Accuro WoundPro Apex User manual

Negative Pressure Wound Therapy
Owners and Operators Manual
Apex

2
Negative Pressure Wound Therapy Owners and Operators Manual
DANGER .............................................................................................................. 4
WARNINGS.......................................................................................................... 4
ADDITIONAL PRECAUTIONS................................................................................ 4
CAUTIONS4
INTRODUCTION.................................................................................................. 5
INDICATIONS FOR USE........................................................................................ 5
CONTRAINDICATIONS FOR USE .......................................................................... 5
PATIENT RISK FACTORS/CHARACTERISTICS TO CONSIDER................................... 6
PRECAUTIONS ..................................................................................................... 7
SYSTEM COMPONENTS....................................................................................... 7
Control Unit................................................................................................ 7
Canister Sets ............................................................................................... 7
Power Supply.............................................................................................. 8
Dressing Kits ............................................................................................... 8
Clamp......................................................................................................... 8
SYSTEM FEATURES ............................................................................................... 8
Control Unit Features.................................................................................. 8
Canister Features ........................................................................................ 8
SYSTEM SPECIFICATIONS .................................................................................... 9
Electrical Specifications ............................................................................... 9
Equipment Symbols.................................................................................... 9
Environmental Conditions .......................................................................... 9
Agency Approvals ....................................................................................... 9
Electromagnetic Emissions ........................................................................ 10
Electromagnetic Immunity........................................................................ 11
SAFETY INSTRUCTIONS ..................................................................................... 13
INSTRUCTIONS FOR USE ................................................................................... 14
Initial Startup ............................................................................................ 14
Programming Changes ............................................................................. 15
Continuous Mode Programming...................................................... 15
Intermittent Mode Programming ..................................................... 15
Runtime Hours Display..................................................................... 16
Canister Changes...................................................................................... 16
Dressing Changes ..................................................................................... 17
DETAILED EXPLANATION OF KEYPAD................................................................. 19
Power Button............................................................................................ 19
Menu Button ............................................................................................ 19
Up Arrow .................................................................................................. 19
Down Arrow ............................................................................................. 19
Canister Light............................................................................................ 19
Alarm Mute............................................................................................... 19
Lock Out................................................................................................... 20
ALARMS ............................................................................................................ 20
Informational Alarms ................................................................................ 20
Low Power ....................................................................................... 20
Canister Full ..................................................................................... 20
Warning Alarms ........................................................................................ 20
Suction Line Blocked ........................................................................ 20
Vacuum Leak.................................................................................... 21
Standby............................................................................................ 21
CLEANING AND MAINTENANCE ........................................................................ 22
General Cleaning Guidelines..................................................................... 22
Cleaning Procedure .................................................................................. 22
STORAGE AND CARE ......................................................................................... 22
WARRANTY........................................................................................................ 23
Table of Contents

www.accuromedical.com 3
Negative Pressure Wound Therapy Owners and Operators Manual
DANGER
Explosion hazard - Do not use around flammable gases.
Do not use in the presence of flammable gases.
Never drop or insert any object into the openings on the Apex control unit.
WARNINGS
Failure to observe these warnings may cause serious injury or death to the patient.
All instructions and guidelines in this manual and the dressing kits should be read and
followed.
This manual provides general guidelines for the proper use of the WoundPro® Apex NPWT
System. These guidelines do not replace instructions from the patient’s physician. Failure to
obtain and follow instructions from the treating physician could result in injury or death.
Be aware of bone fragments, hardware or staples in the wound bed. These items could
puncture the protective barrier. If the Protective barrier is punctured serious injury or death
could result.
Coming into direct contact with bodily fluids is potentially dangerous. Direct contact could
result in serious illness up to and including death. Follow universal precautions if there is any risk
of coming into contact with the contents in the Apex canister, tubing or dressing.
Do not use the WoundPro® Apex NPWT System if tamper-evident seal is broken or missing.
ADDITIONAL PRECAUTIONS
Care should be taken when using the Apex on patients taking blood thinners or platelet
aggregation inhibitors. Care should also be taken on patients with active bleeding.
Care should be taken when using the Apex on patients with wound hemostasis. Care should
also be taken on patients that have a history of irradiated blood vessels. Care should be taken
on wounds that involve a fistula. Care should also be taken on wounds with sinus tracks and
wounds with tunneling. Care should be taken when using the Apex in close proximity to
blood vessels or organs.
Care should be taken to avoid injury to the patient’s skin where it comes into contact with the
tubing from the dressing.
CAUTIONS
Federal (U.S.) law restricts this device to sale by or on the order of a physician.
Service work is to be done by Accuro Medical authorized personnel only.
Do not immerse or spray any type of liquid directly onto the WoundPro® Apex control unit.
Instead, spray a cloth and wipe down the exterior as described in the cleaning procedure (page
21). The control unit is designed to cover all internal components; however internal components
are not sealed from liquid immersion, over-saturated wipes, or direct spray.
Interrupting Apex therapy for more than two hours may increase the presence of bacteria in
the wound bed. An increase in bacteria may raise the risk of infection. If the Apex therapy is
interrupted for more than two hours remove the old dressing, irrigate the wound, and apply a
new sterile dressing before resuming WoundPro® Apex therapy.

