Acnodes APM5200 User manual

20" Industrial Panel Mount LCD Monitor
Supports 1600 x 1200 Display Resolution
Rugged Aluminum Front Bezel
APM5200
All rights reserved. Product description and product specifications are subject to change without notice.
For latest product information, please visit Acnodes’ website at www.acnodes.com.
14628 Central Ave. Chino, CA 91710 Tel: [phone]
Fax: [phone]
© Copyright 2020 Acnodes Corp.
Industrial Monitors
User Manual

Legal Information
First English printing, November 2020
Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness
of the contents. The information in this document is subject to change without notice. We are not liable for any injury or
loss that results from the use of this equipment.
Safety Instructions
Please read all of these instructions carefully before you use the device. Save this manual for
future reference.
■Unplug equipment before cleaning. Don’t use liquid or spray detergent; use a moist cloth.
■Keep equipment away from excessive humidity and heat. Preferably, keep it in an air-conditioned environment with
temperatures not exceeding 40º Celsius (104º Fahrenheit).
■When installing, place the equipment on a sturdy, level surface to prevent it from accidentally falling and causing
damage to other equipment or injury to persons nearby.
■When the equipment is in an open position, do not cover, block or in any way obstruct the gap between it and the
power supply. Proper air convection is necessary to keep it from overheating.
■Arrange the equipment’s power cord in such a way that others won’t trip or fall over it.
■If you are using a power cord that didn’t ship with the equipment, ensure that it is rated for the voltage and current
labeled on the equipment’s electrical ratings label. The voltage rating on the cord should be higher than the one listed
on the equipment’s ratings label.
■Observe all precautions and warnings attached to the equipment.
■If you don’t intend on using the equipment for a long time, disconnect it from the power outlet to prevent being
damaged by transient over-voltage.
■Keep all liquids away from the equipment to minimize the risk of accidental spillage. Liquid spilled on to the power
supply or on other hardware may cause damage, fire or electrical shock.
■Only qualified service personnel should open the chassis. Opening it yourself could damage the equipment and
invalidate its warranty.
■If any part of the equipment becomes damaged or stops functioning, have it checked by qualified service personnel.
What the warranty does not cover
■Any product, on which the serial number has been defaced, modified or removed.
■Damage, deterioration or malfunction resulting from:
□Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or
failure to follow instructions supplied with the product.
□Repair or attempted repair by anyone not authorized by us.
□Any damage of the product due to shipment.
□Removal or installation of the product.
□Causes external to the product, such as electric power fluctuation or failure.
□Use of supplies or parts not meeting our specifications.
□Normal wear and tear.
□Any other causes which does not relate to a product defect.
■Removal, installation, and set-up service charges.
Regulatory Notices Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment offand on, the
user is encouraged to try to correct the interference by one or more of the following measures:
■Re-position or relocate the receiving antenna.
■Increase the separation between the equipment and receiver.
■Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Contents
< Part. 1 > APM5200
1.1 Package Content P.1
1.2 Structure Diagram & Dimension P.2
1.3 Mounting Hardware & Installation P.4
< Part. 2> Specifications / OSD
2.1 Product Specifications P.5
2.2 On-screen Display Operation ( OSD ) P.7
< Part. 3> Options
3.1
3.2
3.3
3.4
MCS Multi-display control solution
AV2.2D Upgrade : DVI-D, S-Video + BNC & Audio
AV2.2H Upgrade : HDMI, S-Video + BNC & Audio
Resistive ( 1-point touch )
DC Power : 12V / 24V / 48V / 125V
P.8
P.9
P.11
P.13

