Acesonic KOD-2400 User manual

1
KOD-2400
KARAOKE-ON-DEMAND JUKEBOX
®
Uaer Manual
ank you for purchasing Acesonic’s KOD-2400 Ka-
raoke-On-Demand Jukebox. Acesonic takes pride in
providing its customers with only the most advanced
and highest quality products on the market.
With proper care and use you will get many years of
satisfying use from your Acesonic product.
Be sure to keep original packaging in case re-shipping
is required for returns or repairs.
Care and cleaning: Use a slightly damp cloth to clean
the front panel and other surfaces of the KOD-2400.
Do not use the device in areas that are wet or prone
to dampness. Always allow sucient room around the
device to provide sucient air ow for cooling.
First Things First
Before using your KOD-2400, there are a few things
you should do and know:
• Check to see that your local power outlets supply
the correct voltage for the AC adapter.
• Except for the hard drive compartment, do not open
the device as there are no user-serviceable parts inside.
For repairs, contact the local distributor, an authorized
service center or Acesonic’s U.S. headquarters.
• When the system will not be used for a long time,
disconnect the power plug from the wall and remove
all connecting cables for proper storage.
Rear Panel
Front Panel
NOTE
Your Acesonic KOD-2400 Karaoke-On-Demand arrives with everything you need to start making music and per-
forming except a microphone and speakers.ese can be obtained from Acesonic, or you can use any standard audio
equipment that conforms to contemporary standards.
User Manual

2
Getting Started
Your Acesonic KOD-2400 Karaoke-On-Demand
Jukebox is designed for years of enjoyment. Please
take a moment to review the following instructions
for proper use and care of the player.
Included Accessories
Your KOD-2400 includes the following items:
• ACESONIC KOD-2400 Karaoke Player (1)
• Audio/Video Connecting Cable (1)
• Remote Control (1)
• USB Male/Male Cable (1)
• HDMI Cable 10FT (1)
• VGA Extension Cable 10FT (1)
• Network Connecting Cable, Cat 5E 10FT (1)
• ACESONIC 19” Black Touch Screen (1)
• Power Adapter and Power Cord (1)
• Touch Screen Mouse Cable, Y-Shape (1)
• User Manual (1)
If your box is missing any of these items, contact your
Acesonic dealer.
Precautions
Player precautions:
• Avoid moisture, water and dust.
• Do not place the player in a moist environment or
where dust will build up, such as near a fan.
• If exposed to water, immediately turn o the
player and unplug. Consult your dealer or an autho-
rized service center — using the player in this state
could cause res or fatal electric shocks.
• Avoid high temperatures. Do not place the player
in direct sunlight or near any heaters.
• Unplug the player when it will not be in use for an
extended period of time.
• Use the plug, not the cord, to disconnect the player
from its wall outlet.
• Never handle the power cord with wet hands.
Replace the cord if it is damaged or if wires are
exposed, and check it every few months for signs of
wear and use.
Installation precautions:
• Select an area that is level, dry and has a moderate
temperature all year.
• Do not use the player on its side.
• Do not place the player next to items that vibrate,
Table of Contents
Getting Started....................................................2
Player Specications............................................3
SD/USB Specications (Compatible Media)......3
Video Signal Formats..........................................3
Audio Signal Formats..........................................3
Cleaning ..............................................................3
Front/Rear Panel Functions and Operation ........4
Remote Control Functions..................................5
KOD-2400 Connections................................. 6-7
Power Connection...............................................8
How to Turn O Correctly .................................9
Basic Karaoke Functions .....................................9
Searching Song in Single Screen Mode ..............9
Searching Song in Dual Screen Mode ..............10
Basic Karaoke Functions (Dual Screen Mode)..13
Advanced Computer Program Function............13
Backup...............................................................13
Add Songs.........................................................13
Troubleshooting ................................................15
Safety, Warnings and Precautions......................16
Technical Specications ....................................18
FAQ (Frequently Asked Questions)..................18
Register 6 month free New Songs Download
Account .............................................................19
NOTE
Your Acesonic KOD-2400 Karaoke-On-Demand arrives with everything you need to start making music and per-
forming except a microphone and speakers.ese can be obtained from Acesonic, or you can use any standard audio
equipment that conforms to contemporary standards.

