Acnodes FES93 Series User manual

User Manual
Embedded Computers
FES93XX
Compact DIN-Rail Fanless Embedded Box PC
Intel Pentium N4200 Quad-Core Processor
-25°C to 70°C Wide Range Working Temperature
14628 Central Ave. Chino, CA 91710 Tel: [phone] Fax: [phone]
© Copyright 2020 Acnodes Corp.
All rights reserved. Product description and product specifications are subject to change without notice.
For latest product information, please visit Acnodes’ website at www.acnodes.com
1

Table of Contents
Legal Information ......................................................................................................................
Declaration of Conformity ........................................................................................................
Safety Precautions ....................................................................................................................
Service and Maintenance .........................................................................................................
4
5
6
7
1Introduction
1.1
1.2
1.3
1.4
1.5
1.5.1
1.5.2
1.5.3
1.6
1.6.1
1.6.2
1.6.3
Specifications of FES9300 .............................................................................................
Specifications of FES9310 ............................................................................................
Specifications of FES9320 ............................................................................................
Specifications of FES9330 ............................................................................................
Dimension .......................................................................................................................
Mounting Options ..........................................................................................................
2System Overview
2.1
2.2
2.2.1
2.2.2
2.2.3
2.2.4
2.2.5
2.2.6
2.2.7
2.2.8
2.2.9
2.3
2.3.1
2.3.2
2.3.3
2.4
2.4.1
2.4.2
2.4.3
9
11
13
15
17
17
18
19
20
20
21
22
3System Installation
3.1
3.2
3.2.1
3.2.2
3.2.3
3.2.4
Disassembling the System Enclosure .........................................................................
Installing Internal Components ....................................................................................
44
45
45
46
48
50
Front View ..............................................................................................................
Top View .................................................................................................................
Bottom View ...........................................................................................................
DIN-Rail Mount Clip ................................................................................................
Wall Mount Bracket (WM-300V) .............................................................................
Wall Mount Bracket (WM-300H) .............................................................................
Unpacking the System ..................................................................................................
Front Panel .....................................................................................................................
Top Panel .......................................................................................................................
Internal I/O ......................................................................................................................
USB 2.0 Port ..........................................................................................................
Power Button .........................................................................................................
Reset Button ..........................................................................................................
Gigabit Ethernet .....................................................................................................
System Status LED ...............................................................................................
DVI-I Port ...............................................................................................................
USB 3.0 Port ..........................................................................................................
IEEE 802.3at Power over Ethernet Port #1 & #2 (FES9300/ FES9320 Only) ......
3-Pin Terminal Block for DC input .........................................................................
COM Port (COM1) .................................................................................................
COM Ports (COM2/ COM3/ COM4) ......................................................................
3.5mm Microphone-in/ Speaker-out Jack ..............................................................
DDR3L SO-DIMM Socket .......................................................................................
Full-size mini-PCIe Socket .....................................................................................
Half-size mSATA Socket ........................................................................................
DDR3L SO-DIMM Installation ................................................................................
mini-PCIe Module and SIM Card Installation .........................................................
mSATA Module Installation ....................................................................................
2.5" HDD/ SDD Installation ....................................................................................
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
41
2

3.3
3.4
3.5
3.6
3.7
3.7.1
3.7.2
3.7.3
3.7.4
Powering On Using the Power Button ....................................................................
Powering On Using An External Non-Latched Switch ...............................................
Powering On Using
An External Latched Switch.......................................................
Powering On Using Wake-on-LAN ..........................................................................
4BIOS Settings
4.1
4.2
4.3
4.4
4.5
4.6
4.7
4.8
4.9
COM1 Port Configuration ..............................................................................................
COM2/ 3/ 4 Port Configuration ......................................................................................
SATA Interface Speed ...................................................................................................
C-States ...........................................................................................................................
Wake-on-LAN ..................................................................................................................
Power On after Power Failure ..........................................................................................
Position New Boot Device ...............................................................................................
Watchdog Timer..............................................................................................................
Select a Boot Device ........................................................................................................
5OS Support and Driver Installation
5.1
5.2
5.2.1
5.2.2
5.3
Installing the System Enclosure ..................................................................................
DIN Rail Installation .......................................................................................................
Wall Mount Bracket Installation (with WM-300V) ........................................................
Wall Mount Bracket Installation (with WM-300H) .......................................................
Powering on the System ...............................................................................................
51
52
54
56
59
59
60
61
62
65
66
67
68
69
70
71
72
73
Operating System Compatibility ..................................................................................
Driver Installation ...........................................................................................................
Driver for Watchdog Timer and DIO .............................................................................
Install Drivers Automatically ...................................................................................
Install Drivers Manually...........................................................................................
74
75
75
75
76
3