4
Negative Pressure Wound Therapy Owners and Operators Manual
Introduction
Thank you for purchasing the WoundPro® Apex Negative Pressure Wound Therapy System
(NPWT).
The Apex offers providers various options for NPWT. We are able to do this by using the
highest quality materials and advanced electronics. The custom battery system enables the
Apex to operate on battery power for 24 hours.
Please take the time to read the contents of this manual before using the system. If you have
questions about any WoundPro®product please call 1-800-669-4757.
Indications For Use
The WoundPro®Apex Negative Pressure Wound Therapy System may promote wound healing,
through the drainage and removal of infectious material and other fluids from the wound
site using continuous and/or intermittent negative pressure. Patients with chronic, acute,
traumatic, subacute and dehisced wounds, partial-thickness burns, ulcers (such as diabetic
or pressure), flaps and grafts may benefit from the use of this device. The WoundPro Apex is
intended for use in a healthcare facility only.
Types of Wounds Indicated are:
●Diabetic/Neuropathic ulcers
●Pressure ulcers
●Chronic wounds
●Acute wounds
●Dehisced wounds
Contraindications For Use
The use of the Apex NPWT system is not recommended for patients with any malignancy of
the wound, untreated osteomyelitis, non-enteric or unexplored fistulas, and necrotic tissue
with the presence of eschar.
●The Apex NPWT system may be used after debridement of necrotic tissue and the
complete removal of eschar.
Never use the Apex NPWT system where there are exposed blood vessels, organs, or
exposed bone. Do not place the Apex dressings over anastomosis, sutured vessels, or
exposed nerves.
●In the cases of exposed blood vessels, organs or bone, they must first be covered with
a porous, non-adherent wound contact layer prior to initiating Negative Pressure to the
area.

www.accuromedical.com 5
Patient Risk Factors/Characteristics
to Consider
Patients at high risk for bleeding and hemorrhage: Certain patients are at high risk of bleeding
complications with or without the use of the Apex NPWT System. Patients that are at an increased
risk of bleeding (which, if uncontrolled, could be potentially fatal) include the following:
●Patients with weakened or friable blood vessels or organs in or around the wound as a
result of, but not limited to:
❍Suturing of the blood vessel/organ
❍Infection – infected wounds should be monitored closely and may require more
frequent dressing changes. The treating physician should determine if Apex NPWT
needs to be discontinued and what treatment steps need to be taken.
❍Trauma
❍Radiation
●Patients without adequate wound hemostasis
●Patients on anticoagulants or platelet aggregation inhibitors
●Patients without adequate tissue coverage over vascular structures.
●Patients with Vascular Anastomosis
●Patients with Osteomyelitis
●Patients with exposed organs, vessels, nerves, tendons, ligaments
●Sharp edges in the wound (i.e. bone fragments) which could puncture protective
barriers, vessels or organs, which could lead to bleeding.
If Apex NPWT has been prescribed for patients with an increased risk for bleeding/hemorrhage,
the patient should be closely monitored by the treating physician. This device should only be
used in a healthcare facility.
If active bleeding develops suddenly or in large amounts during Apex NPWT, immediately stop
therapy (DO NOT REMOVE THE DRESSING), take appropriate measures to stop the bleeding
and seek immediate medical assistance.
800cc Canister: The 800cc canister SHOULD NOT be used on patients with a high risk
of bleeding, or on patients unable to tolerate a large loss of fluid volume. When using this
canister monitoring capability should be taken into account as well as patient risk factor. This
canister is recommended for acute care use only.
Exposed Vessels/Organs and Sharp Edges: If there are any Exposed Vessels, Organs or
Sharp Edges in the wound, they must be completely covered and protected prior to the use of
Apex NPWT. Sharp edges must either be removed or covered prior to treatment.
MRI (Magnetic Resonance Imaging): The Apex NPWT unit is MR unsafe and should never be
taken into an MRI machine. The Apex unit was not designed for this and should be considered a
fire hazard. Replace the Apex Dressing with an approved dressing for use in an MRI machine.
Hyperbaric Oxygen Therapy: The Apex NPWT unit has not been tested for Hyperbaric
Oxygen Therapy and should be considered unsafe for use with Hyperbaric Oxygen Therapy.
Never take the Apex unit into a Hyperbaric Chamber. The Apex unit was not designed for this
and should be considered a fire hazard.