3
such as speakers.
• Do not put heavy objects on the top of your player.
• Allow space for your player to ventilate. e vents
on your player are designed to circulate air and
moderate its internal temperature. Blocking these
vents may damage the player.
User Repair Precautions
No parts of this player are to be serviced by the user.
If the player fails to operate or if you feel it needs
servicing, turn o the player, unplug it and contact an
Acesonic dealer or service center.
Player Specifications
• One (1) year manufacturer warranty
• Lifetime technical support
• Worldwide video compatibility with settings for
both NTSC and PAL video formats
• Universal power supply: AC 100 ~ 240V
• Player dimensions: 430mm (W) x 305mm (D) x
64mm (H)
• Designed in the U.S.A.
USB Specifications (Compatible Media
Fromats)
Your KOD-2400 is a robust player that can accept
a wide variety of media formats (USB ash/thumb
drives formatted in FAT32).
• MPEG1 (dat, mpg)
• MPEG2 (vob,mpg)
• MPEG4 (avi, divx, xvid)
• CDG + MP3
Some methods of encoding (“ripping”) audio and
video formats may aect playback. Use standard or
pre-set encoding settings, if possible.
Files defect may also aect video quality.
e media formats not described in this manual are
not compatible with the unit.
Video Signal Formats
e KOD-2400 supports NTSC, a broadcast format
generally found in the U.S., Canada, most countries in
South America, Japan, South Korea and the Philip-
pines.
e KOD-2400 also supports the PAL format, which
is used in many parts of Europe, Asia and South
America.
Check your video device to see which standard it is
compatible with.
Audio Signal Formats
e KOD-2400 features RCA stereo outputs.
Other features
e KOD-2400 is a multi-function professional
hard drive Karaoke-On-Demand jukebox.is
KOD is perfect for Club, DJs, KJs, Pub, rentals,
restaurants, other public entertainment or if you
simply want to have the ultimate karaoke system for
any occasions!
• Supports High Capacity Of Hard Disk (up to
4TB).
• Easy to add songs from the PC program (only
standard MPEG1, MPEG2 & MPEG4 support-
ed).
• Easy to nd your songs. You can search songs by
Artists, Song Title, Genre, Language, and Song
Number.
• Playback songs and pictures from SD cards or
USB ash drivers.
• Use a mouse, remote controller or touch screen to
operate the system.
• Full karaoke function.
• Save your favorite songs to your personal account
(by number). Next time, simply login to your ac-
count to load all your favorite songs.
Cleaning
• Use a soft cloth to clean the surface of the unit.
• Always wipe from the center to the edges.
• DO NOT use circular motions.
• DO NOT use household cleaning products on
the unit, unless they are specically formulated for
cleaning player products.
Reminder: Never attempt to play cracked or unsp-
ported les with your player. It may cause the player
to malfunction.

4
Front Panel Functions and Operation
1. POWER: Press this button to toggle the KOD-
2400 on and o.Turning o the power on the player’s
front panel will not allow it to be powered on by the
remote control.
2. USB: is interface allows the KOD-2400 to access
mass storage devices such as USB/ash/thumb drives
as long as they are formatted as FAT32 (Supports up
to 16GB).
3. REMOTE SENSOR: Receive signals from the
remote controller.
4. ENTER: Press this button to conrm selections.
5. CANCEL: Press this button to cancel or clear
inputs.
6. VOCAL: Press this button to isolate the left or
right audio channel.
7. RETURN: Press this button to return to the previ-
ous menu or last step.
8. NUMBERIC KEYS: Press these buttons to input
song numbers.
9. DELAY CONTROL: is switch control eecter.
10. ECHO CONTROL: Press to adjust the echo of
a karaoke singer during their performance.
11. VOL CONTROL: is switch control volume.
12-13. MIC 1 & 2: Microphones input jacks
14. TRABLE: is switch control high sound.
15. BASS: is switch control bass sound.
vious menu or last step.
Back Panel Functions and Operation
1. MOUSE INPUT (Green): For connectiong a
PS/2 mouse or touch screen mouse connect.
2. KEYBOARD INPUT: For touch screen, extension
control panel & MCU updating.
3. VGA OUTPUT: For connecting a Touch Screen
or a Monitor screen.
4. EXT INPUT: For Acekaraoke reserved.
5. SATA 1 &2 PORTS: For connecting the two
internal SATA hard drives.
6. IR PORT: For Acekaraoke reserved.
7. USB PORT: For support USB devices play and
add new songs.
8. HDMI PORT: For connecting to TV or Amplier.
9. TV-AUDIO-L OUTPUT: is connection is for
the RCA audio output.
10. TV-AUDIO-R OUTPUT: is connection is for
the RCA audio output.
11. TV-VIDEO-1 OUTPUT: is connection is for
the RCA video output.
12. TV-VIDEO-2 OUTPUT: is connection is for
the RCA video output.
13. Power Input: AC 100 ~ 240V / 50~60 Hz
Note: MOUSE PORT can connect to a mouse or
touch screen. Please select the right one for your
touch screen according to the type of connection.

