Acer APG User manual

1
English
Acer Projector Gateway
Introduction
The Acer Projector Gateway (APG) is a smart, integrated system that enhances
presentations via your Acer projector. The APG provides versatile source
connectivity, the latest eDisplayPro Management tools for networking display,
supports for media contents playback via the built-in decoder and more.
Networking APG features
•With high-performance wireless projection via an acer USB WiFi adapter or
an RJ-45 port for wired connections (only for the models with RJ-45 port).
•The projector can act as an access point (AP) or work in WiFi con-current
mode when doing networking display.
•Users can easily launch the Acer eDisplayPro Management to do Full
screen, L/R, 4-split screen projection and enable high quality video
streaming.
•Powerful wireless display features ready for devices with different OS (MS
Windows, Mac OS, Android, iOS)
•Supports wireless network security (WPA-PSK, WPA2-PSK).
•Acer Projector Gateway Web Management enables a web-based control of
Acer projector for Windows NB/PC (only when the projector is in AP mode).
•Supports firmware upgrade via USB flash drive.
•Crestron compliant (only for the models with RJ-45 port).
Multi-media features
•Fancy and stylish user interface for better experience.
•You can enjoy media & documents playback via internal memory, USB flash
drive and SD card (for selected models).
•Supports high resolution JPEG and BMP picture formats, slideshow and
various slideshow effects for the best viewing experience.
•Supports MP3, PCM and WMA...audio formats, music spectrum and
random play function for your pleasing.
•Supports MPEG4, H.264, WMV, MKV and RMVB...video formats and
smooth video playback with 1080p@30Hz.
•Supports office documents playback (Word, Excel, PowerPoint, PDF).
•Easy control for all media functions by the remote control.
•You can mirror or extend your screen via the source USB B or USB
Connection.

2
English
Getting Started
Connecting multi-media device to the projector
To switch between different inputs,
press SOURCE on the projector or
remote control to open the Source
menu that allows you to select an
input signal source.
#Component Description
1 LAN port Connects to an Ethernet 10/100-based network.
2 Mini USB Projects NB/PC screen via mini USB (USB B or USB
Connection).
NOTE: USB Type A is for USB display (K1
series).
3 USB Type A Connects to USB flash drive for multimedia playback.
Or connects to a USB WiFi adapter (optional).
NOTE: To enable wireless function, the
USB Wireless Adaptor must be plugged
into the USB A/USB A1/Wireless Dongle
port.
4SDcardslot(for
selected models)
Insert the SD card for multimedia playback.
123 4
USB B

3
English
Copyright © 2015. Acer Incorporated.
All Rights Reserved.
Changes may be made periodically to the information in this publication
without obligation to notify any person of such revisions or changes.
Such changes will be incorporated in new editions of this manual or
supplementary documents and publications.
This company makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims the
implied warranties of merchantability or fitness for a particular purpose.

4
English
Control Panel and Remote Control
Control Panel
Remote Control
#Function Description
1 MENU Launches the projector Onscreen Display (OSD) menu.
2BACK
Stop
Cancels your selection, or goes back to previous page.
Stops the playing of media files.
3 SOURCE Press to open the Source
menu that allows you to select
an input signal source.
4 Four directional
selection keys
Selects the media files or features in four directions.
5ENTER
Play/Pause
Confirms your selection of items.
Plays/Pauses the of playing media files.
#Function Description
1 ENTER Confirms your selection of items.
2 BACK Cancels your selection, or goes back to previous page.
3 MEDIA HOME Goes to MEDIA HOME page.
NOTE: This button is only available when
the input signal is MEDIA.
3
1
25
4

5
English
4Four
directional
select pad
Selects the media files or features in four directions.
5 VOL +/- Increases/decreases the volume.
6Rewind •Goes to the previous file.
•Rewinds the playing of media files with a long
press for 1 second.
Play/Pause Plays/Pauses the playing of media files.
Stop Stops the playing media files.
Fast-forward •Goes to the next file.
•Fast-forwards the playing of media files with a
long press for 1 second.
Previous Goes to the previous file.
Next Goes to the next file.
Rewind Rewinds the playing of media files.
Fast-forward Fast-forwards the playing of media files.
7 SOURCE Press to open the Source
menu that allows you to
select an input signal source.
8 MENU Launches the projector Onscreen Display (OSD) menu.
9 MEDIA SETUP Opens MEDIA SETUP page.
10 PAGE ^/v
PgUp/PgDn
For computer mode only. Use the button to select the
next or previous page. This function is only available
when connected to a computer via a USB cable.
11 INFO Displays information of the selected file.
12 A/a Launches the projector OSD subtitle menu during video
playback.
#Function Description

6
English
Media Mode
This mode allows you to browse media files stored in different devices, such as
RAM (internal memory), USB flash drive, USB hard drive and SD card (for
selected models) when connected to the projector. No matter where you are,
you can always press MEDIA HOME to go back to MEDIA HOME page.
Adjust projector source to MEDIA.
NOTE: Document mode is an optional function.
NOTE: Supported capacity for USB flash drive: up to USB 3.0 64GB,
for USB hard drive: up to 1TB.
NOTE: Supported capacity for SD/SDHC/MicroSD: up to 64GB Class
2-10.
NOTE: Some external USB hard drives may not be supported due
to lack of USB power.
NOTE: Disks with partitions are not supported.
Main features
Content
sources
Main Home page

7
English
Music
When viewing music files
You can press /to select the file and press ENTER to access.
When playing music
You can press / to select a feature such as PLAY/STOP/REPEAT/REWIND/
FAST-FORWARD/VOLUME UP/VOLUME DOWN and press ENTER to execute.