6
Negative Pressure Wound Therapy Owners and Operators Manual
Precautions
Standard Precautions: Implement standard institutional protocol to reduce the risk of
transmission of bloodborne pathogens.
Continuous vs. Intermittent Apex Therapy: Research is constantly revealing the benefits
of both types of therapy in different cases. The patient’s treating physician should decide
which therapy mode is appropriate for the wound and the circumstances.
Patient size and Weight: Patient size and weight should be considered when prescribing
Apex NPWT. Fluid loss and dehydration should be closely monitored in all patients. Large wounds
in relation to the patient size and weight can have excessive fluid loss and lead to dehydration.
Monitor at risk patients closely. This device has not been evaluated for use in children and infants.
Bradycardia: The Apex NPWT MUST NOT be placed in proximity to the Vagus Nerve.
Circumferential Dressing Application: Caution should be taken when using these
dressings to ensure that the circulation distal to the dressing is not impaired.
System Components
Control Unit
The Control unit is the device that delivers the negative pressure. It is
composed of a pump, lithium ion batteries, software, user interface panel
and a number of sensors that monitor and adjust the vacuum pressure.
Canister Sets
The Apex uses either a 300cc standard canister or an 800cc
large capacity canister. In most cases the 300cc canister should
be used. Each canister set comes with the canister (either 300cc
or 800cc), five feet of dual lumen extension tubing, a patient
connector and slide clamp.
The canister comes with a coagulant built inside to reduce the risk of fluid spills. The coagulant
turns fluids it comes into contact with into gels. There is no discernable difference in the level
of fluid in the canister with coagulant when compared to a canister without coagulant.
The disposal of used canisters should be done in a manner that is consistent with state and
local requirements for medical waste. If you are unsure of your local and state requirements
contact the physician.
CAUTION: Do not use the 800cc canister on patients that are at high risk
of bleeding. Do not use it on patients that cannot tolerate large losses of fluid
volume including children and elderly patients. If considering the use of the 800cc
canister consider the size and weight of the patient, wound type, monitoring
capability and care setting. Generally this canister should be used in acute care
hospitals only.

www.accuromedical.com 7
Power Supply
Each Apex NPWT System comes with an external switching power supply. The power supply
is capable of handling: from 90 to 264Volts AC, from 0.8 to 0.4 Amps, at 47 to 63Hertz. The
power supply comes with several adapters for use with many standard outlets around the
world. Select the adapter that is suited for your outlet and attach it to the power supply. The
other end of the cable connects directly to the Apex control unit.
Dressing Kits
A variety of dressing kits are available for use with the WoundPro Apex. Select the dressing kit
based on the wound that is being treated. All dressing kits come with all required materials to
properly apply the dressing.
Clamp
A clamp is provided with the Apex
pump that allows you to attach the
pump to an IV pole or the head / foot
board of the bed. The clamp is easily
attached to or removed from the back
of the pump with the attached Philips
screw. Simply open the clamp by
turning the handle counter clockwise.
Next determine which direction you
want the clamp to face (side to side for pole mount, or up and down for footboard mount).
Then screw the Philips screw that is on the back of the clamp into the receptacle on the
back of the pump. Finally, position the clamp on the pole or footboard and turn the handle
clockwise to close clamp.
System Features
Control Unit Features
●Compact and lightweight power unit is quiet, robust and powerful.
●Crisp, easy to read graphics for intuitive set up and therapy control.
●Lock-out feature to avoid accidental therapy setting adjustments.
●Audible and visual alarms.
●Audible alarm mute.
Canister Features
●Two sizes (300cc and 800cc)
●High impact plastic to reduce risk of spillage of contents.
●Integrated filter.
●Positive locking mechanism to help ensure canister stays firmly attached to control unit.
●Semi-translucent to help reduce negative appearance of canister contents.
●Coagulant in canister to help reduce the risk of spillage of contents.

8
Negative Pressure Wound Therapy Owners and Operators Manual
System Specifications
Weight:
Control Unit - 3.8 lbs. (1.7 Kg)
Dimensions:
Control Unit – 6 ¾ (W) x 8 ½ (H) x 3 ½ (D) in. (17 x 21 x 9 cm)
Electrical Specifications
18VDC, 25W
Switching Power Adapter
Model: TR30RAM180
IEC 60601-1 EN55011 Class B
Input: 90-264VAC, 0.8-0.4A, 47-63Hz
Output: 18VDC 1.67A
Equipment Symbols
Refer to user manual SN Serial Number
Type CF Li-Ion Battery
Do not dispose with
Municipal Waste. Special
Collection/Disposal Required
CE Mark
Environmental Conditions
IP33
Operating Conditions:
Ambient Temperature: +10°C to +40°C
Relative Humidity: 30% to 75% Non-Condensing
Storage and Shipping Conditions:
Ambient Temperature: -10°C to +40°C
Relative Humidity: 10% to 100%
Agency Approvals
UL Classified Medical Equipment UL 60601-1
CSA C22.2 No. 601.1-M90
IEC/EN 60601-1
IEC 60601-1-2 (2007)

www.accuromedical.com 9
IEC 60601-1-2 Table 201
Electromagnetic Emissions
The following Electromagnetic Emissions information is provided for healthcare facilities where
the use of this device around other devices could result in electromagnetic interference.
All WoundPro®Apex NPWT Systems are designed so that they can be used in
electromagnetic environments. The use of these products in these environments should be
restricted as listed in the following table.
Emission Test
Compliance
with Standard Guidelines
RF Emissions CISPR 11 Group 1 (one)
WoundPro®Apex products produce very little
RF energy in the course of operation. The RF
emissions created by the WoundPro®Apex
products are very low and should not cause
any interference with other electronic devices
located in close proximity.
RF Emissions CISPR 11 Class B
In terms of RF emissions all WoundPro®Apex
products are safe for use in all types of buildings
including private residences. In terms of RF
emissions the WoundPro®Apex products are safe
for use in buildings that are directly connected
to low voltage public service used to supply
residential buildings.
Harmonic Emissions
IEC 6100-3-2 Class A
With respect to Harmonic emissions all
WoundPro®Apex products are safe for use in all
types of buildings including private residences.
In terms of harmonic emissions the WoundPro®
Apex products are safe for use in buildings that
are directly connected to low voltage public
service used to supply residential buildings.
Voltage Fluctuations /
Flicker Emissions
IEC 6000-3-3
Complies
With respect to voltage fluctuations and flicker
emissions all WoundPro®Apex products can be
used in all types of buildings including private
residences. WoundPro®Apex products may be
used in buildings that are directly connected
to low voltage public service used to supply
residential buildings.
WARNING: When ever possible the WoundPro®Apex NPWT Systems should not be
used when in close proximity to other electrical devices. Whenever possible do not stack
the Apex pump on or under other electronic devices. If it is necessary to use the Apex in
close proximity to or stacked on or under other electrical devices care must be taken to
insure the Apex is performing as expected.

10
Negative Pressure Wound Therapy Owners and Operators Manual
IEC 60601-1-2 Table 202
Electromagnetic Immunity
The following Electromagnetic Immunity information is provided for healthcare facilities where
the use of this device around other devices could result in electromagnetic interference.
All WoundPro®Apex NPWT Systems are designed for use in electromagnetic
environments. The use of these products in these environments should be restricted as
listed in the following table.
Immunity Tests
IEC 60601
Test Level Compliance Level
Electromagnetic
Environment Guidance
Electrostatic
Discharge (ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood,
concrete or ceramic tile.
If floors are covered with
synthetic materials (carpet)
the relative humidity
should be at least 30%
Electrical fast
transient / burst
IEC 61000-4-4
± 2 kV for power
supply lines
± 1 kV for input /
output lines
± 2 kV for power
supply lines
± 1 kV for input /
output lines
Main power quality
should be that of a typical
commercial or hospital
environment
Surge
IEC 61000-4-5
± 1 kV differential
mode
± 2 kV common
mode
± 1 kV differential
mode
± 2 kV common
mode
Main power quality
should be that of a typical
commercial or hospital
environment
Voltage
dips, short
interruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
< 5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT)
for 5 cycles
70% UT
(30% dip in UT)
for 25 cycles
< 5% UT
(>95% dip in UT)
for 5 seconds
< 5% UT
(>95% dip in UT)
for 0.5 cycle
40% UT
(60% dip in UT) for
5 cycles
70% UT
(30% dip in UT) for
25 cycles
< 5% UT
(>95% dip in UT) for
5 seconds
Main power quality
should be that of a typical
commercial or hospital
environment. IF the
user requires continued
operation during power
mains interruptions, it is
recommended that an
uninterruptible power
supply is used to power the
WoundPro®Apex NPWT
system.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m
Power frequency magnetic
fields should be at levels
of a typical commercial or
hospital environment.
NOTE 1: UT is the A.C. mains voltage prior to application of the test level.