5
Remote Control Functions
1. POWER: Press this button to toggle the KOD-2400 on and
o. Using the remote POWER key will put the KOD-2400 in
standby. Using the POWER button on the player’s front panel
will shut it down completely. Power o password: 999999 for
save shutdown.
2. MENU: Main Page.
3. b / # : KEY +/- CONTROL
4. VOLUME + -: Press this buttons to adjust the music volume.
5. PAUSE/PLAY: Press this button to begin play; press again to
pause and press it again to resume.
6. NEXT: Press this button to stop playing current song and play
the next song.
7. PLAYLIST: Songs in Playing Queue.
8. PRIORITY: Add the song as First into Playing Queue.
9. REPLAY: Press this button to repeat the current playing song.
10. EXPRESSION: Expression.
11. VIDEO: Touch Screen show video like TV.
12. PgUp/PgDn: Press this button to advance or return to previ-
ous pages.
13. SETUP: Press this button to set the KOD-2400’s user pref-
erences. Setup Password is 4652.
14. VOCAL: Press this button to isolate the left or right audio
channel.
15. ARROW KEYS: Up/Donw/Right/Left Arrow Keys.
16. OK: Press this button to conrm selections.
17. USB: Press this button to play songs from USB.
18. RETURN: Press this button to return to the previous menu.
19. KARAOKE: Press this button to return to karaoke mode.
20. WORD COUNT: Show word number.
21. FAVORITE: Press this button to show the Favorite page.
22. ARTIST: Press this button to search by artist.
23. TITLE: Press this button to search by song title.
24. LANGUAGE: Press this button to search by language.
25. CATEGORIES Press this button to search by category.
26. NUMERIC KEYS: Press these buttons to input song selec-
tions.
27. TV / MONITOR: Press this button switch TV/Monitor.
28. CANCEL: Press this button to cancel selections.

6
External Storage Devices
e KOD-2400 can accept playing music and pictures
from most USB drives. ese drives are also called
thumb and ash drives and are often used to store
and transport music les. To access the music on these
devices, insert the ash drive or the USB cable into
the USB port illustrated above.
Please note that the KOD-2400 is not a computer.
It cannot support larger, desktop-sized hard drives,
or any Flash Drive device with an abundance of les.
External storage devices will not be recognized if
unsupported le types are detected.
For best compatibility, format ash in FAT32. If you
have problems formatting in FAT32, please refer to
your computer’s operating manual.
A/V, Monitor, Touch Screen Connections
Ensure that your KOD-2400 is turned o and un-
plugged before connecting it to a TV/Touch Screen
and audio system.
Also, check that your audio and video components
have the appropriate inputs. Refer to their manuals if
you are not sure.
If you are going to use dual-screen mode, make sure
you have a touch screen or a PC monitor + a PS/2
mouse connecting your KOD-2400 as a purely kara-
oke device. Rrefer to the following diagram.
If you use touch screen, the touch screen cable con-
nect to KOD-2400’s mouse port.
Inputs for the microphones will be found on the front
panel of the KOD-2400.
KOD-2400 Connections

7
Touch Screen Connection
SATA Connection
USB Male-to-Male Cable
Use an USB Male-to-Male Cable, your PC can access
the Hard Disks and run KTVManager software to
manage KOD-2400 song library.
Plug in KOD-2400’s SATA 1/2 port and PC’s USB
port and then turn on the KOD-2400. Your PC will
see one of the two Hard Disks in KOD-2400 player.
Run KTVManage.exe, you can add songs into KOD-
2400 and many things. We will introduce it’s func-
tions later.

