Ace Plus WPS-Interactive User manual

Wireless Presentation System
Quick Installation Guide
(Model Name: WPS-Interactive)
ACE PLUS CORP.
!
Page 1 of 7
JUL 15 / 2012
Version 1.0
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw
WPD-230

1.Package Contents
zWPS Box
zWPS USB Token
zPower Adapter (DC +5V, 2.5A)
zAntenna *2
zQuick Installation Guide
zWarranty Card
2.USB Token Contents
Client Folder
zSoftware and MobiShow software for Smartphone
Applications Folder
zVAC (For Windows XPAudio Projection)
zVDD (For Virtual Extended Screen)
zPtG Converter (For MobiShow PtG function)
zSNMP Manager(For WPS device management)
3.Physical Details
zFront Panel
USB port for plug-in HID Mouse and
keyboard to remote desktop control
Power LED
ACE PLUS CORP.
!
Page 2 of 7
JUL 15 / 2012
Version 1.0
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

zRear Panel
4.Installation
1) Connect projector VGA/HDMI cable to WPS box VGA/HDMI connector and
2) Turn on WPS box.
iWhen Projector shows the default menu on the screen as below, it
indicates the WPS box is ready now.
RJ-45 VGA Connector Audio Antenna
HDMI Connector DC Jack
Antenna
turn on projector power.
ACE PLUS CORP.
!
Page 3 of 7
JUL 15 / 2012
Version 1.0
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

zWindows
1) Make sure your PC WLAN is enabled already, and connect your PC with
WPS box.
2) Open your browser and it will redirect to WPS main page automatically, or
you can enter the IP address to access the WPS web home page.
iThe default IP address of WPS is 192.168.100.10 or refers to the IP
address shown on the left corner of projector screen.
ACE PLUS CORP.
!
Page 4 of 7
JUL 15 / 2012
Version 1.0
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

3) Download the client software. Please select the “Windows 7/Vista / XP” and
execute the installation program.
ƇAfter install the program, WPS shortcut will come out on the PC desktop.
4) Make sure your personal firewall allows WPS software to pass through.
ACE PLUS CORP.
!
Page 5 of 7
JUL 15 / 2012
Version 1.0
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

5) Enter the LOGIN CODE and
iYou can see the login code on the projector screen
6) Click the button to start projection, or choose one of the numbers (1
to 4) to project to the split screen.
ACE PLUS CORP.
!
Page 6 of 7
JUL 15 / 2012
Version 1.0
Headquarters :
9F.-2, No.190, Sec. 2, Zhongxing Rd., Xindian Dist., New Taipei City 231, Taiwan
Tel : [phone]
Fax : [phone]
E-Mail: [email protected]
Technical Support: [email protected]
http://www.ace-plus.com
http://www.ace-plus.tw

zMac
1) Enable your WiFi and connect to WPS device.
2) Execute WPS client software for Mac. (You can find it in WPS USB Token
or download it from the WPS web page)
3) Launch WPS software and enter the login code.
4) Click the button to start projection.