www.accuromedical.com 11
IEC 60601-1-2 Table 204
Electromagnetic Immunity (continued)
The following Electromagnetic Immunity information is provided for healthcare facilities where
the use of this device around other devices could result in electromagnetic interference.
All WoundPro®Apex NPWT systems are designed for use in electromagnetic environments.
The use of these products in these environments should be restricted as listed in the
following table.
Immunity
Tests
IEC 60601
Test Level
Compliance
Level
Electromagnetic Environment
Guidance
Conducted RF
IEC 61000-4-6
3 Vrms
150kHz
To 80 MHz
3 Vrms
Portable and mobile RF communications
devices should not be used any closer to
any part of the WoundPro®Apex NPWT
system than the distance calculated using
the following frequency formulas:
80 MHz to 800 MHz =
d = 1.2 √ P
800 MHz to 2.5 GHz
d = 2.3 √ P
Where “P” is the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and “d” is the recommended separation
distance in meters (m)
Field strengths from fixed RF transmitters
as determined by an electromagnetic site
survey should be less than the compliance
level in each frequency range.
Interference may occur in the vicinity of
equipment marked with the following symbol:
Radiated RF IEC
6100-4
3 V/m
80 MHz to 2.5
GHz
3 V/m
NOTE 1: At 80 MHz and 800 MHz the higher frequency range applies
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
NOTE 3: Field strengths from fixed RF transmitters, such as base stations for radio (cellular
/ cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast
and TV broadcast cannot be predicted. To assess the electromagnetic environment due to
fixed RF transmitters, an electromagnetic site survey should be considered. If the measured
field strength exceeds the applicable RF compliance level above Apex operations should
be closely observed to verify normal Apex operation. If abnormal operation is observed
additional measures may be necessary such as relocating the Apex.
NOTE 4: The frequency ranges of 150 kHz to 80 MHz the field strengths should be less than 3 V/m

12
Negative Pressure Wound Therapy Owners and Operators Manual
Safety Instructions
1. To avoid damaging the Apex control unit, be sure the power available at your location
matches the power call-out on the rear of the Control Unit (i.e. 110VAC, USA; 220VAC
Europe/Australia)
2. Do not spill food or liquids onto the Apex Control Unit. If a spillage does occur, disconnect it
from its power supply and allow at least 24 hours for drying.
3. Do not insert items into any openings of the Apex Control Unit. Doing so may cause fire or
electrical shock by shorting internal components.
4. Keep unit away from radiators or other heat sources.
5. Be sure nothing is placed on the power cable and ensure it is not located where it can be
stepped on or tripped over.
6. Do not attempt to service the Control Unit except as explained in this guide. Always follow
installation and servicing instructions closely.
WARNING: SERVICE AND REPAIR MUST ONLY BE PERFORMED BY AN AUTHORIZED
Accuro Medical Products, LLC Technician.

www.accuromedical.com 13
Instructions For Use
CAUTION: These instructions are general guidelines. Refer to the instructions in
the dressing kit for dressing changes.
The physician should set the rate of dressing changes. The physician should set the
expected amount of fluid that the system will remove in 24 hours.
Coming into direct contact with bodily fluids is potentially dangerous. Direct
contact could result in serious illness up to and including death. Follow universal
precautions if there is any risk of coming into contact with the contents in the Apex
canister, tubing or dressing.
The following instructions are given as general guidelines and are not intended in any way to
replace your organizations wound care protocol. At no time should NPWT be used without
an order from a physician. All instructions provided in this manual are only suggestions and
should be approved by the physician.
Initial Startup:
When the Apex is first powered up the entire display will illuminate. After several seconds
the screen will change and you will see the software revision number. After several additional
seconds the screen will change to display the last setting used. If the unit was used in
intermittent mode the display will look something like this:
If the unit was used in the continuous mode the display will look something like this:
In either case the unit will be in standby.
At this point you will want to change the setting to coincide with the physician’s orders. Follow
the following programming instructions.