Legal Information
All of Acnodes' products shall be subject to the latest Standard Warranty Policy. Acnodes may modify,
update or upgrade the software, firmware or any accompanying user documentation without any prior
notice.
Before installing any software, applications or components provided by a third party, customer should
ensure that they are compatible and interoperable with Acnodes' product by checking in advance with
Acnodes. Customer is solely responsible for ensuring the compatibility and interoperability of the third
party’s products. Customer is further solely responsible for ensuring its systems, software, and data
are adequately backed up as a precaution against possible failures, alternation, or loss.
For questions in regards to hardware/ software compatibility, customers should contact Acnodes' sales
representative or technical support.
To the extent permitted by applicable laws, Acnodes shall NOT be responsible for any interoperability
or compatibility issues that may arise when (1) products, software, or options not certified and
supported; (2) configurations not certified and supported are used; (3) parts intended for one system is
installed in another system of different make or model.
This manual is intended to be used as an informative guide only and is subject to change without prior
notice. It does not represent commitment from Acnodes. Acnodes shall not be liable for any direct,
indirect, special, incidental, or consequential damages arising from the use of the product or
documentation, nor for any infringement on third party rights.
4

Declaration of Conformity
FCC This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at own expense.
CE The product(s) described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to remain
CE compliant, only CE- compliance also requires proper cable and cabling
techniques.
5

Safety Precautions
Read these instructions carefully before you install, operate, or transport the system.
Install the system or DIN rail associated with, at a sturdy location
Install the power socket outlet near the system where it is easily accessible
Secure each system module(s) using its retaining screws
Place power cords and other connection cables away from foot traffic. Do not place items over
power cords and make sure they do not rest against data cables
Shutdown, disconnect all cables from the system and ground yourself before touching internal
modules
Ensure that the correct power range is being used before powering the device
Should a module fail, arrange for a replacement as soon as possible to minimize down-time
By means of a power cord connected to a socket-outlet with earthing connection
This product is intended to be supplied by a Listed Power Adapter or DC power source, rated
24Vdc, 16A, Tma 60 degree C and 5000m altitude during operation.
If the system is not going to be used for a long time, disconnect it from mains
(power socket) to avoid transient over-voltage
Hot Surface Warning
HOT SURFACE. DO NOTTOUCH. "ATTENTION: Surface
chaude. Ne pas toucher."
WARNING!
Components/ parts inside the equipment may be hot to
touch! Please wait one-half hour after switching off before
handling parts.
Battery Warning
Batteries are at risk of exploding if incorrectly installed
Do not attempt to recharge, force open, or heat the battery
Replace the battery only with the same or equivalent type
recommended by the manufacturer
6

Service and Maintenance
ONLY qualified personnel should service the system
Shutdown the system, disconnect the power cord and all other connections before servicing
the system
When replacing/ installing additional components (expansion card, memory module, etc.),
insert them as gently as possible while assuring proper connector engagement
ESD Precautions
Handle add-on module, motherboard by their retention screws or the module’s frame/ heat
sink. Avoid touching the PCB circuit board or add-on module connector pins
Use a grounded wrist strap and an anti-static work pad to discharge static electricity when
installing or maintaining the system
Avoid dust, debris, carpets, plastic, vinyl and styrofoam in your work area
Do not remove any module or component from its anti-static bag before installation
Restricted Access Location
The controller is intended for installation only in certain environments where both of the following
conditions apply:
Access can only be gained by QUALIFIED SERVICE PERSONNEL who have been instructed
on the reasons for restrictions applied to the location and any precautions that shall be taken
Access is through the use of a TOOL, lock and key, or other means of security, and is
controlled by the authority responsible for the location
7

