ACME uPilot LED-RC64 User manual

1. General Instructions
uPilot is a marvelous pre-programmed remote matrix controller for 8pcs of CP-208; and can control
up to 16 groups ( 8 x 2) of CP-208. With the easy access, great 32 pre-programmed “Matrix” chase,
the Color Panels can deliver eye catching effects that are perfect for stage, clubs, and various
background enhancement.
Fixed color mode: instant access to 9 fixed colors.
Matrix mode: 32 different 8 x8 matrix chases with manual speed control or triggered by music.
Spectrum mix: 32 different mix colors, including color fade.
Adjustable speed and dimmer with fader.
Blackout and full on functions.
Power Input: DC 9V 300mA min
Size: 210 x 134 x 53 mm
Weight: 1.2 kgs
Function Instructions:
Mode select Use to select Fixed Colors / Matrix / Spectrum mix mode
Fixed color
/ matrix
1. In Fixed Color mode, use to select color on Red /Orange / Yellow / Green /
Cyan / Blue / Purple / Magenta /White
2. In Matrix mode, use to select 32 matrix chases with matrix pattern fader.
Matrix pattern
fader In Matrix mode, use the fader to select 32 matrix chases with matrix buttons
Spectrum Mix
fader Use to select 32 spectrum mix colors in Spectrum mix mode.
Speed fader Use to adjust chase speed in the range of 0.1 to 2.5 seconds
Fade Time
fader Use to adjust fade time. Fade time is amount of one color to fade in or fade out
Master fader Use to dimmer / shutter the fixture
Black out Blackout the fixture
Full on All lighting effect at once
Sound to
chase Use to receive audio signal for sound activated

Rear view:
Power Switch Turn On/Off the power
DC Input DC 9V, 300mA min
DMX Output Set DMX value to the fixture
2. Address Setting
A. Each fixture needs to have an address set to receive the data sent by the controller.
B. No need to turn the fixture off when you change the DMX address, as new DMX address setting will
be effected at once.
Please follow the instructions below to set these address:
yConnecting all LED lightings to the LED-RC64 and power them on.
yHold the “black out” button for about 5 seconds until the LED blinking.
yAll LED lightings will light in white, and show their addresses on the display.
yPress “red” button to set address for matrix 1, press “orange” button to set address for matrix 2.
yPress white button to change the direction.
yPress the “black out” button for about 5 seconds to quit address setting.
3. How to connect the unit
Please refer to the following diagram to connect the fixtures:
