Acnodes FPC 8121 User manual

FPC 8121
All-in-One
12.1” SVGA TFT Fanless Compact-Size
PANEL PC
User’s Manual
i

Disclaimers
The information in this manual has been carefully checked and is believed to
be accurate. ACNODES Co., Ltd. assumes no responsibility for any
infringements of patents or other rights of third parties, which may result from
its use.
ACNODES assumes no responsibility for any inaccuracies that may be
contained in this document. ACNODES makes no commitment to update or
to keep current the information contained in this manual.
ACNODES reserves the right to make improvements to this document and/or
product at any time and without notice.
No part of this document may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of
ACNODES Co., Ltd.
© Copyright 2006 by ACNODES Co., Ltd.
All rights reserved.
Octorber 2006, Version A1
Printed in Taiwan
ii

‹ CE Marking
‹ FCC Class A
FCC Compliance
Safety Approvals
This equipment has been tested and complies with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. If not installed and used in
accordance with proper instructions, this equipment might generate or
radiate radio frequency energy and cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measurers:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for
help.
Shielded interface cables must be used in order to comply with
emission limits.ou
iii

Safety Precautions
Before getting started, read the following important cautions.
1. The FPC 8121 does not come equipped with an
operating system. An operating system must be loaded first
before installing any software into the computer.
2. Be sure to ground yourself to prevent static charge when
installing the internal components. Use a grounding wrist strap
and place all electronic components in any static-shielded
devices. Most electronic components are sensitive to static
electrical charge.
3. Disconnect the power cord from the FPC 8121 before making
any installation. Be sure both the system and the external
devices are turned OFF. Sudden surge of power could
ruin sensitive components. Make sure the FPC
8121 is properly grounded.
4. The brightness of the flat panel display decreases with usage.
However, hours of use vary depending on the application
environment.
5. Turn OFF the system power before cleaning. Clean the
system using a cloth only. Do not spray any liquid cleaner
directly onto the screen. The FPC 8121 may come with or
w/o a touchscreen. Although the touchscreen is chemical
resistant, it is recommended that you spray the liquid cleaner
on a cloth first before wiping the screen. In case your system
comes without the touchscreen, you must follow the same
procedure and not spray any cleaner on the flat panel
directly.
6. Avoid using sharp objects to operate the touchscreen.
Scratches on the touchscreen may cause malfunction or
internal failure to the touchscreen.
7. The flat panel display is not susceptible to shock or vibration.
When assembling the FPC 8121, make sure it is securely
installed.
iv

8. Do not open the system’s back cover. If opening the cover for
maintenance is a must, only a trained technician is allowed to
do so. Integrated circuits on computer boards are sensitive to
static electricity. To avoid damaging chips from electrostatic
discharge, observe the following precautions:
9 Before handling a board or integrated circuit, touch an
unpainted portion of the system unit chassis for a few seconds.
This will help to discharge any static electricity on your body.
9 When handling boards and components, wear a
wrist-grounding strap, available from most electronic
component stores.
Trademarks Acknowledgments
ACNODES is a trademark of ACNODES Co., Ltd.
IBM, PC/AT, PS/2, VGA are trademarks of International
Business Machines Corporation.
Intel and Pentium are trademarks of Intel Corporation.
MS-DOS, Microsoft C and QuickBASIC are trademarks of
Microsoft Corporation.
VIA is a trademark of VIA Technologies, Inc.
SST is a trademark of Silicon Storage Technology, Inc. UMC
is a trademark of United Microelectronics Corporation.
Other brand names and trademarks are the properties of their
respective owners.
v

This page does not contain any information.
vi

Table of Contents
Disclaimers...........................................................................ii
Safety Approvals................................................................iii
Safety Precautions ............................................................. iv
C h a p t e r 1 .....................................................................1
Introduction ..........................................................................1
1.1 General Description ................................................1
1.2 Specifications ..........................................................2
1.2.1 Main CPU Board......................................................2
1.2.2 I/O System...............................................................2
1.2.3 System Specification..............................................9
1.3 Dimensions ............................................................10
1.4 I/O Outlets ..............................................................11
1.5 Package List ..........................................................13
C h a p t e r 2 ...................................................................14
Hardware Installation.......................................................14
2.1 HDD Installation ....................................................14
2.2 CF card Installation...............................................16
2.3 MiniPCI Wireless Card Installation ......................18
2.4 3 x Serial Ports ......................................................20
2.5 VGA ........................................................................22
2.6 Ethernet..................................................................22
2.7 Mountings: Panel / Wall / Desktop / VESA ..........23
2.7.1 VESA-ARM/Wall-Mount...........................................23
2.7.2 Desktop Kit Assembly ............................................. 24
2.7.3 Panel-mount Kit Assembly ..................................... 24
C h a p t e r 3......................................................................25
Driver Installation .............................................................25
3.1 Touch Screen ........................................................25
3.1.1 Driver Installation- Windows XP..............................26
Table of Contents vii

3.2 Embedded O.S.......................................................29
3.2.1 Windows XP Embedded..........................................29
3.2.2 Windows CE.NET 5.0 ................................................29
viii
Table of Contents