8
Power Connections
When you have completed connecting your KOD-
2400 to your video and audio components, refer to
the diagram below to connect the player to the power
cord and an appropriate electrical outlet.
Please note that the KOD-2400 uses 100 V to 120 V,
at 50/60 Hz. It is compatible with electrical outlets in
North America and all US states.
Installation of Foot Stand

9
Random Play
After the KOD-2400 boots up and it will play the
hard drive’s collections of songs randomly.
Auto Play List
If the auto play list is not empty, the KOD-2400 will
paly the songs in the list.
is mode is useful for competitions, demonstrations
and background music.
Selecting Songs
e KOD-2400 oers a number of dierent ways to
nd, play and organize the songs you access the most.
Select by Song Number
1. Power on the KOD-2400 by pushing the POW-
ER button on the front panel. A copyright notice
page should show up immeditaly and the player will
go through its boot process for a few minutes.
2. You are now in karaoke mode.
3. Press [6] key enter the page and then input its
corresponding numeric code on your remote control
using the NUMERIC KEYS. Songs and their codes
may have been provided in a folder and the Song
Book.
4. Push the [CANCEL] button if you’ve entered a
wrong number.
5. Push [OK] to add song to the playlist and then it
will start playing the songs.
6. Push [PRIORITY] to add the song at top in the
playlist and it it will play next.
7. Repeat step 3 to enter more songs.
Select by Singer
1. Push [1] to enter the page in which you can nd
the song by a singer.
2. Select a song using the Up/Down button in the
remote control’s DIRECTION CONTROL.
3. Push [OK] to add song to the playlist and then it
will start playing the songs.
4. Push [PRIORITY] to add the song at top in the
playlist and it it will play next.
Prioritizing a Song
To move a song to the top of a playlist:
1. Select a song using the Up/Down button in the
remote control’s DIRECTION CONTROL.
2. Press the [INSERT] key.
Pressing [INSERT] instead of the [OK] key during
song search will also put it at the top of the playlist.
Replaying a Song
To play a current song again from the start, press
[REPLAY] on the remote control or the unit’s front
panel.
Skipping a Song
To skip a song, press the [NEXT] button on the re-
mote control or on the unit’s front panel.
Selecting Songs by Single Screen Karaoke Mode
1. Power on the KOD-2400 by pushing the POW-
ER button on the front panel. A copyright notice
page should show up immeditaly and the player will
go through its boot process for a few minutes.
2. You are now in single screen karaoke mode.
Searching Songs in Single Screen Mode
Basic Karaoke Functions
How to turn the KOD-2400 Off Correctly
1. Press and hold [POWER] on the remote controller
for few seconds.
2. A text message will show up and ask you to input a
password.
3. Input default password “999999” then press [EN-
TER] to conrm.
4. Press [ENTER] again to turn o the KOD-2400.
5. By doing these steps, the KOD-2400 is in standby
mode.
6. If you want to power the KOD-2400 o, please
press [POWER] on the front panel of KOD-2400.