■It is very important to mount the equipment in a suitable cabinet or on a stable surface.
■Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive
dust, dirt, heat, water, moisture and vibration.
The equipment comes with the standard parts shown in package content. Check and make sure they are
included and in good condition. If anything is missing, or damaged, contact the supplier immediately.
Unpacking
Before Installation
How To Clean Your LCD Monitor
Caution :
3
4
■To avoid the risk of electric shock, make sure your hands are dry before unplugging your monitor from or
plugging your monitor into an electrical outlet.
■When you clean your monitor, do not press down on the LCD screen. Pressing down on the screen can
scratch or damage your display. Pressure damage is not covered under warranty.
■Use only cleansers made specifically for cleaning monitors and monitor screens. Cleansers not made to
clean monitors and monitor screens can scratch the LCD display or strip offthe finish.
■Do not spray any kind of liquid directly onto the screen or case of your monitor. Spraying liquids directly
onto the screen or case can cause damage which is not covered under warranty.
■Do not use paper towels or abrasive pads to clean your monitor. Using an abrasive pad or any wood
based paper product such as paper towels can scratch your LCD screen.
Cleaning Your Monitor
To clean your LCD safely, please follow these steps :
Disconnect the power cord.
Gently wipe the surface using a clean, dry microfiber cloth. Use as little pressure as possible.
1
2
Cleaning Tough Marks and Smudges
To remove tough marks and smudges, please follow these steps :
Disconnect the power cord.
Spray a small amount of non-abrasive cleanser on a microfiber cloth.
Gently wipe the surface. Use as little pressure as possible.
Wait until your monitor is completely dry before plugging it in and powering it up.
1
2
Caution : Do not spray or apply any liquids directly onto the monitor. Always apply the solution to your
microfiber cloth first, not directly on the parts you are cleaning.

Audio
Power
out - in - in
Video PC
VGA
HDMI
S-VideoBNC
AV2.2H upgrade I/O
Basic I/O
AV2.2D upgrade I/O
Power VGADVI-D
Audio
Power
out - in - in
Video PC
VGADVI-DS-VideoBNC
20" LCD display X 1
6ft VGA cable X 1
Power adapter X 1
Power cord X 1
APM5200
Mounting hardware X 1 pack
- Mounting bracket x 4 pcs
- M4* 6mm screw x 8 pcs
- M4* 50mm screw x 8 pcs
< Part 1 > APM5200
< 1.1 > Package Content
P.1

Rear case
LCD panel
Protective 3mm glass
6mm aluminum front bezel
Audio speaker ( for HDMI or Audio )
LCD membrane
Remote sensor
1
2
3
4
5
6
7
7
1
2
3
4
6
5
Model Product Dimension
(W x D x H)
Packing Dimension
(W x D x H) Net Weight Gross Weight
APM5200 512.5 x 72.1 x 391.6 mm
20.2 x 2.8 x 15.4 inch
651 x 124 x 597 mm
25.6 x 4.9 x 23.5 inch
7 kg
15.4 lb
9 kg
19.8 lb
< 1.2 > Structure Diagram
Front View
Rear View
Side View
Bottom View
P.2

Front View Side View
Rear View
UNIT : mm
1mm = 0.03937 inch
Bottom View
< 1.2 > Dimension
P.3

1
x 4 pcs
Mounting
bracket x 8 pcs
M4*6mm screw
2 3
x 8 pcs
M4*50mm screw
Hardware set part no. UV-BK#2
■Install 4 mounting brackets with 8 x M4*6mm screws
■Adjust the LCD panel with 8 x M4*50mm screws and fix it on the surface.
Steps
M4 screw
■Hardware and M4*4 pcs for VESA mount are not provided
VESA mount ( 100*100mm )
< 1.3 > Installation
( I) Panel mount( I) Panel mount
( II ) VESA mount ( 100*100mm )
P.4

< Part 2>
< 2.1 > Product Specifications
Mechanical Design APM5200 APM5200-IP
Protection 6mm front bezel NEMA 4 / IP65
Front Panel Black, RAL 9005
Rear Casing Black, RAL 9005
VESA mount 100 x 100 mm
Universal mount -
Desktop stand option
Panel mount bundled
Video
VGA Analog 0.7Vp-p
DVI DVI-D single link
Option
HDMI HDMI 1.2 / HDCP 1.1
Composite ( BNC ) NTSC & PAL
S-Video ( 4-pin ) NTSC & PAL
Power
Input Auto-sensing 100 to 240VAC, 50 / 60Hz
Consumption:
Screen ON Max. 45W
Power saving mode Max. 2W
Power button OFF Max. 1W
Compliance
EMC FCC & CE certified
Safety CE / LVD certified
Environment RoHS3 & REACH compliant
LCD Panel
Panel Size ( diagonal ) 20-inch TFT color LCD
Native resolution 1600 x 1200
Brightness ( cd/m2) 300
Contrast Ratio ( typ. ) 800:1
Colors 16.7 M
Viewing Angle ( L/R/U/D ) 89/89/89/89
Response Time ( ms ) 16
Dot pitch ( mm ) 0.255
Display Area ( mm ) 408.00H x 306.00V
Surface treatment Anti-glare, Hard-coating
Surface hardness 3H
Backlight Type CCFL
MTBF ( hrs ) 45,000
Audio Option
Input
Connector
Impedance / Power level
3.5mm stereo jack
30kΩ/ 750mV
Output
Connector
Resistance / Power level
3.5mm stereo jack
30kΩ/ 2.8V
Speaker:
Dual Stereo 2W x 2
*When the audio output is connected, speaker output is OFF
P.5

