Acer Veriton 7500GE Series User manual

Veriton 7500GE series
User’s guide
WU8611tfsjft`FO/cppl!!Qbhf!j!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

Changes may be made periodically to the information in this publication without obligation
to notify any person of such revision or changes. Such changes will be incorporated in new
editions of this manual or supplementary documents and publications. This company makes
no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims the implied warranties of merchantability or fitness for a
particular purpose.
Record the model number, serial number, purchase date, and place of purchase information in
the space provided below. The serial number and model number are recorded on the label
affixed to your computer. All correspondence concerning your unit should include the serial
number, model number, and purchase information.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopy, recording, or otherwise,
without the prior written permission of Acer Incorporated.
Model Number : _________________________________
Serial Number: ___________________________________
Purchase Date: ___________________________________
Place of Purchase: ________________________________
Copyright © 2002 Acer Incorporated
All Rights Reserved.
Veriton 7500GE!series
User’s guide
Original Issue December 2002
Acer and the Acer Logo are registered trademarks of Acer Inc. Other company’s product
names or trademarks are used herein for identification purposes only and belong to their
respective companies.
WU8611tfsjft`FO/cppl!!Qbhf!jj!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

iii
Notices
FCC notice
This device has been tested and found to comply with the limits for a Class B
digital device pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This device generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful interference to radio or television
reception, which can be determined by turning the device off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the device and receiver
• Connect the device into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio/television technician for help
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables
to maintain compliance with FCC regulations.
Notice: Peripheral devices
Only peripherals (input/output devices, terminals, printers, etc.) certified to
comply with the Class B limits may be attached to this equipment. Operation
with noncertified peripherals is likely to result in interference to radio and TV
reception.
Caution! Changes or modifications not expressly approved by
the manufacturer could void the user’s authority, which is granted
by the Federal Communications Commission, to operate this
computer.
WU8611tfsjft`FO/cppl!!Qbhf!jjj!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

iv
Use conditions
This part complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Remarque à l’intention des utilisateurs canadiens
Cet appareil numérique de la classe B respected toutes les exigences du
Règlement sur le matériel brouilleur du Canada.
Important safety instructions
Read these instructions carefully. Save these instructions for future reference.
1 Follow all warnings and instructions marked on the product.
2 Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
3 Do not use this product near water.
4 Do not place this product on an unstable cart, stand, or table. The product
may fall, causing serious damage to the product.
5 Slots and openings in the housing and the back or bottom are provided for
ventilation; to ensure reliable operation of the product and to protect it
from overheating, these openings must not be blocked or covered. The
openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should never be placed near or
over a radiator or heat register, or in a built-in installation unless proper
ventilation is provided.
6 This product should be operated from the type of power indicated on the
marking label. If you are not sure of the type of power available, consult
your dealer or local power company.
7 Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
8 If an extension cord is used with this product, make sure that the total
ampere rating of the equipment plugged into the extension cord does not
exceed the extension cord ampere rating. Also, make sure that the total
rating of all products plugged into the wall outlet does not exceed the fuse
rating.
9 Never push objects of any kind into this product through cabinet slots as
they may touch dangerous voltage points or short out parts that could
WU8611tfsjft`FO/cppl!!Qbhf!jw!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

v
result in a fire or electric shock. Never spill liquid of any kind on the
product.
10 Do not attempt to service this product yourself, as opening or removing
covers may expose you to dangerous voltage points or other risks. Refer all
servicing to qualified service personnel.
11 Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
a When the power cord or plug is damaged or frayed
b If liquid has been spilled into the product
c If the product has been exposed to rain or water
d If the product does not operate normally when the operating
instructions are followed. Adjust only those controls that are covered
by the operating instructions since improper adjustment of other
controls may result in damage and will often require extensive work
by a qualified technician to restore the product to normal condition.
e If the product has been dropped or the cabinet has been damaged
f If the product exhibits a distinct change in performance, indicating a
need for service.
12 Replace the battery with the same type as the product's battery we
recommend. Use of another battery may present a risk of fire or explosion.
Refer battery replacement to a qualified serviceman.
13 Warning! Batteries may explode if not handled properly. Do not
disassemble or dispose of them in fire. Keep them away from children and
dispose of used batteries promptly.
14 Use only the proper type of power supply cord set (provided in your
accessories box) for this unit. It should be a detachable type: UL listed/CSA
certified, type SVT, rated 7A 125V minimum, VDE approved or its
equivalent. Maximum length is 15 feet (4.6 meters).
Laser compliance statement
The CD or DVD drive in this computer is a laser product. The CD or DVD drive’s
classification label (shown below) is located on the drive.
CLASS 1 LASER PRODUCT
CAUTION: INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO
BEAM.
Lithium battery statement
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the
WU8611tfsjft`FO/cppl!!Qbhf!w!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

