PLW 8150
15” portable LCD workstation
Core Duo T2500 2.0GHz system
2 x PCI full-size expansion slot
» Specifications
» Ordering Guide
» Features
» portable LCD workstation
» 15” 1024x768 LCD monitor
» Intel Core Duo T2500 2.0GHz all-in-one system
» On-Board video, Audio and 10/100/1000BT LAN
» Built-in SATA HD, DVD-RW, 1.44MB FDD
» 2 x 2.5” SATA HD removable bay
» 108-key keyboard with touch-pad
» 160W 110/220VAC power supply, optional for battery
PLW8150:
15” portable computer comes with Core Duo 2.0GHz, 2GB
DDR2 memory, 100GB HD, DVD-RW, 1.44MB FDD
Material by:
External chassis-flame retardant ABS plastic
Internal aluminum alloy chassis
LCD panel:
15.1" 1024x768 TFT LCD
Brightness: 250 nit (cd/m2)
Resolution: 1024 x 768
Anti-reflection tempered glass protection LCD monitor
Front panel control:
LED indicators for HD, LAN, power
Power ON/OFF and reset switch
Main system:
Embedded Board
CPU: Intel Core Duo Processors T2500 2.0GHz
Chipset: Intel 945GM
Memory:2GB DDR2 memory (up to 4GB memory)
On board Graphics: Intel 945GM Integrated Function
Hard Disk Drive:4 x SATA-II, 1 x IDE ATA-100
LAN: 1x RJ45 for 10/100 Base Tx
1x RJ45 for 10/100/1000 Base Tx
Audio: AC'97, Line-in , Line-out , Microphone
Serial Ports: 2 x RS-232
Parallel port: 1 x SPP/EPP/ECP supported
1 x Firewire 400 IEEE1394a
PS/2 Interfaces: 1 x mouse, 1 x keyboard
Storage device:
1 x DVD
1 x 1.44MB FDD
1 x 2.5" SATA-II internal HD bay
2 x 2.5" SATA-II removable HD bay
Keyboard & touch-pad:
1 x 105-key Mechanical type keyboard
1 x 2-buttons touch-pad
Expansion slot:
2 x PCI full-size wxpansion slot
Connectors:
2 x D-Sub 9 pin (male) for RS-232
1 x D-Sub 25 pin (female) for Parallel
2 x P/S 2 for Keyboard and Mouse
2 x RJ-45 for LAN, 4 x USB 2.0 ports
1 x D-sub 15 (female) for S-VGA output
1 x Speaker-out, 1x line-in & MIC
1 x 1394a port
Power bay:
1 x 160W 110/220VAC power supply (STD)
Optional:
190 Watt-hours Smart Packs Battery (2 x battery pack,
Hot-Swappable) with external power adapter
Battery operation time:
Idle:4.5 Hour, (based on system only with LCD backlight on
in Windows OS desktop)
Full Load:3.7 Hour, (based on system only with LCD back
light on and both CPU core on full load and 1 HDD perform-
ing sequential reading in Windows OS)
Charging: 2.5 Hour (From Empty to Full)
Carry case:
It comes with telescoping handle and wheels, one exterior
pocket holds documents and accessory.
Dimensions (W x H x D):
16 3/8" x 11 3/8” x 6 3/8"
Gross weight:
20 LBS
OS supported
Windows XP, Red-Hat Linux
Environmental
Operation Temperature Range:0°C-60°C (32°F~140°F)
Storage Temperature Range:-20°C~80°C (-68°F~176°F)
Relative humidity:10%~90% (non-condensing)
Safety:CE, FCC, RoHS