< 2.1 > Product Specifications
Environmental Conditions
Operating Temperature 0 to 55°C degree
Humidity 20~90%, non-condensing
Altitude 16,000 ft
Storage /
Non-operating Temperature -20 to 60°C degree
Humidity 5~90%, non-condensing
Altitude 40,000 ft
Shock 10G acceleration ( 11ms duration )
Vibration 10~300Hz 0.5G RMS random vibration
Physical Specification APM5200 APM5200-IP
Product ( W x D x H )
mm 512.5 x 72.1 x 391.6 512.5 x 72.1 x 391.6
inch 20.2 x 2.8 x 15.4 20.2 x 2.8 x 15.4
Packing ( W x D x H )
mm 651 x 124 x 597 651 x 124 x 597
inch 25.6 x 4.9 x 23.5 25.6 x 4.9 x 23.5
Net Weight 7 kg / 15.4 lb 7 kg / 15.4 lb
Gross Weight 9 kg / 19.8 lb 9 kg / 19.8 lb
Chassis color Dark
Chassis materials Aluminum
* All dimensions stated are subject to change if options are selected / integrated to base model part codes
Applicable Format
DVID / VGA Input PC Signal 1600 x 1200 x 60Hz
1400 x 1050 x 60Hz
1440 x 900 x 60Hz
1360 x 768 x 60Hz
1280 x 1024 x 60 / 75Hz
1280 x 960 x 60Hz
1280 x 768 x 60 / 75Hz
1152 x 864 x 75Hz
1024 x 768 x 60 / 70 / 75Hz
848 x 480 x 60Hz
800 x 600 x 60 / 72 / 75Hz
720 x 400 x 70Hz
640 x 480 x 60 / 72 / 75Hz
640 x 400 x 70Hz
640 x 350 x 70Hz
Audio Signal 2ch Linear PCM
HDMI Input PC signal Same as VGA
HDMI 1.2 1280 x 720 x 50 / 60Hz ( 720p )
720 x 480 x 50 / 60Hz ( 576p / 480p )
Audio Signal 2ch Linear PCM
* In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display
incorrectly on a full screen. If so, please adjust the display card setting on display size to fix the issue.
P.6

Exit the OSD screen
Toggle analog, digital & video connection (DVI-D and video options only)
Scrolls through menu options and adjusts the displayed control
(To auto adjustment by pressing the button for 5 seconds)
Display the OSD menu
Power on / offLCD
Power light
Green = On
Orange = Power saving
Membrane Switch Function
OSD Configuration Page
Image:
for the brightness, contrast, color temp, red, green, and blue
Geometry:
for the auto adjust, H position, V position, phase and clock
Video:
for the colour, tint, sharpness, noise reduction, DCDi and TV Setup
Audio:
for volume, bass, treble, balance, AVL and mute
Misc:
for the language, OSD position, graphic mode, ratio, reset and timer
< 2.2 > On-screen Display Operation ( OSD )
P.7

< Part 3> Options
< 3.1 > Options : MCS
MCS
( Multi-display Control )
Audio
Power
out - in - in
Video PC
VGADVI-D
HDMI
BNC S-Video
Link
MCS
set out in
Set switch
For the 1st and last display,
push the set switch upward
For other daisy chain displays,
push the set switch downward
LINK OUT IN OUT
RS-232C
Cat5 / 6 cable
max. 300 meters
up to 64 displays
Daisy chain up to 1,000
meters and 64 displays
RJ-45 jack
IN OUT IN OUT
Cat5 / 6 cable
max. 300 meters
Cat5 / 6 cable
max. 300 meters
15 feet serial cable
( over 15 feet, extender required )
*** Please download the protocol of MCS control at : https://www.acnodes.com/files/downloads/MCS-UM.pdf
More control is always good. Especially when it is necessary
and easy. Acnodes provides MCS solution to control the OSD of
various LCD display up to 64 units.
The RS-232C is used for the communication between the PC
and the first display via a 15 feet serial cable while the CAN bus
is used for the various LCD displays cascade together via CAT
5/6 cable, and daisy chain up to 1,000 meters.
Designed for use with LCD displays, Acnodes provides a
MCS input module without using additional space or power and
it comes standard with a 2-year warranty.
P.8