14
Negative Pressure Wound Therapy Owners and Operators Manual
Programming Changes:
Enter the programming mode by pressing and holding the Power button and then pressing
the Menu button . The mode that is currently selected (either continuous or intermittent)
will be flashing on the display screen. To change between continuous and intermittent modes
press either the up or down arrow keys.
Continuous Mode Programming:
●The current mode will be flashing. If the display shows that the unit is in “Intermittent
Mode” press the up or down arrow keys to change to the “Continuous Mode”
●Depress the Menu button to enter the pressure adjustment mode. The pressure
setting will begin to flash. Use the Up and Down Arrows to adjust the pressure. Use the
up arrow to increase the pressure and the down arrow to decrease the pressure. You can
set the pressures from 20 mmHg to 150 mmHg in 5 mmHg increments.
●When you are finished making changes press the power button to exit the
programming mode and enter standby mode.
Intermittent Mode Programming:
●The current mode will be flashing. If the display shows that the unit is in “Continuous
Mode” press the up or down arrow keys to change to the “Intermittent Mode”.
●Depress the Menu button to enter the time and pressure adjustment mode. The current
value that you are able to change will be flashing. The top right value is the “High’
pressure setting (what the pressure will be on the high pressure). The high pressure can
be set from 20 mmHg to 150 mmHg in 5 mmHg increments. The top left value is the
“Low” pressure setting (what the pressure will be on the low pressure). The low pressure
can be set at 0 mmHg or from 20 mmHg to 140 mmHg in 5 mmHg increments. The
bottom right value is the “High Pressure” Cycle time (how long the unit will operate at
the high pressure before changing to the low pressure). The high pressure time can be
set from 1 minute to 10 minutes in 1 minute increments, and then up to 95 minutes in
5 minute increments. The bottom left value is the “Low Pressure” Cycle time (how long
the unit will operate at the low pressure before changing to the high pressure). The low
pressure time can be set from 1 minute to 10 minutes in 1 minute increments, and then
up to 95 minutes in 5 minute increments.
●Use the Up and Down Arrows to increase or decrease the values.
Note: When adjusting the pressure settings, the “High” pressure setting must always be
larger than the “Low” pressure setting.
●Press the Menu button to cycle between the four setting (High Pressure, Low Pressure,
High Pressure Cycle Time, and Low Pressure Cycle time) in the intermittent mode.
●When you are finished making changes press the Power button to exit the
programming mode and enter standby mode.
●During intermittent mode operation, the corresponding cycle (low or high) flashes on
the screen to indicate which therapy cycle the unit is currently providing to the patient.

www.accuromedical.com 15
Runtime Hours Display:
●To enter the “runtime hours” display press the menu key when the unit is in standby
mode. The display show the total number of hours the Apex NPWT system has been
providing therapy to the patient, both in continuous and intermittent modes.
●To reset the hour counter press and hold the up or the down arrow and then press the
opposite arrow and release. The “runtime hours” counter will reset to zero hours.
●Press the Menu key to return to standby mode.
Canister Changes:
●Check the volume of fluid in canister. Each canister is graduated with measurement
marks on the side of the canister. Document the volume change since last dressing or
canister change in patients chart. If canister is nearing the full mark replace the canister
and extension tubing.
●To replace the canister
❍Close the slide clamp on the extension tubing
❍Close the pinch clamp on the drain tube
❍Turn the Apex off by depressing the power button for 3 seconds .
❍Disconnect the extension tubing from the drain tube.
❍Remove the patient connector cap from the bottom of the
canister and place it on the tip of the patient connector.
❍Depress the blue canister release button on the top of the unit
while pulling the canister away from the unit.
❍Release the canister release button and slide the new canister into
the unit. You will hear it click.
WARNING: If the amount of fluid from the wound is more than expected a serious
medical condition could exist.
CAUTION: Always monitor the amount of fluid in the canister since the last dressing
change. Be sure to notate how much fluid was in the canister when it was changed.

