Acer ACTAB821 User manual

• For trac safety, do not use earphones while driving or cycling.
• This product is capable of producing loud noises which may damage your hearing.
It is recommended to place the product at a safe distance from your ear.
Exposure to Radio Waves
• Your mobile is designed not to exceed the limits for exposure to radio waves (radio
frequency electromagnetic elds) recommended by international guidelines.
• The guidelines were developed by an independent scientic organization (ICNIRP)
and include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
• The radio wave exposure guidelines use a unit of measurement known as the
Specic Absorption Rate, or SAR. The SAR limit for mobile devices is 2.0 W/kg.
• Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certied power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for this device model are:
• Body SAR : 0.998 W/Kg (10g)
• During use, the actual SAR values for this device are usually well below the values
stated above. This is because, for purposes of system eciency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
Built-in Battery Care
• Your product is powered by a built-in rechargeable battery.
• The battery can be charged and discharged hundreds of times, but will eventually
wear out.
• Unplug the charger from the electrical plug and the product when not in use.
• Do not leave a fully charged battery connected to a charger, since overcharging
may shorten its lifetime.
• If left unused, a fully charged battery will lose its charge over time.
• Leaving the product in hot or cold places, such as in a closed car in the summer
and winter conditions, will reduce the capacity and lifetime of the battery.
• Always try to keep your device in a cool, moisture-free environment that’s less
than 32°C. A product with a hot or cold battery may not work temporarily, even
when the battery is fully charged. Battery performance is particularly limited in
temperatures well below freezing.
• If you plan to store your device for longer than six months, charge the battery for
an hour every six months to keep it fresh.
• The unit should be fully recharged after using the device each time. This will keep
the health of the battery.
Safety Warnings
• Read all the instructions carefully before using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit onto a third party, make sure to include this
manual.
• The device is restricted to indoor use only when opening in the 5G WLAN band in
the following countires:
AT BE BG HR CY CZ DK
EE FI FR DE EL HU IE
IT LV LT LU MT NL PL
PT RO SK SI ES SE UK
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any doubt about it working
normally, or if it is damaged in any way - switch o, unplug from the mains socket
and consult your dealer.
Wireless Devices
• Wireless devices can transmit radio frequency (RF) energy, whenever batteries are
installed and the wireless device is turned on (If it has an On/O switch).
Temperature
• Avoid extreme degrees of temperature, either hot or cold. Place the unit well away
from heat sources such as radiators or gas / electric res.
• Avoid exposure to direct sunlight and other sources of heat.
Naked Flames
• Never place any type of candle or naked ame on the top of or near the unit.
Interference
• Do not place the unit on or near appliances which may cause electromagnetic
interference. If you do, it may adversely aect the working performance of the unit,
and cause a distorted sound.
Audio Safety
• Listening to loud sounds for prolonged periods of time may permanently
damage your hearing.
• Before putting on earphones, turn the volume down then put the earphones on
and slowly increase the volume until you reach a comfortable listening level.
Battery Warning!
• The battery used in this product may present a risk of re or chemical burn if
mistreated.
• Do not attempt to open the product or replace the battery. It is built-in and not
changeable. Use of other batteries may present a risk of re or explosion and the
warranty will be terminated.
• Only recharge your battery with the provided approved USB cable designated for
this product.
• Dispose of batteries according to local regulations. Please recycle when possible.
Do not dispose as household waste or in a re as they may explode.
• Batteries may explode if damaged.
Wall Charger
• Always insert the USB device in the correct direction. Failure to do so may result in
damage to the USB device and this unit.
• Only use with products designed to be powered or charged via a USB socket.
• The power supply must be located near the unit and should be easily accessible.
• Do not use the charger when it is damaged.
• Do not use with a damaged USB charging cable as it can cause overheating and
damage to your device.
• Do not drop, tamper, disassemble or attempt to repair the unit by yourself.
• Do not immerse it in water or expose it to wet conditions.
• For IT equipment use only.
• This unit is designed for indoor use only.
• This equipment is a Class II or double insulated electrical appliance. It has
been designed in such a way that it does not require a safety connection to
electrical earth.
• AC voltage: This symbol indicates that the rated voltage marked with the
symbol is AC voltage.
• DC voltage: This symbol indicates that the rated voltage marked with the
symbol is DC voltage.
• If the devices does not power on or system crashes, please
charge the battery for half an hour and then press and hold the
on/o button for more than 10 seconds until the device turns
o. Then switch it on again in normal way.
• If the device cannot wake up from sleep mode, please press
and hold the On/O button for more than 10 seconds until the
device turns o. Then switch it on again in normal way.

