Acer Veriton L670G Installation instructions

I
Veriton L670G
Product End-of-Life Disassembly Guide
PRINTED IN TAIWAN
Service guide files and updates are available
on the AIPG/CSD web; for more information,
please refer to http://csd.acer.com.tw
All manuals and user guides at all-guides.com
all-guides.com

2
Machine Disassembly and Replacement
To disassemble the computer, you need the following tools:
zWrist grounding strap and conductive mat for preventing electrostatic discharge.
zWire cutter.
zPhillips screwdriver (may require different size).
NOTE: The screws for the different components vary in size. During the disassembly process, group the screws
with the corresponding components to avoid mismatches when putting back the components.
All manuals and user guides at all-guides.com

3
General Information
Before You Begin
Before proceeding with the disassembly procedure, make sure that you do the following:
1. Turn off the power to the system and all peripherals.
2. Unplug the AC adapter and all power and signal cables from the system.
All manuals and user guides at all-guides.com

4
Disassembly Procedure
This section tells you how to disassemble the system when you need to perform system service.
CAUTION: Before you proceed, make sure you have turned off the system and all peripherals
connected to it.
All manuals and user guides at all-guides.com

5
Standard Disassembly Process
1. Opening the computer:
1.1 Remove the screw fixed in the cover_stand.
1.2 Remove the screw fixed in the cover_top.
1.3 Drag the cover_top rearward removal.
All manuals and user guides at all-guides.com

6
2. Removing the CPU
2.1 Release the four screws fixed in the thermal_module.
2.2 Remove the CPU.
3. Removing the Memory
3.1 Release the two latches shownbellow then remove the Memory.
All manuals and user guides at all-guides.com
all-guides.com

7
4. Removing the HDD
4.1 Remove the two screws fixed in the chassis.
4.2 Removethe HDD.
5. Removing the WLAN mini pci-e card
5.1 Remove the screw fixed in the cover_bottom.
All manuals and user guides at all-guides.com

8
5.2 Drag the cover_bottom rearward removal.
5.3 Remove the two screws fixed in the WLAN mini PCI-E card.
5.4 Disconnect the main & aux antenna cable from the WLAN mini PCI-E card .
All manuals and user guides at all-guides.com

9
6. Removing the Serial port cable
6.1 Disconnect the serial port cable.
6.2 Remove the six screws fixed in the chassis.
7. Removing the ODD
7.1 Remove the one screw fixed in the chassis.
All manuals and user guides at all-guides.com

10
7.2 Remove the four cover Front IO Latches.
7.3 RemovetheODD.
8. Removing the Main Board
8.1 Remove the three screws fixed in the Bracket_Front_IO.
All manuals and user guides at all-guides.com

11
8.2 Release the Bracket_Front_IO.
8.3 Remove the five screws fastening the main board to the chassis.
8.4 Disconnect the two FAN cables.
All manuals and user guides at all-guides.com
all-guides.com

12
8.5 Remove the M/B and RTC Battery.
9. Removing the FAN
9.1 Remove the eight screws fixed in the chassis.