10
3. Push the [MENU] key on your remote control or
on the front panel of the player.
4. You will see a text-menu:
5. Navigate through the menus using the DIREC-
TION CONTROL on your remote. Push [RE-
TURN] on the DIRECTION CONTROL to
return to the last menu.
In single-screen play mode you can only use the re-
mote controller to access all the below functions.
Press [MENU] on the remote controller to display its
text menu in single-screen play mode.
ere is a number for each item shown on the TV
screen. You can select the corresponding number to
enter a category or press [
] directly on the
remote controller to move the cursor to the item you
choose then press [ENTER] to access.
ARTIST:
Press [1] directly to enter “Artist” sub-menu or
[] to select “Artist” then press [ENTER] to enter
its menu and then you can select an artist according to
the artist’s genre or select option “8” in the sub-menu
to show all artists.
Tips: You can also press [ARTIST] on the remote
controller to enter the “ARTIST” menu directly too.
SONG TITLE:
Press [ , ] to select the “Song Title” then press
[ENTER] or [2] directly to enter “Song Title” menu.
Input the rst letter of the song title to search a song.
For example: Song title is “Pretty Girl”. You can input
the rst letter of the song title “P”, then all songs
starting with the letter “P” will be listed on the screen
automatically.
Tip: You can also press [TITLE] on remote controller
to enter “Song Title” menu directly too.
GENRE:
Press [ , ] to select “Genre” then press [EN-
TER] or [3] directly to enter its menu.
Tip: You can also press [GENRE] on the remote con-
troller to enter the “Genre” menu directly too.
LANGUAGE:
Press [ , ] to select “Language” , then press
[ENTER] or [5] directly to enter then search a song
by language.
Tip: You can also press [LANGUAGE] on the re-
mote controller to enter the “Language” menu directly
too.
NEW RELEASES:
Press [ , ] to select “New Releases” then press
[ENTER] or [6] directly to enter then select a song
from the latest updated song list.
Tips: Press [RETURN] to return to the previous
menu; press [MENU] again to exit.
Make sure your karaoke mode is in Dual Screen
Karaoke Mode to access all functions (See P. 15 for
more information).
1. Power on the KOD-2400 by pushing the POW-
ER button on the front panel. A copyright notice
page should show up immeditaly and the player will
go through its boot process for a few minutes. en
the player will show the Main Page.
2. You are now in dual screen karaoke mode. If you
are in the single screen karaoke mode, please see
P.15 for how to change to dual screen mode.
3. Touch the icon on your touch screen or use
your mouse to click the icon.
4. You will see the following menu:
ARTIST:
Search songs by artist
1. Touch or click then it will
show a submenu of “ARTISTS”.
Searching Song in Dual Screen Mode

11
2. In this menu, you can use “INPUT INITIAL
LETTER” box to nd your desired artists. Artists
can be found by the rst letter of each word in art-
ist’s name when pressing the “FIRST LETTER
SEARCH” icon.
e search for “Air Supply”, for example, would be for
the letters “A” and “S”. Press “ [Delete]” icon to delete
wrong inputs.
3. After nding the artist, press the Artist’s picture to
nd desired songs.
SONG TITLE:
Search Song by Song Title
1. Touch or click then it will
show a submenu of “TITLE”.
2. In this menu, you can use “INPUT INITIAL
LETTER” box to nd your desired songs. Songs can
be found by the rst letter of each word in the song
title’s name. e search for “Amazing Grace”, for ex-
ample, would be for the letters “A” and “G”. Press
[Delete] icon to delete wrong entries. * is function
is only used for Chinese and English songs only.
3. After nding the desired songs, use your nger to
touch each song name to add songs to the playlist.
LANGUAGE:
Search songs by Language
1. Touch or click . e “LAN-
GUAGE” submenu will appear.
2. Touch or click your desired language to search
songs.

12
SONG NUMBER:
Search songs by Song Number
1. Touch or click . e “SONG
NUMBER” submenu will appear.
2. To access a song on the KOD-2400’s hard disk
drive, press or click its 6 corresponding numeric code
on the song number menu using the NUMERIC
KEYS. Songs and their codes may have been provided
in a folder.
3. e song title will be displayed if the numbers you
input are found in the song database.
4. Press or click ENTER to add the song to the re-
served list.
MOST POPULAR:
Search songs by Most Popular
1. Touch or click . e “MOST
POPULAR” submenu will appear.
2. Top Hist songs: e songs that have been played
the most will be listed in this category.
TOUCH WRITING:
Search Song by New Releases
1. Touch or click . e “Touch
Writing” submenu will appear.
2. e latest updated songs can be found in this cat-
egory.