( 1 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio
signals, the LCD may display incorrectly on a full screen. If so, please adjust the display card
setting on display size to fix the issue.
( 2 ) AV2.2 upgrade option comes with RC-2 remote controller x 1 ( please refer to P.10 )
***
( Built-in Dual Stereo Speakers, 2W x 2 )
( 3.5mm audio jacks for audio in & out )
Audio
Power
out - in - in
Video PC
VGA
HDMI
S-VideoBNC
Audio
Power
out - in - in
Video PC
VGADVI-DS-VideoBNC
- HDMI ( HDMI 1.2, CEA-861-D )
- AV
- Audio
( S-Video + Composite, BNC )
- AV
- Audio
)
( S-Video + Composite, BNC )
( Built-in Dual Stereo Speakers, 2W x 2 )
AV2.2H Upgrade Options
( 3.5mm audio jacks for audio in & out )
< 3.2 > Options :
AV2.2D Upgrade Options
- DVI-D ( DVI-D TMDS single link
P.9

How to Use RC-2 Remote Controller
123
456
AUTO 0-/--
78 9
PIP
MENU SELECT
BACK EXIT
SOURCE POSITION
SWAP PIP
AUDIO
ASPECT
SLEEP
PIP
ENTER
CH
FREEZE
MUTEINPUT
VOL
W
a
t
e
r
p
r
o
o
f
1
4
3
2
5
7
6
20
21
8
9
10
8
11
12
1
12
13
15
16
17
18
1
19
14
14
INPUT Select the source
Switches on or offthe TV
0 - 9 Only use in TV mode. Select channels. For channel numbers 10 and
above, enter the second digit within two seconds.
AUTO Auto adjust
MENU Display the menu on the screen or go to the previous menu
▲/ ▼/ ◄/ ►/ ENTER
Go to the upper menu or select the previous value /
Go to the next menu or select the next value /
Decrease the setting value /
Increase the setting value or enter to the select item setting
Enter to the select item settings or excude the setting
BACK Back to previous value
MUTE Turn on or offthe speaker
Vol + / - Increase or decrease the speaker volume
CH + / - For TV model only, increase or decrease the channel number
FREEZE Reserve for OEM model
- / -- For setting input single or double digits
ASPECT Adjust the screen size
SELECT To select the existing item
SLEEP Select the sleeping time
EXIT Exit the menu or cancel
PIP functions
PIP Picture in picture
PIP AUDIO To set the audio of in PIP mode
POSITION To set the screen position in PIP mode
SOURCE PIP Source
SWAP Swap screen in PIP mode
1
8
2
3
4
5
6
7
9
10
11
12
13
14
15
16
17
18
19
20
21
P.10

Model TRB e-Resistive
Technology 5-Wire Resistive
Touch Point Single
Input Type Finger or Stylus
Resolution 2048 x 2048
Touch Point Accuracy -
Response Speed 15 ms
Activation Force ≤50 g
Surface Hardness 3H
Light Transmission 80% ± 3%
Haze 8% ± 3%
Durability 10 million touches
Top Layer ITO Film
Bottom Layer ITO Glass
Thickness 3.2 ± 0.2 mm
Connector USB Type A
Compatibility Windows 7 / XP / Vista, Linux
■USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■For detailed information, please refer to the attached CD disc
■As the touchscreen unit is not made of toughened glass, please handle it carefully
< 3.3 > Options : Touchscreen & Driver
20" USB Touchscreen Specification
Power VGADVI-D
USB Touchscreen
P.11

< 3.3 > Options : Touchscreen & Driver
TRB Driver
Please follow the below steps to setup the touch screen:-
Step 1. Run the bundled CD disc
Step 2. Double click the Setup.exe
Step 3. Follow the installation instruction to finishthesetup
Step 4. After installation, run the TouchKit program & the “4 point calibration”
Please do the initial calibration
after the first setup
P.12

Model 12V 24V 48V 125V
Input rating
Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt
Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V
Input current
- No load 50 mA 50 mA 50 mA 35 mA
- Full load 4950 mA 2450 mA 1220 mA 749 mA
Output rating
Output voltage: 12-Volt 12-Volt 12-Volt 12-Volt
Output current: 4.16A 4.16A 4.16A 6.25A
Efficiency 84% 85% 85% 91%
< 3.4> Options : DC Power
( 1 ) If the unit with LCD, earthing may be required
For DC power option :
***
P.13