16
Negative Pressure Wound Therapy Owners and Operators Manual
Dressing Changes
●Determine the proper dressing based on the diameter, depth, location and caregivers
preferences. Generally speaking dressings should be changed every 48 hours unless
directed otherwise by physician.
●Verify that all kit components are accounted for and that there is no damage to the
packaging of the individual items.
❍There are two tubing clamps provided with the Apex system. One in the dressing kit
and one in the canister kit.
●To disconnect the patient connector, attach the tubing clamp that
comes in the dressing kit approximately 1 to 2 inches from the end
of the tubing and pinch it closed.
●Then place the slide clamp 1 to 2 inches from the patient connector
and slide it so that the clamp pinches the tubing closed.
●Turn Apex unit off by depressing the power button for 3 seconds .
●Remove old dressing from wound making sure that all components
are removed.
●Clean wound and periwound area as per organizations wound care protocol.
●Measure wound per organizations wound measuring protocol.
●Irrigate wound with saline, blotting away any excess saline using a sterile gauze sponge
●Prep periwound area with skin prep, and allow prepped area to dry until sticky
●Slide the pinch clamp onto the drain tube
Applying the Wound Dressing Set
●Step 1 – Debride any necrotic tissue and cleanse wound
and periwound area according to institution guidelines and
physician’s orders.
●Step 2 – Cut Non-Adherent Petroleum Gauze to the shape of
the wound. Cover the entire wound bed with the Gauze. [See
Figure A]
●Step 3 – Saturate one of the antimicrobial gauze sponges with
saline, wring out excess saline, and place in the wound bed.
[See Figure B]
●Step 4 – Trim the drain (flat or round) so the groove or holes are
confined to the wound bed. Place it directly on top of the gauze
applied in Step 4. Caution: Do not place the drain in a fistula
tract. [See Figure C]
●Step 5 – Saturate additional antimicrobial gauze with saline,
wring out excess saline, open and fluff into the wound to
completely cover the drain and fill the wound with antimicrobial
gauze to skin level. Caution: Care should be taken to ensure the
gauze is restricted to the wound area and does not protrude
onto the periwound area. [See Figure D]
●Apply skin prep and allow to dry until sticky.
Figure A
Figure B
Figure C

www.accuromedical.com 17
●Step 6 – Apply a thin strip of stoma paste (approximately 1”
long X 1/8” thick) on the periwound area where the drain leaves
the wound. Taper the ends of the stoma paste down to a paper
thin thickness. Lay the drain tube across the strip of stoma paste.
Apply a second thin strip of stoma past (approximately 1” long X
1/8” thick) over the top of the drain tube. Press drain tube into
stoma paste creating a seal around the drain tube.
[See Figure E]
●Step 7 – Cut a piece of transparent dressing 1-2 inches beyond
the wound border on each side. Create an airtight seal by
applying the transparent dressing starting with the side opposite
the tubing. Press the dressing down firmly around the entire
wound to ensure the wound environment is sealed. [See Figure
F]
●Step 8 – Monitor the dressing to ensure that the dressing
maintains a vacuum (dressing is contracted) and the volume
of exudate being removed from wound is within physician’s
expectation. Caution: If exudate volumes exceed physician’s
expectations notify physician immediately for further
instructions.
Applying the Foam Wound Dressing Set
●Step 1 – Debride any necrotic tissue and cleanse wound
and periwound area according to institution guidelines and
physician’s orders.
●Step 2 – Cut foam dressing to the shape of the wound. Care
should be taken to ensure that cut pieces of foam do not fall
into wound bed. [See Figure A]
●Step 3 – Place foam into wound bed. A proper fit will result
in wound area being completely covered with no foam
extending beyond the wound edges onto the periwound
area. [See Figure B]
●Step 4 – Cut a piece of transparent dressing 1-2 inches
beyond the wound border on each side. Apply skin prep to
the peri wound area and allow to dry until tacky. Create an
airtight seal by applying the transparent dressing over the
wound and peri wound area. [See Figure C]
●Step 5 – Gently pull up on the transparent dressing over the
center of the wound. Using scissors cut a small hole (between
½ to 1 inch round) over the center of the dressing.
[See Figures D & E]
Figure D
Figure E
Figure F
Figure A
Figure B
Figure C