8
English
When viewing photos
You can press // / to select the file and press ENTER to access.
When playing photos
You can press / to select a feature and press ENTER to execute. For details
on the Photo Setting, see "Photo Setting".

9
English
Video
When viewing video files
You can press /to select the file and press ENTER to access.
When playing videos
You can press / to select a feature such as PLAY/STOP/REPEAT/REWIND/
FAST-FORWARD/VOLUME UP/VOLUME DOWN and press ENTER to execute. For
details on the Video Setting, see "Video Setting".

10
English
Document (optional)
When viewing document files
You can press // / to select the file and press ENTER to view it. Button
operations are different when viewing different types of documents.
For details on the Document Setting, see "Document Setting".
NOTE: Office Reader:
1 All IPR, including but not limited to copyright, in the Picsel Products is
owned by Picsel suppliers.
2 The End User may not:
• Make copies of the Picsel Products or make them available for
use by third parties.
• Reverse engineer, disassemble, reverse translate, or in any way
decode the Picsel Products or any copy or part of it in order to
derive any source code, save only as is permitted by any
applicable law.
3 Picsel make no representations or warranties whether express or
implied (by statute or otherwise) relating to the performance, quality,
merchantability or fitness for a particular purpose of the Picsel
Products or otherwise and all such representations or warranties are
specifically disclaimed and excluded.
4 Picsel agrees and acknowledges that Picsel and the Picsel Products will
not be specifically mentioned in the end user license agreement.

11
English
NOTE: No support for advanced settings, such as Microsoft Word
drawing plug-in or table background settings.
NOTE: Contents outside the defined borders in Microsoft Word
will not be displayed.
NOTE: Microsoft PowerPoint slide effects not supported.
NOTE: Worksheets are displayed individually and sequentially
when the workbook has multiple worksheets.
NOTE: Page layout and numbering may be changed during
decoding.
NOTE: Objects embedded in files cannot be activated or viewed.
NOTE: Decoding may take a while for large files with complex
contents.

12
English
Media Setup
Media setup page allows you to adjust settings for file listing and playing. To
use the media setup page:
Press MEDIA SETUP when listing or playing media files to access individual menu
items for different types of media files.
Or you can follow below steps to access all menu items.
1 Adjust projector source to MEDIA.
2 Press / to select Setup and press ENTER.
3 Press / to select a main menu item and press ENTER to enter.
4 Press / to select a submenu item and press / to change setting
values.
5 To exit, press "X".

13
English
Video Setting
Photo Setting
Music Setting
Document Setting
Firmware Upgrade
There are 2 ways to do this:
• Using a USB flash drive
1 Download new media FW files by one compressed file from acer global
website.
2 Copy all uncompressed files in USB flash drive (Acer_Upgrade.bin as
released and Acer_upgradeinfo.ini), and plug in projector.
3 Check projector source upto USB A.
4 Media Gallery > Setup > Firmware Upgrade.
5 Confirm to go.
6 Projector will show welcome screen automatically when upgrade finishes.
Menu item Options
Display Ratio Letter box/Cut screen/Full screen/Original
Repeat Mode Sequence/Single/Random/Once
Menu item Options
Display Ratio Original/Full screen
Slideshow Pattern
Random/Ring Diffusion/Middle Enlarge/Expand Blink/
Window Shades/Linear Interaction/Cross Interleaved/
Banding Alternate
Slideshow
Duration
10 sec/30 sec/1 min
Menu item Options
Repeat Mode Sequence/Single/Random/Once
Menu item Options
Display Ratio Fit to screen/Fit to width/Fit to height

14
English
NOTE: When upgrading the firmware, remove all cables and other
USB devices.
NOTE: To utilize the Mirroring Display function (optional), make
sure you have updated the firmware to the latest version from
www.acer.com, and use the acer USB WiFi adapter.
• OTA (Over-the-air)
1 Connect a USB wireless adapter (optional) or a RJ45 cable to the projector.
(Make sure it connects to the internet.)
2 Select "LAN/WiFi" or "eDisplayPro" mode via the OSD menu.
3 The projector will automatically search for the latest firmware version
available.
4 Select YES when the projector pops out a message to remind you that
there is a new firmware version for you (by Acer eDisplayPro app remote).
5 Do not turn off the projector while the firmware is updating.