ACTAB821-Safety-200914V2
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
EU Representative
DSG Retail Ireland Ltd (259460)
3rd Floor Oce Suite
Omni Park SC, Santry, Dublin 9, Republic of Ireland
Specications
Tablet
Model ACTAB821
Processor MediaTek™ MT8168B ARM Cortex-A53
Quad-Core Processor (@ 2.0GHz)
Operating System Android™ 10
Display 8” (800 x 1280) IPS panel
with 10 points multitouch
Audio Mono front speaker
Memory 2GB Low-Power LPDDR4
Battery capacity 4000mAh
Storage 16GB – Expendable by an additional 512GB
with Micro SD card
Ports TYPE C 2.0 / 3.5mm Audio Jack / Micro SD Card slot
Camera Front 2M / Rear 5M
Connectivity Dual Band WIFI, Bluetooth 5.0
GPS YES
Microphone YES
Frequency Range and
Max. Radio Frequency
Power Transmitted
Bluetooth: 2400 – 2482 MHz, Max power (EIRP): 6 dBm
2.4G Wifi: 2410 – 2474 MHz, Max power (EIRP): 20 dBm
5G Wifi: 5178 – 5242 MHz, Max power (EIRP): 16 dBm
5G SRD: 5743 – 5827 MHz, Max power (EIRP): 15 dBm
GPS Receiving
Frequency 1575.42 MHz
Dimensions 208.3 x 124.5 x 9.5 mm
Weight 330g
Built-in Battery
Model U30100103P
Battery Type Li-ion Polymer Battery
Battery Rating 3.7V 4000mAh 14.8Wh
Designation Code 1ICP3 / 100 / 103
Manufacturer Shenzhen Utility Power Source Co., Ltd
Dimension 3 x 100.5 x 104mm
Net Weight 70g
Wall Charger
Energy related Products (ErP) Directive
Model JK050200-S37BSVU
Input voltage AC 100-240 V
Input AC frequency 50-60 Hz
Output voltage DC 5.0 V
Output current 2.0 A
Output power 10.0 W
Average active efficiency 78.7 %
Efficiency at low load (10%) N/A
No-load power consumption 0.07 W

8” Tablet
Instruction Manual
ACTAB821

Contents
Unpacking............................................................................. 4
Product Overview................................................................. 5
Setup at the First time.......................................................... 6
Power On/O ........................................................................ 6
Charging Your Tablet ............................................................ 7
Connecting to the Internet .................................................. 7
Touching and Typing............................................................ 8
Home Screen......................................................................... 9
Screen Buttons.................................................................... 10
Using the Cameras.............................................................. 11
Tablet Updates.................................................................... 12
Google Play ......................................................................... 12
Force shutdown/reboot ..................................................... 12
Troubleshooting ................................................................. 13
Specication ....................................................................... 14

4
Thank you for purchasing your new
product.
We recommend that you spend some time reading
this instruction manual in order that you fully
understand all the operational features it oers. You
will also nd some hints and tips to help you resolve
any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
Unpacking
Remove all items from the packaging. Retain the packaging.
If you dispose of it please do so according to local
regulations.
The following items are included:
Main unit Instruction manual
USB cable Mains adapter
Instruction
Manual

5
Front View
Product Overview
Rear View
Speaker Microphone
Power button
Pinhole reset
button
Volume control
SD Card Slot Earphones socket
Front camera Rear camera USB charging port

6
Setup at the First time
1. Press and hold the Power button for 2-3 seconds.
2. Startup Wizard
3. The rst time you start up the tablet, the startup wizard
will help you set up:
- Language
- WiFi connection
- Date & time
- Your name
- Location service options
- 3rd party apps
We strongly recommend that you open a Google
Account (you need this to download new apps)
and we recommend that you answer yes to back
up your tablet to the Google Account. This will save
your les and settings in case you need to restore
your tablet to factory defaults at any point.
Power On/O
1. During standby mode, press the Power button to turn
on the tablet.
2. At the Start-up screen, swipe up from the bottom of the
screen to unlock.
3. Once you’ve arrived at the Home screen, you can begin
using the tablet.
4. Press the Power button to switch to standby mode.
If you are not using the tablet for a long time, you
can press and hold the Power button to shut it
down completely.