FPC 8121 User’s Manual
C h a p t e r 1
Introduction
This chapter contains the general information and the detail
specifications of the FPC 8121. Chapter 1 includes the following
sections:
„ General Description
„ System Specification
„ Dimensions
„ I/O Outlets
„ Utilities Supported
„ Package List
1.1 General Description
The FPC 8121 is a fan-less and compact-size touch panel
computer, and is equipped with a 12.1" TFT LCD display and low
power consumption CPU. The FPC 8121 supports
Windows® XP, Windows® CE.NET, Windows® XP embedded. The
panel is also able to install a miniPCI module for extended wireless
card and a CompactFlash™ card. The FPC 8121 is cost-
effective choice for operator interface applications.
„ FPC 8121: 12.1” SVGA TFT Fanless Touch panel w/extend
temp.
„ FPC 8121: 12.1” SVGA TFT Fanless Touch panel(Entry
level)
„ FPC 8121: 12.1” SVGA TFT Fanless Touch panel w/NEMA 4X
front bezel
Reliable and Stable Design
The FPC 8121 adopts a fan-less cooling system and a
CompactFlash™ card, which makes it especially suitable for
vibration-heavy environments, best for the transportation, ship, and
industrial machinery markets.
Embedded O.S. Supported
The FPC 8121 not only supports Windows
®
XP, but also supports
embedded OS, such as Windows
®
CE.NET, and Windows
®
XP
embedded. For storage device, the FPC 8121 supports
Introduction 1

FPC 8121 User’s Manual
2.5" HDD or CompactFlash™ card.
Industrial-grade Product Design
The FPC 8121 has an incredible design that can be used in different
industrial harsh environments.
z A fuse helps prevent over-voltage for power input.
z Stainless front bezel (FPC 8121) meets IP65/NEMA4X and
Aluminum front bezel(FPC 8121) meets the IP65/NEMA4
standard.
z For connecting other devices, the FPC 8121 also features
several interfaces: USB, Ethernet, and RS-232/422/485.
Wireless support- MiniPCI slot
The FPC 8121 offers a MiniPCI slot that allow for wireless
application requirements.
1.2 Specifications
1.2.1 Main CPU Board
„ CPU: Intel® Celeron M ULV 1G/0k onboard
„ System Chipset: Intel® 852GM +ICH*4
„ BIOS: AWARD BIOS, 4Mbit Flash ROM with RPL/PEX
LAN boot ROM,SmartView and customer CMOS
backup..
„ System Memory: One 200-pin DDR DIMM socket.
Maximum up to 1GB
1.2.2 I/O System
„ Standard I/O:
− 3 x serial ports with power;
2 x RS-232,
1 x RS-232/422/485
− 2 x USB Ports 2.0compliant
2 Introduction

FPC 8121 User’s Manual
„ Ethernet:
- Realtek RTL 8100C PCI Bus 10/100M Base-T
- RJ-45 interface equipped
„ Expansion Slot:
- MiniPCI wireless module
1.2.3 System Specification
„ 12.1” TFT LCD
„ Heat dispensing design
„ One slot for MiniPCI
„ Net weight:
− 5.4 Kg
 Dimension (main body size):
− 332x 267 x 68.5mm
 Operating temperature: -15° to 50°C ; Relative
humidity:40% (If the GOT series will be operated over
5
5 ℃ f or l ong time, please sel ect the DR AM a nd HDD w hich
sup ports wi de -temperature)
 Relative humidity: 10% to 90% @ 40° C, on-condensing
„ Vibration (operating):
5 to 500 Hz, 1.0 G random ( install HDD )
5 to 500 Hz, 2.0 G random ( install CompactFlash card )
9

FPC 8121 User’s Manual
1.3 Dimensions
The following diagrams show the dimensions and outlines of
FPC 8121.
„ FPC 8121 dimension
„ FPC 8121 dimension
10

FPC 8121 User’s Manual
1.4 I/O Outlets
The following figure shows the I/O locations of the FPC 8121. Most of
the I/O connectors are located on the back panel of the
FPC 8121.
11

FPC 8121 User’s Manual
1: Power Switch 6: 10/100 Base-T
2: Audio(Line out) 7: USB v2.0
3: COM1 8: PS2 keyboard/mouse
4: VGA 9: COM2
5: 10/100 Base-T 10: COM3 (USB)
12

FPC 8121 User’s Manual
1.5 Package List
When you receive the FPC 8121 there are following items in the
package. If you can not find it, please contact ACNODES
distributors.
1. FPC 8121 x 1
2. CD driver x1
3. Panel mount kit x 6
4. Anti-vibration HDD rubber x5
5. Y cable for PS2 keyboard/mouse
6. Antenna x1
7. Desktop kit x 2(optional)
8. VESA ARM/Wall-mount kit x 1(optional)
9. Jumper
13

FPC 8121 User’s Manual
C h a p t e r 2
Hardware Installation
The FPC 8121 provides lots of flexible ways for you to select different
configuration such as HDD,(recommend adopt wide temperature HDD
in harsh environment) CF card and more. The chapter will show you
how to install the hardware. It includes:
2.1 HDD Installation
The FPC 8121 offers a convenient drive bay module for users to
install HDD. The FPC 8121 offers one 2.5” HDD drive for users to
install. Please follow the steps:
1. Take out HDD bracket kit, 4 anti-vibration screws, 4 anti-vibration
rubbers and 4 bracket screws from the accessory package.
2. Screw 4 anti-vibration screws and fix HDD on the bracket kit.
14

FPC 8121 User’s Manual
3. Fix the HDD kit to system by 4 screws.
15

FPC 8121 User’s Manual
2.2 CF card Installation
The FPC 8121 offers a solution for users to install CF card. When
installing the CF card, refer to the following instructions and
illustration:
1. Take apart FPC 8121 and find embedded system board from
system and turn it to back side.
2. Install user’s CF card.
16

FPC 8121 User’s Manual
17

FPC 8121 User’s Manual
2.3 MiniPCI Wireless Card Installation
The FPC 8121 provides one Mini PCI slot for wireless
module.(Default Wireless module:AC92203 ) When installing the
wireless card, refer to the following instructions and illustration:
1. Find EMBEDDED board(EP810).
2. Install user’s Wireless card.
18