18
Negative Pressure Wound Therapy Owners and Operators Manual
●Step 6 – Remove the protective backing on the Suction Bell.
Apply the suction bell over the hole cut in the transparent fill
in step 4 above. Make sure that the hole is completely covered
with the suction bell.
[See Figure F]
●Step 7 – Slide the tubing clamp onto the Suction Bell tubing.
Attach the Suction Bell tubing to the Patient connector.
●Step 8 – Monitor the dressing to ensure that the dressing
maintains a vacuum (dressing is contracted) and the volume
of exudate being removed from the wound is within the
physician’s expectations. Caution: If exudate volumes exceed
physician’s expectations notify physician immediately for further
instructions.
Finish (? not sure about the headings here)
●Attach the drain tubing to the patient connector on the
extension tubing, which is attached to the canister, by pushing the end of the patient
connector into the drain tube.
●Power up the pump.
●Adjust the setting on the pump as directed by physician.
❍Select either Continuous or Intermittent Mode.
❍Set the pressures and times as directed by physician.
●Open both the pinch clamp and the slide clamp.
●Press the power button to initiate negative pressure therapy. The dressing surface
should contract considerably when the pump is set to run. The system will immediately
start checking for leaks. If it determines there is a leak that it cannot overcome audible
and visual alarms will sound and display (see alarms section).
INFORMATION: Periodically check dressing to ensure that it is place and that the air
tight seal is intact. Check canister and determine volume of drainage.
Figure D
Figure E
Figure F

www.accuromedical.com 19
Detailed Explanation of Keypad
1
3
4
2
5
6
1. Power Button
This key turns the Apex on
and off, and also to save any
programming changes and exit
to standby mode. The ‘Standby’
indicator on the display is visible
when the unit is on but operation
of the unit has been temporarily
suspended.
• To activate the unit press the
power button. The ‘Standby’
indicator will go away, and the
unit will begin to operate.
2. Menu Button
The menu button is used to
select what function you want
to change. It is used to select
between Continuous and
Intermittent modes, the pressure
setting for each mode as well as
the time for both high and low
pressures in the intermittent
mode. The menu button
may also be used to enter the
“Runtime hours” display when
the unit is in standby mode.
3. Up Arrow Button
The Up Arrow is used to increase
the setting of the currently se-
lected function.
4. Down Arrow Button
The Down Arrow is used to
decrease the setting of the
currently selected function.
5. Canister Light Button
This key is used to illuminate the
inside the canister. This makes it
easier to see the fluid level in the
canister so you know when to
change it.
6. Alarm Mute Button
Alarm Mute is used to either
temporarily or permanently mute
the Apex Alarms. This is normally
done to allow the provider to
correct the alarm reason.
• Press the ‘Alarm Mute’ button
to mute for 30 minutes. Press
and hold for 3 seconds to
mute all alarms until the unit
is powered down. You can
also un-mute the alarms by
pressing the “Alarm Mute”
button again.
Keypad Functions
1. Power
2. Menu
3. Up Arrow
4. Down Arrow
5. Canister Light
6. Alarm Mute

20
Negative Pressure Wound Therapy Owners and Operators Manual
CAUTION: In most circumstances it is not recommended to permanently mute the
Alarms. This should only be done when absolutely necessary.
Lock Out
A special key stroke is required to modify therapy settings. This feature is to ensure that therapy
settings are not changed by accident. When the Lock Out function is engaged the “Lock” icon
is displayed on the screen. This tells you that the therapy settings cannot be adjusted.
Settings are “Locked” automatically when exiting the therapy adjustment menu.
To “Unlock” and make adjustments to the settings press and hold the “Power” button then
press the “Menu” button.
Alarms
The Apex NPWT system monitors several functions and will alarm if it detects a change in
normal operation. There are both visual and audible alarms. Refer to the following explanation
of alarm conditions to correct the issue. If the problem persists contact Accuro Medical’s
customer service department.
Informational Alarms
Informational alarms are set off when either the battery power is low or the canister has
reached its full mark. The unit will continue to operate normally for a while to allow the
alarm condition to be corrected without interruption in therapy.
Low Power
(3 beeps every minute)
This alarm sounds when the battery has less than 10% of its usable life. When the battery
has less than 10% of its usable life left the battery symbol is displayed
●To fix this alarm, plug the Apex control unit into an outlet.
Canister Full
(3 beeps every minute)
This alarm sounds when the fluid level in the canister has reached its capacity.
●To correct this alarm condition pause the pump and then replace the canister.
Warning Alarms
Warning alarms are set off when a suction line is blocked or there is a vacuum leak, or
the unit is left in standby mode. These conditions affect the ability of the system to work
correctly. The system will stop working until the alarm reason is corrected. Warning alarms
must be addressed as quickly as possible.
Suction Line Blocked
(3 beeps every 5 seconds)
This alarm sounds when the system’s pressure sensor detects a change in the pressure
created by a blockage in the tubing or canister.
●To correct this alarm condition pause the pump and replace the canister and tubing.