vi
same or equivalent type recommended by the manufacturer. Discard used
batteries according to the manufacturer’s instructions.
Macrovision®statement
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights
owned by Macrovision Corporation and other rights owners. Use of this
copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
Year 2000 compliance statement
Your computer carries the "Hardware NSTL Tested Year 2000 Compliant" logo,
which certifies that this model has been tested by NSTL using the YMark2000
test, and has been found to meet NSTL's standards for Year 2000 hardware
compliance.
WU8611tfsjft`FO/cppl!!Qbhf!wj!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

Contents
Notices iii
FCC notice iii
Important safety instructions iv
Laser compliance statement v
Lithium battery statement v
Macrovision® statement vi
Year 2000 compliance statement vi
1 First things first 1
Package contents 3
Taking care of your computer 4
Important tips 4
Cleaning and servicing 4
Asking for technical assistance 5
Accessing the user’s guide 6
2 System tour 7
Features 9
Performance 9
Multimedia 9
Connectivity 9
Front panel 11
Rear panel 13
Keyboard 15
Function keys 16
Lock keys 16
Windows keys 17
Cursor keys 17
Palm rest 17
Volume control/Mute knob 18
Multimedia keys 18
Internet/Suspend keys 19
Programmable keys 19
Mouse 20
Disk drives 21
Floppy drive 21
CD-ROM/DVD-ROM/CD-RW drive 22
Hard disk 24
3 Setting up your computer 25
Arranging a comfortable work area 28
WU8611tfsjft`FO/cppl!!Qbhf!wjj!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

viii
Adjusting your chair 28
Positioning your PC 28
Positioning your monitor 29
Positioning your keyboard 29
Positioning your mouse 29
Connecting peripherals 30
Connecting your mouse 30
Connecting your keyboard 32
Connecting a monitor 34
Connecting the power cable 35
Turning on your computer 36
Turning off your computer 37
Connecting options 38
Connecting your printer 38
Connecting the modem (optional) 39
Connecting to the network 40
Connecting multimedia devices 41
Connecting USB devices 44
4 Upgrading your computer 47
Installation precautions 50
ESD precautions 50
Preinstallation instructions 50
Post-installation instructions 51
Opening your computer 52
To remove the side panel 52
To replace the side panel 53
Internal components 55
System boards 56
Mainboard layout 56
Audio board 59
Upgrading your computer 60
Installing additional memory 60
Replacing the hard disk 62
Installing an expansion card 64
5 System utilities 67
Acrobat Reader 70
Acer LANScope (optional) 71
Norton AntiVirus 72
NTI CD-Maker
(for models with CD-RW) 73
PowerDVD (for models with DVD) 74
WU8611tfsjft`FO/cppl!!Qbhf!wjjj!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

ix
BIOS utility 75
Reinstalling programs 76
Recovering your system 76
6 Frequently asked questions 77
Index 83
WU8611tfsjft`FO/cppl!!Qbhf!jy!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

x
WU8611tfsjft`FO/cppl!!Qbhf!y!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

1 First things first
WU8611tfsjft`FO/cppl!!Qbhf!2!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

This chapter describes the contents of your
computer package and also provides important
tips on how to take care of your computer.
WU8611tfsjft`FO/cppl!!Qbhf!3!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

3
Package contents
Before you unpack your computer, make sure that you have enough
space to set up your computer.
Carefully unpack the carton and remove the contents. If any of the
following items are missing or damaged, contact your dealer
immediately:
• Veriton 7500GE series
• Items contained in the accessory box
• USB or PS/2 keyboard
• USB or PS/2 mouse
• User’s guide and installation poster
• Other user documentation and third-party software
WU8611tfsjft`FO/cppl!!Qbhf!4!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