1 Introduction
The FES93XX series are ultra-compact fanless embedded computers featuring Intel®
Apollo-Lake Atom™ x7-E3950 or Pentium® N4200 processor. It has a compact and
rugged chassis with dimensions measuring just 56 (W) x 153 (H) x 108 (D) mm.
Designed for DIN rail mounting with front panel I/O port access, the FES93XX is easy
to setup and ideal for industrial applications where space is limited. The system
utilizes Intel Atom™ x7-E3950 quad-core processor that features an updated 14nm
microarchitecture with integrated HD graphics and faster memory speeds
(DDR3L-1866) for efficient computing. For applications such as industrial automation,
machine vision and real-time surveillance can all benefit from its higher throughput
performance. The FES93XX series provides rich I/O ports. It has one Gigabit Ethernet
port, two 802.3at Gigabit PoE+ ports, two USB3.0 ports, two USB2.0 ports, one DVI-I
connector for VGA + DVI dual video output, and four COM ports. As an industrial
embedded computer, the FES93XX series can function under 100% CPU load under
wide temperature ranging from -25°C to 70°C. It also accepts a wider range of power
inputs from 8 to 35V DC and is fully tested for 24/7 operation in harsh environments.
8

1.1 FES9300 Specification
System Core
Processor Intel® Atom™ E3950 1.6/ 2.0GHz quad-core processor
Graphics Integrated Intel® HD Graphics 505
Memory 1x SODIMM socket for DDR3L-1866, up to 8GB
Panel I/O Interface
Ethernet 3x Gigabit Ethernet ports by Intel® I210 GbE controller
PoE IEEE 802.3at PoE+ on port #1 and #2
Video Port 1x DVI-I connector for both analog RGB and DVI outputs, supporting up
to 1920 x 1200 resolution
Serial Port
1x programmable RS-232/ 422/ 485 port (COM1)
3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port (COM2)
USB 2x USB 3.0 ports
2x USB 2.0 ports
Audio 1x speaker-out
1x microphone-in
Internal I/O Interface
Mini-PCIe 1x full-size mini PCI Express slot with USIM socket
Storage Interface
mSATA 1x half-size mSATA port
Power Supply
DC Input Built-in 8~35 VDC DC input
Input
Connector 3-pin pluggable terminal block for DC input
Max. Power
consumption 19.68W (0.82A@24V)*
Mechanical
Dimension 56 x 108 x 153 mm
Weight 0.96 kg
Mounting DIN-rail mount (Standard)
Wall-mount (Optional)
Environmental
Operating
Temperature -25°C ~ 70°C with SSD, 100% CPU loading */**
Storage
Temperature -40°C ~85°C
9

Humidity 10%~90% , non-condensing
Vibration
Operating, 5 Grms, 5-500 Hz, 3 Axes (w/ SSD,
according to
IEC60068-2-64)
Shock Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to
IEC60068-2-27)
EMC CE/FCC Class A, according to EN 55022 & EN 55024
** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD)
is required.
10

1.2 FES9310 Specification
System Core
Processor Intel® Atom™ E3950 1.6/ 2.0GHz quad-core processor
Graphics Integrated Intel® HD Graphics 505
Memory 1x SODIMM socket for DDR3L-1866, up to 8GB
Panel I/O Interface
Ethernet 3x Gigabit Ethernet ports by Intel® I210 GbE controller
Video Port 1x DVI-I connector for both analog RGB and DVI outputs, supporting up
to 1920 x 1200 resolution
Serial Port 1x programmable RS-232/ 422/ 485 port (COM1)
3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port (COM2)
USB 2x USB 3.0 ports
2x USB 2.0 ports
Audio 1x speaker-out
1x microphone-in
Internal I/O Interface
Mini-PCIe 1x full-size mini PCI Express slot with USIM socket
Storage Interface
mSATA 1x half-size mSATA port
Power Supply
DC Input Built-in 8~35 VDC DC input
Input
Connector 3-pin pluggable terminal block for DC input
Max. Power
consumption 19.68W (0.82A@24V)*
Mechanical
Dimension 56 x 108 x 153 mm
Weight 0.96 kg
Mounting DIN-rail mount (Standard)
Wall-mount (Optional)
Environmental
Operating
Temperature
Operating temperature:
-25°C ~ 70°C with SSD, 100% CPU loading */**
Storage
Temperature -40°C ~85°C
Humidity 10%~90% , non-condensing
11

