are the meter and test strips working
properly?
Perform a control test. See Chapter 4, Performing a
Control Test, for instructions.
7. Are you still unsure of the problem? Contact the Accu-Chek Customer Careline on
0800 701 000 (UK) or 1 800 709 600 (ROI).
53134_07019505001_02.indb 13 1/5/15 10:49 AM

14
Blood Glucose Tests
2
Symptoms of Low or High Blood Glucose
Being aware of the symptoms of low or high blood glucose can help you understand your test results and
decide what to do if they seem unusual.
Low blood glucose (hypoglycaemia): Symptoms of hypoglycaemia may include, but are not limited to:
anxiety, shakiness, sweating, headache, increased hunger, dizziness, pale skin colour, sudden change in
mood or irritability, fatigue, diculty concentrating, clumsiness, palpitations, and/or confusion.
High blood glucose (hyperglycaemia): Symptoms of hyperglycaemia may include, but are not limited to:
increased thirst, frequent urination, blurred vision, drowsiness, and/or unexplained weight loss.
w WARNING
If you are experiencing any of these symptoms, or other unusual symptoms, test your blood glucose
from the fingertip or palm. If your blood glucose result is displayed as LO or HI, contact your
healthcare professional immediately.
53134_07019505001_02.indb 14 1/5/15 10:49 AM

15
Meter Memory, Setup, and Data Transfer 3
Memory
Storing Blood Glucose and Control Results
The meter automatically stores up to 500blood glucose results and up to 20 control results with the time
and date of the result and any test result marker which you can review at any time. Test results are stored
from the newest to the oldest, so set the time and date correctly in the meter. Having the correct time and
date setting helps ensure appropriate interpretation of stored blood glucose results by you and your
healthcare team.
NOTE
• The memory is not lost when the battery is replaced; however, confirm that the time and date are still
correct. See Chapter3, Setting the Time and Date.
• Once 500blood glucose results are in memory, adding a new test result causes the oldest one to be
deleted.
• If more than 500blood glucose tests are performed within a 90 day period, only the most recent
500test results are included in the 90 day average.
• Control results are stored in memory, but cannot be reviewed on the meter. To view stored control
results, first transfer them to a compatible software application. Contact the Accu-Chek Customer
Careline on 0800 701 000 (UK) or 1 800 709 600 (ROI) for product availability.
• Control results are not included in the 7, 14, 30, and 90 day averages.
• Only test results that have been assigned a pre-meal or post-meal marker are included in pre-meal
and post-meal averages. All blood glucose results are included in the general 7, 14, 30, and 90 day
averages.
53134_07019505001_02.indb 15 1/5/15 10:49 AM

16
Meter Memory, Setup, and Data Transfer
3
Memory
Viewing Test Results in Memory
With the meter on or o, press and release or to enter memory. The most recent test result appears
on the display.
Button Function Action
(left arrow
button)
Previous test results Press to view previous test results from newest to oldest.
(right arrow
button)
General averages Press to view 7, 14, 30, and 90 day averages.
n = number of test results in the average
(right arrow
button)
Pre-meal averages
Post-meal averages
Continue to press to view 7, 14, 30, and 90 day pre-meal
and post-meal averages.
w WARNING
Do not change your therapy based on an individual test result in memory. Talk to your healthcare
professional before changing therapy based on test results in memory.
53134_07019505001_02.indb 16 1/5/15 10:49 AM

17
Meter Memory, Setup, and Data Transfer 3
Setup
Using the Set-Up Mode
The following features can be customised as required.
Symbol Function Action Factory Pre-set
Time and date Set the time and date.
Beeper Select On or OFF. Setting the beeper to OFF
does not aect test results.
The beeper must be On to use the test
reminders feature.
Post-meal test
reminder
Select 1hour or 2hours. The meter will
beep 1 or 2 hours after the pre-meal test to
remind you to do a post-meal test.
Test reminders Select On or OFF. You can set up to 4test
reminders per day.
A-1 8:00
A-2 12:00
A-3 18:00
A-4 22:00
Hypoglycaemic
alert
Select On or OFF. The hypoglycaemic alert
can be set to a level between 2.8 and
5.0mmol/L to let you know when your
blood glucose is possibly too low.
53134_07019505001_02.indb 17 1/5/15 10:49 AM

18
Meter Memory, Setup, and Data Transfer
3
Setup
Setting the Time and Date
1
Press and release
(power/set button) to turn
the meter on.
The flashing test strip
symbol appears on the
display.
2
Press and hold until
set-up appears on the
display.
The hour flashes.
3
Press and release or
to decrease or
increase the hour.
Press and release to
set the hour.
The minutes flash.
4
Repeat step3 to set
minutes, day, month, and
year.
To set up more options,
press and release .
To exit, press and hold
until the flashing test strip
symbol appears on the
display.
53134_07019505001_02.indb 18 1/5/15 10:49 AM