13
FILE:
Please DO NOT rename or delete any system les
on the hard drive, otherwise, the KOD will not work
properly.
Backup
ڊⅼᓛ㇑⨶ࡽˈڊྭۉԭᐕ֌DŽ
⭘аọ86%䙓㐊䙓᧕䴫㞖઼.2'Ⲵ6$7$ᡆ
6$7$᧕DŽ
8VH86%WR86%WRFRQQHFW\RXU3&DQG
.2'ÿV6$7$RU6$7$86%SRUW
7XUQRQ.2'DQG\RXU3&VXSSRVHGULYHU
)?LVRQHRIWKHWZR7%+DUG'LVNV
ᔪ䆠ڊᮤⴔⲴۉԭDŽ䎧⻬㾱࠶ࡕۉԭޙػⴔⲴ᮷
Ԧ཮ ?.79?6<67(0?
%DFNXS?.79?6<67(0?GLUHFWRU\
1RWLQFOXGH621*?GLUHFWRU\
621*? ᮷Ԧ཮ᱟ⭘ֶ᭮ⅼᴢⲴˈ䙊ᑨᴳᖸབྷDŽ
6DYHEDFNXSWRRWKHUSODFHᆈࡠަᆳ⺜ⴔDŽ
ADD SONG
䴫㞖䙓᧕唎ⅼ₏࣐ⅼ˖
86%㐊䙓᧕䴫㞖઼唎ⅼ₏ˈว㹼唎ⅼ₏⺜ⴔлⲴ
.79?.WY0DQDJHUH[H
ᴹӋ󰪞֌䴰㾱ᱲ䙓᧕ޙ઼䚨ػ⺜⻏DŽ
Advanced Computer Program Functions

14
ᴹӋ󰪞֌䴰㾱ᱲ䚨䙓᧕ޙػ⺜ⴔDŽ
6XSSRVHZHDGGWKLVVRQJֻྲᡁف㾱࣐䙉俆
ⅼᴢ˖
In this windows, input the song’s information :
ⅼ˖
ⅼᴢ㐘㲏˖⻪ᇊ䚨аػ⋂ᴹ൘֯⭘Ⲵⅼᴢ㐘㲏
ⅼᱏ˖
䃎䀰˖
ֶⓀ˖䙊䙾☿㿭᢮ࡠⓆۉྭⲴⅼᴢ
࣐ᇶᯩᔿ˖⭘ᡧа㡜䚨⭘Ā❑࣐ᇶā
դୡ丣䓼˖㚢䚃˄а㡜ᱟᐖ㚢䚃  ৏ୡˈ
㚢䚃  դୡ˅
$IWHUDGGVRQJV\RXQHHGGRĀ䕨ࠪ2ā

䚨󰪘˖㑱億ѝ᮷

15
ADD AUTO PLAY LIST
Run KTVManager.exe
Go:㇑⨶㇑⨶!ޜ󰩾ࡇ㺘㇑⨶
ᗎᐖ䚺デ䚨󰪘ⅼᴢˈ␫࣐ࡠ䚺Ⲵデˈ䙉Ӌ
ቡᡀ⛪ޜ󰩾ⅼᴢDŽ
؞᭩ᆼᡀˈڊа⅑˖䗃ࠪ!㑱փѝ᮷!⺞ᇊ
Troubleshooting
For common problems, please consult the chart below.
If these suggestions do not solve your problem, please
call Acesonic Customer Service at [phone].
No Sound
• Inspect the KOD-2400 to conrm it is connected
to audio equipment and that the audio equipment
or TV is connected to the player.
• Check that volume levels on TVs and audio equip-
ment are audible.
• Check the cables connecting the player to audio
equipment or TV.
No Picture
• Check connections between TV and KOD-2400.
• Check the TV to see if its on the correct input or
channel to view the player.
Distorted Sound
• Check connections on the KOD-2400 and audio
equipment or television.
• Check input and volume settings on the audio
equipment or television.
Distorted Picture
• Check connections between TV and KOD-2400.
• Check the TV to see if its on the correct input or
channel to view the player.
• Select one video output — RCA Video – and
inspect the video cord.
Selected Song Won’t Play in Hard Disk Drive Mode
• Conrm the song is on the hard disk drive and
that it hasn’t been deleted.
No Power
• Check to see that the AC power cord is plugged
into the wall and the player.
No Microphone Volume
• Check microphone connection.
• Check microphone power.
• Set microphone volume on the front panel.
• Set microphone volume on the remote control.
Remote Won’t Work
• Ensure there’s a clear path between the KOD-