7
Connecting to the Internet
In order to connect to the internet, you will need the
following:
• A wireless router or an access point with a broadband
internet connection.
• The name of your network (SSID), as well as the password
or other credentials, if your network is secure.
The wireless router must support WiFi 802.11 a/b/g/n/ac
connections.
Go to SETTINGS > Network & internet > WiFi
Tap on WiFi to activate wireless connectivity. The tablet
will scan for available WiFi networks within range. Secured
networks will require a password. Once you have successfully
entered your information the tablet will remember your
settings.
Charging Your Tablet
It is recommended to fully charge the tablet before rst use.
To charge the tablet,
• Plug the USB cable into the wall charger.
• Attach the other end to the USB-C input on the tablet.
• Plug the wall charger into a wall socket.
When the tablet is ON and charging, the battery icon will
pulsate.
A complete battery charge may take up to 3 hours. It is
normal for the tablet to get warm while charging, playing
games, or streaming video.
Battery life will vary depending on usage.
Leave the tablet in a well ventilated area while
charging.

8
Touching and Typing
To select an item on the screen, simply tap
it once with your ngertip. Some items may
require you to “double-tap”.
To type in to a text eld (e.g., when inputting your name , or
a web address), tap the text eld. The on-screen keyboard
will appear, and allow you to type the information you wish
to enter.
Touch and Hold: Keep your
nger on an on-screen item
until it glows or activates an
alternate menu.
Drag: Move an App or
object by touching and
holding the image, then
moving it to the destination.
Slide: When there are extra
“screens” to the side, slide
one or more ngers from
one side to another.
XXXXX
XXXXX

9
Home screen
On the rst home screen, there is a Google Search Bar and
some useful apps.
Add a widget to a home screen
Press and hold anywhere on the home screen except the
icons, select WIDGETS from the pop up menu, press and
hold the widget you want to add, then drag it to where you
want to place it, and release.
Change the wallpapers
Press and hold anywhere on the home screen except the
icons, select WALLPAPERS from the pop up menu, and then
choose your preferred wallpaper.
Move an app to another screen
Press and hold an app that you want to move, drag it to
where you want to place it, then release.
Uninstall an app
Press and hold the app that you want to uninstall, drag to
Uninstall, and then release and tap OK.
You can customize your home screen at any time.
Some of the system apps cannot be uninstalled.
Home Screen

10
Back button
Tap to return to the previous page.
Home button
Tap to return to the default home screen.
Recent button
Tap to view recent apps. Then you can do the following.
1. Tap an app to open it.
2. Swipe an app window up to close it.
3. Select CLEAR ALL to stop running all apps.
Screen Buttons

11
Swipe up from the bottom of the screen to show all apps,
select Camera app.
Taking photos and videos
You can take photos and record videos with your tablet’s
built-in camera.
• Tap to take a photo.
• Tap to record a video.
• Tap to switch between the front and the rear camera.
• Tap / to open or close HDR.
Taking screenshots
Press and hold the Power button and the Volume down
button at the same time.
Viewing pictures and videos
Photos, videos and screenshots are stored in the tablet’s
internal storage. You can view your photos and videos by
using the following methods:
• Tap the thumbnail when using the Camera app.
• Go to Photos app.
Using the Cameras

12
Tablet Updates
To ensure the tablet runs smoothly it is recommended to
perform periodic system software updates, especially during
initial set up of the tablet. You may receive notications (on
the Lock screen) from time to time that software updates are
available.
Tap the notication to be directed to the update.
Alternatively, you can go to Settings > About Tablet >
Updater > Check for Updates
Google Play
The rst time you sign in on Google Play, updates will
automatically start downloading on to the tablet. The
download icon will appear in the status bar at the top left
of screen.
Installing a new application while multiple apps are
downloading will reduce tablet speed and performance.
After all downloads and updates have been installed, the
tablet will resume normal operating performance.
To view the progress of downloads working in the
background, swipe down from the top edge of the screen.
Force shutdown/reboot
There are 2 methods to force shutdown the tablet.
• Press and hold the Power button for about 10 seconds
until the tablet turns o.
• Use a toothpick to punch into the Pinhole reset button.
Then turn it on again in the normal way.
To perform an update, you must be connected to
WiFi.

