X275

Efficient Multitasker

•The Veriton X275 targets users who demand ease

of use, robust management features and

expandability in a small chassis.

•Performance:

9Intel®Pentium®or Core™2 Duo processors

9Intel®G41 Express Chipset

9Dual-channel DDR3 memory

9High-capacity SATA 3 Gb/s hard disk

•Veriton ControlCenter: a fast-access panel that

comprises handy utilities

•Acer Security Suite ensures document security

and corporate privacy

•Acer Client Manager simplifies MIS and company

network operation for remote management of

common IT tasks

•Designed with a tool-less and modular chassis,

making component swapping, upgrades and

expansion hassle-free

Windows®. Life without Walls™. Acer recommends Windows 7.

Veriton X275 SPECIFICATIONS

Product view 1Internal speaker

2GS-compliant finish

3Enhanced ventilation

4Power switch

5Optical drive bay

6Onebutton Recovery

7USB 2.0 ports and audio jacks

8PS/2 keyboard and mouse ports

9DVI-D port

10 VGA port

11 Serial port

12 USB 2.0 and Ethernet ports

13 Three audio ports

Operating system1Genuine Windows®7 Professional Downgrade rights to Genuine Windows®XP Professional

Processor1Intel®Core™2 Duo Processor E7600

Intel®Pentium®Processor E6600

Intel®Pentium®Processor E5500

Chipset1Intel®G41 Express Chipset

Memory1In Configuration: 2GB (2/0) DDR3 SDRAM, 3GB (2/1) DDR3 SDRAM or 4GB (2/2) DDR3 SDRAM

Expansion Slots: Two memory slots: upgradeable up to 4GB (one 2GB in each slot)

Hard drive1320GB SATA hard drive, 7200RPM 500GB SATA hard drive, 7200RPM

Optical drive1SuperMulti

Expansion bays One PCI Express®1.1 x1 One PCI Express®1.1 x16

Graphics Intel®Graphics Media Accelerator x4500 including Microsoft®DirectX®10 support

Audio Embedded high-definition audio with 5.1-channel surround sound support

Networking LAN: Gigabit Ethernet

I/O ports Front:

•Four USB 2.0 ports (on models without multi-in-1 card

reader)3

•Multi-in-1 card reader4

•High-definition headphone and microphone jacks

Rear:

•Four USB 2.0 ports

•PS/2 keyboard and mouse ports

•Ethernet (RJ-45) port

•Three audio ports

•VGA port

•Serial port

I/O expansion PCI Express®1.1 x16 slot

PCI Express®1.1 x1 slot

Two PCI v2.3 (5 V) slots

Parallel port connector4

Serial port connector4

Software1Acer Client Manager

Acer eRecovery Management

Acer Security Suite

Adobe®Reader®

Veriton ControlCenter (Acer eLock

Management, Acer eSettings Management,

QuickMigration, PowerSaver, SmartBoot,

HelpDesk)

Microsoft®Office 2007 (Ready/Trial) Service

Pack 1

McAfee®Internet Security Suite 2010 Trial5

CyberLink®PowerDVD®

Security Acer eLock Management

Padlock and Kensington lock slots

Intrusion alert

TPM module4

OneButton Recovery

Dimensions/Color 4.0" (101.5mm) W x 15.6" (396.8mm) D x 10.5" (266.5mm) H Black/Silver

BIOS Acer PnP BIOS compatible with SMBIOS 2.6

Power supply1220 W

System compliance PC 2001

Certification UL, VCCI, FCC, CE, BSMI, CCC, MET, Nemko (CB & GS)

Optional

accessories

Acer USB or PS/2 keyboard and mouse Acer external/internal speakers

Acer LCD monitor

Warranty One year limited warranty with limited on-site service9

1. Specifications vary depending on model.

2. Support for RAID 0 and 1 requires two hard drives, RAID 5 requires three, and RAID 10 requires four.

3. Optional.

4. Intel® Core™i7 and Core™i5 700 processors require a discrete graphics card.

5. For models with Windows®7.

6. Trial periods vary depending on the geographic region and specifications: 365-day trial for China,

Hong Kong (Simplified Chinese and Traditional Chinese OS models), Taiwan and Singapore; 60-day trial for other

regions.

7. Trial periods vary depending on the geographic region and specifications: 365-day trial for China,

Hong Kong (Simplified Chinese and Traditional Chinese OS models), Taiwan and Singapore; 60-day trial for other

regions.

8. ENERGY STAR®5.0 is available only on G models.

9. EPEAT®Silver is only available for the M498G model.

10. On-site service applies to the continental U.S. and Canada only and may not be available in all locations. In those

areas where on-site service is provided,a technician will be dispatched, if necessary, following efforts to resolve the

problem by telephone support.

In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability

may vary depending on region.