1 First things first4
Taking care of your computer
Please read the important instructions listed in this section. Following
these instructions will help you maximize the durability of your
computer.
Important tips
• Do not expose the computer to direct sunlight. Do not place it
near sources of heat, such as a radiator.
• Do not subject the computer to magnetic fields.
• Do not expose the computer to rain or moisture.
• Do not spill water on the computer.
• Do not subject the computer to heavy shock or vibration.
• Do not expose the computer to dust and dirt.
• Never place the system on uneven surfaces.
• Do not step on the power cord or place heavy objects on top of it.
Carefully route the power cord and any cables away from personal
traffic.
• When unplugging the power cord, do not pull on the cord itself
but pull on the plug.
• The total ampere rating of the equipment plugged in should not
exceed the ampere rating of the cord if you are using an extension
cord. Also, the total current rating of all equipment plugged into
a single wall outlet should not exceed the fuse rating.
• Check the documentation that came with your software programs
to see if you can select other combinations of resolution and color.
These adjustments could make viewing the screen more
comfortable.
Cleaning and servicing
To clean your computer and keyboard
1 Turn off the computer and unplug the power cord.
2 Use a soft cloth moistened with water and gently wipe the exterior
of the computer and the keyboard. Do not use liquid or aerosol
cleaners.
WU8611tfsjft`FO/cppl!!Qbhf!5!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

5
To clean your pointing device
To clean a regular mouse (with rubber ball)
1 Open the circular cover underneath the mouse.
2 Take out the rubber ball and wipe it with a soft, damp cloth.
3 Put the ball back and close the cover.
To clean an optical mouse
For users of an optical mouse, refer to the documentation that came
with your mouse for maintenance instructions.
To clean your monitor
Make sure that you keep your screen clean. For cleaning instructions,
refer to the documentation that came with your monitor.
When to contact a service technician
• If you dropped and damaged the computer
• If liquid has been spilled into the computer
• If the computer is not operating normally
• If a computer problem persists even after you have checked and
done the troubleshooting tips discussed in the “Frequently-asked
questions” section on page 77
• If your problem is not listed in the “Frequently-asked questions”
section on page 77
• If you want to replace or upgrade any of your computer’s internal
components
Asking for technical assistance
For technical assistance, contact your local dealer or distributor. You
may also access the Web site (www.acersupport.com) for information
on how and where to contact the service centers available in your area.
WU8611tfsjft`FO/cppl!!Qbhf!6!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

1 First things first6
Accessing the user’s guide
This user’s guide is also available on your computer as an Adobe
Acrobat PDF file.
To access the user’s guide (for Windows XP)
1 On the Windows XP taskbar, click on the Start button then select
Help and Support Center.
2 On the Help and Support Center home page, double-click the
Veriton 7500GE series Online icon.
To access the user’s guide (for Windows 2000)
1 Double-click on the Veriton 7500GE series Online icon on your
Windows desktop.
WU8611tfsjft`FO/cppl!!Qbhf! !!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

2 System tour
WU8611tfsjft`FO/cppl!!Qbhf!8!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

This chapter discusses the features and
components of your computer.
WU8611tfsjft`FO/cppl!!Qbhf!9!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

9
Features
Here are just a few of your computer’s many features:
Performance
• Intel Pentium®/Celeron CPU
• Intel 845GE/ ICH4
• System memory DDR-SDRAM 266/333, 2 DIMM slots, Expandable
to 2GB
• Power management function
• 3.5-inch floppy drive
• DVD-ROM, CD-ROM or CD-RW drive
• High-capacity, Enhanced-IDE hard disk
• Supports USB 2.0 high-performance peripherals
Multimedia
• 3-D quality audio system via onboard audio controller
• Audio-in/Line-in, Audio-out/Line-out, Headphone-out, and
Microphone-in interfaces
Note: The system has two microphone-in jacks (front and rear).
However, you can not use both of them at the same time. By
default, your system enables the microphone-in jack in front and
disables the one at the back.
Connectivity
• Two PS/2 interfaces for mouse and keyboard
• One serial port
WU8611tfsjft`FO/cppl!!Qbhf!:!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN

2 System tour10
• One parallel port
• One VGA port
• Six Universal Serial Bus (USB)1.1/1.2 ports (two on the front and
four on the rear panel)
• High-speed V92, 56K Fax/modem (optional)
• 10Base-T/100Base-TX network support with remote wake-up
function
WU8611tfsjft`FO/cppl!!Qbhf!21!!Uivstebz-!Efdfncfs!23-!3113!!3;3 !QN