16
2400 and the remote control.
• Replace batteries.
• Try the remote out close to the player, pointing
directly at the sensor.
KOD-2400 Boots Up to a Blue Screen
• ere may be possible hard drive damage or data-
base corruption. Call Acesonic customer service at
[phone].
PC software & Firmware updated
• For a latest PC software & the unit’s rmware
updated, please visit http://www.acesonic.com/.
Safety, Warnings and Precautions
Mises en garde, precautions et procedures de sûreté
e lightning-with-arrowhead symbol inside a
triangle alerts the user that potentially dangerous
voltage in the product enclosure may constitute a risk
of electric shock.
e exclamation point within a triangle alerts the user
to important operating, maintenance, and servicing
information in this User Manual.
CAUTION
To reduce the risk of electrical shocks, re, and
possible injuries, you should not
• remove screws, buttons, antennae, jacks, or any
part of the enclosure; or
• expose the product to rain or moisture.
FCC ADVISORY (U.S.A.)
1. is equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. ese limits
are designed to provide reasonable protection against
harmful interference in a residential installation.
is equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try correcting the
problem by one or more of the following measures:
• Reorienting and/or relocating the receiving
antennae
• Increasing the distance between the radio/TV
equipment and the KOD-2400
• Connecting the radio/TV equipment to an outlet
on a dierent circuit than the one into which the
receiver is plugged
• If necessary, consulting the dealer or an
experienced radio/TV technician for help
2. IMPORTANT: When connecting the KOD-2400
to audio equipment, use only high-quality, shielded
cables such as what is supplied with this product.
Follow all installation instructions do not modify the
equipment in any way, as this could void your FCC
authorization to use the device in the U.S.
FOR CANADA/POUR LE CANADA
Caution: To prevent electric shock, match the wide
blade of the plug to the wide slot, and fully insert.
Attention: Pour eviter les chocs electriques, introduire la
lame la plus large de la che dans la borne correspondante
de la prise et pousser jusquau fond.
is product does not exceed the Class B limits for
radio noise emissions from digital devices as set out
in the Canadian standard for interference-causing
equipment (“Digital Apparatus, ICES-003” from the
Department of Communications).
Cet appareil numerique respecte les limites de bruits
radio electriques applicables aux appareils numeriques de
Classe B prescrites dans la normesur le materiel brouilleur
(“Appareils Numeriques, NMB-003” edictee par le
Ministre des Communications).
Important Safety Procedures
1. Read and follow these instructions, keep them
handy for reference, familiarize yourself with the
product’s operation, and heed all safety warnings.
2. Do not use this product near water, on wet surfaces,
or in places where moisture may accumulate. Do not
expose the device to dripping or splashing, and do
not place items lled with liquids – such as vases,
beverages, etc. – on top. Clean only with a dry cloth.
3. Do not block any ventilation openings or set device
on carpets or rugs. Maintain sucient room on all