15
English
Supported multi-media formats
NOTE: The video clip and its SRT subtitle file must be located in
the same folder and with same filename (ex. Abcde.avi &
Abcde.srt).
NOTE: Some user-made subtitles may not work properly.
NOTE: Video clips produced with some encoders may not be
played correctly. Detail is to follow format supported table.
NOTE: The media mode supports max. 999 directories and max.
9999 files for USB devices/disks.
1JPEG Decode Supports JPEG picture formats
Thumbnails preview
Supports BMP picture formats
2Video Decode and
Movie Formats
Supports MJPEG
Supports H263, H264
Supports AVI, MOV movie formats
Supports 3gp movie format
Supports SRT Subtitle format.
3Music Formats Supports PCM, ADPCM audio formats
Supports WMA/OGG/MP3
4Card Reader
Interface (for
selected models)
Supports SD memory card
Supports SDHC memory card
5USB Interface Supports mass storage class
Supports USB2.0

16
English
Supported photo formats
NOTE: JPEG header size must be under 512 Kbytes.
Supported music formats
Image type (ext
name) Sub type Encode type Max pixels
Jpeg / Jpg Baseline YUV420 No Limitation
YUV422
YUV440
YUV444
Progressive YUV420 5120 X 3840
YUV422
YUV440
YUV444
BMP No Limitation
Music type (ext name) Sample rate (KHz) Bit rate (Kbps)
MP3 8-48 8-320
WMA 22-48 5-320
OGG 8-48 64-320
ADPCM-WAV 8-48 32-384
PCM-WAV 8-48 128-1536
AAC 8-48 8-256

17
English
Supported video formats
NOTE: B-Frame function is not supported.
Supported subtitle formats
NOTE: Mixed code in subtitle files is not supported.
File
format
Video
format
MAX
res
MAX bit
rate
Frame
rate
Audio
format Remark
AVI
MKV
XVID
MPEG-2/4
H.264
M-JPEG
WMV3
1080P 30Mbps 30fps AC3
DTS
MPEG1/2/3
PCM
ADPCM
AAC
No support VC-1 AP
H. 264 support less
than 6 reference
frames
No Support AC3-
HD,DTS-HD
TS MPEG-2
H.264
1080P 30Mbps 30fps AC3
DTS
MPEG1/2/3
LPCM
AAC
H. 264 support less
than 6 reference
frames
No Support AC3-
HD,DTS-HD
DAT
VOB
MPG
MPEG
MPEG-1
MPEG-2
1080P 30Mbps 30fps MPEG1/2/3
AC3
DTS
LPCM
No Support AC3-
HD,DTS-HD
MOV
MP4
3GP
MPEG-4
H.264
1080P 30Mbps 30fps AC3
PCM
AAC
H. 264 support less
than 6 reference
frames
RM
RMVB
RV3
RV4
720P 5Mbps 30fps Cook
(RA6)
AAC (RA9)
RACP
(RA10)
-
WMV WMV3 1080P 25Mbps 30fps WMA2
WMA3
No Support VC-1
AP
Format Font Subtitle Size
Standard SRT UTF-8/ UTF-16 4bits up to 448x200
2bits up to 896x200

18
English
Supported document formats
File format Support
version
Pages/lines
limitation
Size
limitation Remark
Adobe PDF PDF 1.0 Up to 1000 pages
(One File)
Up to
75MB
-
PDF 1.1
PDF 1.2
PDF 1.3
PDF 1.4
MS Word British
Word 95.
Because office
viewer does not load
all pages of MS
Word file at the
same time, there are
no obvious
limitations of page
and line.
Up to
100MB
Not
support
Bold Text
in Simple
Chinese
font
Word 97,
2000, 2002,
2003.
Word
2007(.docx),
2010(.docx)

19
English
MS Excel British Excel
5, 95.
Row Limit: up to 595 Up to
15MB
Not
support
password-
protected
sheets
Excel 97,
2000, 2002,
2003.
Column Limit: up to
256
Excel
2007(.xlsx),
2010(.xlsx).
Sheet up to 100
Office XP
Excel
Note: Any one of
three limitations
above can not
appear on one excel
file simultaneously.
MS
PowerPoint
British
PowerPoint
97.
Up to 1000 pages
(One File)
Up to
19MB
No
support
SlideShow
order
PowerPoint
2000, 2002,
2003.
PowerPoint
2007(.pptx).
PowerPoint
2010(.pptx),
.
Office XP
PowerPoint.
PowerPoint
presentatio
n-2003 and
earlier(.ppx)
PowerPoint
presentatio
n-2007 and
2010(.ppsx)

20
English
eDisplayPro Management for
Windows/Mac OS
Adjust projector source to LAN/WiFi.
NOTE: To utilize the Mirroring Display function (optional), make
sure you have updated the firmware to the latest version from
www.acer.com, and use the acer USB WiFi adapter.
System Requirements:
•Windows
Minimum requirement
Recommend system settings
Component Requirement Remark
CPU Dual Core Intel Core i 1.6 GHz or
higher
ATOM and Celeron are not
supported
Graphic card Intel, nVIDIA or ATI graphic card
with 64MB VRAM or above
Operating
System
Windows XP SP3, Vista SP2, Win 7
SP1 and Win 8
Not support Starter version
HDD 40MB free space 40MB free space
CPU Dual Core Intel Core i5 2.4Ghz
Memory DDR 4GB and above
Graphic card 256MB VRAM or above
Operating System Windows 7 SP1