13
Troubleshooting
If your tablet is frozen:
Press the Power button for at least 10 seconds or use the
hardware reset.
To use the Hardware reset, press the“pinhole reset” button
by using a sharp object such as a toothpick.
If your tablet doesn’t turn on:
Charge your tablet then switch on normally.
If this does not work, press the “pinhole reset”button by
using a sharp object such as a toothpick.
If your WiFi reception is poor:
• Make sure you are not far from the WiFi hotspot.
• Update the rmware of the tablet.
• Reset and redeine your connection parameters.
• Reset your wi setting, go to Settings > Advanced >
Reset options > Reset WifFi, mobile & Bluetooth >
Reset settings.
• Contact your WiFi connection provider.
If you want to extend the life of your battery:
Decrease the screen brightness and turn of the wireless
connections if not in use.
If your tablet is functioning too slowly:
Close all apps which are not currently being used.
If you want to restore your product (erase all your
settings or forgotten password) :
If your tablet is turned on:
1. Go to Settings > Advanced > Reset options >
Erase all data (factory reset) > Delete all data
2. This will erase all your les, settings and applications, so
make sure you have backed-up your data in your Google
Account.
3. When you restart your tablet it will open the Startup
wizard again, follow the onscreen instructions.
4. Access your Google Account to retrieve your backed-up
data in Google.

14
Specication
Model ACTAB821
Processor MediaTek™ MT8168B ARM Cortex-A53
Quad-Core Processor (@ 2.0GHz)
Operating System Android™ 10
Display 8” (800 x 1280) IPS panel
with 10 points multitouch
Audio Mono front speaker
Memory 2GB Low-Power LPDDR4
Battery capacity 4000mAh
Storage 16GB – Expendable by an additional
512GB with Micro SD card
Ports TYPE C 2.0 / 3.5mm Audio Jack /
Micro SD Card slot
Camera Front 2M / Rear 5M
Connectivity Dual Band WIFI, Bluetooth 5.0
GPS YES
Microphone YES
Dimensions 208.3 x 124.5 x 9.5 mm
Weight 330g
Declaration of Conformity (RED)
Hereby, DSG Retail Ltd. declares that the radio
equipment type [ACTAB821] is in compliance with
Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
https://www.teamknowhow.com/
Click on SEARCH and enter the model number.

15
Visit Partmaster.co.uk today for the easiest way to buy electrical
spares and accessories. With over 1 million spares and accessories
available we can deliver direct to your door the very next day. Visit
www.partmaster.co.uk or call 0344 800 3456 (UK customers only).
Calls charged at National Rate.
Notes for battery disposal
The batteries used with this product contain chemicals that
are harmful to the environment.
To preserve our environment, dispose of used batteries
according to your local laws or regulations. Do not dispose
of batteries with normal household waste.
For more information, please contact the local authority or your
retailer where you purchased the product.
The symbol on the product or its packaging indicates that
this product must not be disposed of with your other
household waste. Instead, it is your responsibility to
dispose of your waste equipment by handing it over to a
designated collection point for the recycling of waste
electrical and electronic equipment. The separate collection and
recycling of your waste equipment at the time of disposal will help
conserve natural resources and ensure that it is recycled in a manner
that protects human health and the environment.
For more information about where you can drop o your waste for
recycling, please contact your local authority, or where you purchased
your product.
The Bluetooth® word mark and logos are registered trademarks
owned by the BluetoothSIG, Inc. and any use of such marks by DSG
Retail Limited is under license. Other trademarks and trade names are
those of their respective owner.
Google, Android, Google Play and other marks are trademarks of
Google LLC.
The Acer trademark is licensed to DSG Retail Limited by Acer
Incorporated, a Taiwan R.O.C. company.
Currys.co.uk
All the support you need.
Whether it’s a tech emergency or
you need plain good advice, we’re
always on hand to help.
UK: 0344 5611234
IRE: 1 890 818 575

IB-ACTAB821-200914V2