Vibration
Operating, 5 Grms, 5-500 Hz, 3 Axes
(w/ SSD, according to
IEC60068-2-64)
Shock Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to
IEC60068-2-27)
EMC CE/FCC Class A, according to EN 55022 & EN 55024
** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD)
is required.
12

1.3 FES9320 Specification
System Core
Processor Intel® Pentium® N4200 1.1/ 2.5GHz quad-core processor
Graphics Integrated Intel® HD Graphics 505
Memory 1x SODIMM socket for DDR3L-1866, up to 8GB
Panel I/O Interface
Ethernet 3x Gigabit Ethernet ports by Intel® I210 GbE controller
PoE IEEE 802.3at PoE+ on port #1 and #2
Video Port 1x DVI-I connector for both analog RGB and DVI outputs, supporting up
to 1920 x 1200 resolution
Serial Port
1x programmable RS-232/ 422/ 485 port (COM1)
3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port (COM2)
USB 2x USB 3.0 ports
2x USB 2.0 ports
Audio 1x speaker-out
1x microphone-in
Internal I/O Interface
Mini-PCIe 1x full-size mini PCI Express slot with USIM socket
Storage Interface
mSATA 1x half-size mSATA port
Power Supply
DC Input Built-in 8~35 VDC DC input
Input
Connector 3-pin pluggable terminal block for DC input
Max. Power
consumption 14.16W (0.59A@24V)*
Mechanical
Dimension 56 x 108 x 153 mm
Weight 0.96 kg
Mounting DIN-rail mount (Standard)
Wall-mount (Optional)
Environmental
Operating
Temperature -25°C ~ 70°C with SSD, 100% CPU loading */**
Storage
Temperature -40°C ~85°C
13

Humidity 10%~90% , non-condensing
Vibration
Operating, 5 Grms, 5-500 Hz, 3 Axes
(w/ SSD, according to
IEC60068-2-64)
Shock Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to
IEC60068-2-27)
EMC CE/FCC Class A, according to EN 55022 & EN 55024
** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD)
is required.
14

1.4 FES9330 Specification
System Core
Processor Intel® Pentium® N4200 1.1/ 2.5GHz quad-core processor
Graphics Integrated Intel® HD Graphics 505
Memory 1x SODIMM socket for DDR3L-1866, up to 8GB
Panel I/O Interface
Ethernet 3x Gigabit Ethernet ports by Intel® I210 GbE controller
Video Port 1x DVI-I connector for both analog RGB and DVI outputs, supporting up
to 1920 x 1200 resolution
Serial Port 1x programmable RS-232/ 422/ 485 port (COM1)
3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port (COM2)
USB 2x USB 3.0 ports
2x USB 2.0 ports
Audio 1x speaker-out
1x microphone-in
Internal I/O Interface
Mini-PCIe 1x full-size mini PCI Express slot with USIM socket
Storage Interface
mSATA 1x half-size mSATA port
Power Supply
DC Input Built-in 8~35 VDC DC input
Input
Connector 3-pin pluggable terminal block for DC input
Max. Power
consumption 14.16W (0.59A@24V)*
Mechanical
Dimension 56 x 108 x 153 mm
Weight 0.96 kg
Mounting DIN-rail mount (Standard)
Wall-mount (Optional)
Environmental
Operating
Temperature -25°C ~ 70°C with SSD, 100% CPU loading */**
Storage
Temperature -40°C ~85°C
Humidity 10%~90% , non-condensing
15

Vibration
Operating, 5 Grms, 5-500 Hz, 3 Axes
(w/ SSD, according to
IEC60068-2-64)
Shock Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to
IEC60068-2-27)
EMC CE/FCC Class A, according to EN 55022 & EN 55024
** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD)
is required.
16

1.5 Dimension
1.5.1 Front View
17

1.5.2 Top View
18

1.5.3 Bottom View
.
19

1.6 Mounting Options
The system comes with various mounting options such as DIN-rail and wall-mount
bracket. DIN-rail mount clip is shipped with FES93XX series as standard mounting
option. Two optional mounting brackets, WM-300V and WM-300H, are available for
wall-mount applications.
1.6.1 DIN-Rail Mount Clip
20