17
sides for airow.
4. Do not position the device on or near radiators,
stoves, or other electrical equipment (such as ampliers)
that produce heat.
5. Do not defeat the safety purpose of a polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other, while a grounding-type
plug has two blades and one prong. e wide blade
and the prong are safety features. If the provided plug
does not t into your outlet, consult an electrician for
replacement of the obsolete outlet.
6. Protect the power cord from being walked on or
pinched, particularly where it is plugged in to an
electrical socket and the point where it exits from the
rear of the device.
7. Only use the attachments and accessories specied by
the manufacturer.
8. Use only with a cart, stand, tripod, bracket or table
specied by the manufacturer or sold with the device.
When using a cart, use caution when moving the cart.
9. Unplug the product during lightning storms or when
it will not be used for long periods of time.
10. Refer all servicing to qualied service personnel.
Servicing is required when the unit has been damaged
in any way, such as when the power-supply cord or
plug is damaged, liquids have been spilled or objects
introduced into the enclosure, the device has been
exposed to rain or moisture, the product does not
operate normally or it has been dropped.
11. Never push objects of any kind into this product,
through jacks or other openings, as they may contact
dangerous voltage points or short-circuit components,
thus causing re or electrical shock.
12. is product should be operated only from the type
of power source indicated on the product label and in
this User Manual. If you are not sure of the type of
power supplied to your home, consult your product
dealer or local utility.
13. An outside antenna system should not be located
in close proximity to overhead power lines, or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, be extremely careful not to
touch such power lines or circuits, as contact with
them could be fatal.
14. Do not overload wall outlets or extension cord
as this can increase the risk of re, power outages or
electrical shock.
15. When replacement parts are required, be sure the
service technician has used replacement parts specied
by the manufacturer or with the same characteristics
as the original part. Unauthorized substitutions may
result in re, electric shock or other hazards.
16. Following any servicing or repair of this product,
ask the service technician to perform the appropriate
safety checks to ensure the product is in proper
operating condition.
17. e product should not be mounted to walls or
ceilings except as recommended by manufacturer, with
mounting hardware approved by manufacturer.
18. If your product is not operating correctly or
exhibits a marked change in performance, and you
are unable to restore normal operation by following
procedures in this User Manual, do not attempt to
service it yourself. Opening the enclosure may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualied service personnel.
NOTE: With the proper care and maintenance, your
KOD-2400 Karaoke-On-Demand Jukebox will give
you years of dependable, enjoyable use. Make sure you
are using proper power sources and good (unfrayed)
cables at all times. Remember, any alterations or user
repairs performed on the device voids your warranty.

18
FAQ (Frequently Asked Questions)
1. No microphone sound? Check if the volume of
microphone is o.
2. Remote controller doesn’t work? Check batteries.
3. Can you save a queue list? No, but you can save
your favorite songs to My Favorite Folder.
4. No picture? Check if all video connections are cor-
rectly. If so, connect the KOD-2400 to the TV direct
and see if a picture shows up.
5. How do I connect the KOD-2400 hard disk drive
(HDD) to a PC or laptop? If your PC or laptop
doesn’t have a SATA connection, you need to use an
External Hard Drive SATA Enclosure /Docking
Station, 3.5-inch form factor with a USB interface,
to connect the KOD-2400 HDD to your computer.
6. How many songs can I record to my KOD-2400
HDD? is depends entirely on the HDD capacity
and the le format(s) in which you choose to save
your songs.
7. No Sound? Check if all audio connections are cor-
rect. If so, connect the KOD-2400 to the TV directly
and see if a picture shows up.
8. Song cannot be played? Check if the song exists in
the database.
Technical Specifications
Signal Format System NTSC, PAL
Frequency Response 20Hz–20KHz ± 3 dB
Signal-to-Noise Ratio > 80 dB
Channel Separation > 70 dB (1 KHz)
Dynamic Range > 70 dB (1 KHz)
Audio Output (Analog) 2V ± 10% / load impedance 75Ω
Video Output 1Vp-p ± 20% / load impedance 75Ω
Microphone Ø 6.35mm single plug
HDD Two 3.5-inch FAT32 SATA, max 2000GB X 2 (4TB)
AC Power AC 100V–120V (50/60Hz)
Power Consumption < 54W
Dimensions 430mm (W) x 305mm (D) x 64mm (H)
Weight (7.10 lbs.)

19
KOD-2400
Karaoke-On-Demand Jukebox
One (1) Year Manufacturer Warranty
Lifetime Technical Support
Designed in U.S.A.
Technical Support: [phone]
techsuppor[email protected]
Web site: www.acesonic.com
Acesonic USA, Inc.
161 S. 8th Avenue
City of Industry
CA 91746-3208
U.S.A.
© 2012 Acesonic USA, Inc. • All rights reserved
KOD-2400
Karaoke-On-Demand Jukebox
®
New Songs Download Account Register
Purchase of KOD-2400, you can register 6 months free account for downloading Acesonic new
songs. Please send Email at [email protected] with following information:
Reference Number(Sales Order Number, etc.):
Name:
Phone Number:
Address:
Email address:
Qualied customer will get an email with the userid, password and our FTP server address.
